Tornatech VP series Manual

2018/10 1 VPX-MAN003-E REV3.DOCX3
INSTALLATION AND MAINTENANCE MANUAL FOR
ELECTRIC FIRE PUMP CONTROLLERS
MODEL VPx

2018/10 2 VPX-MAN003-E REV3.DOCX3

2018/10 3 VPX-MAN003-E REV3.DOCX3
Table of content
GENERAL DESCRIPTION ............................................................................................................................. 6
1. TYPES OF ELECTRIC FIRE PUMP CONTROLLERS........................................................................... 6
1.1. ACROSS-THE-LINE STARTER..................................................................................................... 6
1.1.1. Model VPA: .............................................................................................................................. 6
1.2. REDUCED VOLTAGE STARTER.................................................................................................. 6
1.2.1. Model VPR: AUTOTRANSFORMER STARTER...................................................................... 6
1.2.2. Model VPS: SOLID STATE STARTER..................................................................................... 6
2. METHODS OF STARTING / STOPPING............................................................................................... 7
2.1. methods of starting......................................................................................................................... 7
2.1.1. automatic start.......................................................................................................................... 7
2.1.2. manual start.............................................................................................................................. 7
2.1.3. remote manual start.................................................................................................................. 7
2.1.4. emergency start........................................................................................................................ 7
2.1.5. sequential start......................................................................................................................... 7
2.1.6. weekly start .............................................................................................................................. 7
2.2. methods of stopping....................................................................................................................... 7
2.2.1. manual stop.............................................................................................................................. 7
2.2.2. automatic stop.......................................................................................................................... 7
2.2.3. emergency stop........................................................................................................................ 7
3. variable speed pressure limiting control ................................................................................................. 8
3.1. General.......................................................................................................................................... 8
3.2. VARIABLE speed MODE............................................................................................................... 8
3.3. Preset speed mode........................................................................................................................ 8
3.4. bypass mode.................................................................................................................................. 8
3.5. STOP PUSH BUTTONS................................................................................................................ 8
4. front panel .............................................................................................................................................. 9
4.1. generals......................................................................................................................................... 9
4.2. PRS DISPLAY ............................................................................................................................... 9
4.3. PRS ANNUNCIATORs................................................................................................................... 9
4.3.1. POWER AVAILABLE................................................................................................................ 9
4.3.2. SYSTEM Trouble...................................................................................................................... 9
4.3.3. PHASE REVERSAL................................................................................................................. 9
4.3.4. Low system pressure...............................................................................................................10
4.4. Flange annunciators......................................................................................................................10
4.4.1. BYPASS MODE ......................................................................................................................10
4.4.2. VFD FAILURE.........................................................................................................................10
4.5. Audible alarm................................................................................................................................10
5. alarm contacts.......................................................................................................................................11
6. INSTALLATION.....................................................................................................................................12
7. LOCATION............................................................................................................................................12
8. Mounting................................................................................................................................................12
8.1. wall mounting................................................................................................................................12
8.2. floor mounting...............................................................................................................................12
9. connections...........................................................................................................................................13
9.1. WATER CONNECTIONS..............................................................................................................13
9.2. ELECTRICAL CONNECTIONS ....................................................................................................13
9.2.1. ELECTRICAL WIRING............................................................................................................13
9.2.2. enclosure drilling......................................................................................................................13
9.2.3. INCOMING POWER CONNECTIONS ....................................................................................13
9.2.4. MOTOR CONNECTIONS........................................................................................................13
9.2.5. alarm contact connection.........................................................................................................13

2018/10 4 VPX-MAN003-E REV3.DOCX3
9.2.6. connection to external device..................................................................................................14
10. START-UP AND TEST PROCEDURES................................................................................................15
10.1. VeRIFICATIONS...........................................................................................................................15
10.1.1. ELECTRICAL INSTALLATION................................................................................................15
10.1.2. PIPING INSTALLATION..........................................................................................................15
10.2. SETTINGS on the electronic boards.............................................................................................16
10.3. DIPSWITCH..................................................................................................................................16
10.3.1. PHASE REVERSAL (Ph Rev).................................................................................................16
10.3.2. RUN PERIOD TIMER (RPT) ...................................................................................................16
10.3.3. SEQUENTIAL START TIMER (Seq Timer).............................................................................16
10.3.4. TEST (Test).............................................................................................................................16
10.3.5. PRESSURE UNIT (Pr Unit).....................................................................................................16
10.3.6. SERIAL (Serial).......................................................................................................................16
10.4. PRS...............................................................................................................................................17
10.4.1. pressure adjustment................................................................................................................17
10.5. SETTINGS on the sequential module (SM1) ................................................................................17
10.6. Timers...........................................................................................................................................17
10.6.1. T1 : Sequential start timer .......................................................................................................17
10.6.2. T2 : minimum run period timer.................................................................................................17
11. Variable speed drive (VFD) settings......................................................................................................18
11.1. NON-critical parameters................................................................................................................18
11.1.1. VFD power up / shutdown.......................................................................................................18
11.1.2. minimum speed.......................................................................................................................18
11.1.3. PRESET speed .......................................................................................................................18
11.1.4. Pressure SETPOINT...............................................................................................................19
11.1.5. gain..........................................................................................................................................19
11.1.6. INTEGRAL TIME.....................................................................................................................19
12. ACTUAL START-UP .............................................................................................................................20
12.1. CHECK MOTOR ROTATION........................................................................................................20
12.2. CHECK WRONG PHASE ROTATION INDICATION....................................................................20
13. PUMP START TEST.............................................................................................................................21
13.1. START FROM START PUSHBUTTON PB1.................................................................................21
13.2. START FROM REMOTE START STATION .................................................................................21
13.3. WATER PRESSURE CONTROL..................................................................................................21
13.3.1. MANUAL SHUTDOWN MODE................................................................................................21
13.3.2. AUTOMATIC SHUTDOWN MODE..........................................................................................22
13.4. START FROM EMERGENCY START HANDLE ..........................................................................22
14. Sequential module Programming instructions.......................................................................................23
14.1. How to adjust date ........................................................................................................................23
14.2. how to program a weekly test .......................................................................................................23
14.3. How to set SM1 in run mode.........................................................................................................24
14.4. How to set run period timer...........................................................................................................24
14.5. How to set SEQUENTIAL START timer........................................................................................24
15. PRS99 Programming instructions..........................................................................................................25
15.1. How to read the display.................................................................................................................25
15.1.1. Top Line ..................................................................................................................................25
15.1.2. SECOND LINE........................................................................................................................25
15.1.3. THIRD LINE ............................................................................................................................25
15.1.4. FOURTH LINE.........................................................................................................................25
15.2. How to adjust the cut in / cut out pressure....................................................................................25
15.3. What is the flashing symbol on the second line ............................................................................26
15.4. Why 'Low System Pressure' LED is flashing.................................................................................26
15.5. How to adjust the date and time....................................................................................................26
15.6. How to print reports.......................................................................................................................27
15.7. How to replace the paper..............................................................................................................28

2018/10 5 VPX-MAN003-E REV3.DOCX3
15.8. How to replace the ribbon.............................................................................................................28
15.9. How TO RETRIEVE PRESSURE DATA’S FROM RS232 PORT .................................................28
15.10. preventive and maintenance test ..................................................................................................31
15.11. VISUAL INSPECTION ..................................................................................................................31
15.12. OPERATIONAL INSPECTION......................................................................................................31

2018/10 6 VPX-MAN003-E REV3.DOCX3
GENERAL DESCRIPTION
Model VPx electric fire pump controllers are
designed to automatically start an electric
driven fire pump upon detection of a
pressure drop in the fire protection system. It
is intended to control 3-phase squirrel cage
induction motors and is arranged for
electrical or manual starting and stopping
and for automatic start, controlled by the
pressure sensor. The combination
automatic/non-automatic option provides a
10-minute automatic stop after automatic
start but only after all starting causes have
returned to normal
1. TYPES OF ELECTRIC FIRE PUMP CONTROLLERS
FIRE PUMP CATALOGUE NUMBER
MODEL n° EXAMPLE: VPA-208 / 50 / 3 / 60
VPA
208
50
3
60
Model prefix
Voltage
HP rating
Phase
Frequency
1.1.ACROSS-THE-LINE
STARTER
1.1.1.MODEL VPA:
This model is intended to be used where the
local utility or the capacity of the power
source permits across-the-line starting.
Upon a start command, the controller
connects the variable speed frequency drive
to the motor. The motor ramps up and
adjusts its speed. When the variable speed
drive is bypassed, full voltage is applied to
the motor as soon as the controller receives
a start command.
1.2.REDUCED VOLTAGE
STARTER
These models are intended to be used
where the local utility or the capacity of the
power source does not permit full voltage
starting.
1.2.1.MODEL VPR:
AUTOTRANSFORMER
STARTER
The manual “EMERGENCY RUN” device
will initiate across-the-line starting.
Upon a start command, the controller
connects the variable speed frequency drive
to the motor. The motor ramps up and
adjusts its speed. With any starting method,
and when the variable speed drive is
bypassed, an autotransformer is used to
start the motor at reduced voltage. After a
time delay, the autotransformer is shunted
out and the motor is connected to full
voltage by a closed transition switching
sequence.
1.2.2.MODEL VPS: SOLID
STATE STARTER
The manual “EMERGENCY RUN” device
will initiate across-the-line starting.
Upon a start command, the controller
connects the variable speed frequency drive
to the motor. The motor ramps up and
adjusts its speed.
With any starting method, and when the
variable speed drive is bypassed, a soft
starter is used to supply a ramp-up voltage
to the motor until the motor reaches its full
speed. If the soft starter fails, an across-the-
line starting will be initiated.

2018/10 7 VPX-MAN003-E REV3.DOCX3
2. METHODS OF STARTING / STOPPING
The controllers are available as combination automatic / non-automatic with provision for manual
or automatic shutdown (automatic shutdown only possible after automatic start)
2.1.METHODS OF STARTING
2.1.1.AUTOMATIC START
The controller will start automatically on low
pressure detection by the pressure sensor
when pressure drops below cut-in threshold.
The controller must be in automatic mode
(Remove jumper IJ2 to disable automatic
start).
2.1.2.MANUAL START
The motor can be started by depressing the
START push button whatever the system
pressure.
2.1.3.REMOTE MANUAL
START
The motor can be started from a remote
location by momentarily closing a contact of
a manual push button.
2.1.4.EMERGENCY START
The motor can be started manually by using
the emergency handle. This handle can be
maintained in a closed position.
Important: to avoid damaging the contactor,
it is recommended to start the motor in the
manor:
1) shutdown the main power by using
the main disconnect means,
2) pull the emergency handle and lock
it in closed position,
3) turn the power back on by using the
main disconnect means.
2.1.5.SEQUENTIAL START
In case of multiple pump application, it may
be necessary to delay the starting of each
motor in case of water pressure drop to
prevent simultaneous starting of all motors.
2.1.6.WEEKLY START
The motor can be started (and stopped)
automatically at the preprogrammed time.
2.2.METHODS OF STOPPING
2.2.1.MANUAL STOP
Manual stop is done by depressing the
INSTANT STOP or DELAYED STOP push
button.
Note : All start conditions must be
disappeared to stop the pump.
2.2.2.AUTOMATIC STOP
The automatic stop is possible only after an
automatic start, and this function must be
activated. When this function is enabled,
the motor is automatically stopped 10
minutes (factory setting) after the restoration
of the pressure (above the cut-out
threshold).
2.2.3.EMERGENCY STOP
The emergency stop is always possible in
any starting conditions and is done by using
the main disconnecting means located on
the door.

2018/10 8 VPX-MAN003-E REV3.DOCX3
3. VARIABLE SPEED PRESSURE LIMITING CONTROL
3.1.GENERAL
The variable speed pressure limiting control
is enabled if the speed selector switch is in
‘VARIABLE’ or ‘PRESET’position.
While in ‘VARIABLE’ position, the motor
speed varies depending of the pump flow in
order to maintain the pressure at constant
value.
While in ‘PRESET’ position, the motor runs
at a predetermined constant speed.
The variable speed pressure limiting control
is disabled either if the speed selector switch
is in ‘BYPASS’ mode, either if the
emergency start handle is used to start the
motor, or if the variable speed pressure
limiting system failed. In those cases, the
motor is directly connected to the main
power source and motor runs at its
maximum speed.
The speed selector switch is located behind
a breakable and lockable window.
3.2.VARIABLE SPEED MODE
This mode is the normal mode of the
controller and permits the system to work at
its full capability.
The speed selector switch must be in
‘VARIABLE’position. Upon a start demand
(pressure drops below the PRS pressure
threshold, manual start, remote start), the
variable speed drive is energized and the
motor speed ramps up to its minimal speed
in several seconds. Then, the motor speed
is automatically adjusted depending of the
system pressure.
This mode is automatically replaced by the
bypass mode if failure occurs in the variable
speed drive path or if emergency handle is
activated or if the pressure stays below the
PRS pressure threshold for more than 15
seconds.
3.3.PRESET SPEED MODE
In this mode, the speed of the motor is
constant
The speed selector switch must be in
‘PRESET’ position. Upon a start demand
(pressure drops below the PSR threshold,
manual start, remote start), the variable
speed drive is energized and the motor
speed ramps up to the predetermined speed
in several seconds. The speed is constant
and is independent of the system pressure.
This mode is automatically replaced by the
bypass mode if failure occurs in the variable
speed drive path or if emergency handle is
activated.
3.4.BYPASS MODE
This mode is activated when the speed
selector switch is in ‘BYPASS’ position.
Upon a start demand (pressure drops below
the PSR threshold, manual start, remote
start), the variable speed drive is
disconnected and the bypass contactor is
activated to connect the motor to the main
power supply.
This mode is also activated, even if the
selector switch is in variable or preset
position in case of drive failure or
emergency start.
3.5.STOP PUSH BUTTONS
In ‘VARIABLE’or ‘PRESET’ position the
motor stop can be progressive by
depressing the DELAYED STOP push
button. It can be instantaneous too, by
depressing the INSTANT STOP push
button.
Note : In BYPASS mode , the motor can
only be stopped instantaneously, no matter
what push button is used. All start conditions
must be disappeared to stop the pump.

2018/10 9 VPX-MAN003-E REV3.DOCX3
4. FRONT PANEL
4.1.GENERALS
A display located on the left side is used to
monitor the electrical parameters of the
incoming power and to set the automatic
start pressure threshold. See PRS display
and PRS annunciators. Some others
annunciators are located on the flange of the
controller.
4.2.PRS DISPLAY
The first line shows the power source status.
The three line-to-line voltages and the
frequency of the normal source are
displayed. The last two digits are reserved
to write a status symbol.
The status symbol "W" indicates the source
is in wrong phase sequence.
The status symbol "n" indicates the source
is not acceptable. This non-acceptability
occurs when :
any line voltage drops below 85%,
the frequency is too high or too low,
an unbalance occurs between the three
phases.
The third line is dedicated for the motor and
trouble status. When no trouble, the three
line currents are shown followed by the
elapse time meter of the motor. The elapse
time meter is expressed in hours and tenths
of hours.
If trouble occurs, the two last digits of the
elapse time meter are replaced by a status
symbol. The symbol can be :
P for Pump starting failure (see below)
O for Overcurrent problem (see below)
U for Undercurrent (see below)
T for Transducer problem (see below)
The fourth line is dedicated for the pressure
system status. The first section shows the
cut-out threshold, the second section shows
the cut-in threshold, the third section shows
the system pressure.
'O' means cut-Out which is the value where
the pump has to stop,
'I' means cut-In which is the value where the
pump has to start.
Those values are adjustable on the field by
removing the adjustment cover plate with a
Philips screwdriver. When removed, it is
possible to have access to small switch. The
pressure unit (PSI or kPa) can be selected
on the field.
4.3.PRS ANNUNCIATORS
4.3.1.POWER AVAILABLE
This LED indicates power acceptable on all
3 phases and phase sequence is correct for
the power source.
4.3.2.SYSTEM TROUBLE
This LED indicates unexpected situation
occurring. This LED is flashing and a
flashing symbol appears on the last digit of
the third line. To help the user, the trouble
legend is written on the display (See
troubleshooting hint).
oPfor pump starting failure. This trouble
occurs when the low system pressure
is detected but the current did not
reach 10% of the nominal current after
20 seconds.
oOindicates an over current. This
trouble occurs when the current is over
130% of the nominal current for more
than 20 seconds.
oUindicates an undercurrent. This
trouble occurs when the detected
current is under 30% of the nominal
current for more than 20 seconds.
oTindicates a pressure transducer
problem (PT1 only).
This can occur if :
- the pressure transducer is not
connected (atmospheric pressure)
- the transducer does not send a
correct signal
- a wire to the transducer is cut.
The last trouble is recorded and displayed.
To clear the symbol and the LED, the Reset
Push button must be depressed.
Note : this LED is not activated under drive
failure condition.
4.3.3.PHASE REVERSAL
This LED indicates phase reversal of the
power source.

2018/10 10 VPX-MAN003-E REV3.DOCX3
4.3.4.LOW SYSTEM
PRESSURE
This LED indicates that pressure drops
below the lowest threshold.
4.4.FLANGE
ANNUNCIATORS
4.4.1.BYPASS MODE
This pilot light indicates when the selector
switch is in bypass mode or when the
bypass contactor is activated.
4.4.2.VFD FAILURE
This pilot light indicates when the drive
failed. This pilot light is reset if the VFD is
reset. To reset the VFD failure, press the
Reset/Silence push button.
A drive failure is initiated by one of the
following conditions :
If the variable speed drive fails for
overload, over-temperature, or other
internal failure;
Within the first 30 seconds of powering
on the controller;
If the variable speed drive is not in
‘ready’ condition in the first 5 seconds
after power up;
If the system pressure has not been
recovered after 15 seconds;
4.5.AUDIBLE ALARM
The audible alarm is triggered when the
bypass mode light or when the VFD failure
light is activated. The alarm can be silenced
by the SILENCE push button. If the alarm is
present more than 24 hours, the audible
alarm will restart sounding.
The audible alarm is also activated when
sequential module is in STOP mode. In this
case, there is no possibility of silencing the
buzzer. The sequential module must be
restarted in RUN mode.

2018/10 11 VPX-MAN003-E REV3.DOCX3
5. ALARM CONTACTS
The following alarm contacts are available
on all controllers:
-motor run
-power available (loss of phase)
-phase reversal
-motor trouble
-bypass mode
-VFD failure

2018/10 12 VPX-MAN003-E REV3.DOCX3
6. INSTALLATION
The VPx electric fire pump controller is listed
cULus and is intended to be installed in
accordance with the Standard of the
National Fire Protection Association for the
Installation of Centrifugal Fire Pumps, NFPA
n°20-2007 (Centrifugal Fire Pumps) and
in USA
National Electrical Code NFPA 70
in Canada
Canadian Electrical Code, Part 1
others *
Local Electrical Codes *
Only American and Canadian applicable codes have been considered during the
design of the controllers and the selection of components.
7. LOCATION
Controller shall be located as close as
practical to the motor it controls and shall be
within sight of the motor.
Controller shall be so located or so
protected that it will not be damaged by
water escaping from pump or pump
connections.
Working clearances around controller shall
comply with NFPA 70, National Electrical
Code, Article 110 or C22.1, Canadian
Electrical Code, Article 26.302 or other local
codes.
Controller shall be suitable for use in
locations subject to a moderate degree of
moisture, such as a damp basement. The
pump room ambient temperature shall be
between 41°F (5°C) and 104°F (40°C).
The standard controller enclosure is rated
NEMA 2. It is the installer’s responsibility to
assure that either the standard enclosure
meets the ambient conditions or that an
enclosure with an appropriate rating has
been provided.
Controllers shall be located in a building;
they are not designed for outside location.
The paint color may change if controller is
exposed to Ultraviolet rays during long
period of time.
8. MOUNTING
8.1.WALL MOUNTING
The fire pump controller shall be mounted in
a substantial manner on a single
noncombustible supporting structure.
Wall mounted controller shall be attached to
the structure or wall using all mounting ears
provided on the controller with hardware
designed to support the weight of the
controller at a height not less than 12 in.
above floor level.
8.2.FLOOR MOUNTING
Floor mounted controller shall be attached to
the floor using all holes provided on the
mounting brackets with hardware designed
to support the weight of the controller. A
concrete slab is recommended to avoid
water accumulation on the controller’s feet.

2018/10 13 VPX-MAN003-E REV3.DOCX3
9. CONNECTIONS
9.1.WATER CONNECTIONS
The pipe connection for the pressure sensor
is 1/2”. The pressure sensor connection is
located on the side of the controller.
The pump start - stop pressure sensor shall
be connected to the system as per NFPA
20-2007, Chapter 10-5.2.1.6 (b) and (c) and
figure A-10-5.2.1 (a) and (b).
9.2.ELECTRICAL
CONNECTIONS
9.2.1.ELECTRICAL WIRING
The electrical wiring between the power
source and the fire pump controller shall
meet the NFPA 20-2007, Chapter 9-3,
NFPA 70 National Electrical Code Article
695 or C22.1 Canadian Electrical Code,
Section 32-200 or other local codes.
Electrical wiring shall be typically sized to
carry at least 125% of the full load current of
the fire pump motor.
Incoming power terminals on the controller
are suitable to accept wire based on that
selection with insulation not less than 60°C.
(Refer to terminal diagram for terminal
sizes.)
The electrical wiring between the fire pump
controller and the pump motor shall be in
rigid, intermediate, or liquid tight flexible
metal conduit or Type MI cable and meet the
requirements of NFPA 70 National Electrical
Code or C22.1 Canadian Electrical Code or
other local codes.
The number of conductors required varies
depending on the model of starter:
3-wires plus ground sized at 125%
of full load current for models VPA,
VPR, VPS.
9.2.2.ENCLOSURE DRILLING
The dimension drawings show the area
suitable for incoming power and motor
connections. No other location shall be
used. Only watertight hub fittings shall be
used when entering the cabinet to preserve
the NEMA rating of the cabinet.
The installer is responsible for adequate
protection of fire pump controller
components against metallic debris or
drilling chips. Failure to do so may cause
injuries to personnel, damage the controller
and subsequently void warranty.
9.2.3.INCOMING POWER
CONNECTIONS
Incoming normal power is to be connected
to terminals identified L1-L2 and L3 located
on the disconnecting means IS.
The electronic board is phase sensitive, thus
the incoming power leads must be
connected in the correct phase order.
9.2.4.MOTOR CONNECTIONS
Motor connections are connected to
terminals identified by:
-T1-T2 and T3 located on main
contactor (1R) for models VPA,
VPR, VPS
It is the responsibility of the installer to
obtain connection information on the motor
and to assure that the motor is connected as
per motor manufacturer recommendations.
Failure to do so may cause injuries to
personnel, damage the motor and/or the
controller and subsequently void warranty
on both items.
9.2.5.ALARM CONTACT
CONNECTION
Since these alarm connections are derived
from control relays or motor contactor
auxiliary contacts located inside a metallic
enclosure with wiring that can pick up
induction from the line voltage, an induced
voltage can be present at the terminal
connections. It is the responsibility of the
alarm contractor to evaluate the potential
danger for their equipment. A remote alarm
panel Type APE with interface relays may
be required if induced voltages cause
problems to electronic equipment.
(NOTE: This induction problem is more likely
to occur in 600 V. models.)

2018/10 14 VPX-MAN003-E REV3.DOCX3
9.2.6.CONNECTION TO
EXTERNAL DEVICE
REMOTE MANUAL START SIGNAL
Each electric fire pump controller has
provision for connection to a manual remote
start station (manually operated). This
remote start contact must be normally open.
Change of state of this contact will initiate a
manual start of the pump.

2018/10 15 VPX-MAN003-E REV3.DOCX3
10. START-UP AND TEST PROCEDURES
DANGER
HAZARDOUS VOLTAGE IS PRESENT IN THE
ENCLOSURE WHICH WILL CAUSE SEVERE
PERSONAL INJURY OR DEATH.
MAINTENANCE OR START UP SHOULD BE
PERFORMED ONLY BY EXPERIENCED LICENSED
ELECTRICIANS.
ONLY QUALIFIED PERSONNEL SHOULD WORK
ON OR AROUND THIS EQUIPMENT.
10.1. VERIFICATIONS
10.1.1. ELECTRICAL
INSTALLATION
A representative for the electrical contractor
responsible for the installation shall be
available on-site to assist during the
verification of the following points and the
actual start-up.
All electrical label ratings meet incoming
power voltage and frequency as well as
motor voltage, HP and frequency.
All electrical connections in controller are
tight. Retighten if necessary.
All electrical connections are properly
completed and power is available.
10.1.2. PIPING
INSTALLATION
A representative for the sprinkler contractor
responsible for the installation shall be
available on-site to assist during the
verification of the following points and the
actual start-up.
All water connections are properly
completed; water is available and free of dirt
and/or contamination.
NOTE: Standard controllers have pressure
sensor rated for fresh water only. If other
conditions exist, make sure that the
controller pressure sensor is compatible.
WARNING
Water lines must be flushed before
connecting pressure switch or pressure
transducer. Failure to do so will void
warranty.

2018/10 16 VPX-MAN003-E REV3.DOCX3
10.2. SETTINGS ON THE ELECTRONIC BOARDS
ATS99 is the name of the internal circuit board located on the controller (left side).
PRS99 is the name of the electronic circuit board located on the controller door (left side)
Sequencial module (SM1) is the name of the control unit located on the controller (left side)
10.3. DIPSWITCH
Required
N/A
The Dipswitch S2 is located on the middle top of the electronic board.
Select the appropriate dipswitch for the setting that needs to be changed.
Use a small screwdriver or a pencil to change the position of the dipswitch.
The factory setting is shown in figure 1.
10.3.1. PHASE REVERSAL (PH REV)
The S2-1 dip switch is used to change the reference phase sequence (see
page 19 –“Check wrong phase rotation indication”).
10.3.2. RUN PERIOD TIMER (RPT)
The S2-2 dip switch must be set to the left. The run period timer is set in the
sequential module (SM1) if necessary.
10.3.3. SEQUENTIAL START TIMER (SEQ TIMER)
The S2-3 & S2-4 dip switches must be set to the left. Sequential start timer
is set in the sequential module (SM1) if necessary.
10.3.4. TEST (TEST)
This Dip switch (S2-5) is used by factory and must be set to the left.
10.3.5. PRESSURE UNIT (PR UNIT)
The S2-6 dipswitch is set to the right if PSI is required as pressure unit.
The S2-6 dipswitch is set to the left if kPa (kilo Pascal) is required as
pressure unit.
10.3.6. SERIAL (SERIAL)
The S2-7 and S2-8 dipswitches are used by factory. S2-7 must be set to
the left, S2-8 must be set to the right.
Ph Rev
RPT
Seq
Timer
Test
Pr Unit
Serial
Figure 1

2018/10 17 VPX-MAN003-E REV3.DOCX3
10.4. PRS
Required
N/A
DANGER.
Hazardous
voltage is
present in the
enclosure and
will cause
severe
personal
injury or
cause death
10.4.1. PRESSURE ADJUSTMENT
Set the cut-out and cut-in threshold on the PRS board. It is recommended
to set the cut-out threshold 5 psi above the cut-in threshold. If the cut-out
threshold is set above the maximum pump pressure, it is impossible to stop
the pump with ‘stop’ push button.
10.5. SETTINGS ON THE SEQUENTIAL MODULE (SM1)
The chapter 15 provides the instructions to adjust the Sequential module parameters.
The adjustments can only be done when the power is on and the door is open.
DANGER : Hazardous voltage is present
in the enclosure and will cause severe
personal injury or cause death.
10.6. TIMERS
Requis
N/D
10.6.1. T1 : SEQUENTIAL START TIMER
The sequential start can be adjusted with T1 timer. The value is in seconds.
(ex : 002.5 = 2 sec ½).
10.6.2. T2 : MINIMUM RUN PERIOD TIMER
The minimum run period timer can be adjusted with T2 timer. The value is
in minutes and seconds ( ex : 12 :30 = 12 minutes 30 seconds). Timer is
set at 10 minutes by factory.

2018/10 18 VPX-MAN003-E REV3.DOCX3
11. VARIABLE SPEED DRIVE (VFD) SETTINGS
11.1. NON-CRITICAL PARAMETERS
Required
N/A
The Variable speed drive (VFD) is factory set to start the system. Some
adjustments must be done on the field to improve the performance of the
system.
A list of all VFD parameters is attached on the inside of the enclosure.
The non-critical parameters can be adjusted on the field by the Tornatech
technician. Critical parameters shall not be changed.
11.1.1. VFD POWER UP / SHUTDOWN
On the sequential module (SM1), press any gray key to energize the VFD.
Note, the VFD will be automatically de-energized after 15 minutes. The
VFD can also be shut down before the expiration of the 15 minutes delay
by depressing a second time any gray key on SM1.
11.1.2. MINIMUM SPEED
To adjust the minimum speed,
- start the controller with manual start push button - main
switch in ‘preset’ position,
- create a very small water flow (almost 0 gpm flow) by
opening a valve,- shutdown jockey pump.
- select on VFD the “Minimum Speed” parameter and adjust
it until the pressure is at requested value.
11.1.3. PRESET SPEED
The preset speed is expressed in percentage of motor speed.
To adjust the preset speed,
- start the controller with manual start push button - main
switch in ‘preset’ position,
- select on VFD parameter “Fixed speed setpoint” and adjust
it until the preset speed is at requested value.
Note : preset speed must be greater than minimum speed.

2018/10 19 VPX-MAN003-E REV3.DOCX3
11.1.4. PRESSURE SETPOINT
The pressure setpoint is expressed in percentage of 300 psi. To adjust the
pressure setpoint,
- start the controller with manual start push button - main
switch in ‘variable’ position,
- create a flow demand by opening a valve,- shutdown
jockey pump.
- select on VFD parameter “Technology controller fixed
value” and adjust it until the pressure is at requested value.
Important : the pressure may stabilize after several
seconds (or minutes) - this stabilization time is set by gain
and integral parameter - see below.
11.1.5. GAIN
The gain is parameter “Proportional gain setting”. By incrementing the
value, the drive will react faster due to a flow change in order to maintain
the pressure at constant level. By decrementing this value, the drive will
react slowly.
It is recommended to start by a low value and increase the value slowly (by
step of 0.2) in order to have a decent speed change when changing the
flow.
11.1.6. INTEGRAL TIME
The integral time is parameter “Integral time setting”. By incrementing the
value, the drive will adjust the speed to stabilize the pressure at its
requested value but it will also reduce time of reaction.
It is recommended to start by a low value and increase the value slowly (by
step of 0.2) in order to have a decent speed change when changing the
flow.

2018/10 20 VPX-MAN003-E REV3.DOCX3
12. ACTUAL START-UP
12.1. CHECK MOTOR ROTATION
Required
N/A
DANGER.
Hazardous
voltage is
present in the
enclosure and
will cause
severe
personal injury
or cause
death.
Only
experienced
licensed
electricians
should
perform start
up.
Only qualified
personnel
should work
on or around
this
equipment.
Turn the speed selector switch to BYPASS position
Note : the buzzer will sound when the controller will be powered
up. The buzzer can be silenced by depressing silence push button
Turn circuit breaker handle to the ON position.
If the system pressure is above the cut out pressure setting
(pressurized system), the motor will not start right away. If motor
does not start, press the START pushbutton.
Turn the circuit breaker handle to the OFF position as soon as motor
starts to stop motor.
Check the motor rotation.
If the motor rotation is correct, no further adjustment is required,
move to the next section.
Correct the motor rotation.
Motor rotation can be changed by swapping any two motor wires
either at the motor junction box or on the motor connection
terminals inside the controller. In both cases, the operator shall
assure that the power is disconnected before proceeding. NOTE :
Under no circumstances shall the internal wiring of the controller be
tampered with. Failure to comply will void warranty, may cause
injuries and damage the controller. Only the wires directly feeding
the motor can be reversed.
Turn circuit breaker handle to the ON position.
Check the motor rotation once more.
12.2. CHECK WRONG PHASE ROTATION
INDICATION
Requir ed
N/A
Turn circuit breaker handle to the ON position.
If the display does not show a 'W' symbol on the right side of the
first line, feeders are in the right phase sequence. No further
adjustment is required, move to the next section.
If the display shows a 'W' symbol on the right side of the first line,
feeders and electronic module do not have the same sequence
and the electronic needs to be adjusted.
-Turn circuit breaker handle to the OFF position.
-Open control panel door.
-Locate the S2 dipswitch on the middle top of the electronic
board.
-With a small screwdriver or pencil, change S2-1 (Ph rev)
dipswitch from left to right.
-Close controller panel door.
-Turn circuit breaker to the ON position.
Verify that display does not show 'W' symbol on the first line. No further
adjustment is required.
