Torque X-CREATE WALL SPACE User manual

X-CREATE WALL SPACE
Assembly Guide
PART # 5615201-B

NOTE:
X-CREATE Wall Space Systems can be customized in countless ways. This
manualprovides instructions for assembling base units, module options and
attachment options. If you worked with Torque X-Team Design during the
purchasing process, please request a Bill of Material Drawing to reference your
exact set-up. For assistance, contact [email protected] or call
[phone]; Toll free in USA [phone].
NOTE:
When assembling any X-CREATE System that is longer than one module wide,
the hardware will shared between two side by side modules and pull-up bars.
It is recommended to keep all bolt connections loose until the base system and
all of the module stations have been assembled. Securely tighten all frame
connections at this time, and then proceed to the attachment options.
Attachment options can be securely tightened as they are assembled.
TOOLS FOR ASSEMBLY:
3/8" ALLEN WRENCH •
5/16" ALLEN WRENCH •
3/16" ALLEN WRENCH •
3/4" WRENCH OR SOCKET •
9/16" WRENCH OR SOCKET •
1/2" WRENCH OR SOCKET •
RUBBER MALLET •
TABLE OF CONTENTS
ONE MODULE ASSEMBLY: PAGE 3 1.
MODULE ASSEMBLY 2.
8' UPRIGHT EXTENSION MODULE: PAGE 6 •
STORAGE MODULE: PAGES 8-11 •
STALL BAR MODULE: PAGE 13 •
BALL & HANGING STORAGE MODULE: PAGES 15-18 •
BALL TARGET WALL MODULE: PAGE 20 •
8' OLYMPIC LIFTING STATION MODULE: PAGES 22-25 •
ATTACHMENT ASSEMBLY 3.
BALL & HANGING STORAGE EXTENSION: PAGE 28 •
BATTLE ROPE ANCHOR: PAGE 29 •
HANGING STORAGE HOOK: PAGE 30 •
DOUBLE PLAY: PAGE 31 •
HORIZONTAL MOUNT GROUND ROTATIONAL TRAINER: PAGE 32 •
3-DIMENSIONAL SWIVEL: PAGES 33-34 •
BALL TARGET: PAGES 35-37 •
RESISTANCE BAND ANCHOR: PAGE 38 •
VERTICAL DUMBBELL RACK 4 PAIR: PAGE 39 •
ENDLESS ROPE DRUM (UPRIGHT): PAGES 40-41 •
ATTACHMENT ANCHOR: PAGE 42 •
DIP ATTACHMENT: PAGE 43 •
PLYO STEP: PAGE 44 •
ANCHORING: PAGE 45 4.
URETHANE BOOT: PAGE 46 5.
WARNING!
ALL X-CREATE ARE REQUIRED TO BE ANCHORED TO THE
FLOOR TO PREVENT ROCKING OR TIPPING DURING USE.
2

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U (2)
XCREATE-4SX (2)
NOTE:
REMOVE END CAPS PRIOR TO ASSEMBLY.
RE-ATTACH END CAPS AFTER ASSEMBLY (2)
NOTE:
URETHANE BOOTS
WILL BE ASSEMBLED
IN THE LAST STEP
NOTE:
MAKE SURE TO USE PRE-
INSTALLED SPACERS (4)
1/2" FLAT WASHER (8)
(PRE-INSTALLED)
1/2 X 4-3/4" BOLT (4)
(PRE-INSTALLED)
1/2" LOCK NUT (4)
(PRE-INSTALLED)
3
ONE MODULE
ASSEMBLY
NOTE:
LOOSELY assemble bolt connections in this step.
If more than one module will be assemble, refer to PAGE 6 .

8' UPRIGHT
EXTENSION MODULE
STORAGE MODULE STALL BAR MODULE
BALL & HANGING
STORAGE MODULE
BALL TARGET WALL MODULE
8' OLYMPIC LIFTING
STATION MODULE
4
MODULES

XCREATE-4SX (2X)
XCREATE-8U
5
8' UPRIGHT EXTENSION MODULE

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U
XCREATE-4SX
NOTE:
MAKE SURE TO USE PRE-
INSTALLED SPACERS (4)
NOTE:
REMOVE END CAP
PRIOR TO ASSEMBLY.
RE-ATTACH END CAP
AFTER ASSEMBLY (2)
1/2 X 4-3/4" BOLT (4)
PRE-INSTALLED
1/2" FLAT WASHER (8)
PRE-INSTALLED
1/2" LOCK NUT (4)
PRE-INSTALLED
8' UPRIGHT EXTENSION MODULE
6
NOTE:
LOOSELY assemble bolt connections in this step.
Repeat this step for as many modules there are to assemble.

XCREATE-4BS
XCREATE-4AT (4)
STORAGE MODULE
7

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
1/2" LOCK NUT (16)
1/2" FLAT WASHER (32)
1/2 X 4-1/4"
BOLT (16)
XCREATE-8U (2)
XCREATE-4AT (4)
NOTE:
LOOSELY assemble bolt connections in this step.
8
STORAGE MODULE

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
END BRACKET (2)
1/2 X 4-1/4" BOLT (4)
1/2" FLAT WASHER (8)
1/2" LOCK
NUT (4)
XCREATE-8U
9
STORAGE MODULE
NOTE:
LOOSELY assemble bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
RAIL (2)
END BRACKET (2)
3/8 X 1-1/4" BOLT (4)
3/8" FLAT WASHER (4)
NOTE:
RAILS ARE ASSEMBLED
FOR STABILITY BALL WIDTH.
RAILS CAN BE BOLTED TO
NARROWER HOLES FOR
SMALLER ACCESSORIES
10
STORAGE MODULE
NOTE:
If more modules will be assembled, do not tighten bolts at this time.

XCREATE-4AT (4)
ACCESSORY LABEL
3/8"
1-3/4"
ATTACH DESIRED
LABEL TO EACH
ACCESSORY TRAY
11
STORAGE MODULE
NOTE:
If you are a professional contractor installing this system for a facility,
leave these labels and instruction with manager or inquire what label
to attach to each accessory tray.

12
STALL BAR MODULE

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U (2)
1/2 X 4-1/4" BOLT (20)
1/2" FLAT WASHER (40)
1/2" LOCK NUT (20)
XCREATE-4SB (2)
13
STALL BAR MODULE
NOTE:
If more modules will be assembled, do not tighten bolts at this time.

14
BALL & HANGING STORAGE MODULE

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U (2)
END BRACKET (2)
1/2 X 4-1/4" BOLT (4)
1/2" FLAT WASHER (8)
1/2" LOCK
NUT (4)
15
BALL & HANGING STORAGE MODULE
NOTE:
LOOSELY assemble bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
RAIL (2)
END BRACKET (2)
3/8 X 1-1/4" BOLT (4)
3/8" FLAT WASHER (4)
NOTE:
RAILS ARE ASSEMBLED
FOR STABILITY BALL WIDTH.
RAILS CAN BE BOLTED TO
NARROWER HOLES FOR
SMALLER ACCESSORIES
NOTE:
LOOSELY assemble bolt connections in this step.
BALL & HANGING STORAGE MODULE
16

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
END BRACKET (2)
4' HANGING
STORAGE
3/8 X 1-1/4" BOLT (4)
3/8" FLAT WASHER (4)
NOTE SLOT
ORIENTATION
17
BALL & HANGING STORAGE MODULE
NOTE:
After this step has been completed SECURELY tighten all bolt
connections made to this point.
If more modules will be assembled, do not tighten bolts at this time.
Some parts have been hidden for assembly clarity.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
4' HANGING STORAGE
MAT STORAGE PIN (2)
ACCESSORY HOLDER PIN (3)
3/8" FLAT WASHER (10)
3/8" LOCK NUT (5)
BEFORE TIGHTENING NUT,
ADJUST MAT STORAGE
PIN TO DESIRED POSITION
BALL & HANGING STORAGE MODULE
18
NOTE:
SECURELY tighten connections in this step.

BALL TARGET WALL MODULE
19

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE-8U (2)
XCREATE-4BTW
1/2 X 4-1/4" BOLT (20)
1/2" FLAT WASHER (40)
1/2" LOCK
NUT (20)
NOTE:
If more modules will be assembled, do not tighten bolts at this time.
BALL TARGET WALL MODULE
20
