TIME LED 781043 User manual

Installation and Operating Instructions
INS-781043-V2
Read and follow instructions before operating your LED Strip Light.
Save this manual for future reference.
Package includes:
1 x Ambient 5m LED IP20 RGB Soft Strip Light 24V
1 x Remote
1 x Manual
TIME LED is part of Pitacs Limited. For customer support contact:
Bradbourne Point, Bradbourne Drive, Tilbrook, Milton Keynes, Buckinghamshire MK7 8AT
T: [phone] F: [phone] E: [e-mail] W: www.timeled.co.uk
015
015
Ambient 5m LED IP20 RGB Soft Strip Light with Remote 24V
Safety:
• Installation of this luminaire should only be carried out by a qualied electrician or competent person to the current
building and IEE Wiring Regulations (BS7671).
• Before installation/maintenance, ensure that all mains supply to the luminaire is switched off and the circuit fuses are
removed or switched off.
• Check the total load on the circuit (including when this luminaire is tted) does not exceed the rating of the circuit
cable, fuse or circuit breaker.
• Please note the IP (Ingress of Protection) rating of this luminaire when deciding the location for installation.
• This product is IP20.

Product Code 781043
Size Length: 5 metres
Height: 2mm
Width: 10mm
Watts 7.2 W/m
Dimmable No
Cable Length 15cm
Lifespan 25000 Hours
Colour Temp RGB
Material FPC
IP Rating IP20
Voltage DC24V
Warranty 3 Years
controller
driver
1 2
3
controller
driver
1 2
3
controller
driver
1 2
3
1) Peel the backing off all strips to reveal the adhesive coating. Carefully secure the strip to the surface in the required
position.
2) Connect the LED strip to the IR Controller by carefully inserting the 4 pin connector into each female input, aligning
the arrows on each side. Connect the IR controller to an appropriate driver.

Remote Interface:
FLASH
W
ON
B
OFF
GR
STROBE
FADE
SMOOTH
Mode Settings
Power Off
Brightness
Adjustments
Red Hue Variations White Colour Temperature
Green Hue Variations Blue Hue Variations
Power On

Full Technical specification available upon request. Contact inf[email protected].uk for PDF.
Ambient 5m LED IP20 RGB Soft Strip Light
with Remote 24V
Cleaning:
• Do not use any chemical or abrasive cleaners.
• Clean product with a soft, dry cloth.
Warranty:
• This product is warranted to be free of defects in materials, design and workmanship for 3 years from the date of
purchase (conditions apply, please see TIME LED website for further details). If a suspected fault should develop in this
time, please contact us via the address on the front.
Recycling Advice:
Waste Electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check
with your local authority or retailer for recycling advice.
