Thermo Scientific Jewett PRF17 Guide

Thermo Scientific Jewett® PRF17
Refrigerator/Freezers
Installation and Operation
307950H01 Rev ESeptember 2014
Part of Thermo Fisher Scientific
Visit us online to register your warranty
www.thermoscientific.com/labwarranty

© 2014 Thermo Fisher Scientific Inc. All rights reserved.
IMPORTANT Read this instruction manual. Failure to follow the instructions in this manual can result in
damage to the unit, injury to operating personnel, and poor equipment performance.
CAUTION All internal adjustments and maintenance must be performed by qualified service personnel.
Material in this manual is for informational purposes only. The contents and the product it describes are
subject to change without notice. Thermo Fisher Scientific makes no representations or warranties with
respect to this manual. In no event shall Thermo be held liable for any damages, direct or incidental, arising
from or related to the use of this manual.

Table of Contents
Introduction.........................................................................................................................1
Inspection for Damage.......................................................................................................3
Operating Standards .......................................................................................................... 5
Installation........................................................................................................................... 7
Safety instructions.................................................................................................................................. 7
Location ................................................................................................................................................ 7
Wiring................................................................................................................................................... 8
Operation............................................................................................................................. 9
Initial Startup ........................................................................................................................................ 9
Refrigerator Section Performance....................................................................................................... 9
Freezer Section Performance .............................................................................................................. 9
Defrost................................................................................................................................................. 10
Installation and Removal of Drawers.............................................................................. 11
Mounting Drawer Slides...................................................................................................................... 11
Installation........................................................................................................................................... 11
Removal............................................................................................................................................... 12
Hinge and Latch Adjustment...........................................................................................13
Hinge Adjustment ............................................................................................................................... 13
Latch and Strike Adjustment ............................................................................................................... 14
Maintenance ...................................................................................................................... 15
Gasket Maintenance ............................................................................................................................ 15
Condenser Maintenance ...................................................................................................................... 16
Troubleshooting................................................................................................................ 18
Accessories....................................................................................................................... 20
Warranty ............................................................................................................................ 22
You have purchased a high-quality product from ThermoFisher Scientific. If you experience any problems not
covered in this manual or the TROUBLESHOOTING section, please visit our website at www.thermo.com
for additional information. If you still need assistance call 1-800-438-4851 for technical support. Please have
your model and serial number ready.
Bulb Maintenance ................................................................................................................................17

This page is intentionally left blank

Thermo Scientific Jewett PRF17 Refrigerator/Freezers Installation and Operation 1
1
Introduction
This product is a complete packaged unit ready to operate when plugged into an electrical
source. It is not necessary to have a refrigeration serviceman set the unit in operation. The unit
has been tested prior to shipment. Read all the instructions before proceeding with
installation.
In this manual and on labels attached to this product, the words WARNING and CAUTION
mean the following:
WARNING A potentially hazardous situation which, if not avoided, could result in
serious injury or death.
CAUTION A potentially hazardous situation which, if not avoided, may result in
minor or moderate injury or damage to the equipment.
WARNING The electrical hazard symbol to the left indicates situations with
dangerous voltages and a potential for electric shock.
Before installing, using or maintaining this product, please be sure to read this manual and
product warning labels carefully. Failure to follow these instructions may cause this product to
malfunction, which could result in injury or damage.
Below are important safety precautions that apply to this product:
• Use this product only in the way described in the product literature and in this manual.
Before using it, verify that this product is suitable for its intended use.
• Do not modify system components, especially the controller. Use OEM exact replacement
equipment or parts. Before use, confirm that the product has not been altered in any way.
• Your unit must be properly grounded in conformity with national and local electrical
codes. Never connect the unit to overloaded power sources.
• Disconnect the unit from all power sources before cleaning or performing other
maintenance on the product or its controls.

Introduction
2 Installation and Operation Thermo Scientific Jewett PRF17 Refrigerator/Freezers
The following symbols are used in caution, warning and informational labels attached to the
unit:
caution, info
electrical hazard
hot surface
earth ground
protective conductor terminal
on
off
alternating
current
cold surface
watch hands
on (control panel)
off (control panel)
standby
(battery enable)

Thermo Scientific Jewett PRF17 Refrigerator/Freezers Installation and Operation 3
2
Inspection for Damage
At delivery, examine the exterior for physical damage while the carrier’s representative is
present. If exterior damage is present, carefully unpack and inspect the unit and all accessories
for damage.
If unit or accessories have been damaged in shipping place a damage claim with the carrier.
If there is no exterior damage, unpack and inspect the equipment within five days of delivery.
If you find any damage, keep the packing materials and immediately report the damage to the
carrier. Do not return goods to the manufacturer without written authorization. When
submitting a claim for shipping damage, request that the carrier inspect the shipping container
and equipment.

Inspection for Damage
4 Installation and Operation Thermo Scientific Jewett PRF17 Refrigerator/Freezers
This page is intentionally left blank

Thermo Scientific Jewett PRF17 Refrigerator/Freezers Installation and Operation 5
3
Operating Standards
The refrigerator/freezers described in this manual are classified for use as stationary equipment
in a Pollution Degree 2 and Overvoltage Category II environment.
These units are designed to operate under the following conditions:
• Indoor use
• Altitude up to 2000m
• Main supply voltage fluctuations not to exceed 10% of the nominal voltage.
Model Voltage Frequency Current
PRF17-1B 120V 60HZ 10.5A
Electrical Specifications:
Packing List
Inside the refrigerator/freezer is a bag containing:
•This manual
If you have ordered a HemaPro, the bag will also contain:
• HemaPro instructions

Operating Standards
6 Installation and Operation Thermo Scientific Jewett PRF17 Refrigerator/Freezers
This page is intentionally left blank

Thermo Scientific Jewett PRF17 Refrigerator/Freezers Installation and Operation 7
4
Installation
Safety instructions
• Only plug into a grounded outlet
• Do not remove ground prong
• Do not use a 3 prong to 2 prong adapter
• Do not use an extension cord
• Disconnect power before servicing
• Do not operate with any panels or parts removed
Location
1. Measure all doorways and passageways for clearance before moving cabinet. These units
will pass through a standard 30" x 84” door opening.
2. Inspect the interior, exterior and mechanical equipment for special instruction tags
fastened at various points.
3. Move the unit into the desired location. Make sure the bottom is evenly supported and the
floor is level. Thin shims under the points of rest can be used to equalize the distribution
of weight. If the cabinet sets on an uneven floor, a slight rocking or vibration might result
when the condensing unit is set in operation.
4. A minimum of 6" clearance is required at the back and sides of the unit, and 12” on top of
the unit to allow adequate ventilation of the mechanical equipment.
Note
• All units are provided with locking casters. Apply the brakes prior to operation.
• Do not position the equipment in direct sunlight, near heating diffusers, radiators, or
other sources of heat. The ambient temperature range at the location must be 59°F to 90°F
(15°C to 32°C).
• Do not position the unit in a way that impedes access to the switch on the back of the
unit.

Installation
Wiring
8 Installation and Operation Thermo Scientific Jewett PRF17 Refrigerator/Freezers
Explosion Hazard Keep flammable materials and vapors away from refrigerator. Failure
to do so can result in death, explosion, or fire.
Wiring
CAUTION Operation under electrical conditions other than those specified on the
dataplate will cause permanent damage to the mechanism. The dataplate is
located inside the refrigerator at the top of the right hand wall.
Before connecting your freezer to a power source, be sure to check the dataplate for correct
voltage. Standard NEMA plugs are provided with all units.
WARNING For personal safety and trouble-free operation, this unit must be properly
grounded before it is used. Failure to ground the equipment may cause
personal injury or damage to the equipment. Always conform to the
National Electrical Code and local codes. Do not connect unit to already
overloaded power lines.
Always connect the equipment to a dedicated (separate) circuit. Electrical codes require fuse or
circuit breaker protection for branch circuit conductors. Use time delay fuses for #12 AWG
circuits.
CAUTION Do not use an outlet that can be turned off by a switch.

Thermo Scientific Jewett PRF17 Refrigerator/Freezers Installation and Operation 9
5
Operation
Initial Startup
• Make sure that the unit is free of all wood or cardboard shipping materials, both inside
and outside.
• Plug unit into a power outlet on a dedicated circuit.
• Turn unit on using power switch on the back of the unit. Turn unit off using power switch
before unplugging or servicing.
• Allow unit to reach operating temperature before storing contents.
Refrigerator Section Performance
The refrigerator section is factory preset to operate within a +2 ºC to +4 ºC temperature
range. The refrigerator section temperature will be shown on the digital display at the top of
the unit.
Freezer Section Performance
Ther freezer section setpoint is factory preset and will vary based on ambient conditions.
Typical performance:
Ambient Temperature Freezer Temperature
15 ºC-32 ºC
25 ºC-26 ºC
32 ºC-20 ºC
The freezer setpoint cannot be changed.

Operation
Defrost
10 Installation and Operation Thermo Scientific Jewett PRF17 Refrigerator/Freezers
Defrost
The defrosting process initiates automatically in response to a built-in timer.
All models are set for one defrost cycle every eight hours. The maximum length of the defrost
cycle is 20 minutes. The cycle terminates automatically if during defrost the evaporator coil
temperature exceeds 15°C.
Note
• The condensing unit is shipped with all service valves open and ready for operation. Do
not adjust the refrigerant valves or the temperature control. If adjustment of the
temperature control should become necessary, the adjustments may be made by qualified
personnel.
• All models have been provided with an electric condensate evaporator located on the back
of the cabinet. Periodic cleaning of the condensate pan will ensure proper operation. Refer
to image below for location of condensate pan.
Condensate pan

Thermo Scientific Jewett PRF17 Refrigerator/Freezers Installation and Operation 11
6
Installation and Removal of Drawers
Mounting Drawer Slides
1. Push into slots in rear standard as shown in Step # 1. Make certain that the opposite
drawer slides are in the same slots in the opposite standards.
2. Push into slots in front standard and press down. If necessary, tap into place.
Installation
1. Place drawer on top of slides and push into rear stops.
2. Align slot on lever with the tabs on the drawer slide. Push lever down to lock in place.
LEVER

Installation and Removal of Drawers
Removal
12 Installation and Operation Thermo Scientific Jewett PRF17 Refrigerator/Freezers
Removal
1. Lift lever up to unlock drawer from the drawer slides.
2. Lift front of drawer up and pull clear of slides.
LEVER

Thermo Scientific Jewett PRF17 Refrigerator/Freezers Installation and Operation 13
7
Hinge and Latch Adjustment
Hinge Adjustment
1. Remove exterior hinge cover plate by opening the refrigerator door. Place a screwdriver
under interior portion of cover and gently pry cover outward. Pull straight out. Close
cover.
2. Loosen the three (3) screws "B" which hold adjusting plate "C" in position.
3. To tighten gasket seal, place hand against exterior of door near hinges; gently press in on
door so gasket sits firmly against cabinet face. Tighten screws "B".
4. When adjustment is complete, it hinges are adjusted so gasket seal is too tight, door will
tend to spring open. Door must be readjusted. To test gasket seal, insert a dollar bill (or
piece of paper of similar size) between the gasket and the cabinet opening. Close door; a
slight resistance to removal of the dollar bill (test strip) should be felt. Check the perimeter
of the door. If the latch is loose, see latch-adjusting information.
5. Replace cover plate "A."
Note To accomplish different offsets, shims are utilized. If replacing hinges, make sure to reuse any
shims furnished on the cabinet.

Hinge and Latch Adjustment
Latch and Strike Adjustment
14 Installation and Operation Thermo Scientific Jewett PRF17 Refrigerator/Freezers
Latch and Strike Adjustment
1. Latch is fastened to door.
2. For up or down adjustment (proper latch engagement) loosen mounting screws "B".
3. Strike plate "C" remains in position.
4. Move strike "D" up or down as required and tighten screws "B" when adjustment is
satisfactory. No play will be present in the latch handle with the door closed.
5. For in and out adjustment (proper gasket seal) loosen screw "E". Adjust in or out as
required and tighten screw when adjustment is satisfactory.
6. The stainless steel hex head cap screw is 10/32" X 5/16" long. Use box wrench, open-end
wrench, or ratchet to tighten. Do not use a nut driver or pliers.
Note If replacing latch and strike assembly, make sure to reuse any shims furnished on the cabinet.

Thermo Scientific Jewett PRF17 Refrigerator/Freezers Installation and Operation 15
8
Maintenance
CAUTION Make sure power switch is off and unit is unplugged before doing any
maintenance or servicing.
WARNING Use nonflammable cleaner.
Failure to do so can result in death, explosion, or fire.
• Frequent cleaning of the interior and exterior with water and a good fungicidal detergent
that eliminates harmful bacteria, stains and other foreign matter will keep the unit fresh
and new looking.
• Shelves and/or drawers should be removed from the cabinet and thoroughly scrubbed. To
clean the drawers or shelves, use a solution of water and a mild detergent. Rinse the
drawers or shelves and wipe them dry with a soft cloth. For instructions on how to remove
the drawers/shelves refer to “Installation and Removal of Drawers”.
• The unit cooler fans do not require lubrication.
• The condensing unit does not require oil or other lubrication.
• Annual inspection of the mechanical refrigeration equipment by a qualified serviceman is
recommended. A qualified technician can make adjustments that will prevent future
breakdown.
Gasket Maintenance
Periodically check the gaskets around the door for punctures or tears. Door seal integrity is
critical for refrigerators and freezers. A gasket with a poor seal allows moist air to be drawn into
the cabinet, resulting in quicker frost buildup on the evaporator coil, longer running time,
poor temperature maintenance, and increased operation cost. Gasket leaks are indicated by
condensation that forms on the interior or exterior of the unit at the point of gasket failure.
Keep the door gaskets clean and debris free by cleaning with a solution of water and a mild
detergent. Gently wipe the gasket dry with a soft cloth.

Maintenance
Condenser Maintenance
16 Installation and Operation Thermo Scientific Jewett PRF17 Refrigerator/Freezers
Condenser Maintenance
CAUTION The finned condenser can become clogged with lint and dust. The
openings between fins should be kept clean. Condensers should be cleaned
at least every six months at a minimum. In heavy traffic areas, condensers
load with heavy dirt more quickly. Failure to keep the condenser clean can
result in equipment warm-up or erratic temperatures.
WARNING Be sure to disconnect the unit from main power before cleaning the
condenser.
CAUTION Never clean near condensers with your fingers. Some surfaces are sharp.
1. Disconnect the power.
2. Remove the screws shown in image below to access the condenser.
3. Use a vacuum cleaner with hose and brush attachments to clean the front face of the
finned surface shown in the image below.
4. Clean up any loose dust and replace the grill.
5. Reconnect the power.
Remove screws to remove grill Finned Surface
