Thermalright Macho 120 User manual

Thermalright
Macho 120

Macho 120
Assembly package
× 1
× 1
4
4
8
× 1
× 1
× 2
× 4 × 1
× 4 × 4
× 7
× 5
Chill Factor 2g
× 4
× 4

Macho 120
1
Exploded View
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Intel 775/1155/1156/1366
Macho Heatsink Body 120mm Fan Clip
120mm Fan
Screw Nut
Anti-Vibration Pads
Mounting Plate
M3 L6 Screw
Anchoring Mount
Intel Washer
(small)
Backplate cap
Metal Back Plate
M3 L10 Screw

The Ultimate Cooling Solutions!
www.thermalright.com
2
Component
1
1
2
2
3
3
4
4
5
5
6
76
7 8
9
9
10
13
16
1615
11
14
12
12
15
1413
8
1110
Macho Heatsink Body ×1
LGA2011 Type B
Screw Pillars x4
120mm Fan Clip ×2
120mm Fan ×1
Thermal paste ×1
AMD Washer (big) ×4
Mounting Plate ×1
Metal Back Plate ×1
M3 L10 Screw ×5
Anti-Vibration Pad ×4
Anchoring Mount ×1
Screw Nut ×4
Intel Washer (small) ×4
Chill Factor 2g
M3 L6 Screw ×7
Backplate cap ×1
Screw driver ×1

3
Installation Instructions:
Step 1:
Step 2:
Step 3: Step 4:
Step 1 : Part Installation
Take out Macho cooler from the paper box.Remove the 120mm Fan from the cooler by pulling the Fan
Clips upwards in order to give room for ease of installation. And leave the Fan Clips on the Heatsink
Body. Do not remove them.Apply Anti-Vibration Padding to 4 corners on the Heatsink Body.
Step 2 : Backplate Installation
Choose the platform (775/1155/1156/1366) you are in use. Make four M3L10 Screw Pillars go through
the Metal Back Plate from bottom towards top.And then place the Metal Back Plate on the table. Put the
four Washers (for Intel) around the Screw Pillars.
Step 3 : 775 backplate cap
Note: When installing on a 775 platform, please
rst insert the Back Plate Cap into the opening on
the Back plate, make sure you have the Cap facing
downwards. (Only for 775).
Step 4 : Place the motherboard on top of the Back
Plate. See the four Screw Pillars go through the
four holes around the processor socket.Cap the
four Screw Pillars with the four Screw Nuts.Make
sure the side with a washer is facing the Back
Plate.
1366
775 1156
1155

The Ultimate Cooling Solutions!
www.thermalright.com
4
Step 5: Step 6:
Step 7:
Step 5 : Anchoring Mount Installation
Place the Anchoring Mount on the Screw Nuts.
Use the four M3L6 Screws to fix the Anchoring
Mount on to the Screw Pillars.
Chill Factor
2g
Chill Factor
2g
Step 6 : Applying Thermal Paste
Apply the Thermal Paste to the base of the
Heatsink and the surface of the CPU evenly.
Chill Factor
2g
Chill Factor
2g
Step 7: Mounting Plate Installation
Place the Heatsink Body on top of the CPU. Make
the Mounting Plate go through the Heatsink Body.
Then use the supplied Screw Driver to fasten the
two M3L6 Screws to Secure the Mounting Plate.
Step 8: Easy Access
Pass the supplied Screw
Driver through the central
hole of the Heatsink Body,
for easier access to the
M3L6 Screw underneath
the cooler.
Step 9: Step 10:
Step 9 : Fan Installation
Place the included 120mm fan onto the Heatsink
Body. And then secure it with the 120mm Fan
Clips, by pulling the Fan Clips to place the four
ends at the four holes on the 120mm Fan.
Step 10 : Installation completed
Plug in the fan connector to the CPU PWM Fan
socket on the motherboard. Installation complete.
Step 8:

Macho 120
5
Exploded View
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Macho Heatsink Body 120mm Fan Clip
120mm Fan
Mounting Plate
M3 L6 Screw
Anchoring Mount
LGA2011 Type B Screw Pillars
Intel 2011
Anti-Vibration Pads

The Ultimate Cooling Solutions!
www.thermalright.com
6
Component
1
1
2
2
3
3
4
4
5
5
6
76
7 8
9
9
10
13
16
1615
11
14
12
12
15
1413
8
1110
Macho Heatsink Body ×1
LGA2011 Type B
Screw Pillars x4
120mm Fan Clip ×2
120mm Fan ×1
Thermal paste ×1
AMD Washer (big) ×4
Mounting Plate ×1
Metal Back Plate ×1
M3 L10 Screw ×5
Anti-Vibration Pad ×4
Anchoring Mount ×1
Screw Nut ×4
Intel Washer (small) ×4
Chill Factor 2g
M3 L6 Screw ×7
Backplate cap ×1
Screw driver ×1

7
Installation Instructions:
Step 1:
Step 2:
Step 3:
Step 1 : Part Installation
Take out Macho cooler from the paper box.Remove the 120mm Fan from the cooler by pulling the Fan
Clips upwards in order to give room for ease of installation. And leave the Fan Clips on the Heatsink
Body. Do not remove them.Apply Anti-Vibration Padding to 4 corners on the Heatsink Body.
Step 2 : Place the motherboard on top of the Back Plate. See the four Screw Pillars go through the four
holes around the processor socket.Cap the four Screw Pillars with the four Screw Nuts.Make sure the
side with a washer is facing the Back Plate.
Step 3 : Place the Anchoring Mount on the Screw Nuts. Use the four M3L6 Screws to x the Anchoring
Mount on to the Screw Pillars.

Macho 120
The Ultimate Cooling Solutions!
www.thermalright.com
8
Step 4:
Step 5:
Step 6 : Applying Thermal Paste
Apply the Thermal Paste to the base of the Heatsink and the surface of the CPU evenly.
Step 7: Mounting Plate Installation
Place the Heatsink Body on top of the CPU. Make
the Mounting Plate go through the Heatsink Body.
Then use the supplied Screw Driver to fasten the
two M3L6 Screws to Secure the Mounting Plate.
Chill Factor
2g
Chill Factor
2g
Step 6:
Step 7: Step 8:
Step 9 : Fan Installation
Place the included 120mm Fan onto the Heatsink
Body. And then secure it with the 120mm Fan
Clips, by pulling the Fan Clips to place the four
ends at the four holes on the 120mm Fan.
Step 10 : Installation completed
Plug in the fan connector to the CPU PWM Fan
socket on the motherboard. Installation complete.
Step 8: Easy Access
Pass the supplied Screw
Driver through the central
hole of the Heatsink Body,
for easier access to the
M3L6 Screw underneath
the cooler.
Chill Factor
2g
Chill Factor
2g

Macho 120
9
Exploded View
Important! Before proceeding with installation, please check for the most
up-to-date instructions at www.thermalright.com
Macho Heatsink Body 120mm Fan Clip
120mm Fan
Screw Nut
Anti-Vibration Pads
Mounting Plate
M3 L6 Screw
Anchoring Mount
AMD Washer
(big)
Backplate cap
Metal Back Plate
M3 L10 Screw
AM2/AM2+/AM3/AM3+/FM1

The Ultimate Cooling Solutions!
www.thermalright.com
10
Component
1
1
2
2
3
3
4
4
5
5
6
76
7 8
9
9
10
13
16
1615
11
14
12
12
15
1413
8
1110
Macho Heatsink Body ×1
LGA2011 Type B
Screw Pillars x4
120mm Fan Clip ×2
120mm Fan ×1
Thermal paste ×1
AMD Washer (big) ×4
Mounting Plate ×1
Metal Back Plate ×1
M3 L10 Screw ×5
Anti-Vibration Pad ×4
Anchoring Mount ×1
Screw Nut ×4
Intel Washer (small) ×4
Chill Factor 2g
M3 L6 Screw ×7
Backplate cap ×1
Screw driver ×1

11
Installation Instructions:
Step 1:
Step 2:
Step 3: Step 4:
Step 1 : Part Installation
Take out Macho cooler from the paper box. Remove the 120mm Fan from the cooler by pulling the Fan
Clips upwards in order to give room for ease of installation. And leave the Fan Clips on the Heatsink
Body. Do not remove them. Apply Anti-Vibration Padding to 4 corners on the Heatsink Body.
Step 2 : Backplate Installation
Choose the platform (AMD) you are in use. Make four M3L10 Screw Pillars go through the Metal Back
Plate from bottom towards top. And then place the Metal Back Plate on the table. Put the four Washers (for
AMD) around the Screw Pillars.
Step 3 :backplate cap
Note: When installing on a 939 platform, please
first insert the Back Plate Cap into the opening
on the Back plate, make sure you have the Cap
facing downwards. (Only for 939).
Step 4 : Place the motherboard on top of
the Back Plate. See the four Screw Pillars go
through the four holes around the processor
socket.Cap the four Screw Pillars with the four
Screw Nuts.Make sure the side with a washer is
facing the Back Plate.
AMD

The Ultimate Cooling Solutions!
www.thermalright.com
12
Step 5:
Step 7:
Step 9: Step 10:
Step 5 : Anchoring Mount Installation
Place the Anchoring Mount on the Screw Nuts.
Use the four M3L6 Screws to fix the Anchoring
Mount on to the Screw Pillars.
Step 9 : Fan Installation
Place the included 120mm Fan onto the Heatsink
Body. And then secure it with the 120mm Fan
Clips, by pulling the Fan Clips to place the four
ends at the four holes on the 120mm Fan.
Step 6 : Applying Thermal Paste
Apply the Thermal Paste to the base of the
Heatsink and the surface of the CPU evenly.
Step 7: Mounting Plate Installation
Place the Heatsink Body on top of the CPU.
Make the Mounting Plate go through the Heatsink
Body. Then use the supplied Screw Driver
to fasten the two M3L6 Screws to Secure the
Mounting Plate.
Step 10 : Installation completed
Plug in the fan connector to the CPU PWM Fan
socket on the motherboard. Installation complete.
Step 6:
Step 8:
Chill Factor
2g
Chill Factor
2g
Step 8: Easy Access
Pass the supplied Screw
Driver through the central
hole of the Heatsink Body,
for easier access to the
M3L6 Screw underneath
the cooler.
Chill Factor
2g
Chill Factor
2g

Macho 120
13
Explosionszeichnung
Wichtig! Bitte prüfen Sie vor der Montage, ob für Ihren Kühler aktualisierte
Montagehinweise auf der Webseite www.themalright.com verfügbar sind.
Intel 775/1155/1156/1366
Macho Kühlkörper 120mm
Lüfterklammer
120mm Lüfter
Rändelschraube
Anti-Vibrationpad
Befestigungsplatte
M3 L6 Schraube
Montagerahmen
Intel
Unterlegscheibe
(klein)
Backplateeinsatz
Multi Plattform Backplate
M3 L10 Schraube

The Ultimate Cooling Solutions!
www.thermalright.com
14
Komponenten
1
1
2
2
3
3
4
4
5
5
6
76
7 8
9
9
10
13
16
1615
11
14
12
12
15
1413
8
1110
Macho Kühlkörper ×1
LGA2011 Type B
Adapterschraube x4
120 mm Lüfterklammer ×2
120 mm Lüfter ×1
Wärmeleitpaste ×1
AMD Unterlegscheibe
(groß) ×4
Befestigungsplatte ×1
Multi Plattform Backplate×1
M3 L10 Schraube ×5
Anti-Vibrationspad ×4
Montagerahmen ×1
Rändelschraube ×4
Intel Unterlegscheibe
(klein) ×4
Chill Factor 2g
M3 L6 Schraube ×7
Backplateeinsatz ×1
Schraubendreher ×1

15
Multi Plattform Backplate×1
Installationsanleitung:
Schritt 1:
Schritt 2:
Schritt 3: Schritt 4:
Nachdem Sie den Macho Kühler aus der Verpackung genommen haben demontieren Sie zunächst den
120 mm Lüfter, um die Installation zu vereinfachen. Belassen Sie hierbei die Lüfterklammern am
Kühlkörper - entfernen Sie diese nicht. Bringen Sie die vier selbstklebenden Anti-Vibrationspads an den
Ecken des Kühlkörpers an.
Achten Sie auf die für die entsprechenden Intel Sockel (775/1155/1156/1366) vorgesehene
Bohrungen in der Multi Plattform Backplate. Führen Sie die vier M3L10 Schrauben jeweils von unten
durch diese Bohrungen und legen dann die Backplate auf den Tisch. Legen Sie die vier Unterlegscheiben
(für Intel) über die hervorstehenden Gewinde.
Beachten Sie:
Bei Verwendung einer Intel Sockel 775 Plattform
setzen Sie zuerst den Backplateeinsatz in die
quadratische Öffnung der Backplate ein. Gehen
Sie sicher, dass der Aufsatz nach unten zeigt.
Platzieren Sie das Mainboard von oben auf die
Backplate, so dass die hervorstehenden
Schraubengewinde durch die Löcher um den
Prozessorsockel gehen. Schrauben Sie die
beiliegenden Rändelschrauben auf die vier
Schraubengewinde. Achten Sie dabei darauf, dass
die Seite mit der Unterlegscheibe zur Backplate
zeigt.
1366
775 1156
1155

The Ultimate Cooling Solutions!
www.thermalright.com
16
Schritt 5: Schritt 6:
Schritt 7:
Setzen Sie den Montagerahmen auf die
Rändelschrauben. Verwenden Sie die vier
M3L6 Schrauben, um den Montagerahmen
auf den Rändelschrauben zu befestigen.
Chill Factor
2g
Chill Factor
2g
Tragen Sie eine hauchdünne Schicht
Wärmeleitpaste auf der Oberäche der CPU
und auf der Unterseite des Kühlers auf.
Chill Factor
2g
Chill Factor
2g
Platzieren Sie nun den Kühlkörper auf die CPU.
Führen Sie anschließend die Befestigungsplatte
durch den Kühlkörper und benutzen die beiden
M3L6 Schrauben, um die Befestigungsplatte zu
befestigen.
Führen Sie den mitgelieferten
Schraubendreher durch das
Loch in der Mitte des
Kühlkörpers, um leichter
Zugang zu den M3L6
Schrauben unterhalb des
Kühlers zu erhalten.
Schritt 9: Schritt 10:
Positionieren Sie den mitgelieferten 120 mm Lüfter
auf die Kühlerseite mit den bereits angebrachten
AntiVibrationspads. Nun sichern Sie den Lüfter mit
den 120 mm Lüfterklammern, indem Sie diese über
den Lüfterrahmen klappen und die spitzwinkeligen
Ecken in den Montagelöchern des Lüfters einrasten
lassen.
Verbinden Sie den Lüfterstecker mit dem
CPU PWM Lüfteranschluss auf dem Mainboard.
Die Installation ist nun abgeschlossen. Bitte
prüfen Sie die ordnungsgemäße Funktion vor
Inbetriebnahme Ihres PC.
Schritt 8:

Macho 120
17
Explosionszeichnung
Wichtig!Bitte prüfen Sie vor der Montage, ob für Ihren Kühler aktualisierte
Montagehinweise auf der Webseite www.thermalright.comverfügbar sind.
Macho Kühlkörper 120mm
Lüfterklammer
120mm Fan
Befestigungsplatte
M3 L6 Schraube
Montagerahmen
LGA2011 Type B Adapterschraube
Intel 2011
Anti-Vibrationspad
