Timago FS 925L User manual

1
INSTRUCTIONS FOR USE
Underarm crutch
Product code: FS 925L
1. Characteristics
The underarm crutch consists of aluminium leg with rubber tip, soft
crutch pad, and adjustable handgrip. Owing to wide range of
adjustment, the crutch can be used either by short or tall patients.
Ergonomic shape and light weight make the crutch comfortable in use.
a. Handgrip
b. Crutch pad
c. Handgrip adjustment – TF system (knob)
d. Height adjustment – locking pin
e. Rubber tip
2. Application
The underarm crutch is ancillary equipment which is used in case of
lower limb injury with simultaneous injuries of wrist or elbow. It is also
recommended to patients who need help and support while walking
for gait re-education after lower limb injuries, and it can also be used
as an aid in keeping balance in case of serious dysfunctions of lower
limbs or trunk.
Contraindications: coordination and balance disorders, advanced
rheumatic changes, injuries and dysfunctions of upper limbs which may
hinder the user to support on the crutch.

2
3. Adjustment
The crutch should be adjusted individually to the user so that the
shoulder joints are not excessively raised, and adjust the height of the
handgrip so that your elbow is slightly bent at the angle of
approximately 30°.
•To adjust the crutch, press the metal pin and select appropriate
position of the inner tube. Lock the position of the tubes relative
to each other with the use of metal pin. The crutch is adjustable in
2.5 cm increments.
•To adjust the height of handgrip, unscrew the knob, take out the
screws and set the handgrip on the appropriate level. Put the
screws in and tighten the knob.
•When using two crutches, handgrips and locking pins must be set
at the same level. Legs of the crutch should always stand stably on
the ground.
4. Technical data
Type:double adjustable
Colour: silver
Maximum capacity:100 kg
Size S:
Height adjustment: 94-114 cm
Crutch cane: 0.73 kg
Size M:
Height adjustment: 114-134 cm
Crutch cane: 0.8 kg
Size L:
Height adjustment: 134-154 cm
Crutch cane: 0.87 kg
5. Notes
Timago International Group does not bear responsibility of improper
use of the product, failure to comply safety regulations and misuse.

3
6. Cleaning and maintenance
•Clean the crutch using only water and mild detergents, dry
thoroughly.
•Do not use: strong detergents, abrasive agents, bleach, petrol nor
solvents (it may cause frame damage, visible defects, and in
consequence – loss of warranty rights).
•It is recommended to check rubber tip regularly. Replace worn tip
immediately.
7. Storage and transport conditions
Device should not be exposed to direct sunlight, water or moisture.
8. Warranty information
All products distributed by our company are covered by a warranty, the
terms of which are described in the warranty card available on our
website. Please contact the retailer from whom you purchased the
product. Please, keep in mind that for warranty purposes, the proof of
purchase (receipt or invoice) should be retained
9. Labels
Reference
number
Manufacturer
LOT number Manufacture date
Serial number Medical device
Note
Please read the
instruction
The manufacturer checked for compliance with
essential medical devices requirements.

4
Our complete line of products is available from our distributors.
Learn more at: www.timago.com. Thank you for choosing Timago!
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12
43-316 Bielsko-Biała, Polska
T.: [phone]
F.: [phone]
E.: [e-mail]
Rev. II, date 20.05.2021
