Texas Instruments TLV320AIC3268EVM-U User manual

User's Guide
SLAU564A–February 2014–Revised February 2014
TLV320AIC3268EVM-U Evaluation Module
This User’s Guide describes the operation, use, and features of the TLV320AIC3268EVM-U. For
questions and support go to the E2E forums (e2e.ti.com).
The main contents of this document are:
• Hardware descriptions and implementation
• Start up procedure using PurePath™ Console 2 (PPC2) software with the AIC3268 plug-in
Table 1. Related Documents
Document Title Literature Number
TLV320AIC3268 Data Sheet SLAS953
PurePath Graphic Development Suite PurePath Console
Contents
1 Features ...................................................................................................................... 2
2 Introduction .................................................................................................................. 2
2.1 Electrostatic Discharge Warning ................................................................................. 2
2.2 Unpacking the EVM ................................................................................................ 3
3 Getting Started .............................................................................................................. 4
4 PurePath Console 2 Software ............................................................................................. 4
4.1 Installation ........................................................................................................... 4
4.2 Graphical User Interface (GUI) ................................................................................... 5
5 TLV320AIC3268EVM-U Default Jumper Locations .................................................................... 7
6 TLV320AIC3268EVM-U EVM Schematics .............................................................................. 8
7 TLV320AIC3268EVM-U EVM Board Layout ........................................................................... 17
8 TLV320AIC3268EVM-U Bill of Materials ............................................................................... 19
9 Writing Scripts .............................................................................................................. 22
List of Figures
1 TLV320AIC3268EVM-U Top Board Photo .............................................................................. 3
2 TLV320AIC3268EVM-U Bottom Board Photo........................................................................... 3
3 Main Panel................................................................................................................... 5
4 Register Inspector Window ................................................................................................ 6
5 TLV320AIC3268RGC Block Diagram .................................................................................... 8
6 TAS1020BPFB USB Controller ........................................................................................... 9
7 Sample Rate Converters for ASIs....................................................................................... 10
8 GPIO and MCLK for AIC3268 ........................................................................................... 11
9 LDO Supplies and Analog Outputs ..................................................................................... 12
10 TLV320AIC3268 Schematic.............................................................................................. 13
11 Audio Connectors ......................................................................................................... 14
12 I2C Translation and Selection............................................................................................ 15
13 Breakout Board Connections ............................................................................................ 16
14 Top Xray View ............................................................................................................. 17
PurePath is a trademark of Texas Instruments.
Windows is a registered trademark of Microsoft Corporation.
1
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Features www.ti.com
15 Silkscreen Top............................................................................................................. 17
16 Silkscreen Bottom ......................................................................................................... 18
1 Features
• Full featured EVM with the TLV320AIC3268 Audio Codec
• USB connection to PC provides power, control and streaming audio for quick evaluation
• Easy-to-use PurePath Console 2 software provides graphical user interface to configure and control
AIC3268
2 Introduction
This specific evaluation module (EVM) is a programmable USB audio device that features the
TLV320AIC3268 Audio Codec with miniDSP.
2.1 Electrostatic Discharge Warning
Many of the components on the EVM are susceptible to damage by electrostatic discharge (ESD). Users
are advised to observe proper ESD handling precautions when unpacking and handling the EVM,
including the use of a grounded wrist strap at an approved ESD workstation.
CAUTION
Failure to observe ESD handling procedures can result in damage to EVM
components.
2TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com Introduction
2.2 Unpacking the EVM
On opening the TLV320AIC3268EVM-U package, ensure that the following item is included:
• One TLV320AIC3268EVM-U board using one TLV320AIC3268 (Figure 1 and Figure 2)
If either of the board or the TLV320AIC3268 device is missing, contact the Texas Instruments Product
Information Center to inquire about a replacement.
Figure 1. TLV320AIC3268EVM-U Top Board Photo
Figure 2. TLV320AIC3268EVM-U Bottom Board Photo
3
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Getting Started www.ti.com
3 Getting Started
1. Request and download the PPC2 software located in the EVM product folder on the web.
2. Connect the EVM to USB port, LED lights LED1 and LED2 should illuminate once the EVM is detected
by Windows®PC. Also, in the Windows Device Manager, the EVM should be recognized as a USB
composite device, a USB audio device and an HID-compliant device.
3. Connect headphones to jack J7, labeled HP OUT.
4. Open PPC2 and in the Command Buffer Interface select Open.
5. Download the most up-to-date scripts from the product folder. Navigate to that folder and select script
1.1 and click Execute.
6. Play audio through any media tool. Make sure that the playback (and recording) device is USB-
AudioEVM in the Windows control panel.
• To adjust playback volume, open Sound in control panel, select the USB-AudioEVM device and
click Properties.
• Similarly, the other example configurations can be tried and sound can be recorded using the
microphone available on the board.
7. Install jumpers on the EVM as per the requirements to make the right signal connections.
4 PurePath Console 2 Software
4.1 Installation
1. Request and download the PPC2 software located in the TLV320AIC3268 product folder.
2. Open the self-extracting installation file, and extract contents to a known folder.
3. Install the software by double clicking the setup executable and follow the directions.
4. Connect the EVM to a USB port using a micro-USB cable and open PurePath Console 2. If prompted,
select the appropriate EVM name.
4TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com PurePath Console 2 Software
4.2 Graphical User Interface (GUI)
4.2.1 Main panel window
The main panel, shown in Figure 3, provides direct access to the I2C settings of the AIC3268. On the
main panel, users can configure the registers through the single byte write and read or through the
Command Buffer Interface. The analog setup, digital setup, audio inputs, audio outputs, DRC, AGC, SAR
and headset detection can be configured through this interface.
The EVM status, which reflects the hardware connection of the EVM, is shown on the bottom left of the
main panel.
Figure 3. Main Panel
4.2.2 Typical Configuration
In the product folder there are example scripts for typical playback and record applications. These
configurations are used through the Command Buffer Interface.
4.2.3 I2C Logger
The Command Buffer Interface communicates with the TLV320AIC3268 using a simple scripting language
(described in Section 9). The TAS1020B USB controller handles all communication between the PC and
the codec. A script is loaded into the command buffer, either by loading a script file using the Open button
or by pasting text from the clipboard. Click Run to execute the command buffer.
To record the I2C communication between the PC and the device, there is an I2C Logger in the bottom
right of the GUI. The I2C Logger records all register writes sent to the codec when the Logging box is
checked. The recorded register values along with their page numbers are displayed in the I2C Logger
Window. Pressing the Clear button clears the content of the logger.
5
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

PurePath Console 2 Software www.ti.com
4.2.4 Register Inspector
Figure 4. Register Inspector Window
The contents of the TLV320AIC3268 register map can be accessed through the Registers tab in PPC2.
The Page number control selects the page to be displayed in the register table. The register table contains
information such as register name, current register value and the bit field of the current register value.
Specify the page number when using the register inspector table. Once the page is specified, the register
value can then be inspected or changed by either entering the hex value of the register or changing the
corresponding bits for that register.
6TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com TLV320AIC3268EVM-U Default Jumper Locations
5 TLV320AIC3268EVM-U Default Jumper Locations
Table 2 displays the default jumper location information.
Table 2. Default Jumper Locations
Jumper Position Jumper Position
JP1 Shorted JP31 Shorted
JP2 Shorted JP32 Shorted
JP3 Open JP33 1-2
JP4 2-3 JP34 1-2
JP5 2-3 JP35 Shorted
JP6 2-3 JP36 Shorted
JP7 2-3 JP37 1-2
JP8 2-3 JP38 2-3
JP9 2-3 JP39 Shorted
JP10 2-3 JP40 2-3
JP11 2-3 JP41 Shorted
JP12 2-3 JP42 Open
JP13 2-3 JP43 Open
JP14 2-3 JP44 2-3
JP15 2-3 JP45 Shorted
JP16 2-3 JP46 Open
JP17 2-3 JP47 Open
JP18 2-3 JP48 Shorted
JP19 2-3 JP49 Shorted
JP20 1-2 JP50 1-2
JP21 1-2 JP51 1-2
JP22 1-2 JP52 Open
JP23 1-2 JP53 Open
JP24 Shorted JP54 Open
JP25 Shorted JP55 Open
JP26 Shorted JP56 Open
JP27 Open JP57 Open
JP28 Open JP58 Open
JP29 Shorted JP59 Open
JP30 Shorted
7
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
TI
TLV320AIC3268RGC EVALUATION BOARD
1
I2S #3
AUDIO INTERFACE
I2S #2
AUDIO INTERFACE
B
A
I2S #1
AUDIO INTERFACE
OPTICAL
AUDIO OUTPUT
SRC #1
OPTICAL
AUDIO INPUT
ANALOG
OUTPUTS
USB CONTROLLER
I2C & SPI
CONTROL INTERFACE
CONTROLAUDIO
I2C
I2C & SPI
ASI#1
ASI#2
SRC4392
TAS1020B
6 WIRE
AUDIO I/F
SRC4392
I2C
OPTICAL
AUDIO INPUT
SRC #2 OPTICAL
AUDIO OUTPUT
A
B
ASI#3
ANALOG
INPUTS
TLV320AIC3268
QFN, Top View
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
3249
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
GPIO3
IOVDD1_33
MISO
SPI_SELECT
SDA_MOSI
GPIO5
I2C_ADDR/SCLK
SCL_SSZ DVDD_18
IOVDD1_33
RESETZ
WCLK1
GPIO2
DOUT1
DIN1
GPIO1
WCLK2
DIN2
IOVDD2_33
DVDD_18
GPIO4
BCLK2
DOUT2
DVSS
DVSS
DVDD_18
VBAT
SPK_V
SPKM
SVDD
SPKP
AVDD4_18
MICBIAS_EXT MICBIAS RECP RECVDD_33 RECM AVDD2_18 HPR HVDD_18 HPL HPVSS_SENSE VNEG CPFCM CPFCP CPVDD_18 LOL LOR
MICBIAS_VDD
MICDET
AVDD1_18
IN4L
IN4R
VREF_SAR
VREF_AUDIO
IN1L_AUX1
IN1R_AUX2
IN3L
IN3R
IN2R
IN2L
AVDD_18
MCLK
BCLK1
VSS
BLOCK DIAGRAM
333435
363739 38404142434445464748
1 2 3456 7 8 9 10 11 12 13 14 15 16
TLV320AIC3268EVM-U EVM Schematics www.ti.com
6 TLV320AIC3268EVM-U EVM Schematics
The schematics for the TLV320AIC3268EVM-U are shown in Figure 5 through Figure 12.
Figure 5. TLV320AIC3268RGC Block Diagram
8TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

RESETz
TAS_MCLK
TAS_WCLK
TAS_MISO
TAS_MOSI
TAS_SSz
TAS_SCLK
I2S_ENABLE
TAS_SDA
TAS_BCLK
TAS_DIN
TAS_SCL
ASI_S0
ASI_S1
I2S3_DOUT_SRC
DUT_RESETz
TAS_DOUT
I2S2_DOUT_SRC
I2S1_DOUT
+5V
GND
GND GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND GND
GND
GND
GND
1.50k
R1
27.4
R2
27.4
R3
47pF/50V
C1
47pF/50V
C2
100k
R4
1.0uF/16V
C3
2
1
S4
0.1uF/16V
C4
0.1uF/16V
C5
LVC1G126DBVR
VCC
OE
A
GND
1
2
4
5
3
U3
0.1uF/16V
C7
0.1uF/16V
C8
1 2
S1
0.1uF/50V
C9
10k
R5 10k R6
21
S2
0.1uF/16V
C10
0.1uF/50V
C11
1 2
S3
10k
R7
LED1
Yellow
649
R8
LED2
Yellow
649
R9
10k
R10
2
1
EE Program
JP2
0.1uF/16V
C13
R11
3.09k
1000pF/50V
C14
100pF/50V
C15
10k
R12
2.7k
R13 2.7k R14
1
2
JP3
0.1uF/50V
C16
10k
R15
4.7k
R16
1
JP1
2
GND
4.7k
R17
L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
+3.3VIO
+3.3VIO
+3.3VIO +3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
FB5
220ohms/2A
FB6
220ohms/2A
1
2
3
4
5
J1
Data+
GND
ID_NC
5v
Data-
+3.3VIO
1
23
4
Y1
6.0MHz
Vcc
OUT
OE
GND
+3.3VIO
GND
C6
0.1uF/16V
+3.3VIO
GND
U5
PowerPAD
24FC512-I/MF
GND
GND
C12
0.1uF/16V
+3.3VIO
+3.3VIO
+3.3VIO
U4
CBTLV3253DBQ
1
2
3
4
5
6
710
11
12
13
14
15
16
24FC512-I/MF
1
2
3
4 5
6
7
8
U5
GND
+3.3VIO
GND
TAS1020BPFB
U2
(ADC Data)
7
8
9
10
11
12
6
5
4
3
2
1
25
26
27
28
29
30
31
32
33
34
35
36
TAS1020B USB HOST ADAPTER
TLV320AIC3268RGC EVALUATION BOARD
USB CONTROLLER 2
(DAC Data)
DUT RESET
APP
PATCH
USB RESET
USB INPUT
13 14 15 16 17 18 19 20 21
22 23 24 13 14 15 16 17 18 19 20 21 22 23 24
37
38
39
404142434445464748
89
Y
TI
www.ti.com TLV320AIC3268EVM-U EVM Schematics
Figure 6. TAS1020BPFB USB Controller
9
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

SRC1_RXCXO
SRC2_MCLK
SRC1_RDYz
TAS_SCL
TAS_SDA
RESETz
SRC1_MCLK
WCLK2
BCLK2
DIN2
SRC1_LOCKz
I2S2_DOUT_SRC
SRC2_RXCXO
SRC1_MCLK
SRC2_RDYz
SRC2_MCLK
DOUT3
WCLK3
BCLK3
DIN3
SRC2_LOCKz
TAS_DIN
TAS_WCLK
TAS_BCLK
DOUT2
WCLK1
BCLK1
DOUT1
DIN1
I2S1_DOUT
I2S3_DOUT_SRC
GND
GNDGND
GNDGND
GND
GND GND GND
GND
GND
GND
GNDGND
GND
GND
GND GND
GND
GNDGND
GNDGND
GND
GND GND
GND
GND
GND
GNDGND
GND
GND
GND GND
C17
0.1uF/16V
C18
0.1uF/16V
C19
10uF/6.3V
C20
0.1uF/16V
C21
10uF/6.3V
C22
0.1uF/16V
C23
0.1uF/16V
C24
10uF/6.3V
C25
0.1uF/16V
C26
0.1uF/16V
C27
0.1uF/16V
C28
0.1uF/16V
R18
10k
R19
0
R20
0
C29
0.1uF/16V
C30
0.1uF/16V
C31
10uF/6.3V
C32
0.1uF/16V
C33
10uF/6.3V
C34
0.1uF/16V
C35
0.1uF/16V
C36
10uF/6.3V
C37
0.1uF/16V
C38
0.1uF/16V
C39
0.1uF/16V
C40
0.1uF/16V
R21
10k
R22
0
R23
0
R24
4.7k
R25
10k
R26
4.7k
C41
10uF/6.3V
C42
10uF/6.3V
1.00k
R27
1.00k
R28
GND
GND GND
C43
0.1uF/16V
C44
0.1uF/16V
R29
10k
L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
GND
SPDIF-OUT1
2
1
3
PLT133/T10W
SHIELD
GND
INPUT
VCC
1
2
3
SPDIF-IN1
PLR135/T10
Case
GND
VCC
OUT
GND
SPDIF-IN2
3
2
1
PLR135/T10
Case
GND
VCC
OUT
GND
GND
3
1
2
SPDIF-OUT2
PLT133/T10W
SHIELD
GND
INPUT
VCC
IOVD1
+1.8VIO
IOVD2
+1.8VIO
IOVD1
+3.3VIO
1
2
3
4
5
6
78
9
10
11
12
13
14
TXS0104EPWR
U13
B4
NC
OE
NC
A4
B3
B2
B1
VCCB
A1
A2
A3
VCCA
14
13
12
11
10
9
8 7
6
5
4
3
2
1
U9
TXS0104EPWR
B4
NC
OE
NC
A4
B3
B2
B1
VCCB
A1
A2
A3
VCCA
1
2
3
4
5
6
78
9
10
11
12
13
14
U14
TXS0104EPWR
B4
NC
OE
NC
A4
B3
B2
B1
VCCB
A1
A2
A3
VCCA
(DAC Data)
U6
Connect Pin44 to Pin10,
pin 10 to ground plane
SRC #1
SRC4392IPFBR
i2c: 1110 000
13
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
U10
Connect Pin44 to Pin10,
pin 10 to ground plane
SRC4392IPFBR
SRC #2
i2c: 1110 001
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
12
11
10
9
8
7
6
5
4
3
2
1
13
TLV320AIC3268RGC EVALUATION BOARD
3
DATA, SAMPLE RATE CONVERTER
Use same IOVD for IOVD1 and IOVD2.
BCLK3 -> GPIO2 (IOVD1)
WCLK3 -> GPIO1 (IOVD1)
DIN3 -> GPIO3 (IOVD2)
DOUT3 -> GPIO4 (IOVD2)
SAMPLE RATE CONVERTERS FOR ASIs
TI
GND
GND
GND
TLV320AIC3268EVM-U EVM Schematics www.ti.com
Figure 7. Sample Rate Converters for ASIs
10 TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

SRC1_LOCKz
SRC1_RDYz
SRC2_LOCKz
SRC2_RDYz
CLK2_DIV_S1
SRC2_MCLK_S0
CLK1_DIV_S0
CLK1_DIV_S1
SRC1_MCLK_S0
SRC1_MCLK
SRC2_MCLK
TAS_MCLK
MCLK_S0
MCLK_S1
MCLK_SEL
SRC2_MCLK_S1
SRC1_MCLK_S1
MCLK
SRC1_RXCXO
SRC2_RXCXO
SRC2_MCLK
SRC1_MCLK
TAS_SCL
TAS_SDA
RESETz
CLK1_DIV_S0
CLK1_DIV_S1
CLK2_DIV_S0
CLK2_DIV_S1
MCLK_S0
MCLK_S1
MCLK_SEL
SPI_SELECT
6Wire1_EN
I2C_ADDR_SEL
TAS_MCLK
ASI_S0
ASI_S1
SRC1_MCLK_S0
SRC1_MCLK_S1
SRC2_MCLK_S0
SRC2_MCLK_S1
CLK2_DIV_S0
GND
GND GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND GND
GND
GND
GND
GND GNDGND
GND
GND
GND
GND
GND
R30
357
LED6
Green
R31
357
LED3
Green
R32
357
LED4
Green
R33
357
LED5
Green
C45
0.1uF/16V
R34
10k
R35
10k
R36
10k
C46
0.1uF/16V
C47
0.1uF/16V
R37
10k
R38
10k
R39
10k
C48
0.1uF16V
C49
0.1uF/16V
R40
10k
R41
10k
C50
0.1uF/16V
1
2
3
4
5
6
7
8 9
10
11
12
13
14
15
16
U19
CBTLV3253DBQ
16
15
14
13
12
11
10
98
7
6
5
4
3
2
1U20
CBTLV3253DBQ
R42
10k
R43
10k
R44
10k
R45
10k
GND
R46
10k
C51
0.1uF/16V
GND
C52
0.1uF/16V
C53
0.1uF/16V
GND
GND
SPI_SELECT is only information,
Never drive this pin.
Use Jumper JP51 instead
L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
TI
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
IOVD1
+3.3VIO
8
7
6
54
3
2
1
U17
ICS542MLFT
S1
OE
CLK/2
CLKICLK
VDD
GND
S0
24.576MHz
1
23
4
OSC1
Vcc
OUT
OE
GND
22.5792MHz
1
23
4
OSC2
Vcc
OUT
OE
GND
ICS542MLFT
1
2
3
4 5
6
7
8
U18
S1
OE
CLK/2
CLKICLK
VDD
GND
S0
i2c: 1110 100
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
U22
TCA9539PW
1
2
3 4
5
6
U15
LVC2G17DBV
2A
GND
1A 6
5
43
2
1
U16
LVC2G17DBV
2A
GND
1A
16
15
14
13
12
11
10
98
7
6
5
4
3
2
1U21
8
7
6
5
4
3
2
1
U11
+3.3VIO
TLV320AIC3268RGC EVALUATION BOARD CLOCKSDATA
4BOARD GPIO & MCLK FOR AIC3268
VCC
2Y
1Y
VCC
2Y
1Y
www.ti.com TLV320AIC3268EVM-U EVM Schematics
Figure 8. GPIO and MCLK for AIC3268
11
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

AV_ENABLE
DV_ENABLE
AV_ENABLE
DV_ENABLE
DV_ENABLE
AV_ENABLE
BCLK1_DUT
WCLK1_DUT
DIN1_DUT
DOUT1_DUT
BCLK1
WCLK1
DIN1
DOUT1
MCLK_DUT
MCLK
BCLK2
WCLK2
DIN2
DOUT2
DOUT2_DUT
DIN2_DUT
WCLK2_DUT
BCLK2_DUT
TEST1
BCLK3
WCLK3
DIN3
DOUT3
GPIO1
GPIO2
GPIO3
GPIO3
GPIO4
GPIO4
TAS_WCLK
TAS_BCLK
6Wire1_EN
GPIO5
TEST2
+5V
GNDGND GND
+5V
GNDGND GND
+5V
GNDGND GND
+5V
GNDGND GND
+5V
GND
GNDGND GND
+5V
GNDGND GND
GND
0.1uF/16V
C54
10uF/6.3V
C55
10k
R47
0.1uF/16V
C56
10uF/6.3V
C57
10k
R48
0.1uF/16V
C58
10uF/6.3V
C59
10k
R49
0.1uF/16V
C60
10uF/6.3V
C61
10k
R50
0.1uF/16V
C62
10uF/6.3V
C63
10k
R51
0.1uF/16V
C64
10uF/6.3V
C65
10k
R52
47ufd/6.3V
C66
47uF/6.3V
C67
47uF/6.3V
C68
47uF/6.3V
C69
47ufd/6.3V
C70
47uF/6.3V
C71
TP69
TP1
TP2
JP22
1
2
3
JP23
3
2
1
TP62 TP63 TP64 TP65 TP66 TP67 TP68
TP3
TP4
TP5
GND
GND
GND
GND
TP6
TP7 TP8 TP9 TP10
GND
JP4
1
2
3
JP8
3
2
1
JP7
1
2
3
JP6
1
2
3
JP5
1
2
3
JP12
3
2
1
JP11
1
2
3
JP10
1
2
3
JP9
3
2
1
TP11TP12TP13TP14
GND
GND
GND
GND
DNP
J2
12
3 4
56
GND
TP15TP16
GND
0
R53
0
R54
GND
GND
GND
GND
JP13
1
2
3
JP14
3
2
1
JP15
3
2
1
JP16
1
2
3
gpio1/bclk3
TP17
gpio2/wclk3
TP18
gpio3/din3
TP19
gpio4/dout3
TP20
JP20
1
2
3
JP21
3
2
1
GND GND
GND
GND
GND
0.1uF/16V
C72
0.1uF/16V
C73
10k
R55
GND
DATA
CLOCK
SELECT
VDD
MIC3
1
2
3
4
5
6
GND
GNDGND
GNDGND
GND
GND
0.1uF/16V
C91
0.1uF/16V
C90
SELECT
CLOCK
DATA
VDD
MIC2
6
5
4
3
2
1
JP19
3
2
1
JP18
1
2
3
JP17
3
2
1
GND GND GND
GND
GNDGND
GNDGND
GND
GND
0.1uF/16V
C74
0.1uF/16V
C75
DATA
CLOCK
SELECT
VDD
MIC5
6
5
4
3
2
1
DATA
CLOCK
VDD
SELECT
MIC4
1
2
3
4
5
6
L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
+1.8VA
+1.8VD
+3.3VA
+1.8V_CP
+3.3VIO
+3.3VIO
+3.3VIO+1.8VIO
+1.8VIO
+3.3VIO
IOVD2
IOVD1
IOVD2
GND
GND
GND
GND
GND
IOVD1
IOVD1
+1.8VIO
1.8V/400mA
VR3
1
2
3 4
5
TPS73618DBV
3.3V/400mA
VR5
1
2
3 4
5
TPS73633DBV
1.8V/400mA
VR1
5
43
2
1
TPS73618DBV
1.8V/400mA
VR2
1
2
3 4
5
TPS73618DBV
1.8V/400mA
VR4
1
2
3 4
5
TPS73618DBV
3.3V/400mA
VR6
5
43
2
1
TPS73633DBV
DNP
J3
SLIMbus
SATA
7
6
5
4
3
2
1
GND
B+
B-
GND
A+
GND
A-
Case
U23
8
7
6
5
4
3
2
1
TXB0102DCU
B2 A2
VCCA
GND
B1
VCCB
OE
A1
TLV320AIC3268RGC EVALUATION BOARD
LDOs & AIC3268 ANALOG OUTPUTS 5
LDO SUPPLIES
IOVD1: GPIO1: Dig_Mic 1,2 Data and BCLK3
GPIO2: ADC_MOD_CLK and WCLK3
GPIO5: Dig_Mic 3,4 Data
IOVD2: GPIO3: DIN3
GPIO4: DOUT3
Use same IOVD for IOVD1 and IOVD2.
BCLK3 -> GPIO2 (IOVD1)
WCLK3 -> GPIO1 (IOVD1)
DIN3 -> GPIO3 (IOVD2)
DOUT3 -> GPIO4 (IOVD2)
TI
TLV320AIC3268EVM-U EVM Schematics www.ti.com
Figure 9. LDO Supplies and Analog Outputs
12 TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

VSYS_EXT
HS_MIC
MICBIAS_EXT
IN4R
IN4L
MICBIAS_DUT MICBIAS
BCLK1_DUT
MCLK_DUT
IN2L
IN2R
IN3L
IN3R
VSYS_EXT
MICBIAS_EXT_DUT
MICBIAS_DUT
MICBIAS_EXT_DUT
IN1R
IN1L
VSYS_EXT
SPKM
SPKP
RECP
RECM
HPR
HPL
HPVSS_SENSE
RLOUT
LLOUT
GPIO1
DIN1_DUT
DOUT1_DUT
GPIO2
WCLK1_DUT
AIC_RESETZ
SCL_SSZ
ADDR_SCLK
GPIO5
SDA_MOSI
AIC_SPI_SELECT
MISO_GPO1
GPIO3
WCLK2_DUT
DIN2_DUT
GPIO4
BCLK2_DUT
DOUT2_DUT
TEST1
TEST2
GND
JP32
1
2
JP39
1
2
GND
JP37
3
2
1
GND
JP45
2
1
GND
GND GND
JP25
1
2
GND GND
JP48
2
1
JP24
1
2
+1.8VIO
JP47
3
2
1
TP21
vref
GND
TP22
micdet
JP35
1
2
JP33
1
2
3
GND
TP23
Ext_Aux1
TP24
Ext_Aux2
0.1uF/16V
C76
0.1uF/16V
C77
0.1uF/16V
C78
0.1uF/16V
C79
0.1uF/16V
C80
1.0uF/16V
C81
0.1uF/16V
C83
10uF/10V
C84
C85
1.0uF/16V C86
1.0uF/16V
0.1uF/16V
C87
R56
200
R57
200
JP36
2
1
100
R58
R59
2.10k
TP25
in1l
JP34
3
2
1
0.1uF/16V
C88
GND
TP26
in1r
TP27
Ext_In1R
C89
1.0uF/16V
TP28
in4l
TP29
in4r
CP90
1.0ufd/10V
CP91
1.0ufd/10V
GND
MIC1
1
2
JP31
2
1
R60
1.10k
TP30
100
R61
R62
1.00k
R63
2.10k
JP27
1
2
R64
2.10k
JP28
2
1
TP31
in3l
TP32
in3r
C92
1.0uF/16V
C93
1.0uF/16V
JP30
1
2
JP29
2
1
GND TP33
in2r
TP34
in2l
C94
1.0uF/10V
C95
1.0uF/16V
GNDGND
1.0uF/16V
C96
0.1uF/16V
C97
JP26
2
1
1.0uF/16V
C98
GND
TP35
vref_sar
R65
200
0.1uF/16V
C99
GND
JP46
2
1
TP36
C100
2.2ufd/10V
GND
C101
2.2uF/10V
TP37
Vneg
GND GND
0.1uF/16V
C102
10uF/10V
C103
GND
10uF/10V
C104
GND
0.1uF/16V
C105
JP40
1
2
3
JP41
2
1
GND GND
GND
GND
DNP
C106
DNP
C107
JP42 2
1
R66
1.00k
2200pfd/50V
C108
JP43
1
2R67
1.00K
2200pfd/50V
C109
TP38 TP39
120 OHMS/1.5A
FB1
2
1
1
120 OHMS/1.5A
FB2
2
6A/125V
J5
1
2
+
1.0uF/16V
C110
6A/125V
J6
2
1
+
JP44
1
2
3
GND GND GND
GND
+5V
TP40
spkm
TP41
spkp
10uF/10V
C111
0.1uF/16V
C112
JP38
3
2
1
0.1uF/16V
C113
1.0uF/16V
C114
GND GND
GND GND
1.0uF/16V
C116
GND
0.1uF/16V
C117
GND
10uF/10V
C118
PowerPAD
U1
GND
0.1uF/16V
C115
L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
TI
+1.8VD
IOVD1
+1.8VA
+1.8VA
+1.8VD
+1.8V_CP
+1.8VA
+1.8VA
+1.8VA +3.3VA
+3.3VA
+1.8VA
FB4
220ohms/2A
21
U1
64 60 56 52
45
41
37
33
54 5355 51 495058 5759
44
43
42
46
47
48
40
39
38
25 26 2827 31 32302921 22 242319 2018
9
10
11
12
16
15
14
13
5
6
7
8
63 6162
17
34
35
36
4
3
2
1
GND
C140
0.1uF/16V
IOVD2
J4
LEFT
RIGHT
Shield
2
4
1
3
6
5
TLV320AIC3268RGC EVALUATION BOARD
TLV320AIC3268 6
www.ti.com TLV320AIC3268EVM-U EVM Schematics
Figure 10. TLV320AIC3268 Schematic
13
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

HS_MIC
HPVSS_SENSE
HPL
HPL
HPR
HPR
RECP
RECP
RECM
RECM
LLOUT
LLOUT
RLOUT
RLOUT
hpl
TP42
hpr
TP43
vss_sns
TP44
GNDGND
GND
GNDGNDGND
GND
1
2
3
JP52
3
2
1
JP53
3
2
1
JP50
3
2
1
JP51
R68
1.00k R69
1.00k
16.0
R70
32.4
R71
16.0
R90
2200pF/50V
C121
2200pF/50V
C122
32.4
R72
TP45
TP46
GND
2
1
JP49
DNP
R73
GND
GND GND
1.0ufF16V
C123
1.0uF/16V
C124
llout
TP47
rlout
TP48
1
2
JP57
TP49
2
1
JP58
TP50
R74
1.00k
2200pF/50V
C125
R75
1.00k
2200pF/50V
C126
GND
GND GND
2
1
JP54
R76
1.00k
2200pF/50V
C127
1
2
JP55
R77
1.00k
2200pF/50V
C128
TP51 TP52
32.4
R78 1
2
JP56
recp
TP53
recm
TP54
L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
TI
J9
1
2
3
6A/125V
220ohms/2A
12
FB3
J8
3
2
1
4
5
Shield
J7
LEFT
RIGHT
Shield
2
4
1
3
6
5
J10
LEFT
RIGHT
Shield
2
4
1
3
6
5
TLV320AIC3268RGC EVALUATION BOARD
AUDIO CONNECTORS 7
2-32-3
1-21-2
JP51JP50Configuration
L-R-G-M
L-R-M-G
TLV320AIC3268EVM-U EVM Schematics www.ti.com
Figure 11. Audio Connectors
14 TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

SCL_SSZ
SDA_MOSI
AIC_SCLK
AIC_ADDRESS
ADDR_SCLK
TAS_SSz
TAS_MOSI
TAS_SCL
TAS_SDA
DUT_RESETz AIC_RESETZ AIC_RESETZ
TAS_SCLK
TAS_MISO
I2C_ADDR_SEL AIC_ADDRESS
AIC_SPI_SELECT
AIC_SPI_SELECT
AIC_SCLK
SPI_SELECT
MISO_GPO1
ad/sclk
TP55
scl/ssz
TP56
sda/mosi
TP57
gpo1/miso
TP58
spi_sel
TP59
reset~
TP60
GND
GND 0.1uF/16V
C129
GND
GND GND
GND
GND GND
0.1uF/16V
C130
0.1uF/16V
C131
GND
GND
GNDGND
GND
GND
+5V
GND
GND GND
GND
GND
0.1uF/16V
C132
2.7k
R79
2.7k
R80
0.1uF/16V
C133
200k
R81
R82
806k
0.1uF/16V
C134
10k
R83
0.1uF/16V
C135
0.1uF/16V
C136 10k
R84
0.1uF/16V
C137
GND
1
JP59
2
357
R85
Green
LED7
R86
1.00k
GND
GND
GND
GND 0.1uF/16V
C138
0.1uF/16V
C139
GND
GND GND
0.1uF/16V
C119
0.1uF/16V
C120
10k
R87
GND
10k
R88
GND
TP61
R89
1.00k
L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
TI
IOVD1
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO
+3.3VIO IOVD1
IOVD1+3.3VIO
+3.3VIO
IOVD1
IOVD1 +3.3VIO
1
2
3
4
5
6
7
8
U24
LVC2G157DCT
10
9
8
7
6
5
4
3
2
1
U25
AVC2T245RSW
1
2
3
45
6
7
8
U26
PCA9306DCT
SDA2
SCL2
VREF2
EN
SDA1
GND
VREF1
SCL1
1
2
3 4
5
6
U27
TXB0101DBV
OE
VCCB
B
GND
VCCA
A1
2
4
5
3
U28
LVC1G126DBV
1
2
34
5
6
U7
LVC2G04DBV
14
13
12
11
10
9
8 7
6
5
4
3
2
1
U8
TXS0104EPW
B4
NC
OE GND
NC
A4
B3
B2
B1
VCCB
A1
A2
A3
VCCA
U12
1
2
3
4
5
6
7
8
9
10
AVC2T245RSW
TLV320AIC3268RGC EVALUATION BOARD
I2C TRANSLATION AND SELECTION 8
Install this jumper to
use DUT in SPI
mode
www.ti.com TLV320AIC3268EVM-U EVM Schematics
Figure 12. I2C Translation and Selection
15
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

DV_ENABLE
TAS_SCL
TAS_SDA
MCLK
BCLK1
WCLK1
DOUT1
DIN1
TAS_MISO
TAS_MOSI
TAS_SSz
TAS_SCLK
I2S_ENABLE
RESETz
BCLK2
WCLK2
DOUT2
DIN2
BCLK2
WCLK2
DOUT2
DIN2
TAS_BCLK
TAS_WCLK
TAS_DOUT
TAS_DIN
GPIO3
GPIO4
IN1L IN1R
IN2L IN2R
IN3RIN3L
IN4L IN4R
MICBIAS
MICBIAS_EXT HS_MIC
SPKP
SPKM SPKM
SPKP
RECP RECM
LLOUT
RLOUT
HPL
HPR
AV_ENABLE
GPIO5
GPIO1
GPIO2
GND GND
VARVDVARVD
70
68
66
64
62
60
58
56
54
52
50
48
46
44
42
40
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
69
67
65
63
61
59
57
55
53
51
49
47
45
43
41
39
37
35
33
31
29
27
25
23
21
19
17
15
13
11
9
7
5
3
1
71
73
75
77
79
81
83
85
87
89
91
93
95
97
99
72
74
76
78
80
82
84
86
88
90
92
94
96
98
100
J11
mfg: JST
p/n: 100P-JMDSS-G-1-TF(LF)(SN)
100
98
96
94
92
90
88
86
84
76
74
72
70
68
66
64
62
60
58
56
54
52
50
48
46
44
42
40
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
99
97
95
93
91
89
87
85
83
73
71
69
67
65
63
61
59
57
55
53
51
49
47
45
43
41
39
37
35
33
31
29
27
25
23
21
19
17
15
13
11
9
7
5
3
1
75
77
79
81
78
80
82
J12
mfg: JST
p/n: 100P-JMDSS-G-1-TF(LF)(SN)
S03
0.5in
0.5in
S02
0.5in
0.5in
S05
0.5in
0.5in
S04
0.5in
0.5in
S07
0.5in
0.5in
S01
0.5in
0.5in
S06
0.5in
0.5in
S08
0.5in
0.5in
L;DN
11
C
C
JOHN FEDAK IV
JANUARY 31, 2014
AIP013C_Schematic.sbkDESIGN LEAD
PAGE INFO:
FILENAME
DATE OF
DRAWN BY
SHEET
PCB REV
SCH REV
TI
GND GND
+1.8V_CP +3.3VD
GND GND
+5V +5V
+1.8V +1.8V
+3.3VD +3.3VD
GND
J12
Anchor
J11
Anchor
TLV320AIC3268RGC EVALUATION BOARD
9
RESERVED
RESERVED
I2S_4
I2S_3
GPIO
DGND
I2S_ENABLE
DGND
I2S1
DGND
MCLK
I2C
RESERVED RESERVED
DV_ENABLE
VARVD VARVD
+1.8VD +1.8IO
+3.3IO +3.0IO
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
+5VD+5VD
IN8-
IN7-
IN6-
IN5-
IN4-
IN3-
IN1-
IN2-
MICDET
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
IN8+
IN7+
IN6+
IN5+
IN4+
IN3+
IN1+
IN2+
MICBIAS
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND
AGND AGND
SPK1+
SPK1-
SPK2+
SPK2-
CLASS-D
SPEAKER
OUTPUT
CLASS-D
SPEAKER
OUTPUT
SPK2-
SPK2+
SPK1-
SPK1+
HEADSET
GROUND
HPGND
HPGND
HPGND
HPGND
LINE
OUTPUTS
OUT1GND
OUT1+
OUT2+
OUT2GND
OUT3+
OUT3GND
OUT4GND
OUT4+
AGND
HP2L
HP2R
HP1R
OUT4-
OUT4GND
HP1L
HEADSET
OUTPUTS
AGND
OUT3GND
OUT3-
OUT2GND
OUT2-
OUT1-
OUT1GND
LINE
OUTPUTS
AGND
VARVA
BREAK-OUT CONNECTIONSBREAK-OUT CONNECTIONS
ANALOG INTERFACE CONNECTOR
STANDOFFS
+5VA
AGND
+3.3VA
AGND
+1.8V_CP
AGND
VARVA
AGND
AGND
+1.8VA
AGND
+3.3VA
AGND
+5VA
BREAK-OUT CONNECTIONSBREAK-OUT CONNECTIONS
DIGITAL INTERFACE CONNECTOR
AV_ENABLE
HPVDD
HPGND
RESERVED
HPGND
HPVDD
SPKVDD SPKVDD
SPKGND SPKGND RESERVED
MCLK
SPI
RESET
I2S_2
RESERVED
BREAKOUT BOARD CONNECTIONS
TLV320AIC3268EVM-U EVM Schematics www.ti.com
Figure 13. Breakout Board Connections
16 TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com TLV320AIC3268EVM-U EVM Board Layout
7 TLV320AIC3268EVM-U EVM Board Layout
Figure 14 through Figure 16 illustrate the TLV320AIC3268EVM-U EVM board layouts.
Figure 14. Top Xray View
Figure 15. Silkscreen Top
17
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

TLV320AIC3268EVM-U EVM Board Layout www.ti.com
Figure 16. Silkscreen Bottom
18 TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com TLV320AIC3268EVM-U Bill of Materials
8 TLV320AIC3268EVM-U Bill of Materials
Table 3 contains the BOM for the TLV320AIC3268EVM-U.
Table 3. TLV320AIC3268EVM-U Bill of Materials
Item MANU PART NUM MFG QTY REF DESIGNATORS DESCRIPTION
1 TLV320AIC3268IRGC TEXAS INSTRUMENTS 1 U1 STEREO AUDIO CODEC WITH DIRECT PATH HEADPHONE AND CLASS-D
2 TAS1020BPFB TEXAS INSTRUMENTS 1 U2 USB STREAMING CONTROLLER TQFP48-PFB ROHS
3 SN74LVC1G126DBVR TEXAS INSTRUMENTS 2 U3, U28 SINGLE BUS BUFFER GATE WITH 3-STATE OUTPUT SOT23-DBV5 ROHS
4 SN74CBTLV3253DBQR TEXAS INSTRUMENTS 4 U4, U19, U20, U21 LO VOLT DUAL 1OF4 FET MUX/DEMUX SSOP16-DB ROHS
5 24FC512-I/MF MICROCHIP 1 U5 512K I2C SERIAL EEPROM DFN8-MF ROHS
6 SRC4392IPFBR BURR-BROWN 2 U6, U10 2 CHAN,ASYNC,SAMPLE RATE CONV W/DIG AUDIO REC/XMTR ROHS
7 SN74LVC2G04DBVR TEXAS INSTRUMENTS 1 U7 DUAL INVERTER GATE SOT23-DBV6 ROHS
8 TXS0104EPWR TEXAS INSTRUMENTS 4 U8, U9, U13, U14 4-BIT BIDIR LEVEL TRANSLATOR TSSOP14-PW ROHS
9 SN74LVC2G157DCTR TEXAS INSTRUMENTS 2 U11, U24, MUX/DATA SELECTOR 2 TO 1 SSOP8-DCT ROHS
10 SN74AVC2T245RSWR TEXAS INSTRUMENTS 2 U12, U25 2BIT XCVR CONFIGURABLE TRANSLATION 3-STATE OUTS QFN10-RSW ROHS
11 SN74LVC2G17DBVR TEXAS INSTRUMENTS 2 U15, U16 DUAL SCHMITT-TRIGGER BUFFER SOT23-DBV6 ROHS
12 ICS542MLFT IDT 2 U17, U18 CLOCK DIVIDER,SOP8-D,ROHS
13 TCA9539PWR TEXAS INSTRUMENTS 1 U22 REMOTE 16B I2C SMBUS LO PWR IO EXPNDR INT OUT TSSOP24-PW ROHS
14 TXB0102DCUR TEXAS INSTRUMENTS 1 U23 2-BIT BIDIR LEVEL TRANSLATOR VSSOP8-DCU ROHS
15 PCA9306DCTR TEXAS INSTRUMENTS 1 U26 DUAL BIDIR I2C BUS AND SMBUS VOLT LEVEL TRANS SSOP8-DCT ROHS
16 TXB0101DBVR TEXAS INSTRUMENTS 1 U27 1-BIT BIDIR LEVEL TRANSLATOR SOT23-DBV6 ROHS
17 TPS73618DBVT TEXAS INSTRUMENTS 4 VR1, VR2, VR3, VR4 VOLT REG 1.8V 400MA LDO CAP FREE NMOS SOT23-DBV5 ROHS
18 TPS73633DBVT TEXAS INSTRUMENTS 2 VR5, VR6 VOLT REG 3.3V 400MA LDO CAP FREE NMOS SOT23-DBV5 ROHS
19 PLR135/T10 EVERLIGHT ELECTRONICS 2 SPDIF-IN1, SPDIF-IN2 PHOTOLINK FIBER OPTIC RECEIVER 2.4-5.5V 15MB PCB-RA SHUTTER ROHS
20 PLT133/T10W EVERLIGHT ELECTRONICS 2 SPDIF-OUT1, SPDIF-OUT2 PHOTOLINK FIBER OPTIC TRANSMITTER 2.4-5.5V 15MB PCB-RA SHUTTER
ROHS
21 SML-LXT0805YW-TR LUMEX OPTO 2 LED1, LED2 LED, YELLOW 2.0V SMD0805 ROHS
22 SML-LXT0805GW-TR LUMEX OPTO 5 LED3, LED4, LED5, LED6, LED7 LED, GREEN 2.0V SMD0805 ROHS
23 FXO-HC736R-22.5792 FOX ELECTRONICS 1 OSC1 OSCILLATOR SMT 3.3V 24.576MHz ROHS
24 625L3C024M57600 CTS FREQUENCY CONTROLS 1 OSC2 OSCILLATOR SMT 3.3V 22.5792MHz ROHS
25 625L3I006M00000 CTS FREQUENCY CONTROLS 1 Y1 OSCILLATOR SMT 6.0MHz 3.3V OUT-ENABLE ROHS
26 GRM1885C1H470JA01D MURATA 2 C1, C2 CAP SMD0603 CERM 47PFD 50V 5% COG ROHS
27 C1608X7R1C105K TDK 3 C3, C123, C124 CAP SMD0603 CERM 1.0UFD 16V 10% X7R ROHS
28 GRM155R71C104KA88D MURATA 77 C4, C5, C6, C7, C8, C10, C12, C13, C17, C18, C20, C22, C23, C25, C26, C27, CAP SMD0402 CERM 0.1UFD 16V X7R 10% ROHS
C28, C29, C30, C32, C34, C35, C37, C38, C39, C40, C43, C44, C45, C46, C47,
C48, C49, C50, C51, C52, C53, C54, C56, C58, C60, C62, C64, C72, C73, C74,
C75, C76, C77, C79, C80, C83, C87, C88, C90, C91, C97, C99, C102, C112,
C113, C115, C117, C119, C120, C129, C130, C131, C132, C133, C134, C135,
C136, C137, C138, C139, C140
29 C1608X7R1H104K TDK 3 C9, C11, C16 CAP SMD0603 CERM 0.1UFD 50V 10% X7R ROHS
30 C1608C0G1H102J TDK CORP. 1 C14 CAP SMD0603 CERM 1000PFD 50V 5% COG ROHS
31 GRM1885C1H101JA01D MURATA 1 C15 CAP SMD0603 CERM 100PFD 50V 5% COG ROHS
32 GRM188R60J106ME47D MURATA 14 C19, C21, C24, C31, C33, C36, C41, C42, C55, C57, C59, C61, C63, C65 CAP SMD0603 CERM 10UFD 6.3V 20% X5R ROHS
33 JMK212BJ476MG-T TAIYO YUDEN 6 C66, C67, C68, C69, C70, C71 CAP SMD0805 CERM 47UFD 6.3V 20% X5R ROHS
19
SLAU564A–February 2014–Revised February 2014 TLV320AIC3268EVM-U Evaluation Module
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

TLV320AIC3268EVM-U Bill of Materials www.ti.com
Table 3. TLV320AIC3268EVM-U Bill of Materials (continued)
Item MANU PART NUM MFG QTY REF DESIGNATORS DESCRIPTION
34 GRM188R71C104KA01D MURATA 2 C78, C105 CAP SMD0603 CERM 0.1UFD 16V 10% X7R ROHS
35 EMK107B7105KA-T TAIYO YUDEN 6 C81, C96, C98, C110, C114, C116 CAP SMD0603 CERM 1.0UFD 16V 10% X7R ROHS
36 GRM21BR71A106KE51L MURATA 5 C84, C103, C104, C111, C118 CAP SMD0805 CERM 10UFD 10V10% X7R ROHS
37 GRM188R71A105KA61D MURATA 9 C85, C86, C89, C92, C93, C94, C95, CP90, CP91 CAP SMD0603 CERM 1.0UFD 10V 10% X7R ROHS
38 GRM188R71A225KE15D MURATA 2 C100, C101 CAP SMD0603 CERM 2.2UFD 10V 10% X7R ROHS
39 NA NA 0 C106, C107 CAP SMD1206 VALUE TBD
40 GRM188R71H222KA01D MURATA 8 C108, C109, C121, C122, C125, C126, C127, C128 CAP SMD0603 CERM 2200PFD 50V 10% X7R ROHS
41 ERJ-3EKF1501V PANASONIC 1 R1 RESISTOR SMD0603 1.50K OHM 1% THICK FILM 1/10W ROHS
42 ERJ-3EKF27R4V PANASONIC 2 R2, R3 RESISTOR SMD0603 27.4 OHMS 1% 1/10W ROHS
43 ERJ-3EKF1003V PANASONIC 1 R4 RESISTOR SMD0603 100K OHM 1% THICK FILM 1/10W ROHS
44 ERJ-3GEYJ103V PANASONIC 34 R5, R6, R7, R10, R12, R15, R18, R21, R25, R29, R34, R35, R36, R37, R38, RESISTOR SMD0603 10K 5% 1/10W ROHS
R39, R40, R41, R42, R43, R44, R45, R46, R47, R48, R49, R50, R51, R52, R55,
R83, R84, R87, R88
45 RC0603FR-07649RL YAGEO 2 R8, R9 RESISTOR SMD0603 THICK FILM 649 OHMS 1% 1/10W ROHS
46 ERJ-3EKF3091V PANASONIC 1 R11 RESISTOR SMD0603 3.09K OHM 1% THICK FILM 1/10W ROHS
47 ERJ-3GEYJ272V PANASONIC 4 R13, R14, R79, R80 RESISTOR SMD0603 2.7K OHMS 5% 1/10W ROHS
48 ERJ-3GEYJ472V PANASONIC 4 R16, R17, R24, R26 RESISTOR SMD0603 4.7K OHMS 5% 1/10W ROHS
49 ERJ-3GEY0R00V PANASONIC 6 R19, R20, R22, R23, R53, R54 RESISTOR,SMT,0603,ZERO OHM,5%,,1/10W,ROHS
50 RC0603FR-071KL YAGEO 13 R27, R28, R62, R66, R67, R68, R69, R74, R75, R76, R77, R86, R89 RESISTOR SMD0603 THICK FILM 1.00K OHM 1% 1/10W ROHS
51 ERJ-3EKF3570V PANASONIC 5 R30, R31, R32, R33, R85 RESISTOR SMD0603 357 OHM 1% THICK FILM 1/10W ROHS
52 CRCW0603200RFKEA VISHAY 3 R56, R57, R65 RESISTOR SMD0603 200 OHMS 1% 1/10W ROHS
53 ERJ-3EKF1000V PANASONIC 2 R58, R61 RESISTOR SMD0603 100 1% THICK FILM 1/10W ROHS
54 ERJ-3EKF2101V PANASONIC 3 R59, R63, R64 RESISTOR SMD0603 2.10K OHMS 1% THICK FILM 1/10W ROHS
55 ERJ-3EKF1101V PANASONIC 1 R60 RESISTOR SMD0603 1.10K OHMS 1% THICK FILM 1/10W ROHS
56 CRCW120616R0JNEA VISHAY 2 R70, R90 RESISTOR,SMT,1206,16.0 OHM,5%,1/4W,ROHS
57 RC1206FR-0732R4L YAGEO 3 R71, R72, R78 RESISTOR SMD1206 32.4 OHMS 1% 1/4W ROHS
58 ERJ-3GEY0R00V PANASONIC 0 R73 RESISTOR,SMT,0603,ZERO OHM,5%,,1/10W,ROHS
59 ERJ-3GEYJ204V PANASONIC 1 R81 RESISTOR SMD0603 200K OHMS 5% 1/10W ROHS
60 ERJ-2RKF8063X PANASONIC 1 R82 RESISTOR SMD0402 THICK FILM 806K OHMS 1/10W 1% ROHS
61 BLM15EG121SN1D MURATA 2 FB1, FB2 FERRITE BEAD SMD0402 120 OHMS 1.5A ROHS
62 MPZ1608S221A TDK 4 FB3, FB4, FB5, FB6 FERRITE CHIP, 220 OHMS 2A 100MHZ SMD 0603 ROHS
63 ZX62WD1-B-5PC HIROSE 1 J1 JACK USB FEMALE TYPEB MICRO SMT-RA 5PIN ROHS
64 75869-131LF FCI 0 J2 HEADER SHROUDED 100LS MALE GOLD 2x3 PINS ROHS
65 5607-4200-SH 3M 0 J3 CONNECTOR-SATA 7 PIN SMT-RA SERIES 5607 ROHS
66 SJ-43516-SMT CUI STACK 3 J4, J7, J10 JACK AUDIO-STEREO MINI(3.5MM ,4-COND SMT-RA ROHS
67 ED555/2DS ON SHORE TECHNOLOGY 2 J5, J6 TERMINAL BLOCK 2PIN 6A/125V GRAY 3.5mm PITCH 16-28AWG ROHS
68 SJ-435105 CUI STACK 1 J8 JACK AUDIO MINI(3.5MM ,4-COND SMT-RA ROHS
69 ED555/3DS ON SHORE TECHNOLOGY 1 J9 TERMINAL BLOCK 3PIN 6A/125V GRAY 3.5mm PITCH 16-28AWG ROHS
70 100P-JMDSS-G-1- JST 2 J11, J12 PLUG SMD 2x50 FEMALE JMDSERIES 0.5MM LS GOLD ROHS
TF(LF)(SN)
20 TLV320AIC3268EVM-U Evaluation Module SLAU564A–February 2014–Revised February 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated
