Toro Groundsmaster 360 Series User manual

FormNo.3369-161RevA
RegistrationPlateKit
Groundsmaster®360SeriesMulti-PurposeMachine
ModelNo.120-6678
InstallationInstructions
Note:TheGroundsmaster360SeriesMulti-Purpose
MachinemustbeequippedwiththeLightKit,Model
30512or30516tooperatetheRegistrationPlateKit
Light.
1.Positionthemachineonalevelsurface,stopthe
engine,removetheignitionkeyandengagethe
parkingbrake.
CAUTION
Ifyouleavethekeyintheignitionswitch,
someonecouldaccidentlystarttheengineand
seriouslyinjureyouorotherbystanders.
Removethekeyfromtheignitionswitchbefore
youdoanymaintenance.
Figure1
1.Registrationplatebracket6.Flangeheadnut,5/16inch
2.Screws,#10x5/8inch7.Treebracket
3.Platelight8.Plastictreeplug(shownremovedforclarity)
4.Flangeheadscrew,5/16x.613inch9.Wireharness
5.Locknut,#1010.Drilla13mmdiameterholehere
2.Centeringtheregistrationplatebracketontherear
ofthehood,useitasatemplatetolocate,mark
anddrill(2)9mmdiameterholesthroughthehood
(Figure1).
3.AttheapproximatelocationshowninFigure1,mark
anddrilla13mmdiameterholethroughtheinterior
wallofthehood,nearthesealbracket.
4.Routethebulletconnectorendofthewireharness
throughthedrilledhole.
©2011—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved

5.Installatreebracketontoeachoftheharnessclips
(Figure1).
6.Routethewireharnessalongthetopleftsideof
thehoodwhilepluggingthetreebracketsontothe
hoodsexistingplastictreeplugs(Figure1).
7.Drilla13mmholeinthehoodscreentoallowthe
connectoroftheregistrationplatelightwireharness
topassthroughtothelight.Theholeinthehood
screenshouldbealignedwiththewireaccessholein
therearplateassemblyafteritismounted.
8.Mounttherearplateassemblytotherearofthe
hoodwith(2)5/16x.613inchangeheadscrews
and5/16angeheadnuts(Figure1).
9.Routetheharnessthroughtheholeinthehood
screenandtherearplateassembly(Figure1).
10.Plugthewireharnessconnectorintotherearplate
lamp(Figure1).
11.Mounttheplatelighttotheregistrationplatebracket
with(2)#10x5/8inchscrewsand#10locknuts
(Figure1).Donotovertighten.Makesurethelens
pointsdownwardandthewiresareinsertedthrough
theholeintheplatemount.
12.Connecttheregistrationplatelightwireharnessto
theexistinglightkitharness.
Important:Makesurethewireharnessisclear
ofallhot,sharpormovingcomponents.
13.Checktheoperationoftheregistrationplatelight.
Theplatelightshouldilluminatewhenthelightsare
turnedONandthekeyisintheRUNposition.
