Torque XCREATE-LPDWM User manual

4 FT (1.2 M) LAT PULLDOWN WALL MOUNT
ASSEMBLY INSTRUCTIONS
PART # 5676001-A VERSION: XCREATE-LPDWM

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ITEM PART NUMBER DESCRIPTION QTY
1 56641PA PTD ASSY, LOWER WALL MOUNT 1
2 56472PA PTD ASSY, ROW BASE 1
3 2001301 WASHER, FLAT 1/2 SAE ST ZN 18
4 2006803 BOLT, 1/2-13 X 1" (25mm) SOCKET HEAD W/NP 4
5 2001101 WASHER, FLAT 3/8 SAE ST ZN 11
6 5513601 CUSHION, WEIGHT STACK 2
7 5643201 GUIDE ROD, 19 DIA X 1912 2
8 56351PA PTD ASSY, 20 LB WEIGHT PLATE 5
9 56350PA PTD ASSY, 15 LB WEIGHT PLATE 10
10 56345PA PTD ASSY, HEAD PLATE 1
11 5095301 SHAFT COLLAR, GUIDE ROD 2
12 5667301 BUSHING, GUIDE ROD RETAINER 2
13 55181PA PTD ASSY, WEIGHT SELECTOR STORAGE PLATE 1
14 2009402 BOLT, 3/8-16 X 3/4" (19mm) ST HT SOCKET HEAD W/NP 6
15 5664401 WLDMT, UPPER WALL MOUNT 1
16 56495PA PTD ASSY, ROW TOP BOOM 1
17 5094501 PULLEY, 4-1/2 OD X 25 1
18 5094801 SPACER, FLNG 16.2 X 10.1 X 12.5 2
19 2008410 BOLT, 3/8-16 X 2-3/4" (70mm) ST HT SOCKET HEAD 1
20 2001201 NUT, 3/8-16 LK ST ZN 2
21 2008409 BOLT, 3/8-16 X 2-1/2" (64mm) ST HT SOCKET HEAD 1
22 2009418 BOLT, 3/8-16 X 4-3/4" (121mm) ST HT SOCKET HEAD W/NP 2
23 5675301 LABEL, WEIGHT STACK 15-265 LB (6.8-120.2 KG) 1
24 5662501 WLDMT, LEFT SHROUD BASE 1
25 5662901 WLDMT, RIGHT SHROUD BASE 1
26 5645101 SHROUD, XCREATE CABLE STATION 2
27 5664701 SHROUD, TOP CAP 1
28 2002101 WASHER, FLAT 1/4 SAE ST ZN 8
29 2006502 BOLT, 1/4-20 X 1/2" (13mm) SOCKET HEAD W/NP 6
30 5676301 PLACARD, XCREATE-SR-101 1
31 56508PA PTD ASSY, ROW BENCH FRAME 1
32 2005811 BOLT, 1/2-13 X 3" (76mm) SOCKET HEAD 4
33 2001401 NUT, 1/2-13 LK ST ZN 7
34 56513PA PTD ASSY, ROW FOOT SUPPORT 1
35 2005816 BOLT, 1/2-13 X 4-1/4" (108mm) SOCKET HEAD 3
36 5408201 PAD, BACK 1
37 2008411 BOLT, 3/8-16 X 3" (76mm) ST HT SOCKET HEAD 3
ITEM PART NUMBER DESCRIPTION QTY
38 5581301 COVER, FRONT BASE 1
39 2005509 BOLT, 1/4-20 X 3/8" (9mm) SOCKET HEAD 2
40 5674801 WLDMT, ALUMINUM ROW HANDLE 1
41 5091801 SNAP HOOK, 8MM DIA X 80MM 1
2
NOTE:
Anchoring hardware is dictated by the wall construction that the station
is being attached to. See pages 4 and 12 for the requirements.
If multiple stations are going to be attached to the same wall, a minimum
of 4' (2.4 M) center to center is recommended between stations.
For assistance, contact [email protected] or call
[phone]; Toll free in USA [phone].
TOOLS FOR ASSEMBLY:
3/8" ALLEN WRENCH •
5/16" ALLEN WRENCH •
3/16" ALLEN WRENCH •
3/4" WRENCH OR SOCKET •
9/16" WRENCH OR SOCKET •
1/2" WRENCH OR SOCKET •
RUBBER MALLET •

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BASE
LOWER WALL MOUNT
1/2 X 1" BOLT (2)
1/2" FLAT WASHER (2)
NOTE 1:
MAKE SURE THE CABLE IS IN THE GROOVE
OF THE PULLEY BEFORE ASSEMBLING
THE ROW BASE TO THE BASE SUPPORT
NOTE 2:
BEFORE ASSEMBLING ROW BASE,
ROUTE THE CABLE THROUGH THE
SLOT AND BEHIND THE BRACKET
OF THE LOWER WALL MOUNT
NOTE 3:
BEFORE TIGHTENING BOLTS, MAKE SURE
THAT THESE TWO SURFACES ARE FLUSH
CABLE
3
STEP 1
NOTES:
LOOSELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LOWER WALL MOUNT
3/8" FLAT WASHER (4)
3/8" LAG BOLT (4)
(TYPICAL FOR
WOOD STUDS)
NOTE:
BEFORE ANCHORING LOWER WALL
MOUNT TO THE WALL, ADJUST
LEVELERS (2) SO THAT THE BASE
PLATE IS LEVEL WITH THE FLOOR.
BASE PLATE
WALL
3-1/16"
(7.8 CM)
2-1/2"
(6.4 CM)
16"
(40.6 CM)
NOTE:
MAKE SURE THE LOWER
WALL MOUNT IS LEVEL
WARNING:
THE LOWER WALL MOUNT MUST BE ANCHORED TO THE
WALL USING FOUR WALL ANCHORS SUITABLE FOR THAT
PATICULAR WALL CONSTRUCTION.
STEP 2
4
NOTES:
The images shown above is the anchoring hardware used for attaching
to typical walls with wood studs spaced 16" on center. The anchors
used will depend on the wall construction. In all cases, all four
anchoring locations must be used. The pull-out strength of the
anchoring bolts used must be greater than or equal to 200lbs. (91kg)
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BASE
3/8 X 4-3/4" BOLT (2)
3/8" FLAT WASHER (2)
5
STEP 3
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LEFT SHROUD BASE
3/8" FLAT WASHER (4)
LOWER WALL MOUNT
3/8 X 3/4" BOLT (2)
6
STEP 4
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LOWER WALL MOUNT
RIGHT SHROUD BASE
3/8" FLAT WASHER (2)
3/8 X 3/4" BOLT (2)
7
STEP 5
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BASE
WEIGHT STACK CUSHION (2)
15 LB WEIGHT PLATE (10)
HEAD PLATE
GUIDE ROD (2)
SHAFT COLLAR (2)
GUIDE ROD RETAINER (2)
NOTE:
INSERT THE GUIDE RODS THROUGH THE
ROW BASE AND DOWN TO TOP OF BOLTS
20 LB WEIGHT PLATE (5)
CABLE
8
STEP 6

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
WEIGHT SELECTOR
STORAGE PLATE
HEAD PLATE
3/8 X 3/4" BOLT (2)
CABLE
STEP 7
9
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
NOTE 1:
ROUTE THE CABLE THROUGH THE
SLOT IN THE UPPER WALL MOUNT
NOTE 3:
ROUTE THE CABLE THROUGH THE
HOLE IN THE ROW TOP BOOM
NOTE 2:
ROUTE THE CABLE AROUND
THE PULLEY BEFORE ASSEMBLING
IT TO THE ROW TOP BOOM
CABLE
4-1/2" PULLEY
3/8" LOCK NUT (2)
FLANGE SPACER (2)
3/8 X 2-3/4" BOLT
3/8 X 2-1/2" BOLT
3/8" FLAT WASHER (2)
UPPER WALL MOUNT
ROW TOP BOOM
NOTE 4:
MAKE SURE THE CABLE IS
IN THE GROOVE OF THE
PULLEY AND UNDERNEATH
THE RETAINING BOLT BEFORE
SECURELY TIGHTEN BOLT
STEP 8
10
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW TOP BOOM
UPPER WALL MOUNT
CABLE
1/2 X 1" BOLT (2)
1/2" FLAT WASHER (2)
NOTE:
MAKE SURE THE CABLE
IS ROUTED THROUGH THE
HOLE IN THE ROW TOP BOOM
NOTE:
MAKE SURE THE CABLE IS ROUTED THROUGH
THE SLOT IN THE UPPER WALL MOUNT
NOTE:
MAKE SURE THE CABLE IS ROUTED
AROUND THE PULLEY OF THE ROW TOP BOOM
NOTE:
BEFORE TIGHTENING BOLTS,
MAKE SURE THAT THESE TWO
SURFACES ARE PARALLEL
NOTE:
LOOSELY THREAD THE CABLE
END INTO THE STEM OF THE
HEAD PLATE. THE CABLE WILL
BE ADJUSTED IN A LATER STEP
STEP 9
11
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
UPPER WALL MOUNT
3/8" FLAT WASHER (4)
3/8" LAG BOLT (4)
(TYPICAL FOR
WOOD STUDS)
80"
(203.2 CM)
2-1/2"
(6.4 CM)
16"
(40.6 CM)
NOTE:
MAKE SURE THE UPPER
WALL MOUNT IS LEVEL
WARNING:
THE UPPER WALL MOUNT MUST BE
ANCHORED TO THE WALL USING FOUR
WALL ANCHORS SUITABLE FOR THAT
PATICULAR WALL CONSTRUCTION
12
STEP 10
NOTES:
The images shown above is the anchoring hardware used for attaching
to typical walls with wood studs spaced 16" on center. The anchors
used will depend on the wall construction. In all cases, all four
anchoring locations must be used. The pull-out strength of the
anchoring bolts used must be greater than or equal to 200lbs. (91kg)
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
NOTE:
SLIDE THE GUIDE ROD RETAINERS UP INSIDE THE
ROW TOP BOOM. SLIDE THE SHAFT COLLARS UP INSIDE
OF THE GUIDE ROD RETAINERS AND SECURELY
TIGHTEN THE SET SCREWS OF THE SHAFT COLLARS
GUIDE ROD RETAINER (2)
SHAFT COLLAR (2)
ROW TOP BOOM
GUIDE ROD (2)
13
STEP 11
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
CABLE END
STEM
JAM NUT
HEAD PLATE
STORAGE FOR WEIGHT
STACK SELECTOR PIN
HOUSING
SWIVEL PULLEY
NOTE:
ATTACH THE WEIGHT STACK
LABELS TO THE WEIGHT STACK
STARTING WITH THE HEAD
PLATE
THREAD THE CABLE END INTO THE
STEM OF THE HEAD PLATE UNTIL
THE HOUSING IS APPROXIMATELY
1/2" AWAY FROM THE SWIVEL PULLEY,
THEN SECURELY TIGHTEN THE JAM
NUT. SEE NOTE ABOVE
NOTE:
THE HOUSING ON THE CABLE SHOULD BE AT
LEAST 1/2" AWAY FROM THE SWIVEL PULLEY.
IF THE HOUSING IS TOUCHING THE SWIVEL
PULLEY, THEN THE CABLE NEEDS TO BE
ADJUSTED. LOOSEN JAM NUT AND TURN THE
THREADED END OF THE CABLE COUNTER
CLOCKWISE UNTIL THE HOUSING IS 1/2" AWAY
FROM THE SWIVEL PULLEY. SECURELY
TIGHTEN JAM NUT.
14
STEP 12
NOTES:
SECURELY tighten connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
RIGHT SHROUD BASE
LEFT SHROUD BASE
FRONT SHROUD (2)
NOTE:
MAKE SURE THE SHROUD
IS SEATED BETWEEN THE
SHROUD SUPPORT AND
THE FOUR TABS AS SHOWN.
TOP VIEW LEFT
NOTE:
MAKE SURE THE SHROUD
IS SEATED BETWEEN THE
SHROUD SUPPORT AND
THE FOUR TABS AS SHOWN.
TOP VIEW RIGHT
15
STEP 13

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP CAP
FRONT SHROUD (RIGHT SIDE)
FRONT SHROUD (LEFT SIDE)
1/4" FLAT WASHER (4)
1/4 X 1/2" BOLT (4)
NOTE:
MAKE SURE INTERNAL GROOVES OF
THE TOP CAP FIT DOWN OVER THE
TOP EDGES OF BOTH FRONT SHROUDS.
UPPER WALL MOUNT
16
NOTES:
LOOSELY tighten bolt connections in this step.
STEP 14a

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP CAP
ROW TOP BOOM
1/4" FLAT WASHER (2)
1/4 X 1/2" BOLT (2)
17
STEP 14b
NOTES:
SECURELY tighten bolt connections in this step, and previous step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
PLACARD
FRONT SHROUD (RIGHT SIDE)
57-1/2"
(146 CM)
2-1/4"
(5.7 CM)
NOTE
CENTER PLACARD ON
SHROUD SURFACE.
18
STEP 15

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BENCH FRAME
1/2" FLAT WASHER (8)
1/2" X 3" BOLT (4)
ROW BASE
1/2" LOCK NUT (4)
NOTE:
MAKE SURE THE BASE PLATE
SITS FLAT ON THE FLOOR
BEFORE TIGHTENING
19
STEP 16
NOTES:
SECURELY tighten bolt connections in this step.
Some parts have been hidden for illustration clarity.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BENCH FRAME
1/2 X 4-1/4" BOLT (3)
1/2" FLAT WASHER (6)
1/2" LOCK NUT (3)
ROW FOOT SUPPORT
20
STEP 17
NOTES:
SECURELY tighten bolt connections in this step.
Some parts have been hidden for illustration clarity.
