Operator’s Manual
Original Instructions (EN)
Register your product at www.Toro.com
Form No. 3353–240
Roll Over Protection System
Z Masterr400 Series Mowers
Part No. 107–8093

2
W2005 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
Contact us at www.Toro.com
All Rights Reserved
Printed in the USA
Important Always keep this manual with the original manual that came with the machine.
Safety
Slope Operation
•Do not mow slopes greater than 15 degrees.
•Do not mow near drop–offs, ditches, steep banks or
water. Wheels dropping over edges can cause
rollovers, which may result in serious injury, death or
drowning.
•Do not mow slopes when grass is wet. Slippery
conditions reduce traction and could cause sliding and
loss of control.
•Do not make sudden turns or rapid speed changes.
•Use a walk behind mower and/or a hand trimmer near
drop–offs, ditches, steep banks or water.
•Reduce speed and use extreme caution on slopes.
•Remove or mark obstacles such as rocks, tree limbs,
etc. from the mowing area. Tall grass can hide
obstacles.
•Watch for ditches, holes, rocks, dips, and rises that
change the operating angle, as rough terrain could
overturn the machine.
•Avoid sudden starts when mowing uphill because the
mower may tip backwards.
•Be aware that loss of traction may occur going
downhill. Weight transfer to the front wheels may
cause drive wheels to slip and cause loss of braking
and steering.
•Always avoid sudden starting or stopping on a slope. If
tires lose traction, disengage the blades and proceed
slowly off the slope.
•Follow the manufacturer’s recommendations for wheel
weights or counterweights to improve stability.
•Use extreme care with grass catchers or other
attachments. These can change the stability of the
machine and cause loss of control.
Using the Rollover Protection System
(ROPS)
•Keep the roll bar in the raised and locked position and
use the seat belt when operating the machine.
•Be certain that the seat belt can be released quickly in
the event of an emergency.
•Be aware there is no rollover protection when the roll
bar is down.
•Check the area to be mowed and never fold the ROPS
in areas where there are slopes, drop offs or water.
•Lower the rollbar only when absolutely necessary. Do
not wear the seat belt with the roll bar folded down.
•Check carefully for overhead clearances (i.e. branches,
doorways, electrical wires) before driving under any
objects and do not contact them.

3
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near any
area of potential danger. Replace any decal that is damaged or lost.
107-2102
107-3069
1. Warning—in a roll over
accident without the roll
bar raised and seat belt
used, you will be injured or
killed; in a roll over
accident with the roll bar
raised and seat belt used,
you may be uninjured.
2. To mow under obstacles,
lower the roll bar and do
not wear the seat belt; at
all other times, always
raise the roll bar and wear
the seat belt.
3. Read the Operator’s
Manual, and slow down
and turn gradually.

4
Operation
Note: Determine the left and right sides of the machine
from the normal operating position.
Using the Rollover Protection
System (ROPS)
To avoid injury or death from a rollover, keep the
roll bar in the raised locked position and use the
seat belt.
Ensure that the rear part of the seat is secured
with the seat latch.
Warning
There is no rollover protection when the roll bar
is in the down position.
•Lower the roll bar only when absolutely
necessary.
•Do not wear the seat belt when the roll bar is in
the down position.
•Drive slowly and carefully.
•Raise the roll bar as soon as clearance permits.
•Check carefully for overhead clearances (e.g.,
branches, doorways, and electrical wires)
before driving under any objects and do not
contact them.
Warning
Important Lower the roll bar only when absolutely
necessary.
1. To lower the roll bar, loosen the front handles (Fig. 1).
1
m-7406
Figure 1
1. Front handle
2. Remove the hairpin cotter pins and remove the 2 pins
(Fig. 2).
2
1
3
4
m-7431
Figure 2
1. Roll bar
2. Raised position
3. Pin
4. Hairpin cotter pin
3. Lower the the roll bar to the down position.
Note: There are 2 down positions. See Figure 3 for the
positions.
2
1
m-7432a
Figure 3
1. Full down position 2. Down position with bagger
installed
4. Install the 2 pins and secure them with the hairpin
cotter pins (Fig. 2).
Important Always use the seat belt with the roll bar in
the raised position.
Important Ensure that the rear part of the seat is
secured with the seat latch.
5. To raise the roll bar, remove the hairpin cotter pins and
remove the 2 pins (Fig. 2).
6. Raise the roll bar to the upright position and install the
2 pins and secure them with the hairpin cotter pins
(Fig. 2).

5
7. Tighten the front handles against the center roll bar
ends (Fig. 1).
Think Safety First
Read all safety instructions and symbols in the safety
section. Knowing this information could help you or
bystanders avoid injury.
Danger
Operating the machine on wet grass or steep
slopes can cause sliding and loss of control.
Wheels dropping over the edges can cause
rollovers, which may result in serious injury,
death, or drowning.
There is no rollover protection when the roll bar
is down.
Always keep the roll bar in the raised and locked
position, and use the seat belt.
Read and follow the rollover protection
instructions and warnings.
To avoid loss of control and the possibility of
rollover:
•Do not operate the machine near dropoffs or
near water.
•Do not operate the machine on slopes greater
than 15 degrees.
•Reduce the speed and use extreme caution on
slopes.
•Avoid sudden turns or rapid speed changes.
•Avoid operating the machine on wet grass.
2
3
1
m–6478
Figure 4
1. Safe Zone—use the
Z Master here on slopes
less than 15 degrees or
flat areas.
2. Use the walk behind
mower or hand trimmer
near dropoffs and water.
3. Water

6
