Torque XCREATE-4LPDM User manual

ASSEMBLY INSTRUCTIONS
PART # 5675901-A
4 FT (1.2 M) LAT PULLDOWN MODULE
VERSION: XCREATE-4LPDM

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ITEM PART NUMBER DESCRIPTION QTY
1 5642301 WLDMT, BASE SUPPORT 1
2 5581301 COVER, FRONT BASE 1
3 56443PA PTD ASSY, TOP BOOM SUPPORT 1
4 2001301 WASHER, FLAT 1/2 SAE ST ZN 32
5 2005816 BOLT, 1/2-13 X 4-1/4" (108mm) SOCKET HEAD 12
6 2001401 NUT, 1/2-13 LK ST ZN 15
7 5645301 WLDMT, LAT BASE 1
8 56468PA PTD ASSY, LAT FRONT UPRIGHT 1
9 2005815 BOLT, 1/2-13 X 4" (102mm) SOCKET HEAD 2
10 5513601 CUSHION, WEIGHT STACK 2
11 5643201 GUIDE ROD, 19 DIA X 1912 2
12 56351PA PTD ASSY, 20 LB WEIGHT PLATE 5
13 56350PA PTD ASSY, 15 LB WEIGHT PLATE 10
14 56345PA PTD ASSY, HEAD PLATE 1
15 5095301 SHAFT COLLAR, GUIDE ROD 2
16 5667301 BUSHING, GUIDE ROD RETAINER 2
17 55181PA PTD ASSY, WEIGHT SELECTOR STORAGE PLATE 1
18 2009402 BOLT, 3/8-16 X 3/4" (19mm) ST HT SOCKET HEAD W/NP 2
19 56459PA PTD ASSY, LAT TOP BOOM 1
20 2006803 BOLT, 1/2-13 X 1" (25mm) SOCKET HEAD W/NP 2
21 2001101 WASHER, FLAT 3/8 SAE ST ZN 16
22 2009418 BOLT, 3/8-16 X 4-3/4" (121mm) ST HT SOCKET HEAD W/NP 2
23 56475PA PTD ASSY, KNEE HOLD DOWN 1
24 2005821 BOLT, 1/2-13 X 5-1/2" (140mm) SOCKET HEAD 1
25 5454901 PAD, TAPPERED SEAT 1
26 2009404 BOLT, 3/8-16 X 1-1/4" (32mm) ST HT SOCKET HEAD W/NP 2
27 5675301 LABEL, WEIGHT STACK 15-265 LB (6.8-120.2 KG) 1
28 5662501 WLDMT, LEFT SHROUD BASE 1
29 2008414 BOLT, 3/8-16 X 3-3/4" (95mm) ST HT SOCKET HEAD 4
30 2001201 NUT, 3/8-16 LK ST ZN 4
31 5662901 WLDMT, RIGHT SHROUD BASE 1
32 5645101 SHROUD, XCREATE CABLE STATION 2
33 5664701 SHROUD, TOP CAP 1
34 2002101 WASHER, FLAT 1/4 SAE ST ZN 8
35 2006502 BOLT, 1/4-20 X 1/2" (13mm) SOCKET HEAD W/NP 6
36 5676201 PLACARD, XCREATE-LPD-101 1
37 2005509 BOLT, 1/4-20 X 3/8" (9mm) SOCKET HEAD 2
ITEM PART NUMBER DESCRIPTION QTY
38 5674701 ASSY, ALUMINUM LAT BAR 1
39 5091801 SNAP HOOK, 8MM DIA X 80MM 1
40 5692601 WLDMT, XCREATE REAR SHROUD (OPTIONAL) 1
41 2009403 BOLT, 3/8-16 X 1" (25mm) ST HT SOCKET HEAD W/NP 4
NOTE:
X-CREATE CABLE STATIONS can be customized in many ways. This
manual provides instructions for assembling a single stand-alone unit.
If you worked with Torque X-Team Design during the purchasing process,
please request a Bill of Material Drawing to reference your exact set-up.
For assistance, contact [email protected] or call
[phone]; Toll free in USA [phone].
NOTE:
When assembling any X-CREATE CABLE STATIONS that is longer than
one module wide, the hardware will be shared between two side-by-side
modules. It is recommended to keep all bolt connections loose until all the
cable stations have been fully assembled, then securely tighten all frame
connections.
TOOLS FOR ASSEMBLY:
3/8" ALLEN WRENCH •
5/16" ALLEN WRENCH •
3/16" ALLEN WRENCH •
3/4" WRENCH OR SOCKET •
9/16" WRENCH OR SOCKET •
1/2" WRENCH OR SOCKET •
RUBBER MALLET •
2

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
XCREATE UPRIGHT (2)
(SEE NOTE)
TOP BOOM SUPPORT
BASE SUPPORT
1/2 X 4-1/4" BOLT (8)
1/2" FLAT WASHER (16)
1/2" LOCK NUT (8)
3
STEP 1
NOTES:
LOOSELY tighten bolt connections in this step.
The XCREATE-LPD is shown assembled to the XCREATE-7U.
However, the XCREATE-LPD can also be assembled to the
XCREATE-8U and XCREATE-2S8U the same way.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LAT BASE
BASE SUPPORT
1/2 X 4-1/4" BOLT (2) 1/2" FLAT WASHER (4)
1/2" LOCK
NUT (2)
NOTE:
DO NOT TIGHTEN THESE
BOLTS AT THIS TIME
NOTE:
DO NOT TIGHTEN
THESE BOLTS AT THIS TIME
NOTE:
IF ASSEMBLING CABLE STATIONS BACK TO BACK, PLEASE
NOTE THAT THEY SHARE THE SAME BASE SUPPORT AND
HARDWARE AS SHOWN. BOTH LAT BASES NEED TO BE
ASSEMBLED SIMULTANEOUSLY
STEP 2
4
NOTES:
SECURELY tighten bolt connections in this step and previous step,
except as noted.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LAT BASE
3/8 X 4-3/4"
BOLT (2)
3/8" FLAT WASHER (2)
5
STEP 3
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LEFT SHROUD BASE
BASE SUPPORT
3/8 X 3-3/4" BOLT (2)
3/8" FLAT WASHER (4)
3/8" LOCK NUT (2)
6
STEP 4
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
BASE SUPPORT
RIGHT SHROUD BASE
3/8 X 3-3/4" BOLT (2)
3/8" FLAT WASHER (4)
3/8" LOCK NUT (2)
STEP 5
7
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LAT FRONT UPRIGHT
LAT BASE
1/2" FLAT WASHER (4)
1/2 X 4" BOLT (2)
1/2" LOCK NUT (2)
8
STEP 6
NOTES:
LOOSELY tighten bolt connections in this step.
Right upright has been hidden for illustration clarity.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
WEIGHT STACK CUSION (2)
20 LB WEIGHT PLATE (5)
15 LB WEIGHT PLATE (10)
HEAD PLATE
SHAFT COLLAR (2)
GUIDE ROD RETAINER (2)
LAT BASE
NOTE:
INSERT GUIDE RODS THROUGH THE
LAT BASE AND DOWN TO TOP OF BOLTS
9
STEP 7
NOTES:
Some parts have been hidden for illustration clarity.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
3/8 X 3/4" BOLT (2)
WEIGHT SELECTOR
STORAGE PLATE
STEM
HEAD PLATE
10
STEP 8
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LAT TOP BOOM
1/2 X 4-1/4" BOLT (2)
1/2" FLAT WASHER (4)
TOP BOOM SUPPORT
1/2" LOCK NUT (2)
NOTE:
IF ASSEMBLING CABLE STATIONS BACK TO BACK, PLEASE
NOTE THAT THEY SHARE THE SAME TOP BOOM SUPPORT
AND HARDWARE AS SHOWN. BOTH LAT TOP BOOMS NEED
TO BE ASSEMBLED SIMULTANEOUSLY
11
STEP 9
NOTES:
LOOSELY tighten connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
NOTE:
SECURELY TIGHTEN THESE BOLTS (4)
NOTE:
SECURELY TIGHTEN THESE BOLTS (2)
NOTE:
SECURELY TIGHTEN THESE BOLTS (2)
LAT TOP BOOM
1/2" FLAT WASHER (2)
1/2 X 1" BOLT (2)
NOTE:
SECURELY TIGHTEN THESE BOLTS (2)
LAT FRONT UPRIGHT
12
STEP 10
NOTES:
SECURELY tighten bolt connections as shown.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
NOTE:
SLIDE THE GUIDE ROD RETAINERS UP INSIDE THE
LAT TOP BOOM. SLIDE THE SHAFT COLLARS UP INSIDE
OF THE GUIDE ROD RETAINERS AND SECURELY
TIGHTEN THE SET SCREWS OF THE SHAFT COLLARS
GUIDE ROD (2)
SHAFT COLLAR (2)
LAT TOP BOOM
GUIDE ROD RETAINER (2)
13
STEP 11
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
STORAGE FOR WEIGHT
STACK SELECTOR PIN
THREADED END
JAM NUT
HEAD PLATE
STEM
SWIVEL
PULLEY
HOUSING
NOTE:
ATTACH THE WEIGHT STACK
LABELS TO THE WEIGHT STACK
STARTING WITH THE HEAD
PLATE
NOTE:
THE HOUSING ON THE CABLE SHOULD BE AT
LEAST 1/2" AWAY FROM THE SWIVEL PULLEY.
IF THE HOUSING IS TOUCHING THE SWIVEL
PULLEY, THEN THE CABLE NEEDS TO BE
ADJUSTED. LOOSEN JAM NUT AND TURN THE
THREADED END OF THE CABLE COUNTER
CLOCKWISE UNTIL THE HOUSING IS 1/2" AWAY
FROM THE SWIVEL PULLEY. SECURELY
TIGHTEN JAM NUT.
NOTE:
THREAD THE CABLE END INTO THE
STEM OF THE HEAD PLATE UNTIL
THE HOUSING IS APPROXIMATELY
1/2" AWAY FROM THE SWIVEL PULLEY,
THEN SECURELY TIGHTEN THE JAM
NUT. SEE NOTE ABOVE
14
STEP 12
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LAT FRONT UPRIGHT
SPRING
PIN HOLE
1/2 X 5-1/2" BOLT
KNEE HOLD DOWN
NOTE:
PULL SPRING PIN OUT TO
ASSEMBLE THE KNEE HOLD
DOWN. RELEASE THE SPRING
PIN INTO THE DESIRED HOLE
ON THE LAT FRONT UPRIGHT
1/2" LOCK NUT
1/2" FLAT
WASHER (2)
15
STEP 13
NOTES:
SECURELY tighten bolt connections in this step.
LEFT UPRIGHT has been hidden for illustration clarity.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TAPERED SEAT
3/8" FLAT WASHER (2)
3/8" X 1-1/4" BOLT (2)
LAT BASE
16
STEP 14
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
FRONT SHROUD (2)
LEFT SHROUD BASE RIGHT SHROUD BASE
TOP VIEW LEFT
NOTE:
MAKE SURE SHROUD IS
SEATED BETWEEN THE
SHROUD SUPPORT AND
THE FOUR TABS AS SHOWN
TOP VIEW RIGHT
NOTE:
MAKE SURE SHROUD IS
SEATED BETWEEN THE
SHROUD SUPPORT AND
THE FOUR TABS AS SHOWN
17
STEP 14

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP BOOM SUPPORT
TOP CAP
FRONT SHROUD
(RIGHT SIDE)
FRONT SHROUD
(LEFT SIDE)
1/4" FLAT WASHER (4)
1/4 X 1/2" BOLT (4)
NOTE:
MAKE SURE INTERNAL GROOVES OF
THE TOP CAP FIT DOWN OVER THE
TOP EDGES OF BOTH FRONT SHROUDS.
18
NOTES:
LOOSELY tighten bolt connections in this step.
STEP 15a

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP CAP
TOP BOOM
1/4" FLAT WASHER (2)
1/4 X 1/2" BOLT (2)
19
STEP 15b
NOTES:
SECURELY tighten bolt connections in this step, and previous step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
PLACARD
FRONT SHROUD
(RIGHT SIDE)
2-1/4"
(5.7 CM)
57-1/2"
(146 CM)
NOTE:
CENTER PLACARD ON
SHROUD SURFACE.
20
STEP 16
