Timago ROM walker 17 User manual

1
USER MANUAL
ROM walker - 17’’
Product code: 12203 / 12205 / 12207
Dear Customers,
Thank you for purchasing our product. We hope that the equipment you have selected will
meet your expectations. We would like to share some important information with you.
Timago International Group is a Polish company which distributes medical, rehabilitation and
orthopaedic products to pharmacies and medical stores.
Our mission is to ensure your comfort by offering safe, functional, and high-quality products.
We have many years of experience in this sector. Timago products reach a wide range of
users in Poland and throughout Europe through our distributors (medical retailers).
Timago’s company culture promotes openness to your needs. Our goal is to promote safe
and correct use of our products for treatment and rehabilitation in order to improve comfort
and quality of life.
We invite you to access our website for more information: timago.com.

2
1. Introduction
Prior to use of our products you should inspect the equipment for any defects which may
have occurred during transport. If this happens, please contact your retailer.
Then, please read this instruction which includes important information for the user.
Please contact us if you have any questions concerning the use of the equipment. Our
advisors will provide you with any information you require on an ongoing basis.
Please note that if you have questions other than those concerning the use of our products,
you should contact your doctor, nurse or physical therapist.
2. Characteristics
The walker consists of a splint in the shape of a shoe which is made of PVC and two
collateral, stabilizing splints with hinged ROM system enabling angle adjustment. The
orthosis is equipped with material inner liner which is air permeable and removes excessive
heat and moisture perfectly. The walker is equipped with system of circumferential straps
which enable individual adjustment of stabilization force and with profiled anti-sliding sole
which facilitates the patient possibly physiological gait.
3. Application
The walker is used in post-traumatic and post-operative rehabilitation process in order to
limit the range of mobility in ankle joint and to improve functional activities. The orthosis
stabilizes the foot and the shin in plantarflexion or ankle joint flexion position in post-
traumatic injuries in the area of foot and shin.
Indications for use:
•post-operative treatment
•twist and dislocation of ankle joint
•Achilles tendon rupture
•fractures in the area of foot, upper and lower ankle joint
•as an alternative for plaster cast immobilization

3
4. Contraindications
Do not use in case of:
•skin abrasion
•eczema
•wound and other skin injuries
•after application of warming gel or ointment
Note! In case of varicose veins the usage of the air walker is restricted. Contact with
attending physician to determine whether the product may be used together with
compression stockings.
5. Notes and recommendations
•Note! Do not use the product without doctor’s advice.
•Note! Use the product according to doctor’s or physiotherapist’s recommendation.
•Do not use the product in case of contraindications listed in point 4.
•Note! The walker must be adjusted and fitted properly in terms of size. Too loose or
too tight walker may cause skin abrasion.
•Note! Remember that the time of wearing the walker should be shortened
systematically and determined by the professional doctor or physiotherapist who
possesses proper medical qualifications.
•Note! If there are no contraindications, it is recommended to perform passive
exercises several times a day. Exercises should be selected individually by a specialist
or physiotherapist.
•Note! In case of skin lesions (abrasion, eczema, wounds) place bandage before use of
the walker.
•Note! Check the condition of the product regularly. In case of any damage, report
immediately to the point of sale.
•Do not make any repairs or modifications by yourself.
NOTE! Timago International Group does not bear responsibility of improper use of the
product, failure to comply safety regulations and misuse.

4
6. Fitting instruction
Note! Do not use the walker when you notice any visible or perceptible damage.
Note! Follow the information contained in this manual while fitting and adjustment. Users
with severe pain in lower limb and reduced mobility may need help from a third person who
has appropriate skills.
•Unfasten circumferential straps as well as the inner liner and take the liner out.
•Put the inner liner on the leg in sitting position with leg slightly bent in knee joint. If
necessary, use included additional air pads. Fasten the inner liner, then put it into the
orthosis and fasten circumferential straps by means of Velcro.
•To adjust the angle of flexion, take out locking stops which are mounted in ROM
system on the left and right side of the orthosis. Set required angular value and lock
by placing the stops into appropriate openings for angular values.
oPlantar Flexion 0°, 15°, 30°, 45°
oDorsi Flexion 0°, 15°, 30°
o0° intermediate (neutral) position
•Check the correctness of fitting in standing position. If necessary adjust the force of
circumferential straps attachment
Size data (shoe size)
S 37-38 cm
M 39-43 cm
L 44-46 cm
7. Maintenance
•Circumferential straps and inner liner can be washed by hand or in washing machine
at temperature of 30oC. Do not tumble, chlorinate, iron, bleach, dry cleaning, use
tumble dryer.
•Ensure the Velcro is fastened in order not to damage the material.
•Dry at room temperature far from intensive heat source.
•Clean the PVC splint with damp cloth with soap.

5
•Dry the splint thoroughly.
Note! Lack of personal hygiene, usage of improper preservative and washing agents may
cause abrasions and other damage as well as increased perspiration and development of
bacterial flora.
8. Warranty information
All products distributed by our company are under a warranty, the terms of which are
described in the warranty card received at the time of purchase. Please, keep in mind that
for warranty purposes, the proof of purchase (receipt or invoice) should be retained.
As a user friendly company, we only supply products which have been thoroughly tested
with respect to materials, quality and functionality.
Please contact us if you have any questions concerning our servicing procedure.
9. Labels
Reference number Manufacturer
LOT number Manufacture date
Serial number
Representative in Euro-
pean Union
Note
Please read the
instruction
The Manufacturer checked for compliance with
essential medical devices requirements.
10. Recommended products
Products offered by Timago International Group include:
Orthoses and joint stabilizers
Manual and special-use wheelchairs
Walkers and rollators
Crutches and canes
Rehabilitation beds
Ancillary and sanitary equipment

6
Anti-decubitus equipment and accessories
Stabilizing and immobilizing belts
Electro-medical equipment
Disposable medical equipment
Our complete line of products is available from our distributors.
Learn more at: timago.com.
Manufacturer:
UNITED SURGICAL
Fort Wayne, IN 46803,
2235 Pensylvania St., USA
EMERGO EUROPE
Molenstraat 15, 2513 BH,
The Hague, Holandia
Issue I, date 03.08.2016
