Toro Groundsmaster e3200 User manual

Form No. 3464-802 Rev A
Recycler Kit
Groundsmaster
®
e3200 T raction Unit with 60in Side Discharge
Rotary Mower
Model No. 32319
Installation Instructions
1
Preparing the Machine
No Parts Required
Procedure
1. Park the machine on a level surface.
2. Engage the parking brake.
3. Raise the mower deck to the T RANSPORT
position; refer to your Operator ’ s Manual .
4. Shut of f the engine and remove the key .
5. T urn the battery-disconnect switch to the O FF
position; refer to the traction unit Operator ’ s
Manual .
6. Rotate the mower deck to the S ERVICE position;
refer to your Operator ’ s Manual .
2
Removing the Standard
Blades
No Parts Required
Procedure
1. Place a wrench on the at of the blade retainer
or hold the blade end using a rag or thickly
padded glove.
2. Remove the blade bolt, washer , and blade from
the spindle shaft.
Important: Retain the parts for later
installation.
g376322
Figure 1
1. Blade retainer 3. W asher
2. Standard blade
4. Blade bolt
© 2023—The T oro® Company
81 1 1 L yndale A venue South
Bloomington, MN 55420
Register at www .T oro.com.
Original Instructions (EN)
Printed in the USA
All Rights Reserved
*3464-802*

3
Removing the Existing Bafes
No Parts Required
Procedure
Note: In the steps below , the bolts are threaded into the mower deck. Remove the nuts before removing the
bolts.
1. Remove the 2 ange nuts that secure the baf es in place ( Figure 2 ).
2. Remove the 2 bolts and 2 nuts from the adjustable ow baf e ( Figure 2 ).
3. Remove the 3 bolts and 3 nuts that secure the baf es in place ( Figure 2 ).
Note: Retain the baf es and fasteners for use when changing back to side-discharge mode.
g455051
Figure 2
2

4
Installing the Discharge
Cover Plate
Parts needed for this procedure:
1 Discharge cover plate
1
Carriage bolt (5/16 x 7/8 inch)
1
Flange nut (5/16 inch)
2
Carriage bolt (3/8 x 1-1/4 inches)
2
Locknut (3/8 inch)
Procedure
1. Secure the discharge cover plate to the outside
of the mounting bracket using 2 carriage bolts
(3/8 x 1-1/4 inches) and 2 locknuts (3/8 inch) as
shown in Figure 3 .
2. Secure the tab to the inside of the mower deck
using 1 carriage bolt (5/16 x 7/8 inch) and 1
ange nut (5/16 inch) as shown in Figure 3 .
g306390
Figure 3
1. Discharge cover plate
4. Carriage bolt (5/16 x 7/8
inch)
2. Carriage bolt (3/8 x 1-1/4
inches)
5. Locknut (3/8 inch)
3. T ab on the discharge cover
plate
6. Flange nut (5/16 inch)
5
Installing the Recycler
Bafes
Parts needed for this procedure:
1
Left baf e
1
Center baf e
1
Right baf e
8
Carriage bolt (3/8 x 1 inch)
8
Locknut (3/8 inch)
Procedure
Note: Loosely install the baf es to align the baf es
with all the holes in the mower deck ( Figure 4 ).
1. Position the right baf e into the mower deck.
2. Loosely install the right baf e to the discharge
plate using 1 carriage bolt (3/8 x 1 inch) and 1
locknut (3/8 inch) as shown in Figure 4 .
3. Loosely install the right baf e to the mower
deck using 2 carriage bolts (3/8 x 1 inch) and 2
locknuts (3/8 inch) as shown in Figure 4 .
4. Position the left baf e into the mower deck.
5. Loosely install the left baf e to the mower deck
using 2 carriage bolts (3/8 x 1 inch) and 2
locknuts (3/8 inch) as shown in Figure 4 .
6. Position the center baf e into the mower deck.
7. Loosely install the center baf e to the right baf e
and left baf e using 2 carriage bolts (3/8 x 1 inch)
and 2 locknuts (3/8 inch) as shown in Figure 4 .
8. Loosely install the center baf e to the mower
deck using 1 carriage bolt (3/8 x 1 inch) and 1
locknut (3/8 inch) as shown in Figure 4 .
3

g455052
Figure 4
1. Right baf e 4. Carriage bolt (3/8 x 1 inch)
2. Center baf e 5. Locknut (3/8 inch)
3. Left baf e
4

6
Installing the Recycler
Blades
No Parts Required
Procedure
Install the recycler blade, washer , and blade bolt and
tighten the blade bolt to 68 to 81 N∙m (50 to 60 ft-lb)
as shown in Figure 5 .
Important: Ensure that the washer is oriented as
shown to ensure proper cutting.
Important: The curved sail of the blade must
point up to ensure proper cutting.
g376321
Figure 5
1. Blade retainer 3. W asher
2. Recycler blade 4. Blade bolt
7
T ightening the Fasteners
No Parts Required
Procedure
W ARNING
When servicing the blade, the blade can still
move even though the power source is off.
The blade is sharp; contacting the blade can
result in serious personal injury .
• Keep your hands and feet away from a
moving blade.
• W ear gloves when servicing the blade.
1. T ighten all nuts and bolts for the baf es.
2. Rotate the blades and ensure that there is
clearance between the blades and the baf es.
If there is not, loosen the baf e(s) until there is
clearance and then secure the baf e(s).
8
Completing the Installation
No Parts Required
Procedure
Rotate the mower deck to the M OWING position; refer
to your Operator ’ s Manual .
5

9
Converting Back to Side
Discharge
No Parts Required
Procedure
1. Park the machine on a level surface.
2. Engage the parking brake.
3. Raise the mower deck to the T RANSPORT
position; refer to your Operator ’ s Manual .
4. Shut of f the engine and remove the key .
5. Rotate the mower deck to the S ERVICE position;
refer to your Operator ’ s Manual .
6. Remove the recycler baf es and blades.
Note: Retain the fasteners, baf es, and blades
for use when changing back to recycler mode.
7. Replace the recycler blades with standard
blades; tighten the blade bolt to 68 to 81 N∙m
(50 to 60 ft-lb).
8. Install the side-discharge baf es and fasteners.
Note: Y ou must plug all open holes to prevent
sand and/or other small objects from being
thrown up through the deck.
6
