Thuraya XT-LITE User manual

XT-LITE satellite phone
USER GUIDE
THURAYA {()

ENGLISH
DELITSCH
ESPAfilOL
ITALIANO
PORTUGU
PYCCKlllLil
Certification/Compliance/Waminty
Limitation of Liability

Parts Description Overview of the Home Screen
1.
2.
13.
14.
3. 6. 15.
4. 7. 9.
10.
5.
8.
11. 12.
1. Satellite antenna
2. Receiver
3.
Left soft key
4.
Call key
5. Alphanumeric keypad
6.
Navigationkeys
7.
Selection key
8.
Microphone
9. Right soft key
10.
End key
11.
USB/Datacablejack
12.
Chargerjack
13. Earphonejack
(Earphones are
available as an
optional accessory)
14. Battery release
15.
SIMcardholder
Satellite signal
Weak signal. Point
satellite.
Roaming
Active call
Mute
Ciphering (call
Receiving GPS-fix
Earphoneconnected
Status bar
Network information
Unread SMS
Voice mail
Voice mail + SMS
SMS inbox full
Silent
Schedule reminder
Alarm
Call divert
Available soft key
functions

1

Getting Started
Inserting the SIM card
Make sure to insert the SIM card in the
shown direction before inserting the
battery.
Inserting the battery
Insert the battery from the bottom end
first. Then push down the top end until
you hear it click in place.
Charging the battery
Open the cover at the bottom of the
phone and firmly connect the charger to
the charger jack.
Network connection
When the XT-LITE is powered on, the
phone will search for the network and
acquire location information. If the SAT
and location icons are lashing, the phone
is yet to receive the location information
and you will be able to make a call
or send a message once the lashing
stops. Upon successful registration to
the network, the phone will display the
country and the signal strength.

Calls
Making a call
To make a call, enter a phone number
using the keypad or choose a saved
contact and then press the Call key.
Receiving a call
To receive a call, press the Call key or
any key on the keypad.
During a call
During a call, you can mute the call or put
the call on hold from the Options menu.
Swapping calls
While receiving an incoming call during
an already active call, select Swap. This
will allow you to connect with up to 6
users.
Conference calls
1During an active call, go to Options >
New call. The first call is automatically
put on hold.
2Call the other user’s phone number.
3To add the first user into the
conference call, go to Options >
Multiparty.
You can include up to 6 users in the
conference call by repeating steps
1 to 3.
Note
During a conference call, you may
choose to speak with a user in private.
Select the user and go to Options >
Private, and then all other calls are put
on hold automatically.
3
2

*
Messaging Features
Sending messages
1Go to Menu > Messages > New
message.
2Enter the message.
3Add the phone numbers of the
recipient(s).
4Select Options > Send.
Tips
Press the key for symbol entry, the
# key for switching between number
and text, and Options > AutoText for
predictive text entry.
SMS to email
While writing a message, you can change
the sending format to email.
1Select Options > Sending options >
Format > SMS to email.
2Select Options > Send > enter an
email address > OK > enter an email
center number > Send.
Navigation
• Find your current coordinates
• Enter waypoints to navigate to a
specific position with the electronic
compass
• Geo reporting can be used to send
your coordinates to pre-defined
numbers via SMS. Follow Option A to
send only the coordinates and Option
B to send coordinates plus a user-
defined message (see next page).
4

Features
Option A
To send only the GPS coordinates (without
user-defined message):
Go to Menu > Navigation > Geo
reporting.
1Enter recipient(s):
• Enter up to four recipients, one for
each of the empty slots.
• Select the slot, go to Options >
Add recipient, and choose to input
the number or select from contacts.
2Set the interval:
• Select any of the four slots and go
to Options > Message intervals.
• Choose frequency of outgoing
messages (every 3 minutes to
every 2 hours).
Option B
To send a user-defined message along
with the GPS coordinates:
Go to Menu > Navigation > Geo
reporting.
• Follow steps 1 and 2 from above.
• Turn on SOS message:
- Select any of the four slots and go
to Options > SOS message > On.
• Set the SOS message:
- Select any of the four slots. and
go to Options > Setup SOS
message.
- Write the message and press the
Selection key to save.
How to activate and
deactivate Geo reporting:
• To activate from the home screen,
long press the right soft key .
• To deactivate while in use, short
press the right soft key .
Organizer
Use the Organizer of your XT-LITE for
a range of convenient features such as
setting alarms, scheduling appointments,
using the built-in calculator, stopwatch
and world time.
5

Call notification Software Upgrades
Your Thuraya XT-LITE allows you to
receive a notification of an incoming call
even if your satellite signal is too weak to
receive the call itself. This is particularly
useful when the Thuraya XT-LITE is in
your pocket with the antenna stowed, and
only has a weak signal.
1Fully extend the antenna of your
Thuraya XT-LITE.
2Ensure that you have direct line of
sight to the satellite.
3As soon as the signal strength
is strong enough, the warning
disappears from the display. You
can now accept the call as usual by
pressing the Call key.
A software upgrade is only required
if Thuraya releases a newer software
version. Before performing an upgrade
please check your current software
version under Security > S/W version to
see if an upgrade is required.
1Download and install the latest XT-
LITE upgrader file from www.thuraya.
com.
2Download the latest XT-LITE software
from www.thuraya.com.
3Power on your Thuraya XT-LITE with
a fully charged battery.
4Connect the PC and the Thuraya XT-
LITE using the USB cable.
5Double click the XT-LITE upgrader
icon on the desktop and the program
will guide you through the upgrade
process.
How to connect the data cable for a
software upgrade:
Open the cover at the bottom of the
phone and firmly connect the USB cable
to the UDC jack.
Afterwards attach the other side of the
data cable to your PC.
6

Function Operation
Keypad Lock/Unlock Press and hold the # key to lock the keypad. To unlock press the right soft key followed by the # key
within 3 seconds.
Adding Contacts
1. Enter a phone number and press the Selection key.
Or go to Contacts > Add contact.
2. Select the storing location (phone or SIM card) and
phone number information.
Silent Mode Long pressing the key will switch between Silent and
Normal mode.
Checking your current
location
Go to Menu > Navigation > Current position.
Changing text input
mode Long press of the key will switch between AutoText and
Normal mode.
Changing languages Go to Menu > 7.Settings > 3.Language.
Call logs To see your recently called numbers press the Call key (or
go to Call logs).
Useful Tips Maintaining your XT-LITE
Your satellite phone needs to be in
optimal working condition when you need
it. To ensure your phone is prepared,
a regular Thuraya phone test provides
you with peace of mind that ensures
your satellite phone is working when it is
needed:
• Test your Thuraya phone regularly,
especiallyifyouhavenotuseditfor
sometime(dialthefreenumber
11 11 2 from your XT-LITE to test if it
is working properly)
• Charge the XT-LITE's battery once a
monthtohavethephonereadywhen
you needit
• Checkyoursubscriptionorcredit
balance regularly
7

Troubleshooting
Problem Solution
The XT-LITE cannot connect to the
network and ‘No Network’ is shown
on the screen.
• Try to update the SAT registration manually by going to Menu > Network > SAT
registration.
• Ensure the line of sight to the satellite is not obstructed by high buildings, trees, or mountains.
Location icon is lashing or the XT-
LITE shows ‘Position too old’.
• The XT-LITE's location information is being updated. This is done automatically once the
phone is powered on.
• Ensure the line of sight to the satellite is not obstructed by high buildings, trees, or mountains.
The XT-LITE shows ‘Insert SIM’.
• Try to remove and reinsert the SIM card.
• Check if the SIM card is dirty or damaged.
• Entering a wrong PUK code may deactivate the SIM card.
• When using a different SIM card (other than a Thuraya SIM card) in the XT-LITE while
abroad, roaming service must be enabled (please contact your Service Provider to check if
roaming is active).
8

Troubleshooting
Problem Solution
The XT-LITE becomes unresponsive
or sluggish.
• Try restarting your phone.
• Do a reset in case your phone has a persistent problem by going to Menu > Security.
- Soft reset: You can reset your phone without losing your personal settings like contacts or
messages.
- Factory reset: The factory reset will restore the settings on the phone to be as it was when
shipped. Personal settings like contacts and messages will be deleted.
The security code has been lost or
forgotten.
• The factory setting of the security code is 0000.
• Please contact your Service Provider in case the number has been changed and was
forgotten.
The PIN/PUK codes have been lost or
forgotten.
• Entering the wrong PIN code 3 times will lock the SIM card. To unlock, you must enter the
PUK code.
• After entering the PUK code, you can set a new PIN code.
• In case the PUK code has been forgotten, please contact your Service Provider.
9
