FormNo.3430-702RevA

ElectricLiftKit

Workman®GTXUtilityVehiclewithExtendedBed

ModelNo.07167—SerialNo.404400001andUp

ModelNo.07168—SerialNo.404400001andUp

InstallationInstructions

Important:YoumustinstallthiskitinconjunctionwiththeExtendedBedKit(ToroModelNo.07149).

Important:WhenyouhavetheElectricLiftKitinstalledontheextendedbed,donotexceed181kg

(400lb)whenliftingacenteredload;otherwisedamagemayoccur.

Ifyoucentertheloadtowardthefrontofthecargobed,theliftcapacitydecreases.

Important:WheninstallingtheElectricLiftKit,useanoverheadhoisttoraisetheextendedcargobed

(Figure1).

g037510

Figure1

©2019—TheToro®Company

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3430-702*A

PreparingtheMachine

1.Parkthemachineonalevelsurface.

2.Engagetheparkingbrake.

3.Shutofftheengineandremovethekey.

g038563

2

InstallingtheLiftBracket

1x5x5x

Important:Theextendedcargobedisremovedfromthegureforclarity;donotremovetheextended

cargobed.

1.Removetheexistingboltandnutfromtherear-frametube.

Note:Discardtheboltandnut.

2.Removethe2existingplasticrivetsfromtherear-frametube.

Note:Retainthe2plasticrivets.

3.Installtheliftbrackettotherear-frametubeusingthe5ange-headbolts(3/8x2-1/2inches)and5

angenuts(3/8inch).

4.Installthe2previouslyremovedplasticrivetsintotherear-frametube.

g281201

3

InstallingtheActuatorStop

ElectricMachineOnly

1x1x1x

Installtheactuatorstoptothebatterytraymountingbracketusingtheboltandnut.

g037512

ElectricMachineShown

4

InstallingtheFuse

ForMachineswithSerialNumber403446000andBefore

1x

Installthe15Afuseintothefuseblock.

g281197

GasolineMachineShownonTop;ElectricMachineShownonBottom

5

ForMachineswithSerialNumber403446001andAfter

1x

Installthe15Afuseintothefuseblock.

g281196

GasolineMachineShownonTop;ElectricMachineShownonBottom

6

InstallingtheSwitch

1x

1.Removetheplasticcoverfromthedashboard.

Note:Discardtheplasticcover.

2.Installtheswitchconnectorthroughtheopeninginthedashboard.

3.Installtheswitchtotheswitchconnector.

4.Ensurethattheswitchisorientedproperly.

g037514

7

InstallingtheLiftCylinder

1x2x2x1x

Important:Usethecabletietosecurethelift-cylinderwiretothewireharness,awayfromsharpor

movingparts.Ensurethatyouallowenoughslackinthewireharnessforitsfullrangeofmotion.

1.Installtheliftcylinderusingaclevispinandhairpincotter.

2.Connectthewireharnessandsecureittothemachinerailusingthecabletie.

3.Rotatetheliftcylinderupwardtoa45°angle,thenuseablocktosupporttheliftcylinder.

4.Pressupwardontheswitchtoextendtheliftcylinder.

5.Installtheextendedportionoftheliftcylindertothecargobedusingaclevispinandhairpincotter.

g037515

8

Important:Useablocktosupporttheliftcylindersothatitextendsupwardata45°angle.

g038792

9

Operation

WARNING

Drivingthemachinewiththecargoboxraisedmaycausethemachinetotiporrolleasier.The

boxstructuremaybecomedamagedifyouoperatethemachinewiththeboxraised.

•Operatethemachineonlywhenthecargoboxisdown.

•Afterdumpingthecontentsinthecargobox,lowerthebox.

CAUTION

Theweightoftheboxmaybeheavy.Handsorotherbodypartscouldbecrushed.

Keephandsandotherbodypartsclearwhenloweringthebox.

RaisingandLoweringtheBed

Pressupwardontheswitchtoraisethebed.

Pressdownwardontheswitchtolowerthebed.

g037516

10
