Mackworth SA400 User manual

Doc No. 999565 Revision of document: A
Revision Date: 20.04.21
User Manual
SA400 Stand Aid

999565 – Revision A Page | 2 of 32
CONTENTS
Safety Instructions and Warnings.......................................................................................................4
1.1 Introduction ...................................................................................................................................4
1.2 Manufacture...................................................................................................................................4
1.3 European Authorised Representative .............................................................................................4
1.4 Symbols Used .................................................................................................................................5
1.5 Contraindications / Limitations.......................................................................................................6
1.6 Intended Use .................................................................................................................................6
1.7 Warning Notes................................................................................................................................7
1.8 Operating Environment ..................................................................................................................7
Components / Key Parts.....................................................................................................................8
Assembly Instructions ........................................................................................................................9
3.1 Unpacking ......................................................................................................................................9
3.2 Unboxing Stand Aid ........................................................................................................................9
3.3 Stand Aid Assembly ......................................................................................................................10
3.4 Electrical Connections..................................................................................................................11
Final Inspection................................................................................................................................11
Operating Instructions .....................................................................................................................12
5.1 Manoeuvring the Stand Aid ..........................................................................................................12
5.2 Raising and Lowering ....................................................................................................................12
5.3 Open / Close Stand Aid Legs .........................................................................................................12
5.4 Emergency Stop Button ................................................................................................................13
5.5 Mechanical Emergency Lowering..................................................................................................13
5.5.1 Manual Emergency Lowering .............................................................................................13
5.5.2 Electrical Emergency Lowering...........................................................................................13
5.6 Handset Operations......................................................................................................................13
5.6.1 Battery Status ....................................................................................................................14
5.7 Battery .........................................................................................................................................14
5.7.1 Charging the Battery Pack ..................................................................................................14
5.8 Slings ............................................................................................................................................14
Technical Specification .....................................................................................................................17
6.1 Mackworth SA400 Dimensions .....................................................................................................17
6.2 Specifications ...............................................................................................................................18
6.3 Electrical Specifications ................................................................................................................18

999565 – Revision A Page | 3 of 32
6.4 Standards Applied ........................................................................................................................18
Environmental - Storage and Operating Conditions..........................................................................19
7.1 Normal Operating Conditions .......................................................................................................19
7.2 Shipping and Storage Conditions ..................................................................................................19
Disposal ...........................................................................................................................................19
Fault Finding ....................................................................................................................................20
General Inspection, Maintenance and Cleaning ...............................................................................21
10.1 Service ......................................................................................................................................21
10.2 Inspection .................................................................................................................................21
10.3 Cleaning ....................................................................................................................................22
10.3.1 General Cleaning................................................................................................................22
10.3.2 Disinfecting (if necessary) ..................................................................................................22
Warranty..........................................................................................................................................24
Service Record History .....................................................................................................................25

999565 – Revision A Page | 4 of 32
SAFETY INSTRUCTIONS AND WARNINGS
1.1 Introduction
Please read and understand this manual in its entirety before using your Mackworth SA400 Stand Aid.
The information in this manual is important for the safety of anyone near the Mackworth SA400 Stand Aid and must be read and
understood to help prevent injuries. It is also crucial to the proper operation and maintenance of the Stand Aid.
The Stand Aid is designed to be used in conjunction with slings and accessories. Please refer to any user guides supplied with
these components while reviewing this manual.
Should any questions arise from reviewing this manual, contact your local authorised representative.
Failure to comply with warnings in this manual may result in; injury to the operator and/or client and/or damage to the Stand
Aid or related components.
If, during the use of this device or as a result of its use a serious incident has occurred, please report it to the manufacturer and
to your national authority.
Store this manual with the documents included with the Stand Aid and sling(s). Contents of this manual are subject to change
without prior written notice. Ensure you are aware of the sling manufacturer’s fitting instructions.
Do not attempt to use this equipment without first understanding the contents of this manual.
Unauthorised modifications on any Mackworth product may affect its safety. The manufacturer will not be held
responsible for any accident, incident or deficiencies of performance that occur as a result of any unauthorised
modification to its products.
Do not use a clip fit sling on a lifting arm designed specifically for loop fitting slings.
1.2 Manufacture
The Stand Aid is manufactured at the address below:
Prism Medical UK
Unit 1, Tir Llwyd Industrial Estate, St Asaph Avenue, Kinmel Bay, Conwy, LL18 5JZ
Telephone number: 01924 840 100
1.3 European Authorised Representative
The address of the European Authorised Representative for this product:
European Healthcare & Device Solutions (Ireland) Ltd.
Stratton House, Bishopstown Road,
Cork, Ireland.
T12 Y9TC.
Telephone number: [phone]

999565 – Revision A Page | 5 of 32
1.4 Symbols Used
The Table below includes all Symbols from BS EN ISO 15223-1:2016 that can be found in this Manual and on the Product and
what they represent. Refer back to this Table when you are unsure of what a symbol represents.
Consult instructions before use Caution – see instructions for use
Manufacturer
Safe Working Load represents the
maximum load rated for safe
operation
Packaging indicator – This way up Date of manufacture
Serial number Packaging indicator – Keep dry
Please observe local laws on recycling For internal use only
Temperature range
Degree of protection provided by
enclosure.
N1: Ingress of particles
N2: Ingress of water
Humidity range Medical Device
Catalogue number European Authorised Representative
Table 1

999565 – Revision A Page | 6 of 32
1.5 Contraindications / Limitations
There are no known “contraindications” associated with the usage of the Mackworth SA400, provided they are used as per
manufacturer’s recommendations and guidelines. However, it is recommended that a client specific assessment is completed by
a trained and knowledgeable health care professional to determine the method of transfer.
Mackworth does not recommend a required number of care givers for the use of our products. This information and
recommendation can only be provided after a thorough personalised, case specific assessment, as there are many factors that
can influence these decisions.
1.6 Intended Use
For internal use only.
The Mackworth SA400 is a Standing Aid to be used by trained personnel. The Stand Aid is a medical device which
carries out safe lifting and transfers of an individual from one resting surface to another (such as a shower chair to a bed).
Mackworth recommends that the transfer of a patient is fully risk assessed and conducted safely over a short distance only.
Carrying out each transfer correctly for minimal strain or risk to the caregiver, while providing complete safety, dignity and
comfort to the client. The Mackworth SA400 is suitable for patients in the SITTING position only, who have a degree of weight-
bearing ability but require assistance to stand. By removing the foot tray, The Stand Aid can be used as a walking aid if
competent and trained person completes an adequate risk assessment of the surroundings, and the patient is observed during
use. The Mackworth SA400 is designed to support and promote safe patient handling and transfer for both the patient and
carer.
The Stand Aid is one of two components that makes this possible. The other component, the sling, is a specially designed fabric
accessory that attaches to the Stand Aid by means of the boom Loop attachment and straps, and holds the patient during
operation.
Please refer to the user guides supplied with the sling and reference them while reviewing this manual.
The functions of raising and lowering the boom, and opening/closing the legs are accomplished by pressing buttons on the hand
control.
The device is used under instruction and the operation of the aid is undertaken by a trained carer.
A risk assessment must be performed before using any other manufactured slings or Stand Aid is ensure safe use can
be established.
•The Mackworth SA400 is intended to be installed on a flat and levelled surface prior to use.
•The Stand Aid must be installed only by persons authorised by Mackworth or who have the rights to install and
commission the Stand Aid safe for use.
•Under no circumstance should the Mackworth SA400 or the entire system be put in control of a person who has not
been properly trained in the use and care of this equipment. Failure to adhere to this warning may result in serious
injury to the operator and/or the individual being transferred.
•In facilities where more than one operator will be responsible for using the Stand Aid and sling(s) it is imperative that all
such members be trained in the Mackworth SA400 proper use. A training program should be established by the facility
to acquaint new operators with this equipment.
•The Mackworth SA400, and associated slings are not toys. Do not use it for unsafe practices. Do not allow children to
play with the Stand Aid or any of its components.

999565 – Revision A Page | 7 of 32
•Your guarantee is void if persons unauthorized by Mackworth perform work on the Stand Aid.
•To maintain optimum function, the Mackworth SA400 should be inspected and maintained on a regular basis. See
section ‘General Inspection, Maintenance and Cleaning’ within this user manual.
•Any accessories used with this Stand Aid including belt(s), should be checked to ensure that they are in good working
order. Check for signs of wear to each component prior to use. Report any unusual wear, or damage immediately to
your local authorised dealer.
•The Mackworth SA400 and Slings(s) are intended only for transferring of a person. Mackworth will not be responsible
for any damage caused by the misuse, neglect or purposeful destruction of the Unit, and/or its associated components.
•The Stand Aid and its associated parts are certified to a maximum load of 180kg (400 lb). Do not exceed the maximum
rated load of any of the components.
•Ensure that a clear space is maintained around the Stand Aid. Before performing a transfer check for and move all
obstacles out of the way.
•Your Product is for Aiding a human to transfer. Do not use it, or allow it to be used, for any other purpose.
•Protecting the people present, visually monitor the sling(s) loops connection points during transfer stages, so the belt
remains firmly attached to the Stand Aid
•In areas where children are prone to be present be vigilant when carrying out a transfer.
•To reduce the risk of unintended use, when the Stand Aid is not in use remove the sling(s) from the product to prevent
entrapment or strangulation should the device be tampered with.
•Between Stand Aid and Body-Support Unit, the lowest maximum load shall always be used.
You may need to seek specialist advice on how to assist some people with specific moving and handling needs.
Sources of advice include, but is not limited to, professional bodies and organisations, occupational therapist,
physiotherapists, manual handling advisers and ergonomist with experience in health and social care.
1.7 Warning Notes
Your Mackworth SA400 has been manufactured and tested to exceed BS EN 10535:2006. This does not mean that it
can be used without care. ALL OPERATORS should have read the operating instructions and appreciate this warning
section.
1. ALL Stand Aids are less stable on sloping surfaces. A 5-degree slope is the maximum permitted and then only with great
care.
2. ALL Stand Aids are dangerous to the person being transferred when used recklessly or pushed at speed.
1.8 Operating Environment
The Mackworth SA400 is suitable for use within the professional health care facility environment as well as the home health care
environment. The Stand Aid is not suitable for any special environments.
The Stand Aid is not intended to be used in environments where there are rapid changes in the environmental temperature and
humidity during intended use.

999565 – Revision A Page | 8 of 32
COMPONENTS / KEY PARTS
Please see below to familiarise yourself with the components of the Mackworth SA400 Stand Aid. The images below show the
contents of the Stand Aid. If you have not received all the components contact your Mackworth dealer immediately – contact
details are provided on the last page of this manual.
Item
Description
Item
Description
1
Handle
11
Knee Pad Length Adjustment
2
Mast
12
Knee Pad Angle Adjustment
3
Lifting Arm
13
Star Handle Mast Fixture
4
Looped Sling Attachment
14
Front Castors
5
Handset
15
Slack Adjustment Star Handle
6
Manual E-lower
16
Foot Tray
7
Battery
17
Product Serial Number Label
8
Lift Actuator
18
Electric Leg Actuator
9
Control Box
19
Rear Braked Castors
10
Knee Pad
Table 2
Figure 1
1
3
4
6
8
10
11
12
14
16
17
19
2
5
7
9
13
15
18

999565 – Revision A Page | 9 of 32
ASSEMBLY INSTRUCTIONS
3.1 Unpacking
Some of the parts are heavy and will need to be lifted with care. Items weighing over 20kg (44lb) will require a two
person lift. Please refer to (6.0) technical specifications for components weights.
The Stand Aid will arrive to you in a robust box, please be careful when removing the components from the box.
Please read the user guide in full before operating.
This user manual should be kept safe for future reference.
The Stand Aid has been specifically designed to be installed in both the professional and home health care environments.
No matter the environment, health and safety factors should be considered to ensure the safety and essential performance of
the Stand Aid and to avoid unnecessary damage or injuries to people within the area of the Stand Aid.
The environment in which the Stand Aid is situated in, whilst carrying out a transfer, is required to be on a flat surface with no
steep inclines.
3.2 Unboxing Stand Aid
When using a sharp knife, be careful not to damage the product.
This section will summarise the layout of the Stand Aid Packaging and what is included in the Box. It is recommended a knife is
used for smoother unpacking of the Stand Aid. The Stand Aid is packed into a single box (47x32x47 inches) weighing
approximately 50kg (110lb).
Using a knife to open the box around the perimeter, the box should open to a similar view to Figure 3. It will include all the
following components. It is recommended that the components are removed in the numerical order below.
1. Mast
2. Base
3. Fixings
4. Hand Control
5. Charging Lead
6. User Manual

999565 – Revision A Page | 10 of 32
3.3 Stand Aid Assembly
A. Carefully open the box and remove all loose parts and excess packaging from the
box.
2 person lift recommended for the following points.
B. Carefully holding onto the handle and boom, lift the Stand Aid components out of
the box. Place carefully onto the floor.
C. With one person lifting up from the front castors and one person lifting up from
the rear castors, raise the base from the box and place the Stand Aid base on a
flat surface and ensure the rear braked castors are locked.
D. Remove Star handle from the top of the base and slot the mast and boom
assembly onto the base. (As shown in Fig. 2 and 3).
E. Ensure all cables are clear from entrapment while fitting the base and mast
together.
Please ensure both hands are on the handle when lifting the mast into position,
as there is a risk of finger trap.
F. When the mast if fully engaged with the base, fit and fully tighten the mast
star handles is the following order (as shown in Fig. 4 and 5).
Ensure the mast is fully seated into the base and the mast locking wheel
is in position and tight before using the Stand Aid.
NOTE: To disassemble the Stand Aid into the two main sections (Mast/boom and Base)
simply follow the pervious steps in reverse.
Figure 2
Figure 4
Figure 5
Figure 3

999565 – Revision A Page | 11 of 32
3.4 Electrical Connections
Connect all the cables to the control box as shown in the pictures
opposite.
A. Connect the lift actuator cable connector to the second port (marked No. 1)
from the left side of the control box (as shown in Fig. 6).
B. Connect the leg spreading actuator cable connector to the third port (marked
No. 2 in Fig. 6).
C. Connect the handset connector to the large port on the left side of the control
box. A locator pin on the plug ensures correct orientation of the connector (as
shown in Fig. 8).
D. Connect the mains cable/power cord to the control box (as shown in Fig. 9).
Ensure that all cables are located and secure before operating the Stand
Aid.
FINAL INSPECTION
Before first operation of the Stand Aid:
•Confirm all cables are located and secure.
•Ensure the red emergency stop button on the control box is deactivated. (Rotate clockwise to release if required- Refer
to section 5.4 for guidance).
•Press the up button on the handset and confirm the actuator raises the boom.
•Press the down button on the handset and confirm the actuator lowers the boom.
•Press the button on the handset to operate the leg opening and confirm the actuator moves the legs outwards.
•Press the button on the handset to operate the leg closing and confirm the actuator moves the legs inwards.
•Press the red emergency stop button on the control box and check that actuators do not operate until the button is
reset. (See section 5.4 for guidance).
•Check the manual emergency lowering function works properly. (See section 5.5 for guidance)
•Check the rear castors brakes function properly.
•Check the battery pack is fully charged.
Your Stand Aid is now ready to use.
Figure 6
Figure 9
Figure 8
Figure 7

999565 – Revision A Page | 12 of 32
OPERATING INSTRUCTIONS
The Stand Aid may be heavy for users and will need to be lifted with care, please operate the device with the use of
the castors wherever possible to prevent any injury.
Appropriate training in lifting and handling procedures should be undergone by any person operating a Stand Aid,
for their own and the client’s safety and comfort. These instructions are designed to cover the method of using the Stand Aid.
5.1 Manoeuvring the Stand Aid
A. To move the Stand Aid forward, hold onto the handle bar and push forward.
B. Do not stand on the leg actuator, or use the actuator to push the Stand Aid (Fig. 10 and 11).
C. When turning the Stand Aid, use both hands on the handle. Alternatively, it is possible to rotate the Stand Aid by
applying the brake to a single rear castor and rotating the Stand Aid about the braked castor. This movement should be
performed with a smooth, slow action to avoid swinging the patient unnecessarily.
D. The Mackworth SA400 Stand Aid has two rear castors with brake.
E. The rear castors can be braked for rotation (by applying a single brake), lateral movement, and parking. To apply the
brake, press the brake pedal down with your foot (as shown in Fig. 12). To release the brake, press the raised pedal
towards the wheel (as shown in Fig. 13).
F. During lifting, the rear wheels should remain unlocked so that the Stand Aid will not move.
The wheels should be locked if there is a risk of the Stand Aid moving to the patient. For example, when lifting the
patient from the floor.
5.2 Raising and Lowering
The up and down movement of the lifting arm on the Mackworth SA400 Stand Aid is achieved by
an electric actuator which is controlled by hand control. The hand control has two buttons with
directional arrows up and down. The actuator stops automatically at the limit of travel in both
directions.
5.3 Open / Close Stand Aid Legs
The legs of Mackworth SA400 Stand Aid are opened/closed using the appropriate
buttons on the hand control, see figure 15 for guidance. The legs’ motion will be
stopped whenever the hand control button is released. The legs can be opened to
enable access around arm chairs or wheel chairs. When relocating the Stand Aid,
manoeuvring through narrow doorways and/or passages, the Stand Aid legs should be
in the closed position.
Figure 14
Figure 12
Figure 13
Figure 15
Figure 10
Figure 11

999565 – Revision A Page | 13 of 32
5.4 Emergency Stop Button
The Mackworth SA400 Stand Aid is fitted with an Emergency Stop button.
Push the Emergency Stop button (as shown in Fig. 16) to cut all power on the Stand Aid.
To resume power, release the emergency stop button by turning in a clockwise
direction (indicated by arrows on the Emergency Stop button) as shown in Fig. 17.
5.5 Mechanical Emergency Lowering
5.5.1 Manual Emergency Lowering
In case of power failure, it is possible to mechanically lower a patient placed in
Mackworth SA400 Stand Aid.
Turn the manual lowering handle in clockwise direction (as shown in Fig. 18) to
lower the boom until the boom reaches a safe position.
The manual emergency lowering system should be used only if the
lowering procedures described in the previous section of the manual
do not work. Should you have any concerns or questions contact your
local authorised Mackworth Representative.
Do not use the Stand Aid after the manual lowering mechanism has
been used. The lift must be reset by a qualified technician after use.
Contact your local authorised Mackworth Service Provider.
5.5.2 Electrical Emergency Lowering
The Stand Aid lifting arm can be lowered by pushing the emergency lowering button on
the control box with a suitable object, such as a pen nib or pencil (as shown in Fig. 19).
5.6 Handset Operations
The Hand Controls has 4 functions: Up and Down, this will raise and lower the Stand Aid lifting arm, and Legs
Open and Legs Close, these functions will open and close the legs.
Press down on each symbol to operate the desired function. It is not possible to use two functions at the same
time. Once the Stand Aid has reached the extent of its travel in a given direction, the actuator will
automatically stop, allowing you to then choose the opposite direction.
The handset is attached to the control box via a flexible, coiled cable that is secured in place with a friction-fit
plug. The coiled cable is designed to give the greatest number of options for carer positioning without having a
trailing cable around the patient. The handset also incorporates a hook which gives the carer flexibility whist
moving/positioning the patient. Clear and easy to understand labelling of the buttons enable ease of use for
the care giver.
The handset also displays battery level by the use of an LED light.
Figure 16
Figure 17
Figure 18
Figure 20
Figure 19

999565 – Revision A Page | 14 of 32
Figure 21
5.6.1 Battery Status
A single LED is used to indicate Low Battery, the LED will light up orange when battery power is low. This
means the battery needs charging. At this stage some of the functionality of the lift is lost. At this battery
stage, it is not possible to drive the lifting arm up or down. Furthermore, an audio signal will sound when
a control button is activated (17V or lower).
5.7 Battery
The battery pack should never be stored for long periods of time without a regular charge.
The battery pack is protected encased unit located on top of the control box, on the rear of the product. The control box, below
the battery, will inform the user when the battery is flat and requires charging, by an illuminated LED. An LED illuminate when
the battery needs recharging. Complete the lift and place the battery on charge.
5.7.1 Charging the Battery Pack
The battery pack can be recharged via mains lead (terminated with a
figure of eight plug)
A. Fit the mains lead figure of eight plug into charger link cable
(see Fig. 22).
B. Plug the 2-pin mains plug into a suitable mains outlet and
switch the mains supply on.
C. Charging is automatic and will normally take eight to twelve
hours to fully charge (from completely discharged state). You
cannot overcharge the battery pack if left for longer periods of
time.
D. To return the Stand Aid to use, switch off the mains supply.
Remove the figure of eight plug from the socket at the base of
the control box.
E. The Stand Aid is now ready for use.
5.8 Slings
Sling loops should be attached as follows:
1. Put the required sling loop onto your finger and thumb and open the selected sling loop up (Figure 23 & Figure 24).
2. Slide the sling loop onto the sling hook (Figure 25).
3. Follow the hook profile around until the sling loop is positioned at the base of the hook (Figure 26).
To remove the sling, simply reverse the processes shown in the above statements.
Figure 22
Figure 23
Figure 24
Figure 25
Figure 26

999565 – Revision A Page | 15 of 32
We recommend the use of the Mackworth Healthcare or Care-Ability manufactured sling range (type ‘B’ applied part) to be
utilised with the Mackworth SA400 Stand Aid. It is at the user’s discretion to use alternative supplied product. In utilising
another manufacturer’s sling, checks must first be made to ensure the sling is safe to use and meets the requirements of BS EN
ISO 10535 before its use.
The slings with a safe working load of 180kg (400 lb) that can be used with the Mackworth SA400 Stand Aid are shown below in
Table’s 3 and 4, complete with product codes. For all components, the lowest maximum safe working load must always be
adhered to.
Size
Mackworth Sling Range - Product Material and Code
Polyester Solid
Holly - Stand Aid Transport Sling
XS 1201HL7600
Small
1201HL7500
Medium 1201HL7400
Large 1201HL7300
XL 1201HL7200
XXL
1201HL7100
XXXL 1201HL7000
Maple - Stand Aid Sling With Back Support
XS 1201MP7600
Small 1201MP7500
Medium 1201MP7400
Large 1201MP7300
XL 1201MP7200
XXL 1201MP7100
XXXL 1201MP7000
Poplar - Stand Aid Sling
XS 1201PL7600
Small 1201PL7500
Medium 1201PL7400
Large 1201PL7300
XL 1201PL7200
XXL 1201PL7100
XXXL 1201PL7000
Size
Care Ability Sling Range - Product Material and Code
Polyester
Mesh
Spacer
Parachute
CA800 Chest Sling
P1 CA800PP1 CA800MP1 CA800SP1 CA800PAP1
P2 CA800PP2 CA800MP2 CA800SP2 CA800PAP2
Table 3

999565 – Revision A Page | 16 of 32
P3 CA800PP3 CA800MP3 CA800SP3 CA800PAP3
P4 CA800PP4 CA800MP4 CA800SP4 CA800PAP4
P5 CA800PP5 CA800MP5 CA800SP5 CA800PAP5
X Small CA800PXS CA800MXS CA800SXS CA800PAXS
Small CA800PS CA800MS CA800SS CA800PAS
Small/Medium CA800PSM CA800MSM CA800SSM CA800PASM
Medium CA800PM CA800MM CA800SM CA800PAM
Medium/Large CA800PML CA800MML CA800SML CA800PAML
Large CA800PL CA800ML CA800SL CA800PAL
X Large CA800PXL CA800MXL CA800SXL CA800PAXL
XX Large CA800PXXL CA800MXXL CA800SXXL CA800PAXXL
CA801 Chest Sling
P1 CA801PP1 CA801MP1 CA801SP1 CA801PAP1
P2 CA801PP2 CA801MP2 CA801SP2 CA801PAP2
P3 CA801PP3 CA801MP3 CA801SP3 CA801PAP3
P4 CA801PP4 CA801MP4 CA801SP4 CA801PAP4
P5 CA801PP5 CA801MP5 CA801SP5 CA801PAP5
X Small CA801PXS CA801MXS CA801SXS CA801PAXS
Small CA801PS CA801MS CA801SS CA801PAS
Small/Medium CA801PSM CA801MSM CA801SSM CA801PASM
Medium CA801PM CA801MM CA801SM CA801PAM
Medium/Large CA801PML CA801MML CA801SML CA801PAML
Large CA801PL CA801ML CA801SL CA801PAL
X Large CA801PXL CA801MXL CA801SXL CA801PAXL
XX Large CA801PXXL CA801MXXL CA801SXXL CA801PAXXL
CA900 Transport Sling
P1 CA900PP1 CA900MP1 CA900SP1 CA900PAP1
P2 CA900PP2 CA900MP2 CA900SP2 CA900PAP2
P3 CA900PP3 CA900MP3 CA900SP3 CA900PAP3
P4 CA900PP4 CA900MP4 CA900SP4 CA900PAP4
P5 CA900PP5 CA900MP5 CA900SP5 CA900PAP5
X Small CA900PXS CA900MXS CA900SXS CA900PAXS
Small CA900PS CA900MS CA900SS CA900PAS
Small/Medium CA900PSM CA900MSM CA900SSM CA900PASM
Medium CA900PM CA900MM CA900SM CA900PAM
Medium/Large CA900PML CA900MML CA900SML CA900PAML
Large CA900PL CA900ML CA900SL CA900PAL
X Large CA900PXL CA900MXL CA900SXL CA900PAXL
XX Large CA900PXXL CA900MXXL CA900SXXL CA900PAXXL
Table 4

999565 – Revision A Page | 17 of 32
TECHNICAL SPECIFICATION
6.1 Mackworth SA400 Dimensions
All dimensions below are shown in millimetres.
Figure 27
Figure 28

999565 – Revision A Page | 18 of 32
6.2 Specifications
Dimensions
Turning Circle
1230mm (48”)
Overall Height
1720mm (68”)
Overall Width
680mm (27”)
Ground Clearance
33mm (1.3”)
Front and Rear Castors Size
100mm (4”)
Operational Forces
Moving Force with 180 kg (400 lb)
104.5 N
Moving Force with 0 kg (0 lb)
20 N
Operation of the Brake
35 N
Handset
4.5 N
E-Stop Button
12 N
Manual Leg Lever with 0kg (0 lb)
80 N
Table 7
6.3 Electrical Specifications
Battery type: 2 x 12-volt Rechargeable sealed lead acid.
Battery capacity: 24 V DC, 1 x 2.9 Ah
Charger rated input: 230VAC 50/60Hz
Charger rated output: 27.4/29.0 VDC @ 0.8A
Electric Shock Protection
Charger: Class II *Lift - internal power source
Degree of shock protection: Type B *Lift - internal power source
Duty cycle: 10% Use – 90% Rest (90 seconds use - 810 seconds rest)
IP rating, control box: IPX4
IP rating, battery: IPX5
IP rating, handset: IPX4
Expected Product Lifetime
10 yrs. depending usage and compliance to maintenance, servicing and LOLER inspections.
6.4 Standards Applied
The standards that have been applied to the device are as follows:
•EN 10535:2006 Hoists for the transfer of disabled persons. Requirement and test methods.
Weights:
Safe Working Load (SWL)
180 kg / 400 lb
Full Product
47 kg / 104 lb
Base Assembly
23 kg / 51 lb
Mast & Boom Assembly
24 kg / 53 lb
Table 5
Table 6

999565 – Revision A Page | 19 of 32
ENVIRONMENTAL - STORAGE AND OPERATING
CONDITIONS
The Mackworth SA400 is intended for internal use within normal environmental conditions.
It is not intended to be used in environments where there are rapid changes in the environmental temperature and
humidity during intended use.
7.1 Normal Operating Conditions
+5°C to +40°C (41°F to 104°F) at a relative humidity between 15% to 90% RH, non-condensing but not requiring a water vapour
pressure greater than 50hPa and atmospheric pressure between 700hPa to 1060hPa.
7.2 Shipping and Storage Conditions
-25°C to +5°C (-13ºF to 41ºF) with any humidity level.
+5°C to +35°C (41°F to 95°F) at a relative humidity up to 90%.
+35°C to 70°C (95⁰F to 158⁰F) non-condensing at a water vapour pressure up to 50hPa.
DISPOSAL
When the Stand Aid has completed its life cycle and can no longer perform to its intended use safely the Stand
Aid must be decommissioned by an approved Service Engineer. The following specifies the importance of
correct disposal procedure including local laws and being environmentally friendly.
Please observe the local laws on recycling and respect the current laws for disposal within the community the
device is being used within. If there is any uncertainty of the below guidelines, contact your local authorities to
determine the proper method of disposal of potentially biohazardous parts and accessories.
The relevant components utilised in the manufacture of the device that can be recycled at the end of the device
life are:
Fully recyclables:
Consideration when Recycling:
Steel frame (Frame, Upper Assembly, Legs)
Knee Pad
Castors
Lift Actuator
Initial packaging of the device (cardboard)
Control Box
Metallic fixing – screws etc.
Handset + Cables
Foot Tray
Battery
Leg Actuator
The product may be contaminated and has to be disinfected before recycling or disposal.
See section 10.3 ‘Cleaning’ for details of how to do this.
Table 8

999565 – Revision A Page | 20 of 32
FAULT FINDING
If a problem arises with the Stand Aid, the Table below will hopefully assists in determining the fault and what actions you can
take. If the fault cannot be found or the fault is found and the action guide does not provide a fix (e.g. – a damaged wire would
need replacement), contact your local Mackworth authorised dealer immediately, a service engineer will be required to repair
the Stand Aid. Contact details can be found on the last page of this manual.
Fault
Action
Stand Aid doesn’t turn on
•Check the E-Stop button on the control box has not been activated.
•Check the Handset is correctly connected to the correct control box port.
•Check the Handset lead is not damaged, e.g. cuts and breaks.
•Check to see if the Stand Aid battery is out of charge and requires charging.
•Check the Battery is located correctly on top of the control box.
•Check for any damage to the battery terminals, e.g. burns and breaks.
•Perform a visual check on the Control box for any damage.
Stand Aid doesn’t charge
•Check the Charger plug is turned on at the power supply.
•Check that the Charger Lead is connected correctly to the Control Box
•Check charging lead for damage, e.g. cuts and breaks.
•Check that the Battery is connected properly with the Control Box.
•Inspect the Battery terminals for any damage, e.g. burns and breaks.
•Inspect the Control Box terminals for any damage, e.g. burns and breaks
Stand Aid doesn’t lift
•Check if the Stand Aid is plugged into Charge. (Stand Aid will not raise and
lower while on charge)
•Check that the Lift Actuator to Control Box cable is connected properly
between the two ports.
•Check the Lift Actuator to Control Box cable for damage, e.g. cuts and
breaks.
•Inspect the Lift Actuator for any signs of damage which could affect its
function, including the Port. E.g. Large Cracks and breaks, electrical burns.
•
Inspect the Control Box Port for any damage. E.g. electrical burns, breaks.
Stand Aid Leg Actuator is not
responding.
•Check Cable between the Control Box and the Leg Actuator is connected
correctly.
•Check for Cable damage between the Control Box and Leg Actuator cable.
•Inspect the Leg Actuator for any damage, including the cable port. E.g.
large cracks and electrical burns.
•Inspect the Control Box Leg Actuator Cable Port for any damage. E.g. cracks
and electrical burns.
•If there is no indication of any power while commanding the Powered Legs,
Handset buttons could be damaged.
Stand Aid has power but does not
respond to handset commands.
•Check the Handset is correctly connected to the Control Box.
•Check that the Lift Actuator and Leg Actuator Cables are both connected to
the Control Box.
•Check the Handset cable is not damaged, e.g. cuts and breaks.
•Check the Lift Actuator and Leg Actuator Cables for damage, e.g. cuts and
breaks
•Check the Control Box Handset Port for any damage. E.g. cracks and
electrical burns.
Table 9
