Toro 79348 User manual

Form No. 3465-733 Rev A
Powered T win Bagger
79348
Powered T win Bagger (Doppel-Heckfangsystem mit
Antrieb)
79348
Système de ramassage motorisé à deux bacs
79348
Aangedreven dubbele grasvanger
79348
www .T oro.com.
*3465-733*

Form No. 3465-721 Rev A
Powered T win Bagger
TIT AN
®
Zero-T urn-Radius Riding Mower
Model No. 79348 —Serial No. 400000000 and Up
Register at www .T oro.com.
Original Instructions (EN)
*3465-721*

W ARNING
CALIFORNIA
Proposition 65 W arning
Use of this product may cause exposure
to chemicals known to the State of
California to cause cancer , birth defects,
or other reproductive harm.
Introduction
Read this information carefully to learn how to operate
and maintain your product properly and to avoid
injury and product damage. Y ou are responsible for
operating the product properly and safely .
V isit www .T oro.com for product safety and operation
training materials, accessory information, help nding
a dealer , or to register your product.
Whenever you need service, genuine T oro parts, or
additional information, contact an Authorized Service
Dealer or T oro Customer Service and have the model
and serial numbers of your product ready . Figure 1
identies the location of the model and serial numbers
on the product. W rite the numbers in the space
provided.
g005673
Figure 1
1. Model and serial number location
Model No.
Serial No.
This manual uses 2 words to highlight information.
Important calls attention to special mechanical
information and Note emphasizes general information
worthy of special attention.
The safety-alert symbol ( Figure 2 ) appears both in
this manual and on the machine to identify important
safety messages that you must follow to avoid
accidents. This symbol will appear with the word
Danger ,W arning , or Caution .
•Danger indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury .
•W arning indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury .
•Caution indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderate injury .
sa-black
Figure 2
1. Safety-alert symbol
© 2023—The T oro® Company
81 1 1 L yndale A venue South
Bloomington, MN 55420
2
Contact us at www .T oro.com.
Printed in the USA
All Rights Reserved

Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
T owing Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety and Instructional Decals . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1 Preparing the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Installing the W eights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Removing the Grass Deector and Belt
Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Installing the Baf e and Blower
Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Installing the Pulley Assembly , Belt Cover ,
and Shoulder Bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1
6 Installing the Attachment Mount . . . . . . . . . . . . . . . . . . . . . . 1 1
7 Installing the Latch Rod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8 Assembling the Bagger T op . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9 Assembling the Grass Bags . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
10 Installing the Bagger T op . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1 1 Installing the Blower Assembly . . . . . . . . . . . . . . . . . . . . . 16
12 Installing the Blower Belt and Powered
Bagger Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
13 Preparing the Upper Discharge
T ube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
14 Installing the Discharge T ubes . . . . . . . . . . . . . . . . . . . . . 19
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Emptying the Grass Bags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Clearing Obstructions from the Bagger . . . . . . . . . . . . . 23
Removing the Bagger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Operating T ips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Recommended Maintenance Schedule(s) . . . . . . . . . . . 25
Preparing for Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning the Hood Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning the Bagger and Bags . . . . . . . . . . . . . . . . . . . . . . . . . 26
Inspecting the Blower Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Replacing the Blower Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Inspecting the Bagger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Inspecting the Mower Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Storing the Bagger Attachment . . . . . . . . . . . . . . . . . . . . . . . . . 27
T roubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Safety
W ARNING
When the bagger is in operation, the blower
is rotating and can cut off or injure hands and
ngers.
• Before adjusting, cleaning, repairing,
and inspecting the blower , and before
unclogging the chute, shut off the machine
and wait for all moving parts to stop.
Remove the key .
• Use a stick, not your hands, to remove an
obstruction from the blower and tube.
• Keep hands and feet away from moving
parts. Do not make adjustments with the
machine on.
W ARNING
Debris, such as leaves, grass, or brush can
catch re. A re in the engine area can cause
personal injury and property damage.
• Keep the engine and mufer area free of
debris accumulation.
• T ake care when opening the bagger cover
to keep debris from falling onto the engine
and mufer area.
• Allow the machine to cool before storing it.
•Become familiar with the safe operation of the
equipment, with the operator controls, and safety
signs.
•Use extra care with grass catchers or other
attachments. These can change the operating
characteristics and the stability of the machine.
•Follow the manufacturer's recommendations
for adding or removing wheel weights or
counterweights to improve stability .
•Do not use a grass catcher on steep slopes. A
heavy grass catcher could cause loss of control
or overturn the machine.
•Slow down and use extra care on hillsides. Be
sure to travel in the recommended direction on
hillsides. T urf conditions can af fect the stability of
the machine. Use extreme caution while operating
near drop-of fs.
•Keep all movement on slopes slow and gradual.
Do not make sudden changes in speed, direction,
or turning.
•The grass catcher can obstruct the view to the
rear . Use extra care when operating in reverse.
3

•Use care when loading or unloading the machine
into a trailer or truck.
•Never operate with the discharge deector raised,
removed or altered, unless using a grass catcher .
•Keep hands and feet away from moving parts. Do
not make adjustments with the machine on.
•Park the machine on level ground, disengage
the drives, chock the wheels, and shut of f the
machine before leaving the operator's position for
any reason including emptying the grass catcher
or unclogging the chute.
•If you remove the grass catcher , be sure to install
any discharge deector or guard that might have
been removed to install the grass catcher . Do not
operate the mower without either the entire grass
catcher or the grass deector in place.
•Shut of f the machine before removing the grass
catcher or unclogging the chute.
•Do not leave grass in the grass catcher for
extended periods of time.
•Grass catcher components are subject to wear ,
damage and deterioration, which could expose
you to moving parts or allow objects to be thrown.
Frequently check components and replace with
the manufacturer's recommended parts, when
necessary .
T owing Safety
•Do not attach towed equipment except at the hitch
point.
•Follow the attachment manufacturer's
recommendation for weight limits for towed
equipment and towing on slopes.
•Never allow children or others in or on towed
equipment.
•On slopes, the weight of the towed equipment may
cause loss of traction and loss of control. Reduce
towed weight and slow down.
•Stopping distance increases with the weight of the
towed load. T ravel slowly and allow extra distance
to stop.
•Make wide turns to keep the attachment clear of
the machine.
•Do not tow a load that weighs more than the
towing machine.
4

Safety and Instructional Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger . Replace any decal that is damaged or missing.
decal136-4164
136-4164
1. W arning—read the Operator ’ s Manual . 4. Cutting/dismemberment hazard, impeller—keep away from
moving parts; keep all guards and covers in place.
2. W arning—hearing protection must be worn.
5. Cutting/dismemberment hazard, impeller—disengage the
PT O, remove the key , and wait for all moving parts to stop.
3. Thrown object hazard—do not operate the blower without the
entire system installed and latched.
6. W arning; loss of traction—do not operate with only
counterbalance weights installed; do not operate with only
E-Z V ac installed; operate only with both E-Z V ac and
counterbalance weights installed.
decal109-6809
109-6809
1. Crushing hazard of hand—do not remove the whole bagger from the machine; open the bagger top and then remove the bag(s)
from the bagger . Do not remove the bagger top when it is closed; open the bagger top and then remove it.
decal133-8061
133-8061
5

Setup
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure Description
Qty .
Use
1
No parts required
–
Prepare the machine.
Left weight mount
1
Right weight mount 1
Bagger weight 3
Bolt (3/8 x 1 inch)
6
Bolt (3/8 x 2-3/4 inches)
2
W asher 2
2
Flange nut (3/8 inch)
8
Install the weights.
3
No parts required
–
Remove the grass deector and belt
cover .
Blower support 1
Hex washer-head screw (3/8 x 3/4 inch)
2
Baf e
1
Carriage bolt (5/16 x 3/4 inch)
44
Flange nut (5/16 inch)
4
Install the baf e and blower support.
Pulley assembly 15
Belt cover 1
Install the pulley assembly and belt
cover .
Stabilizer bracket
1
Bagger frame
1
Bolt (5/16 x 1 inch)
6
Locknut (5/16 inch)
6
Pivot frame
1
Long clevis pin 1
Hairpin 3
Clevis pin
2
Rod 2
6
W asher 2
Install the attachment mount.
Latch rod 17
Hairpin cotter 1
Install the latch rod.
Bagger top 1
Bagger screen 18
Hairpin cotter 2
Assemble the bagger top.
Bag frame
29
Grass bag
2
Assemble the grass bags.
10
Grass bag assembly
2 Install the bagger top.
1 1
Blower assembly 1 Install the blower assembly .
Powered bagger cover 112
Blower belt 1
Install the blower belt and powered
bagger cover .
13
Upper tube 1
Prepare the upper discharge tube
(Models with 48 inch and 54 inch decks
only).
6

Procedure Description
Qty .
Use
Upper tube 1
Screw (1/4 x 3/4 inches)
2
W asher (1/4 inch)
2
Locknut (1/4 inch)
214
Lower tube 1
Install the discharge tubes.
Determine the left and right sides of the machine from the normal operating position.
1
Preparing the Machine
No Parts Required
Procedure
Perform the following procedure to prepare the
machine for attaching the blower and nishing kit.
1. Park the machine on a level surface.
2. Disengage the blade-control switch, move
the motion-control levers outward to the
NEUTRAL -LOCK position.
3. Shut of f the machine and remove the key .
4. Ensure that the machine is secure from
movement before you begin to work on it.
5. For gas models, disconnect the spark plug. For
electric models, remove the battery packs.
6. Repair all bent or damaged areas of machine
deck and replace any missing parts.
7. Clean the machine of any debris on the machine
deck or rear part of the machine to ease
installation.
2
Installing the W eights
Parts needed for this procedure:
1
Left weight mount
1 Right weight mount
3 Bagger weight
6
Bolt (3/8 x 1 inch)
2
Bolt (3/8 x 2-3/4 inches)
2 W asher
8
Flange nut (3/8 inch)
Procedure
CAUTION
The bagger changes the weight distribution of
the machine. Operating the machine without
the front weights may cause an unstable
condition, which could result in a loss of
control.
Ensure that the front weights are properly
installed before operating the machine with
the bagger attachment.
1. Use 6 bolts (3/8 x 1 inch) and locknuts (3/8 inch)
to secure the left and right weight mounts to the
front of the machine as shown in Figure 3 .
7

g462067
Figure 3
1. Right weight-mount
3. Locknut (3/8 inch)
2. Bolt (3/8 x 1 inch) 4. Left weight-mount
2. Install the bagger weights (amount determined
by deck size) to the weight mounting bracketsto
the weight mounts with 2 bolts (3/8 x 2-3/4
inches), washers, and locknuts (3/8 inch) as
shown in Figure 4 .
Deck Size Plates Required*
48-inch 3
54-inch 2
60-inch 1
Important: Adjust the amount of weight
according to the size of the mower deck.
g462068
Figure 4
1. Bolt (3/8 x 2-3/4 inches)
3. Bagger weights
2. W asher
4. Locknut (3/8 inch)
3
Removing the Grass
Deector and Belt Cover
No Parts Required
Procedure
W ARNING
An uncovered discharge opening could allow
the machine to throw objects toward you or
bystanders and result in serious injury . Also,
contact with the blade could occur .
Never operate the lawn mower unless you
install a mulch plate, discharge deector , or
grass-collection system.
Inspect the grass deector for damage before each
use. Replace any damaged parts before use.
1. Set the height of cut at the lowest cutting
position.
2. Disengage the spring from the notch in the
deector bracket and remove the cotter pin (CE
models only), slide the rod out of the welded
deck brackets, spring, and discharge deector
(Figure 5 ).
Note: Y our chute may look dif ferent than the
one pictured.
8

g466323
Figure 5
1. Rod
4. Deector
2. Cotter pin (CE models
only)
5. Deck brackets
3. Spring 6. Spring installed over the
rod
3. Remove the deector ( Figure 5 ).
4. Pull up the side of the cover with the grommet
and slide the cover of f. ( Figure 6 ).
g454740
Figure 6
4
Installing the Bafe and
Blower Support
Parts needed for this procedure:
1 Blower support
2
Hex washer-head screw (3/8 x 3/4 inch)
1
Baf e
4
Carriage bolt (5/16 x 3/4 inch)
4
Flange nut (5/16 inch)
Procedure
1. Install the blower support to the mower deck
using 2 hex washer-head screws (3/8 x 3/4 inch)
as shown in Figure 7 .
g201299
Figure 7
1. Hex washer-head screw
(3/8 x 3/4 inch)
2. Blower support
9

2. Remove the existing bolt and nut from the
mower deck ( Figure 8 ).
Important: For 48-inch and 60-inch mower
decks, there is only one bolt and nut that you
can remove.
For 54-inch mower deck, remove the bolt and
nut as shown in Figure 8 .
g206498
Figure 8
1. Existing bolt 2. Existing nut
3. Install the left side of the baf e using a carriage
bolt (5/16 x 3/4 inch) and ange nut (5/16 inch)
as shown in Figure 9 .
4. Loosen the 2 carriage bolts (5/16 x 3/4 inch) in
the baf e slots, and slide the baf e until the hole
aligns with the hole in the mower deck ( Figure
9).
5. Install baf e as shown in Figure 9 .
Important: Ensure that you use the correct
hole for the bafe; refer to Figure 9 .
6. T ighten the 2 carriage bolts (5/16 x 3/4 inch) in
the baf e slots ( Figure 9 ).
g206496
Figure 9
54-inch mower deck shown
1. Inner baf e
6. Install this carriage bolt
(5/16 x 3/4 inch) and
ange nut (5/16 inch) after
sliding the baf e.
2. Hole for 48-inch and
60-inch mower deck
installation.
7. Slots in the baf e
3. Hole for 54-inch mower
deck installation.
8. Loosen these 2 carriage
bolts (5/16 x 3/4 inch) and
2 ange nut (5/16 inch).
4. Right blade 9. Install this carriage bolt
(5/16 x 3/4 inch) and
ange nut (5/16 inch) rst.
5. Outer baf e
10

5
Installing the Pulley
Assembly , Belt Cover ,
and Shoulder Bolt
Parts needed for this procedure:
1 Pulley assembly
1 Belt cover
Procedure
1. Remove the nut and washer from the right
mower deck pulley .
2. Install the pulley assembly to the right mower
deck pulley with the previously removed nut and
washer ( Figure 10 ).
Important: For 48-inch mower decks, use
the small blower pulley .
For 54-inch and 60-inch mower decks, use
the large blower pulley .
3. T orque the nut to 136 to 149 N∙m (100 to 1 10
ft-lb).
g201880
Figure 10
54-inch mower deck shown
1. Existing pulley nut
4. Existing deck (spindle)
pulley
2. Existing washer
5. Spindle
3. Blower pulley
4. Install the new belt cover over the pulley
assembly using the 4 previously removed
screws (1/4 x 1/2 inch) as shown in Figure 1 1 .
g201435
Figure 1 1
1. Belt cover
2. Screw (1/4 x 1/2 inch)
6
Installing the Attachment
Mount
Parts needed for this procedure:
1
Stabilizer bracket
1
Bagger frame
6
Bolt (5/16 x 1 inch)
6
Locknut (5/16 inch)
1
Pivot frame
1 Long clevis pin
3 Hairpin
2
Clevis pin
2 Rod
2 W asher
Procedure
1. Remove the existing 2 bolts, 2 nuts, and hitch
bracket from the bottom of the rear guard ( Figure
12 ).
1 1

g465961
Figure 12
1. Nut 3. Bolt
2. Existing hitch bracket
2. Install the stabilizer bracket to the rear guard
using 2 bolts (5/16 x 1 inch) and 2 locknuts (5/16
inch) as shown in Figure 13 .
g462070
Figure 13
1. Locknut (5/16 inch) 3. Bolt (5/16 x 1 inch)
2. Stabilizer bracket
3. Install the bagger mount bracket to the machine
as shown in Figure 14 .
g462069
Figure 14
1. Locknut (5/16 inch) 3. Bolt (5/16 x 1 inch)
2. Bagger mount bracket
4. Install the bagger frame to the bagger mount
bracket using the long clevis pin and a hairpin
(Figure 15 ).
g462458
Figure 15
1. Clevis pin 3. Bagger frame
2. Hairpin
5. Install the bent, ared end of a rod into the
keyed slot in the side of the machine frame, and
move the rod rearward to seat it in the frame
(Figure 16 ).
12

Note: Repeat this step for both sides of the
machine.
6. With the rod fully seated in the frame, adjust the
position of the clevis at the end of the rod so
it aligns with the tab on the side of the bagger
frame.
g462501
Figure 16
Left side shown
1. Rod fully seated in the
frame
2. Clevis adjusted to the side
of the bagger frame
7. Secure the ends of the rods to the bagger frame
as shown in Figure 16 and secure the end of
each rod with a clevis pin and a hairpin.
7
Installing the Latch Rod
Parts needed for this procedure:
1 Latch rod
1 Hairpin cotter
Procedure
Install the latch rod with a hairpin cotter ( Figure 17 ).
g465962
Figure 17
1. Hairpin cotter 3. Latch rod hole
2. Latch rod
13

8
Assembling the Bagger T op
Parts needed for this procedure:
1 Bagger top
1 Bagger screen
2 Hairpin cotter
Procedure
1. T urn the bagger top over .
2. Install the screen as shown in Figure 18 and
ensure that it slopes down toward the collection
bags.
Note: Make sure that the screens snap into
place and the tabs engage the bagger top.
g201881
Figure 18
1. Bagger top
4. Slot in bagger top
2. Screen
5. Hairpin cotter
3. Screen tab
14

9
Assembling the Grass Bags
Parts needed for this procedure:
2
Bag frame
2
Grass bag
Procedure
Snap the 2 bag frames to the 2 grass bags.
g453040
Figure 19
10
Installing the Bagger T op
Parts needed for this procedure:
2
Grass bag assembly
Procedure
1. Install the bagger top to the bagger frame.
Note: Y our bagger may look dif ferent than the
one shown.
2. Slide the brackets over the posts in the bagger
frame and install the circular cotter pin into the
hole in the right hand post ( Figure 20 ).
3. Rotate the bagger hood down to the operating
position.
Note: T o remove the circular cotter pin,
continue to rotate it in the same direction as
installed.
g016265
Figure 20
1. Bagger hood
4. Circular cotter pin
2. Bagger frame
5. Post
3. Bracket, bagger hood
15

4. Lift the bagger top and install the bags
assembled in 9 Assembling the Grass Bags
( page 15 ) by sliding the bag frame hooks onto
the retaining brackets ( Figure 21 ).
g300378
Figure 21
5. Lower the bagger top onto the bags ( Figure 22 ).
g033030
Figure 22
6. Secure the hood with the latch ( Figure 22 ).
1 1Installing the Blower
Assembly
Parts needed for this procedure:
1 Blower assembly
Procedure
W ARNING
An uncovered discharge opening allows the
lawn mower to throw objects toward you or
bystanders, resulting in serious injury . Also,
contact with the blade could occur .
• Never operate the lawn mower without a
cover plate, a mulch plate, or a grass chute
and catcher .
• Make sure that the grass deector is
installed when you remove the grass chute
and catcher .
Important: Install the side-discharge chute when
you remove the bagger and blower .
Important: Save all the hardware and the
side-discharge chute.
1. If necessary , install the belt onto the blower
pulley ( Figure 25 ).
2. Insert the blower pivot pin into the blower
support and rotate the blower assembly inward
toward the machine ( Figure 23 ).
Note: The blower assembly should
automatically latch as shown in Figure 24 .
16

g201514
Figure 23
1. Blower assembly 3. Blower support
2. Blower pivot pin
g201893
Figure 24
1. Blower latch
12
Installing the Blower Belt
and Powered Bagger Cover
Parts needed for this procedure:
1 Powered bagger cover
1 Blower belt
Procedure
1. Install the belt around the blower pulley ( Figure
25 and Figure 26 ); refer to 1 1 Installing the
Blower Assembly ( page 16 ) .
Use the following belt based on the mower
deck size:
48-inch Mower
Deck
54-inch Mower
Deck
60-inch Mower
Deck
T oro Part No.
127-0074
T oro Part No.
127-0075
T oro Part No.
127-0076
g201516
Figure 25
Blower Belt Routing
1. Idler/tension pulley
3. Blower belt
2. Blower pulley 4. Drive pulley
17

g201513
Figure 26
1. Blower pulley 5. Idler arm
2. Blower in position (housing
portion removed for
illustrative purposes)
6. Drive pulley
3. Spring 7. Idler/tension pulley
4. Idler-pulley post 8. Blower belt
2. Ensure that the belt remains aligned to the
blower pulley while you are installing the blower
assembly .
3. Pull the spring loaded idler pulley away from the
xed spring post, and route the belt around the
mower deck pulley ( Figure 26 ).
Note: Ensure that the belt is routed around the
blower pulley correctly .
4. Route the belt around the drive pulley as
illustrated in Figure 25 and Figure 26 .
5. Install the powered bagger cover over the belt
cover , and secure it by tightening the knob
(Figure 27 ).
g201515
Figure 27
1. Knob 3. Belt cover
2. Powered bagger cover
18
