TMG TMG-AJS03 User manual

PRODUCT MANUAL
v.2022.09.01
• Please read and understand the product manual completely before assembly
• Check against the parts list to make sure all parts are received
• Wear proper safety goggles or other protective gears while in assembly
• Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or have questions on assembly?
Please call: 1-877-761-2819 or email: [email protected]
TOLL FREE: 1-877-761-2819
WARNING
www.tmgindustrial.com
TMG-AJS03/06/12MODEL
3/6/12 TON
JACK STAND

www.tmgindustrial.com P1/3 TOLL FREE: 1-877-761-2819
TMG-AJS12
TMG-AJS06
TMG-AJS03 3 Ton
6 Ton
12 Ton
1. Study, understand, and follow all instructions before
operating this device.
2. Do not exceed rated capacity.
3. Use only on hard, level surfaces, with less than 3 degrees
of slope.
4. Center load on saddle.
5. Use as a matched pair only.
6. Stands are not to be used to simultaneously support both
ends of a vehicle.
7. No alterations shall be made to this product.
8. Support only on areas of the vehicle as specified by the
vehicle manufacturer.
9. Only attachments and/or adapters supplied by the
manufacturer shall be used.
10. Use wheel chocks or other blocking device on opposing
wheels before using jack stands.
11. Do not use jack stands for any use other than the
manufacturer specified usage.
12. Do not use if damaged in any way.
13. NEVER use jack stands on a lawn mower or lawn tractor.
14. Do not move or dolly the vehicle while on support stands.
15. Do not rock the vehicle while working on or around
equipment.
16. The following are not recommended for supporting on this
equipment: Foundations, Homes, Mobile Homes, Trailers,
RV’s, Campers, nor Fifth Wheels, etc...
17. Failure to heed these markings may result in personal
injury and/or property damage.
Some models may have screw rather
than a metal tab
Bend Metal
Tab In
OPERATION
N.W.
(kgs)
CapacityItem Min. Heigh
(mm) Max. Heigh (mm)
285
393
465 715 27.4
593 13.4
425 6.2
(Pairs)
SAFETY INSTRUCTIONS
SPECIFICATION
Put the jack stands on hard level ground
Adjust height by pulling up on ratchet.
Place load on the center of saddle for safety it is
strongly recommended that lifting means not be
removed while jack stands are supporting the
vehicle.
Secure ratchet by turning stopper to hold load.
Make sure stopper has been securely insertrd.
Release stopper and let ratchet glide down to the
lowest position when storing the jack stand.
Visual inspection shall be performed before each use
of the stand by checking abnormal condition, such as
cracked welds, leaks and damaged, loose, or ,missing
parts if srand is believed to have been subjected to
abnormal load or shock inspection shall be made by
authorized repair facility.
Equipment that appears damage or worn or operates
abnormally shall be removed from service until repair.
Repair should be made by authorized repair facility.
Annual inspection of the stand is recommended and
should be made by the manufacturer’s or supplier’s
authorized repair facility to ensure that you stand is
optimum conditions and that the stand has correct
decals and safety labels specified by the manufacturer.
PICTURE 1
If the operator is not fluent in English, the product
and safety instructions shall be read to and
discussed with the operator in the operator’s native
language by the purchaser/owner or his designee,
making sure that the operator comprehends their
contents.
Inspect before each use DO NOT USE IF BENT
BROKEN OR CRACKED COMPONENT ARE
NOTED. prevent corrosion. Clean as needed and
wipe with an oily cloth and keep in dry area when
not in use.
Read the instruction manual completely and keep it for
secure lifted loads with jack stands immediately
further information purpose .
Use wheel chocks
to secure the wheel
Stop the car
Use the jack stands
on even ground
Work under the vehicle
with jack stands

ASSEMBLY DIAGRAM
www.tmgindustrial.com P2/3 TOLL FREE: 1-877-761-2819
Ref.
Description Qty
1Ratchet bar
1
2Locking pawl
1
3Spring pin
Ø4x25mm
Spring pin
Ø4x25mm
Spring pin
Ø4x30mm
Spring pin
Ø4x30mm
1
4Locking handle
1
5Handle sleeve
1
6Base frame
1
TMG-AJS06
TMG-AJS03

ASSEMBLY DIAGRAM
www.tmgindustrial.com P3/3 TOLL FREE: 1-877-761-2819
Safe Operating Temperature is between 40°F – 105°F
(4°C - 41°C)
Ref. Description Qty
1Ratchet bar 1
2Locking pawl 1
3Spring pin Ø5x35mm 1
4Locking handle 1
5
Handle sleeve 1
6Base frame 1
7Hex head bolt M8x16mm 1
TMG-AJS12
