Toastmaster E9451-HP34CDN User manual

Foodservice Equipment
Job Item#
Toastmaster®10 Sunnen Dr. St. Louis, MO 63143• www.toastmastercorp.com
Toll Free: 1-800-264-7827 • Telephone: [phone] • Toll Free Fax: [phone] • Fax: [phone]
STANDARD FEATURES:
•Air baffle and circulation air
blower provide even heat
distribution
•Aluminum construction
•Set of 5” swivel casters
w/brakes
•Polycarbonate door
•Magnetic door gaskets
•Lift-off door
•Full length door handle
OPTIONAL FEATURES:
•Solid door
SIZE:
E9451-HP34CDN-
66-7/16” High, 22-13/16” Wide, 33-5/16” Deep
1688 mm High, 580 mm Wide, 847 mm Deep
Toastmaster’s E9451-HP34CDN -In locations
where cabinets will be used primarily for
holding with infrequent serving applications
(gauged by door openings) or in situations with
limited start-up budgets, the non-insulated
cabinet would satisfy most requirements. In
higher volume operations with more frequent
serving applications the insulated cabinet
would be the better choice as it delivers a
faster recovery and greater consistency of
temperature.
CONSTRUCTION:
•Aluminum construction
•Removable heating console
CONTROLS:
•Mechanical controls
•Indicator light for thermostat
•Separate heat and humidity controls
E9451-HP34CDN
Economy Heater / Proofer
LABORATORY CERTIFICATION AND APPROVAL

Toastmaster®10 Sunnen Dr. St. Louis, MO 63143• www.toastmastercorp.com
Toll Free: 1-800-264-7827 • Telephone: [phone] • Toll Free Fax: [phone] • Fax: [phone]
INTENDED FOR COMMERCIAL USE ONLY. NOT FOR HOUSEHOLD USE.
Toastmaster, in line with its policy to continually improve its product,
reserves the right to change materials or specifications without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements,
additions, or replacements for previously purchased equipment.
SPECIFICATIONS:
•120 Volt single phase is standard
SERVICE CONNECTIONS:
•Unit provided with 6 foot detachable cord and plug.
NEMA 5-20P
•Removable console consisting of blower,
three-way toggle switch, running lights to indicate
heater (holding) or proofing mode, stainless steel
water reservoir.
•Element controlled by 180 degrees thermostat.
1500 Watts in heating mode.
1500 Watts in proofing mode. DOOR SWING:
•Door swings 270 degrees to the recessed side
of the cabinet
PACKING SIZE:
72” High, 28” Wide, 40” Deep
(1828 mm High, 711 mm Wide, 1016 mm Deep)
SHIPPING WEIGHT:
140 Pounds, FOB Menominee, MI 49858
E9451-HP34CDN
Economy Heater / Proofer
DIMENSIONS:
Height Width Depth
Exterior 66-7/16” 22-13/16” 33-5/16”
Interior 51-3/4” 18-1/8” 27-1/2”
CAPACITY:
18”x26” Full Size13”x18” Half Size
Heater/ Sheet Pans Sheet Pans Spacing
Proofer 34 68 1-1/2”
Amp Draw120/1 208/3 240/1 240/3
14 n/a n/a n/a
ELECTRICAL:
INSTALLATION:
Allow four inches on each side and back of unit for
ventilation of heater/proofer.
335/16”
667/16”
3211/16”
2213/16”
SIDEFRONT
TOP
LISTINGS:
The E9451-HP34CDNF has C-ETL-US and NSF listings.
TM120/1060
