Toro 22602THD User manual

FormNo.3373-148RevB
SGR-13StumpGrinder
ModelNo.22602THD—SerialNo.311000701andUp
ModelNo.22611—SerialNo.311000001andUp
ModelNo.22611G—SerialNo.311000001andUp
ModelNo.32611—SerialNo.312000001andUp
ToregisteryourproductordownloadanOperator'sManualorPartsCatalogatnocharge,gotowww.Toro.com.OriginalInstructions(EN)
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

WARNING
CALIFORNIA
Proposition65Warning
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
DANGER
Theremaybeburiedpower,gas,and/ortelephone
linesintheworkarea.Shockorexplosionmay
occurifyoudigintothem.
Havethepropertyorworkareamarkedforburied
linesanddonotdiginmarkedareas.Contactyour
localmarkingserviceorutilitycompanytohavethe
propertymarked(forexample,intheUnitedStates,
call811forthenationwidemarkingservice).
ThissparkignitionsystemcomplieswithCanadianICES-002.
Becauseinsomeareastherearelocal,state,orfederal
regulationsrequiringthatasparkarresterbeusedonthe
engineofthismachine,asparkarresterisavailableas
anoption.Ifyourequireasparkarrestor,contactyour
AuthorizedToroServiceDealer.
GenuineTorosparkarrestersareapprovedbytheUSDA
ForestryService.
Important:ItisaviolationofCaliforniaPublic
ResourceCodeSection4442touseoroperatetheengine
onanyforest-covered,brush-covered,orgrass-covered
landwithoutasparkarrestermufermaintainedin
workingorder,ortheengineconstricted,equipped,and
maintainedforthepreventionofre.Otherstatesor
federalareasmayhavesimilarlaws.
Theenclosed
EngineOwner'sManual issuppliedfor
informationregardingtheUSEnvironmentalProtection
Agency(EPA)andtheCaliforniaEmissionControl
Regulationofemissionsystems,maintenance,and
warranty.Replacementsmaybeorderedthroughthe
enginemanufacturer.
Introduction
Thismachineisdesignedtogrindandremovetreestumps
andsurfaceroots.Itisnotintendedtocutrockoranyother
materialotherthanwoodandthesoilaroundastump.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comforproduct
andaccessoryinformation,helpndingadealer,ortoregister
yourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Figure1illustratesthelocationofthe
modelandserialnumbersontheproduct.Writethenumbers
inthespaceprovided.
Figure1
1.Modelandserialnumberplate
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
©2012—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
2
Contactusatwww.Toro.com.
PrintedintheUSA.
AllRightsReserved
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

Figure2
1.Safetyalertsymbol
Thismanualuses2otherwordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
Contents
Introduction..................................................................2
Safety...........................................................................3
SafeOperatingPractices...........................................3
SafetyandInstructionalDecals.................................5
ProductOverview..........................................................6
Controls................................................................6
Specications.........................................................7
Attachments/Accessories.........................................7
Operation.....................................................................8
BeforeyouStart......................................................8
AddingFuel............................................................8
CheckingtheEngineOilLevel..................................9
StartingandStoppingtheEngine..............................10
GrindingaStump...................................................10
Maintenance.................................................................12
RecommendedMaintenanceSchedule(s)......................12
Lubrication...............................................................12
GreasingtheMachine.............................................12
EngineMaintenance..................................................13
ServicingtheAirCleaner.........................................13
ServicingtheEngineOil..........................................14
ServicingtheSparkPlug..........................................14
BrakeMaintenance....................................................15
AdjustingtheParkingBrake.....................................15
BeltMaintenance......................................................16
AdjustingtheDriveBeltTension..............................16
ReplacingtheDriveBelt..........................................16
GrinderMaintenance..................................................17
CheckingtheCuttingWheelBlades...........................17
ReplacingtheCuttingWheelBlades..........................17
Cleaning...................................................................18
RemovingDebrisfromtheMachine..........................18
Storage........................................................................18
............................................................................18
Troubleshooting...........................................................19
Safety
Improperuseormaintenancebytheoperatororowner
canresultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafetyalertsymbol
,which
means:
Caution , Warning ,or Danger —personalsafety
instruction.Failuretocomplywiththeinstructionmay
resultinpersonalinjuryordeath.
SafeOperatingPractices
Thisproductiscapableofamputatinghandsandfeet.Always
followallsafetyinstructionstoavoidseriousinjuryordeath.
WARNING
Engineexhaustcontainscarbonmonoxide,an
odorless,deadlypoisonthatcankillyou.
Donotruntheengineindoorsorinanenclosed
area.
Training
•ReadtheOperator'sManualandothertrainingmaterial.If
theoperator(s)ormechanic(s)cannotreadEnglish,itis
theowner'sresponsibilitytoexplainthismaterialtothem.
•Becomefamiliarwiththesafeoperationoftheequipment,
operatorcontrols,andsafetysigns.
•Alloperatorsandmechanicsshouldbetrained.The
ownerisresponsiblefortrainingtheusers.
•Neverletchildrenoruntrainedpeopleoperateorservice
theequipment.Localregulationsmayrestricttheageof
theoperator.
•Theowner/usercanpreventandisresponsiblefor
accidentsorinjuriesoccurringtohimselforherself,other
peopleorproperty.
Preparation
•Evaluatetheterraintodeterminewhataccessoriesand
attachmentsareneededtoproperlyandsafelyperform
thejob.Onlyuseaccessoriesandattachmentsapproved
bythemanufacturer.
•Wearappropriateclothingincludinghardhat,faceshield,
safetyglasses,longpants,safetyshoes,andhearing
protection.Longhair,looseclothingorjewelrymayget
tangledinmovingparts.
•Inspecttheareawheretheequipmentistobeusedand
removeallobjectssuchasrocks,toys,andwirewhichcan
bethrownbythemachine.
•Useextracarewhenhandlinggasolineandotherfuels.
Theyareammableandvaporsareexplosive.
–Useonlyanapprovedcontainer
–Neverremovethegascaporaddfuelwiththeengine
running.Allowtheenginetocoolbeforerefueling.
Donotsmoke.
3
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

–Neverrefuelordrainthemachineindoors.
•Checkthattheoperatorpresencecontrols,safetyswitches,
andshieldsareattachedandfunctioningproperly.Donot
operateunlesstheyarefunctioningproperly.
•Checkthatthecuttingwheelhasstoppedrotatingwhen
youreducethethrottle.
Operation
•Neverrunanengineinanenclosedarea.
•Onlyoperateingoodlight,keepingawayfromholesand
hiddenhazards.
•Besurealldrivesareinneutralbeforestartingtheengine.
Onlystarttheenginefromtheoperator'sposition.
•Slowdownanduseextracareonhillsides.Besureto
travelintherecommendeddirectiononhillsides.Turf
conditionscanaffectthemachine'sstability.
•Slowdownandusecautionwhenmakingturnsandwhen
changingdirectionsonslopes.
•Neveroperatewiththeguardsnotsecurelyinplace.Be
sureallinterlocksareattached,adjustedproperly,and
functioningproperly.
•Donotchangetheenginegovernorsettingoroverspeed
theengine.
•Stoponlevelground,lowerthegrinder,andshutoff
theenginebeforeleavingtheoperator'spositionforany
reason.
•Keephandsandfeetawayfromthemovinggrinderwheel
andteeth.
•Lookbehindanddownbeforebackinguptobesureof
aclearpath.
•Nevercarrypassengersandkeeppetsandbystanders
away.
•Slowdownandusecautionwhenmakingturnsand
crossingroadsandsidewalks.
•Donotoperatethemachineundertheinuenceof
alcoholordrugs.
•Usecarewhenloadingorunloadingthemachineintoa
trailerortruck.
•Usecarewhenapproachingblindcorners,shrubs,trees,
orotherobjectsthatmayobscurevision.
•Ensurethattheareaisclearofotherpeoplebefore
operatingthemachine.Stopthemachineifanyoneenters
thearea.
•Neverleavearunningmachineunattended.Alwaysstop
theengineandverifythecuttingwheelhasstopped
rotating.
•Neverjerkthecontrols;useasteadymotion.
•Watchfortrafcwhenoperatingnearorcrossing
roadways.
•Donottouchpartswhichmaybehotfromoperation.
Allowthemtocoolbeforeattemptingtomaintain,adjust,
orservice.
•Ensurethatyouoperatethemachineinareaswhere
therearenoobstaclesincloseproximitytotheoperator.
Failuretomaintainadequatedistancefromtrees,walls,
andotherbarriersmayresultininjuryasthemachine
backsupduringoperationiftheoperatorisnotattentive
tothesurroundings.Onlyoperatetheunitinareaswhere
thereissufcientclearancefortheoperatortosafely
maneuvertheproduct.
•Beforegrinding,havetheareamarkedforunderground
utilities,anddonotgrindinmarkedareas.
•Locatethepinchpointareasmarkedonthemachineand
keephandsandfeetawayfromtheseareas.
•Lightningcancausesevereinjuryordeath.Iflightning
isseenorthunderisheardinthearea,donotoperate
themachine;seekshelter.
MaintenanceandStorage
•Stoptheengine.Waitforallmovementtostopbefore
adjusting,cleaning,orrepairing.
•Cleandebrisfromthegrinder,drives,mufers,andengine
tohelppreventres.Cleanupoilorfuelspillage.
•Lettheenginecoolbeforestoringanddonotstorenear
ame.
•Donotstorefuelnearamesordrainindoors.
•Parkthemachineonlevelground.Neverallowuntrained
personneltoservicethemachine.
•Usejackstandstosupportcomponentswhenrequired.
•Carefullyreleasepressurefromcomponentswithstored
energy.
•Removethesparkplugwirebeforemakinganyrepairs.
•Keephandsandfeetawayfrommovingparts.Ifpossible,
donotmakeadjustmentswiththeenginerunning.
•Keepallpartsingoodworkingconditionandallhardware
tightened.Replaceallwornordamageddecals.
•Keepnutsandboltstight.Keepequipmentingood
condition.
•Nevertamperwithsafetydevices.
•Keepthemachinefreeofgrass,leaves,orotherdebris
build-up.Cleanupoilorfuelspillage.Allowthemachine
tocoolbeforestoring.
•Useextracarewhenhandlinggasolineandotherfuels.
Theyareammableandvaporsareexplosive.
–Useonlyanapprovedcontainer.
–Neverremovethegascaporaddfuelwhenthe
engineisrunning.Allowtheenginetocoolbefore
refueling.Donotsmoke.
–Neverrefuelthemachineindoors.
–Neverstorethemachineorfuelcontainerinside
wherethereisanopename,suchasnearawater
heaterorfurnace.
–Neverllacontainerwhileitisinsideavehicle,trunk,
pick-upbed,oranysurfaceotherthantheground.
4
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

–Keepcontainernozzleincontactwiththetankduring
lling.
•Stopandinspecttheequipmentifyoustrikeanobject.
Makeanynecessaryrepairsbeforerestarting.
•UseonlygenuineTororeplacementpartstoensurethat
originalstandardsaremaintained.
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotential
danger.Replaceanydecalthatisdamagedorlost.
119-4701
1.Warning—readtheOperator'sManual.5.Crushinghazardofhand—stayawayfrommovingparts,keep
allguardsandshieldsinplace.
2.Warning—donotoperatethismachineunlessyouaretrained.6.Explosionhazard;electricalshockhazard—donotdiginareas
withburiedutilitylines;contactlocalpowerorganizations
beforedigging.
3.Thrownobjecthazard—keepbystandersasafedistancefrom
themachine.
7.Warning—removetheignitionkey(ifapplicable)andreadthe
instructionsbeforeservicingorperformingmaintenance.
4.Thrownobjecthazard—weareyeprotection,pickupdebris
beforeoperating.
119-4721
1.Engage3.Disengage,engineruns
2.Grindingblade
119-4690
1.Warning;cutting/dismembermenthazard,grinding
blade—keephandsandfeetawayfromallmovingparts,
keepallshieldsinplace;waitforallmovingpartstostop.
5
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

119-4692
1.Warning—stoptheengine;usebothhandholdstoliftthe
grinder.
119-4693
1.Thrownobjecthazard—keepbystandersasafedistance
fromthemachine.
117–4979
1.Rotatingbelt—Keepguardinplace
ProductOverview
g014497
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Figure3
1.Throttlelever8.Cuttingwheel
2.Hourmeter9.Beltcover
3.Cycloneairlter10.Lift
4.Choke11.FuelCap
5.Fuelvalve12.Parkingbrake
6.Sedimentcup13.Safetybail
7.Starter14.Handle
Controls
Becomefamiliarwithallthecontrols(Figure3andFigure4)
beforeyoustarttheengineandoperatethemachine.
ThrottleLever
Thethrottlelevercontrolsenginespeed.Withthelever
down,intheDisengagedposition,theenginerunsatidle.
Thisisalsothestartingposition.Whentheenginespeed
increases,totheEngagedposition,thecentrifugalclutch
engagesandthecuttingwheelrotates.
6
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

Figure4
1.Disengagedthrottle
position
2.Engagedthrottleposition
ParkingBrake
Theparkingbrakeholdstheleftwheelfromturningtosecure
themachineandforeasymovementofthemachinefromside
tosidewhengrindingthestump.
G014632
Figure5
1.Pullbacktoengagebrake
HourMeter
Whentheengineisoff,thehourmeterdisplaysthenumber
ofhoursofoperationthathavebeenloggedonthemachine.
Specications
Note:Specicationsanddesignaresubjecttochange
withoutnotice.
CuttingDepthApprox12inches(30.48cm)
Length76inches(193cm)
Width29.5inches(75cm)
Height42inches(107cm)
Weight240lbs(109Kg)
Attachments/Accessories
AselectionofToroapprovedattachmentsandaccessoriesare
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww.Toro.comforalistofallapproved
attachmentsandaccessories.
7
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
Important:Beforeoperating,checkthefuelandoil
level,andremovedebrisfromthemachine.Also,ensure
thattheareaisclearofpeopleanddebris.Youshould
alsoknowandhavemarkedthelocationsofallutility
lines.
BeforeyouStart
•Digawaytheearthandremoveanystonesnearthetree
stumpthatmayinterferewithyourwork.Checkthatthe
groundisfreeofforeignobjects,suchaselectricalcables,
barbedwire,etc.
•Cutortrimthestumpusingapowersaw.
•Reviewallthemachine’ssafetydecals.
•Useahard-hat,hearing,andeyeprotection.Amesh
visoralonedoesnotprovidesufcienteyeprotection;
supplementwithprotectiveglasses.
•Ensurethatyouarefamiliarwithsafetyregulationsand
shutdownproceduresdescribedintheOperator’sManual.
•Ensurethatallguardsareinplaceandingoodcondition.
•Ensurethatthebladesandcuttersareinplaceandin
goodcondition.
•Ensurethattheworkarea,cutter,andstumpinparticular
arefreefrommetallicobjectssuchaswire,nails,etc.that
couldbethrownoutandinjurepersonsinthevicinity
anddamagetheequipment.
•Ensurethateveryone,includingchildrenandanimals,
maintainadistanceofatleast50feet(15m)fromthe
machine.Debriscanbethrownoutandinjurepeople
andanimals.
AddingFuel
Useunleadedgasoline(87pumpoctaneminimum).Leaded,
regulargasolinemaybeusedifunleadedisnotavailable.
DANGER
Incertainconditions,gasolineisextremely
ammableandhighlyexplosive.Areorexplosion
fromgasolinecanburnyouandothersandcan
damageproperty.
•Fillthefueltankoutdoors,inanopenarea,
whentheengineiscold.Wipeupanygasoline
thatspills.
•Neverllthefueltankinsideanenclosedtrailer.
•Donotllthefueltankcompletelyfull.Add
gasolinetothefueltankuntilthelevelis1/4to
1/2inch(6to13mm)belowthebottomofthe
llerneck.Thisemptyspaceinthetankallows
gasolinetoexpand.
•Neversmokewhenhandlinggasoline,andstay
awayfromanopenameorwheregasoline
fumesmaybeignitedbyaspark.
•Storegasolineinanapprovedcontainerand
keepitoutofthereachofchildren.Neverbuy
morethana30-daysupplyofgasoline.
•Donotoperatewithoutentireexhaustsystemin
placeandinproperworkingcondition.
DANGER
Incertainconditionsduringfueling,static
electricitycanbereleasedcausingasparkwhich
canignitethegasolinevapors.Areorexplosion
fromgasolinecanburnyouandothersandcan
damageproperty.
•Alwaysplacegasolinecontainersontheground
awayfromyourvehiclebeforelling.
•Donotllgasolinecontainersinsideavehicleor
onatruckortrailerbedbecauseinteriorcarpets
orplastictruckbedlinersmayinsulatethe
containerandslowthelossofanystaticcharge.
•Whenpractical,removegas-poweredequipment
fromthetruckortrailerandrefueltheequipment
withitswheelsontheground.
•Ifthisisnotpossible,thenrefuelsuch
equipmentonatruckortrailerfromaportable
container,ratherthanfromagasolinedispenser
nozzle.
•Ifagasolinedispensernozzlemustbeused,
keepthenozzleincontactwiththerimofthe
fueltankorcontaineropeningatalltimesuntil
fuelingiscomplete.
Important:Donotusemethanol,gasolinecontaining
methanol,orgasoholcontainingmorethan10%ethanol
8
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

becausethefuelsystemcouldbedamaged.Donotmix
oilwithgasoline.
UsingStabilizer/Conditioner
Useafuelstabilizer/conditionerinthemachinetoprovide
thefollowingbenets:
•Keepsgasolinefreshduringstorageof90daysorless.
Forlongerstorageitisrecommendedthatthefueltank
bedrained.
•Cleanstheenginewhileitruns.
•Eliminatesgum-likevarnishbuildupinthefuelsystem,
whichcauseshardstarting.
Important:Donotusefueladditivescontaining
methanolorethanol.
Addthecorrectamountofgasstabilizer/conditionertothe
gas.
Note:Afuelstabilizer/conditionerismosteffectivewhen
mixedwithfreshgasoline.Tominimizethechanceofvarnish
depositsinthefuelsystem,usefuelstabilizeratalltimes.
FillingtheFuelTank
1.Parkthemachineonalevelsurface,lowerthegrinder,
andstoptheengine.
2.Allowtheenginetocool.
3.Cleanaroundthefueltankcapandremoveit(Figure6).
Figure6
1.Fueltankcap
4.Addunleadedgasolinetothefueltank,untilthelevelis
1/4to1/2inchbelowthebottomofthellerneck.
Important:Thisspaceinthetankallowsgasoline
toexpand.Donotllthefueltankcompletelyfull.
5.Installthefueltankcapsecurely.
6.Wipeupanygasolinethatmayhavespilled.
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
1.Tiltthemachinesotheengineislevel,andstopthe
engine.
2.Allowtheenginetocool.
3.Cleanaroundtheoildipstick.
4.Removethedipstickandwipetheendclean.
5.Slidethedipstickfullyintothedipsticktubewithout
threadingitintothellerneck.
6.Pullthedipstickoutandlookattheend.Theoil
shouldbetothetopoftheupperlimitrange(Figure7).
Figure7
1.Oildipstick
Important:Runningtheenginewithlowoillevel
cancauseenginedamage.Thistypeofdamageis
notcoveredbywarranty.
Theengineisequippedwithanoilalertsystem
thatwillautomaticallystoptheenginebeforethe
oillevelfallsbelowthesafelimit.
7.Iftheoillevelislow ,slowlypouronlyenoughoilinto
thecrankcasetoraisetheleveltotheupperlimit.
Important:Donotoverllthecrankcasewithoil
becausetheenginemaybedamaged.
8.Replacethedipstick.
9
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

StartingandStoppingthe
Engine
StartingtheEngine
1.MovethefuelvalvetotheOpenposition,alltheway
totheright.
Note:Ifyourmodelisequippedwithanenginewith
anOn/Offswitch,movetheswitchtotheOnposition.
2.MovethechokeleverlefttotheOnpositionifyou
arestartingacoldengine.
Note:Awarmorhotenginemaynotrequirechoking.
3.MovethethrottletotheDisengageposition.
4.Holdthesafetybailagainstthehandleandpushthe
handledownenoughtoraisethecuttingwheeloffthe
ground.
5.Pullthestarterhandlelightlyuntilyoufeelresistance,
thenpullthehandlebriskly.Returnthestarterhandle
gently.
6.Aftertheenginestarts,graduallymovethechoke
leverbacktotheOffposition.Iftheenginestallsor
hesitates,movethechokebacktoOnagainuntilthe
enginewarmsup.ThenmoveittotheOffposition.
StoppingtheEngine
1.MovethethrottletotheDisengageposition.
Note:Iftheenginehasbeenworkinghardorishot,
letitrunforaminutebeforereleasingthesafetybail.
Thishelpstocooltheenginebeforestopping.Inan
emergency,theenginemaybestoppedimmediately.
2.Releasethesafetybailtostoptheengine.
3.MovethefuelvalvetotheClosedposition,alltheway
totheleft.
Note:Ifyourmodelisequippedwithanenginewith
anOn/Offswitch,movetheswitchtotheOffposition.
GrindingaStump
Placethemachineintopositionwiththecuttingwheelnear
thefront-topedgeofthestump.
DANGER
Themachinewillcutandamputatehandsandfeet.
•Stayintheoperator'spositionwhilethemachine
isrunningandkeepawayfromthecutting
wheel.
•Keepallbystandersasafedistancefromthe
machine.
•Stopthemachineimmediatelyifanypeopleor
animalsentertheworkarea.
WARNING
Grindingastumpwillthrowwoodchips,soil,and
otherdebrisintotheairwhichcouldinjureyouor
bystanders.
•Alwaysweareyeprotectionwhenusingthe
machine.
•Keepallbystandersasafedistancefromthe
machine.
WARNING
Themachineisveryloudandcandamageyour
ears.
Alwayswearhearingprotectionwhenusingthe
machine.
1.SetthrottletotheDisengageposition.
2.Starttheengine;referto(page).
3.Allowenginetowarmupatidlefortwominutes.
4.Pushthehandledownenoughtoraisethecutting
wheelofftheground.
5.MovethrottleuptotheEngageposition,thiswill
engagethecentrifugalclutchandthecuttingwheel
rotates.
6.Movethemachinetofrontofthestumpandsetthe
parkingbrake
7.Swingthecuttingwheeltooneside,thenlowerit
approximately1/2inchto1inchintothefront-top
cornerofthestump.Swingthecuttingwheelback
andforth,loweringthecuttingwheelapproximately
1/2inchto1inchbeforeeachsweep,untilyouhave
removedthefrontportionofthestumptoground
level(Figure8).
10
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

g014502
1234
568
7
Figure8
8.Raisethecuttingwheeluntilcenterofcuttingwheelis
justabovetopofthestump.
9.Withthecuttingwheelofftooneside,releasethe
parkingbrakeandadvancethemachineforward,reset
theparkingbrake.
10.Continuesweepingandcuttingwheelleftandright
acrossstump,advancingthemachinebeforeeach
sweep,cutting1/2inchto1inchdepthofcutwith
eachsweep.
11.Continuecuttinguntiltoplevelofstumpisallremoved,
makingsurenottocutstumpdeeperthangroundlevel
duringthisrststage.
12.MovethrottletotheDisengageposition,pushthe
handledownenoughtoraisethecuttingwheeloffthe
ground.Waittensecondsforthecuttingwheeltostop
rotatingthenreleasethebrakeandpullthemachine
awayfromthestump.
13.Rakethechipsawayfromthestump.
14.Continuecuttingthestumpusingtheprocedureabove
untilthedesireddepthisachieved.
15.Stopthemachine;referto(page).
Note:DoNotletthefrontoftheunittouchthe
grounduntilyouaresurethecuttingwheelhasstopped
turning.
WARNING
Arotatingcuttingwheelisverydangerousand
cancutandamputatehandsandfeet.
Stayattheoperatingpositionandbesurethat
thecuttingwheelhascometoacompletestop
beforedoinganythingelse.
11
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
Important:Themachinemaybetippedbackwardor
onitssidetofacilitateaccessforcleaningorservice,
butnolongerthan2minutes.Ifthemachineisheldin
thispositionfortoolong,theenginecanbedamaged
bygasolinedrainingintothecrankcase.Shouldthis
happen,performanextraoilchangeontheengine.
Thenturntheengineoverafewrevolutionswiththe
starterhandlebeforestartingtheengineagain.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst25hours•Changetheoil.
Beforeeachuseordaily
•Checktheengineoillevel.
•Greasethemachine.
•Checktheairlter.
•Checkthedrivebelttension.
•Checkthecuttingwheelblades.
•Removedebrisfromthemachine.
Every50hours•Servicetheairlter.
Every100hours
•Changetheoil.
•Cleanthesedimentcup.
•Checkthesparkplugs.
•Replacethedrivebelt.
Every200hours•Replacetheairlter.
Yearlyorbeforestorage•Changetheoil.
•Cleanthesedimentcup.
Important:Refertoyour EngineOperator'sManual foradditionalmaintenanceprocedures.
Lubrication
GreasingtheMachine
ServiceInterval:Beforeeachuseordaily
GreaseType:General-purposegrease.
1.Cleanthegreasettingswitharag.
2.Connectagreaseguntoeachtting.
3.Lubricatetwottings,oneoneachcuttingwheel
bearing.
4.Pumpgreaseintothettingsuntilgreasebeginsto
oozeoutofthebearings(approximately3pumps).
5.Wipeupanyexcessgrease.
Important:Pumpgreaseinslowlyandcarefully
topreventdamagetothebearingseals.
Figure9
12
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Beforeeachuseordaily
Thecycloneairltercollectsthelargestcontaminantparticles,
whichcollectinthecontainer.Whenyoucanseealayerof
dirtatthebottomofthecontainer,cleanthecyclonehousing,
airchannels,andairintakescreen.
ServicingtheCycloneAirFilter
ServiceInterval:Every50hours
1.Removethe3screwsholdingthecyclonehousing.
2.Removethehousingwiththeairintakescreenand
removetheairchannels.
Figure10
1.Cyclonehousing3.Airchannels
2.Screw4.Cyclonehousingwithair
intakescreen
Note:Theairchannelsmayremainintheupper
portionorfollowalongwiththehousingwhen
removed.
3.Cleanthecomponents.Usewater,detergentanda
brush.Drycarefully.
4.Placetheairchannelsinthecyclonehousing.
5.Insertcyclonehousingintopositionandmakesureit
tsintheupperportion.Donotuseforce;alignitin
placebeforettingthescrews.
ReplacingtheAirFilter
ServiceInterval:Every200hours
Iftheengineislowonpower,producesblacksmokeorruns
unevenly,theairltermaybeclogged.
1.Removethewingnutandliftoffthecyclonelterwith
theairltercowling(Figure11).
Figure11
1.Wingnut4.Airlter
2.Cycloneairlter5.Stud
3.Foampre-lter
2.Removethefoampre-lterandcleanitasfollows
A.Washthepre-lterusingamilddetergentand
water.
B.Squeezeitdrywithacleancloth.
C.Soakitwithnewengineoil.
D.Gentlywindthelterinanabsorbentclothand
squeezeoutexcessoil.
3.Removethewingnutontopoftheairlterand
removethepaperlter.
4.Tapthepaperlteragainstaxedsurfacetoremove
dust.Ifthepaperlterisstilldirtyordamaged,replace
it.Thepaperltershouldbereplacedevery200hours.
Important:Donotusecompressedairtoblow
outthepaperelement,thiscandamageit.
5.Mountthepaperlterintheairlterhousingand
secureitwiththewingnut.
6.Positionthefoampre-lteroverthepaperlter.
7.Installthecyclonelterwiththeairltercoverand
secureitwiththewingnut.
13
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

ServicingtheEngineOil
Note:Changetheoilmorefrequentlywhentheoperating
conditionsareextremelydustyorsandy.
OilType:DetergentoilwithanAPIserviceofSJorhigher.
CrankcaseCapacity:2.1qt(2liters)
Viscosity:SAE10W-30isrecommendedforgeneraluse.
ChangingtheEngineOil
ServiceInterval:Aftertherst25hours
Every100hours
Yearlyorbeforestorage
1.Starttheengineandletitrunveminutes.Thiswarms
theoilsoitdrainsbetter.
2.Parkthemachinesothatthedrainsideisslightlylower
thantheoppositesidetoensurethattheoildrains
completely.
3.Settheparkingbrakeandstoptheengine.
4.Placeapanundertheoildrainhole.
5.Removethedrainpluganddraintheoilthroughthe
holeslotintheframe(Figure12).
g014504
1
2
Figure12
1.Oildrainhole2.Oilllcap
6.Whentheoilhasdrainedcompletely,installtheplug
andwipeupanyspilledoil.
Note:Disposeoftheusedoilatacertiedrecycling
center.
7.Removetheoilllcapandslowlypourapproximately
80percentofthespeciedamountofoilintothe
engine(Figure12).
8.Slowlyaddadditionaloiltobringtheoillevel
totheupperlimitmarkonthedipstick.Refer
toCheckingtheEngineOilLevel(page9).
9.Installtheoilllcap.
CleaningtheSedimentCup
ServiceInterval:Every100hours
Yearlyorbeforestorage
Underneaththefuelvalveisasedimentcuptocatchdirtin
thefuel.
1.MovethefuelvalvetotheOffposition,alltheway
totheleft.
2.Unscrewthesedimentcup.Makesurenottomisplace
theo-ring(Figure13).
Figure13
1.Sedimentcup2.O-Ring
3.Cleanthereservoirandtheo-ringusingacleaning
solventanddrycarefully.
Note:Makesurenottomisplacetheo-ring.
4.Puttheo-ringinplaceinthegrooveofthecupand
replacethesedimentcup.
5.TurnthefuelvalvetotheOnposition,allthewaytothe
right,andcheckforleaks.Ifitleaks,replacetheo-ring.
ServicingtheSparkPlug
ServiceInterval:Every100hours—Checkthesparkplugs.
Ensurethattheairgapbetweenthecenterandsideelectrodes
iscorrectbeforeinstallingthesparkplug.Useasparkplug
wrenchforremovingandinstallingthesparkpluganda
gappingtool/feelergaugetocheckandadjusttheairgap.
Installanewsparkplugifnecessary.
Type:BPR6ES(NKG)orequivalent
AirGap:0.28–0.031inch(0.70-0.80mm)
RemovingtheSparkPlug
1.Lowerthegrinderandstopthemachine;Referto
(page).
14
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

2.Pullthewireoffofthesparkplug(Figure14).
Figure14
1.Sparkplug2.Wire
3.Cleanaroundthesparkplug.
4.Removethesparkplugandthemetalwasher.
CheckingtheSparkPlug
1.Lookatthecenterofthesparkplug(Figure15).Ifyou
seelightbrownorgrayontheinsulator,theengineis
operatingproperly.Ablackcoatingontheinsulator
usuallymeansthattheaircleanerisdirty.
Important:NeverCleanthesparkplug.Always
replacethesparkplugwhenithasablackcoating,
wornelectrodes,anoilylm,orcracks.
Figure15
1.Centerelectrodeinsulator3.Airgap(nottoscale)
2.Sideelectrode
2.Checkthegapbetweenthecenterandsideelectrodes
(Figure15).Bendthesideelectrode(Figure15)ifthe
gapisnotcorrect.
InstallingtheSparkPlug
1.Threadthesparkplugintothesparkplughole.
2.Tightenthesparkplugto20ft-lb(27N-m).
3.Pushthewireontothesparkplug.
BrakeMaintenance
AdjustingtheParkingBrake
1.Loosenthesetscrewonsideofbrakeleverknob.Turn
theknobclockwisetotightenthebrake;adjustcounter
clockwisetoloosenthebrake.Theleftwheelshould
lockcompletelywhenthebrakeisset.
2.Tightenthesetscrew .
15
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

BeltMaintenance
AdjustingtheDriveBelt
Tension
ServiceInterval:Beforeeachuseordaily
Note:Inspectthedrivebeltthroughtheslotontopofthe
beltcover.Adjustasrequired.
1.Removetheboltsandwasherssecuringthebeltguard
tomachine.
2.Removethebeltguard(Figure16).
G017432
Figure16
1.Boltsandwashers2.Beltguard
3.Loosenthe4engineplatemountingboltsandthe4
boltssecuringtherearofthebeltguardtotheengine.
4.Loosenthebelttensionboltandjamnut,slidethe
enginetowardtheywheelhousingtoloosenbelt
(Figure17).
G016617
Figure17
1.Tensionboltandjam2.Engineplatemountingbolt
5.Adjustthedrivebelttensionbytighteningtensionbolt
andjamnutagainsttheenginemountingplate,pushing
theenginerearward.
6.Layastraightedgeacrossclutchandywheelpulleys,
tightenbelttensionboltsothereis0.40inch(1cm)of
exinthebeltwhenpushingdownwith15lbs(6.8
kg)force,atmid-span(whenre-tensioningabeltin
use)orwith18lbs(8kg)forcewheninstallinganew
belt(Figure18).
G017434
Figure18
1.Straightedge2.Flexof0.40inches(1cm)
7.Ensurethatthepulleysarealignedandtheengineis
parallelwiththeframe(notangledtowardtheside),
thentightenthe4engineplatemountingboltsandthe
4boltssecuringtherearofthebeltguardtotheengine.
8.Installthebeltguardandsecureitwiththepreviously
removedwashersandbolts.
ReplacingtheDriveBelt
ServiceInterval:Every100hours
Note:Replacethebeltifitshowsanysignsofwear,cracks,
glazing,ordamage.
1.Removetheboltsandwasherssecuringthebeltguard
tomachine.
2.Removethebeltguard(Figure16).
3.Loosenthe4engineplatemountingboltsandthe4
boltssecuringtherearofthebeltguardtotheengine.
4.Loosenthebelttensionboltandjamnut,slidethe
enginetowardtheywheelhousingtoloosenbelt
(Figure17).
5.Replacedrivebelt.
6.Adjusttensionofnewbeltto18±0.9lbforceand
0.40inch(10mm)beltdeectionatmid-span.
7.Tightenthe4engineplatemountingboltsandthe4
boltssecuringtherearofthebeltguardtotheengine.
8.Installthebeltguardandsecureitwiththepreviously
removedwashersandbolts.
16
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

GrinderMaintenance
CheckingtheCuttingWheel
Blades
ServiceInterval:Beforeeachuseordaily
Amongthemostcriticalelementsofthemachineisthe
cuttingwheelblades.Theyarealsothemostsubjectto
damageandwear.Inthecourseofgrindingstumpstheynot
onlymakecontactwiththewood,buttheyalsoencounter
numerousabrasivesandobjects,suchasdirt,stones,and
occasionallyalargerockorburiedscrap.
Thewearandlossofcuttingteethcansignicantlyimpairthe
efciencyandperformanceofthemachine.Therefore,itis
importanttomakefrequentchecksoftheconditionofall
ofthecuttingteethandreplaceanydamagedorwornblade
sections(Figure19).
Figure19
ReplacingtheCuttingWheel
Blades
1.Cleanalldirtfromthecuttingwheelandmounting
anges.
2.Removethetwoboltsthatholdeachcuttingblade
section.Usecarenottoletasectiondropandchip
whentheybecomeloose(Figure20).
Figure20
3.Checkeachsectionforcracks.Replaceabladesection
ifitiscrackedorhasmissingorwornteeth.
Note:Whenreplacingcuttingwheelbladesections,
makesurebladesectionisplacedincorrectalignment
withbladerotation.
4.Insertthebladesectionbetweentheblademounting
anges(Figure20),andsecurethemwith2bolts,
lockwashers,andnuts.
5.Torquethefastenersto27–33ft-lb(37–45N-m).
17
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

Cleaning
RemovingDebrisfromthe
Machine
Regularcleaningandwashingwillincreasethelifespanof
themachine.Cleanthemachinedirectlyafteruse,beforethe
dirthardens.
Checkbeforecleaningthatthefueltankcapisproperlyin
placetoavoidgettingwaterinthetank.
Usecarewhenusingahigh-pressuresprayerbecauseitcan
damagewarningdecals,instructionsigns,andtheengine
Important:Lubricatethecuttingwheelbladebearings
aftercleaning.
Storage
Forstorageover30days,preparetheunitasfollows:
1.Removedirtandgrimefromtheexternalpartsof
theentireunit,especiallytheengine.Cleandirtand
sawdustchipsfromtheoutsideoftheenginecylinder
headnsandblowerhousing.
Important:Youcanwashtheunitwithmild
detergentandwater.
2.Addapetroleumbasedstabilizer/conditionertofuel
inthetank.Followmixinginstructionsfromstabilizer
manufacturer.(1oz.perUSgallon).Donotusean
alcoholbasedstabilizer(ethanolormethanol).
Note:Fuelstabilizer/conditionerismosteffective
whenmixedwithfreshgasolineandusedatalltimes.
Important:Donotstorestabilizer/conditioned
gasolineover90days.
3.Runtheenginetodistributeconditionedfuelthrough
thefuelsystem(5minutes).
4.Stoptheengine,allowittocool,anddrainthefueltank
usingapumptypesiphon.Disposeoffuelproperly;
recycleasperlocalcodes.
5.Starttheengineandrunituntilitstops.
6.Choketheengine.
7.Startandruntheengineuntilitwillnotstartagain.
8.Cleanthesedimentcup;referto
CleaningtheSedimentCup(page14).
9.Servicetheaircleaner;referto
ServicingtheCycloneAirFilter(page13)and,
ReplacingtheAirFilter(page13).
10.Changetheenginecrankcaseoil;referto
ChangingtheEngineOil(page14).
11.Removethesparkplugandcheckthecondition;refer
toServicingtheSparkPlug(page14).
12.Withthesparkplugremovedfromtheengine,pour
twotablespoonsofengineoilintothesparkplughole.
13.Pullthestarterslowlytocranktheengineanddistribute
theoilinsidethecylinder.
14.Installthesparkplug,butdonotinstallthewireon
thesparkplug.
15.Greasethecutterwheelbearings;referto(page).
16.Checkandtightenallbolts,nuts,andscrews.Repairor
replaceanypartthatisdamaged.
17.Paintallscratchedorbaremetalsurfaces.Paintis
availablefromyourAuthorizedServiceDealer.
18.Storetheunitinaclean,drygarageorstoragearea.
19.Covertheunittoprotectitandkeepitclean.
18
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

Troubleshooting
ProblemPossibleCauseCorrectiveAction
1.ThesafetybaleisintheOffposition.1.Holdthesafetybailagainstthehandle.
2.Ifyourmodelisequippedwithan
enginewithanOn/Offswitch,the
switchisintheOffposition.
2.MovetheswitchtotheOnposition.
3.Thefuelshutoffvalveisclosed.3.Openthefuelvalve.
4.Thechokeisopen.4.Closethechokewhenstartingacold
engine.
5.Thefueltankisempty.5.Filltankwithfreshfuel.
Theenginewillnotstart.
6.Thesparkplugwireislooseor
disconnected.
6.Checktheelectrodegapandcleanor
replacethesparkplug.
1.Thechokeislefton.1.Openthechoke.
2.Theairlterisclogged.2.Cleanorreplacetheairlter.
3.Thefuellineisclogged.3.Cleanthesedimentcup.
4.Thereiswaterorcontaminantsinthe
fuel.
4.Drainandllthetankwithfreshfuel.
Theenginerunsrough.
5.Thesparkplugsarewornorhave
buildupontheelectrodes.
5.Checktheelectrodegapandcleanor
replacethesparkplug.
Thebeltslipsorcomesoffthepulleys1.Thebelttensionisinsufcient.1.Adjustthebelttension.Reducethe
cuttingdepth.
1.Theenginespeedisinsufcientto
activatethecentrifugalclutch.
1.MovethethrottletotheEngaged
position.
2.Thebelttensionisinsufcient.2.Adjustthebelttension.
Thecuttingwheeldoesnotrotate.
3.Theclutchshoesareworn.3.Replacetheclutch.
1.Theenginespeedisexcessive.1.MovethethrottletotheDisengaged
position.
2.Thebeltisoffofthepulleysorbroken.2.Replacethedrivebelt.
Thecuttingwheelcontinuestorotate.
3.Clutchspringsareweakorbroken.3.Replacetheclutch.
1.Theparkingbrakeisoutofadjustment.1.Adjusttheparkingbrake.
Theparkingbrakedoesnothold.
2.Thebrakepadsareworn.2.Replacethebrake.
19
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

ToroCompactUtilityEquipmentWarranty
AOne-YearLimitedWarranty
CUEProducts
ConditionsandProductsCovered
TheT oro®Companyanditsafliate,T oroWarrantyCompany,pursuant
toanagreementbetweenthem,jointlywarrantyourToroCompactUtility
Equipment(“Product”)tobefreefromdefectsinmaterialsorworkmanship.
Thefollowingtimeperiodsapplyfromthedateofpurchase:
ProductsWarrantyPeriod
Loaders,Trenchers,StumpGrinders,
Chippers,LogSplittersandAttachments
1yearor1000operating
hours,whicheveroccursrst
KohlerEngines3years
AllotherEngines2years
Whereawarrantableconditionexists,wewillrepairtheProductatnocost
toyouincludingdiagnosis,labor,andparts.
InstructionsforObtainingWarrantyService
IfyouthinkthatyourToroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:
1.ContactanyAuthorizedT oroCompactUtilityEquipment(CUE)
ServiceDealertoarrangeserviceattheirdealership.Tolocatea
dealerconvenienttoyou,accessourwebsiteatwww.T oro.com.
YoumayalsocallourT oroCustomerCareDepartmenttollfree
at888-865-5676(U.S.customers)or888-865-5691(Canadian
customers).
2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.
3.IfforanyreasonyouaredissatisedwiththeServiceDealer’s
analysisorwiththeassistanceprovided,contactusat:
LCBCustomerCareDepartment
ToroWarrantyCompany
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
TollFree:888-865-5676(U.S.customers)
TollFree:888-865-5691(Canadacustomers)
OwnerResponsibilities
YoumustmaintainyourT oroProductbyfollowingthemaintenance
proceduresdescribedintheOperator’sManual.Suchroutine
maintenance,whetherperformedbyadealerorbyyou,isatyourexpense.
Partsscheduledforreplacementasrequiredmaintenance(“Maintenance
Parts”),arewarrantedfortheperiodoftimeuptothescheduled
replacementtimeforthatpart.Failuretoperformrequiredmaintenance
andadjustmentscanbegroundsfordisallowingawarrantyclaim.
ItemsandConditionsNotCovered
Notallproductfailuresormalfunctionsthatoccurduringthewarranty
periodaredefectsinmaterialsorworkmanship.Thisexpresswarranty
doesnotcoverthefollowing:
•Productfailureswhichresultfromtheuseofnon-T ororeplacement
parts,orfrominstallationanduseofadd-on,modied,orunapproved
accessories
•Productfailureswhichresultfromfailuretoperformrequired
maintenanceand/oradjustments
•ProductfailureswhichresultfromoperatingtheProductinan
abusive,negligentorrecklessmanner
•Partssubjecttoconsumptionthroughuseunlessfoundtobe
defective.Examplesofpartswhichareconsumed,orusedup,during
normalProductoperationinclude,butarenotlimitedto,teeth,tines,
blades,sparkplugs,tires,tracks,lters,chains,etc.
•Failurescausedbyoutsideinuence.Itemsconsideredtobeoutside
inuenceinclude,butarenotlimitedto,weather,storagepractices,
contamination,useofunapprovedcoolants,lubricants,additives,or
chemicals,etc.
•Normal“wearandtear”items.Normal“wearandtear”includes,butis
notlimitedto,wornpaintedsurfaces,scratcheddecalsorwindows,
etc.
•Anycomponentcoveredbyaseparatemanufacturer’swarranty
•Pickupanddeliverycharges
GeneralConditions
RepairbyanAuthorizedT oroCompactUtilityEquipment(CUE)Service
Dealerisyoursoleremedyunderthiswarranty.
NeitherTheToro®CompanynorToroWarrantyCompanyisliable
forindirect,incidentalorconsequentialdamagesinconnectionwith
theuseoftheToroProductscoveredbythiswarranty,including
anycostorexpenseofprovidingsubstituteequipmentorservice
duringreasonableperiodsofmalfunctionornon-usepending
completionofrepairsunderthiswarranty.Allimpliedwarranties
ofmerchantabilityandtnessforusearelimitedtotheduration
ofthisexpresswarranty.Somestatesdonotallowexclusionsof
incidentalorconsequentialdamages,orlimitationsonhowlong
animpliedwarrantylasts,sotheaboveexclusionsandlimitations
maynotapplytoyou.
Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveother
rightswhichvaryfromstatetostate.
ExceptfortheenginewarrantycoverageandtheEmissionswarranty
referencedbelow,ifapplicable,thereisnootherexpresswarranty.The
EmissionsControlSystemonyourProductmaybecoveredbyaseparate
warrantymeetingrequirementsestablishedbytheU.S.Environmental
ProtectionAgency(EPA)ortheCaliforniaAirResourcesBoard(CARB).
ThehourlimitationssetforthabovedonotapplytotheEmissions
ControlSystemWarranty.RefertotheCaliforniaEmissionControl
WarrantyStatementsuppliedwithyourProductorcontainedintheengine
manufacturer’sdocumentationfordetails.
CountriesOtherthantheUnitedStatesorCanada
CustomerswhohavepurchasedToroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirToroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor’sserviceorhavedifcultyobtaining
guaranteeinformation,contacttheToroimporter.Ifallotherremediesfail,youmaycontactusatToroWarrantyCompany.
374-0261RevB
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*
