Timago AMIGO-1 User manual

Strona 1z 8
INSTRUCTIONS FOR USE
Aluminium 4-wheeled rollator
Product code: AMIGO-1 / AMIGO-2
1. Characteristics
Four-wheeled, folding frame made of aluminum frame. Coated with
paint with a metallic sheen. Equipped with parking brakes, seat with
backrest and handy bag. It has full 9'' diameter wheels and height-
adjustable handles finished with anatomical handgrips. The structure is
based on a crossover frame and an oval cross-section of tubes, thanks
to which the resistance to axial pressure is significantly increased.
The set includes: frame with seat and backrest, shopping bag.
Elements of the rollator:
a. Handgrip
b. Parking brake
c. Adjustment clamp
d. Brake cable
e. Seat with handle
f. Wheel
g. Seat rail

Strona 2z 8
2. Application
The rollator is designed for patients with reduced mobility who need
stable support and help while walking. It is also recommended to the
elderly as an aid in keeping balance, improving walking comfort and
ensuring safety from falling. The use of the rollator affects positively on
the return to activity of the people with locomotion and tilting to erect
position problems. It guarantees better stabilization, support and
security while walking.
3. Unfolding, folding and adjustment
Unfolding
•To unfold the rollator, grab both handgrips and pull them outward.
•Press down on the seat rails until it is fully unfolded (click of the
locking mechanism).
Folding
•To fold the rollator, lift the seat by the handle and pull it up.
•Grab both handgrips of the rollator and press them inward.
Handgrips height adjustment
To adjust the height of the handgrip:
•Press the brake down to set the parking mode and immobilize the
rollator (Fig. 1).
•Pull the adjustment clamp (Fig. 2).
•Hold the adjustment clamp and adjust the height of the handles
(Fig. 3).
•Release the adjustment clamp to lock the adjusted height of the
handles. Pull the handle up and down several times to check the
correct height locking (Fig. 4).
•Adjust the height of the second handgrip in a similar manner.
•Both handgrips should be set at the same height.

Strona 3z 8
Brake function
•To stop the rollator, pull the brake handle up toward the handle,
then hold.
•When stationary or using the seat, lock the brake with the parking
clamp by pulling the brake handle down.
•To release the brake, pull the brake handle upward.
Adjustment of lower brake
•To adjust the brake and increase the tension, unscrew the
adjustment screw with the use of appropriate tools and tighten the
locking screw by holding the adjustment screw.

Strona 4z 8
4. Technical data
Parameters
AMIGO-1
AMIGO-2
Overall width
60,5 cm
60,5 cm
Overall depth
72 cm
72 cm
Seat width
25 cm
25 cm
Total height
70-82 cm
70-88 cm
Seat height from the
ground
55 cm
55 cm
Weight
7,9 kg
8,1 kg
Maximum capacity
130 kg
130 kg
Maximum capacity of
the shopping bag
5 kg
5 kg
Frame colour
Silver
Silver
5. Notes
Timago International Group does not bear responsibility of improper
use of the rollator, failure to comply safety regulations and misuse.
6. Maintenance
•Clean the frame with damp cloth and dry thoroughly.
•Do not use strong polishing agents due to the damage of protecting
coatings.
•Clean the dirt from moving parts of the rollator regularly (hinges,
clamping screws, locks).
7. Storage and transport conditions
Device should not be exposed to direct sunlight, water or moisture.
8. Warranty information
All products distributed by our company are covered by a warranty, the
terms of which are described in the warranty card available on our
website. Please contact the retailer from whom you purchased the

Strona 5z 8
product. Please, keep in mind that for warranty purposes, the proof of
purchase (receipt or invoice) should be retained.
9. Labels
Reference
number
Manufacturer
LOT number
Manufacture date
Serial number
Medical device
Note
Please read the
instruction
The manufacturer checked for compliance with
essential medical devices requirements.
Our complete line of products is available from our distributors.
Learn more at: www.timago.com. Thank you for choosing Timago!

Strona 6z 8
NOTES:

Strona 7z 8

Strona 8z 8
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12
43-316 Bielsko-Biała, Polska
T.: [phone]
F.: [phone]
E.: [email protected]
07/2023(I)
