Torque XCREATE-4SRM User manual

4 FT (1.2 M) SEATED ROW MODULE
ASSEMBLY INSTRUCTIONS
PART # 5676001-A VERSION: XCREATE-4SRM

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ITEM PART NUMBER DESCRIPTION QTY
1 5642301 WLDMT, BASE SUPPORT 1
2 5581301 COVER, FRONT BASE 1
3 56443PA PTD ASSY, TOP BOOM SUPPORT 1
4 2001301 WASHER, FLAT 1/2 SAE ST ZN 38
5 2005816 BOLT, 1/2-13 X 4-1/4" (108mm) SOCKET HEAD 15
6 2001401 NUT, 1/2-13 LK ST ZN 19
7 56472PA PTD ASSY, ROW BASE 1
8 5513601 CUSHION, WEIGHT STACK 2
9 5643201 GUIDE ROD, 19 DIA X 1912 2
10 56351PA PTD ASSY, 20 LB WEIGHT PLATE 5
11 56350PA PTD ASSY, 15 LB WEIGHT PLATE 10
12 56345PA PTD ASSY, HEAD PLATE 1
13 5095301 SHAFT COLLAR, GUIDE ROD 2
14 5667301 BUSHING, GUIDE ROD RETAINER 2
15 55181PA PTD ASSY, WEIGHT SELECTOR STORAGE PLATE 1
16 2009402 BOLT, 3/8-16 X 3/4" (19mm) ST HT SOCKET HEAD W/NP 2
17 56495PA PTD ASSY, ROW TOP BOOM 1
18 5094501 PULLEY, 4-1/2 OD X 25 1
19 5094801 SPACER, FLNG 16.2 X 10.1 X 12.5 2
20 2008410 BOLT, 3/8-16 X 2-3/4" (70mm) ST HT SOCKET HEAD 1
21 2001201 NUT, 3/8-16 LK ST ZN 6
22 2001101 WASHER, FLAT 3/8 SAE ST ZN 19
23 2008409 BOLT, 3/8-16 X 2-1/2" (64mm) ST HT SOCKET HEAD 1
24 2009418 BOLT, 3/8-16 X 4-3/4" (121mm) ST HT SOCKET HEAD W/NP 2
25 5675301 LABEL, WEIGHT STACK 15-265 LB (6.8-120.2 KG) 1
26 5662501 WLDMT, LEFT SHROUD BASE 1
27 2008414 BOLT, 3/8-16 X 3-3/4" (95mm) ST HT SOCKET HEAD 4
28 5662901 WLDMT, RIGHT SHROUD BASE 1
29 5645101 SHROUD, XCREATE CABLE STATION 2
30 5664701 SHROUD, TOP CAP 1
31 2002101 WASHER, FLAT 1/4 SAE ST ZN 8
32 2006502 BOLT, 1/4-20 X 1/2" (13mm) SOCKET HEAD W/NP 6
33 5676301 PLACARD, XCREATE-SR-101 1
34 56508PA PTD ASSY, ROW BENCH FRAME 1
35 2005811 BOLT, 1/2-13 X 3" (76mm) SOCKET HEAD 4
36 56513PA PTD ASSY, ROW FOOT SUPPORT 1
37 5408201 PAD, BACK 1
ITEM PART NUMBER DESCRIPTION QTY
38 2008411 BOLT, 3/8-16 X 3" (76mm) ST HT SOCKET HEAD 3
39 2005509 BOLT, 1/4-20 X 3/8" (9mm) SOCKET HEAD 2
40 5674801 WLDMT, ALUMINUM ROW HANDLE 1
41 5091801 SNAP HOOK, 8MM DIA X 80MM 1
42 5692601 WLDMT, XCREATE REAR SHROUD (OPTIONAL) 1
43 2009403 BOLT, 3/8-16 X 1" (25mm) ST HT SOCKET HEAD W/NP 4
NOTE:
X-CREATE CABLE STATIONS can be customized in many ways. This
manual provides instructions for assembling a single stand-alone unit.
If you worked with Torque X-Team Design during the purchasing process,
please request a Bill of Material Drawing to reference your exact set-up.
For assistance, contact [email protected] or call
[phone]; Toll free in USA [phone].
NOTE:
When assembling any X-CREATE CABLE STATIONS that is longer than
one module wide, the hardware will be shared between two side-by-side
modules. It is recommended to keep all bolt connections loose until all the
cable stations have been fully assembled, then securely tighten all frame
connections.
TOOLS FOR ASSEMBLY:
3/8" ALLEN WRENCH •
5/16" ALLEN WRENCH •
3/16" ALLEN WRENCH •
3/4" WRENCH OR SOCKET •
9/16" WRENCH OR SOCKET •
1/2" WRENCH OR SOCKET •
RUBBER MALLET •
2

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP BOOM SUPPORT
BASE SUPPORT
1/2 X 4-1/4" BOLT (8)
1/2" FLAT WASHER (16)
1/2" LOCK NUT (8)
XCREATE UPRIGHT (2)
(SEE NOTE)
3
STEP 1
NOTES:
LOOSELY tighten bolt connections in this step.
The XCREATE-SR is shown assembled to the XCREATE-7U.
However, the XCREATE-SR can also be assembled to the
XCREATE-8U and XCREATE-2S8U the same way.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BASE
BASE SUPPORT
1/2 X 4-1/4" BOLT (2)
1/2" FLAT WASHER (4)
1/2" LOCK
NUT (2)
NOTE:
DO NOT TIGHTEN THESE
BOLTS AT THIS TIME
NOTE:
DO NOT TIGHTEN
THESE BOLTS AT THIS TIME
NOTE 1:
MAKE SURE THE CABLE IS IN THE GROOVE
OF THE PULLEY BEFORE ASSEMBLING
THE ROW BASE TO THE BASE SUPPORT
CABLE
NOTE 2:
BEFORE ASSEMBLING ROW BASE,
ROUTE THE CABLE THROUGH THE
FRONT SLOT AND OUT THE TOP SLOT
OF THE BASE SUPPORT AS SHOWN
NOTE:
IF ASSEMBLING CABLE STATIONS BACK TO BACK, PLEASE
NOTE THAT THEY SHARE THE SAME BASE SUPPORT AND
HARDWARE AS SHOWN. BOTH ROW BASES NEED TO BE
ASSEMBLED SIMULTANEOUSLY
STEP 2
4
NOTES:
SECURELY tighten bolt connections in this step and previous step,
except as noted.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BASE
3/8 X 4-3/4" BOLT (2)
3/8" FLAT WASHER (2)
5
STEP 3
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
LEFT SHROUD BASE
3/8" FLAT WASHER (4)
3/8" LOCK NUT (2)
BASE SUPPORT
3/8 X 3-3/4" BOLT (2)
6
STEP 4
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
BASE SUPPORT
RIGHT SHROUD BASE
3/8" FLAT WASHER (4)
3/8" LOCK NUT (2)
3/8 X 3-3/4" BOLT (2)
7
STEP 5
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BASE
WEIGHT STACK CUSHION (2)
15 LB WEIGHT PLATE (10)
HEAD PLATE
GUIDE ROD (2)
SHAFT COLLAR (2)
GUIDE ROD RETAINER (2)
NOTE:
INSERT THE GUIDE RODS THROUGH THE
ROW BASE AND DOWN TO TOP OF BOLTS
20 LB WEIGHT PLATE (5)
CABLE
8
STEP 6
NOTES:
TOP BOOM SUPPORT has been hidden for illustration clarity.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
WEIGHT SELECTOR
STORAGE PLATE
HEAD PLATE
3/8 X 3/4" BOLT (2)
CABLE
STEP 7
9
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP BOOM SUPPORT
CABLE
NOTE:
BEFORE ASSEMBLING THE TOP BOOM,
ROUTE THE CABLE UP THROUGH THE
BOTTOM SLOT AND OUT THE FRONT
SLOT OF THE TOP BOOM SUPPORT AS
SHOWN
STEP 8
10

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
NOTE 2:
MAKE SURE THE CABLE IS ROUTED THROUGH
THE HOLE OF THE ROW TOP BOOM
4-1/2" PULLEY
FLANGE SPACER (2)
3/8" LOCK NUT (2)
ROW TOP BOOM
NOTE 1:
WRAP CABLE OVER THE TOP OF A 4-1/2"
PULLEY AND ASSEMBLE THE PULLEY TO
THE ROW TOP BOOM AS SHOWN
3/8" FLAT WASHER (2)
3/8 X 2-1/2" BOLT
3/8 X 2-3/4" BOLT
CABLE
CABLE FROM
TOP BOOM SUPPORT
STEP 9
11
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP BOOM SUPPORT
1/2 X 4-1/4" BOLT (2)
1/2" FLAT WASHER (4)
1/2" LOCK NUT (2)
ROW TOP BOOM
CABLE
NOTE:
LOOSELY THREAD THE CABLE
END INTO THE STEM OF THE
HEAD PLATE. THE CABLE WILL
BE ADJUSTED IN A LATER STEP
STEM
CABLE
HEAD PLATE
NOTE:
IF ASSEMBLING CABLE STATIONS BACK TO BACK, PLEASE
NOTE THAT THEY SHARE THE SAME TOP BOOM SUPPORT
AND HARDWARE AS SHOWN. BOTH ROW TOP BOOMS
NEED TO BE ASSEMBLED SIMULTANEOUSLY
12
STEP 10
NOTES:
SECURELY tighten bolt connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
NOTE:
SLIDE THE GUIDE ROD RETAINERS UP INSIDE THE
ROW TOP BOOM. SLIDE THE SHAFT COLLARS UP INSIDE
OF THE GUIDE ROD RETAINERS AND SECURELY
TIGHTEN THE SET SCREWS OF THE SHAFT COLLARS
GUIDE ROD RETAINER (2)
SHAFT COLLAR (2)
ROW TOP BOOM
GUIDE ROD (2)
NOTE:
SECURELY TIGHT THESE BOLTS
NOTE:
SECURELY TIGHTEN THESE BOLTS
13
STEP 11
NOTES:
SECURELY tighten bolt connections in this step, and previous steps.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
CABLE END
STEM
JAM NUT
HEAD PLATE
STORAGE FOR WEIGHT
STACK SELECTOR PIN
HOUSING
SWIVEL PULLEY
NOTE:
ATTACH THE WEIGHT
STACK LABELS TO THE
WEIGHT STACK STARTING
WITH THE HEAD PLATE
NOTE:
THREAD THE CABLE END INTO THE
STEM OF THE HEAD PLATE UNTIL
THE HOUSING IS APPROXIMATELY
1/2" AWAY FROM THE SWIVEL PULLEY,
THEN SECURELY TIGHTEN THE JAM
NUT. SEE NOTE ABOVE
NOTE:
THE HOUSING ON THE CABLE SHOULD BE AT
LEAST 1/2" AWAY FROM THE SWIVEL PULLEY.
IF THE HOUSING IS TOUCHING THE SWIVEL
PULLEY, THEN THE CABLE NEEDS TO BE
ADJUSTED. LOOSEN JAM NUT AND TURN THE
THREADED END OF THE CABLE COUNTER
CLOCKWISE UNTIL THE HOUSING IS 1/2" AWAY
FROM THE SWIVEL PULLEY. SECURELY
TIGHTEN JAM NUT.
14
STEP 12
NOTES:
SECURELY tighten connections in this step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
RIGHT SHROUD BASE
LEFT SHROUD BASE
FRONT SHROUD (2)
NOTE:
MAKE SURE SHROUD IS
SEATED BETWEEN THE
SHROUD SUPPORT AND
THE FOUR TABS AS SHOWN.
TOP VIEW LEFT
NOTE:
MAKE SURE SHROUD IS
SEATED BETWEEN THE
SHROUD SUPPORT AND
THE FOUR TABS AS SHOWN.
TOP VIEW RIGHT
15
STEP 13
NOTES:
ROW BASE and CABLE have been hidden for illustration clarity.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP BOOM SUPPORT
TOP CAP
FRONT SHROUD
(RIGHT SIDE)
FRONT SHROUD
(LEFT SIDE)
1/4" FLAT WASHER (4)
1/4 X 1/2" BOLT (4)
NOTE:
MAKE SURE INTERNAL GROOVES OF
THE TOP CAP FIT DOWN OVER THE
TOP EDGES OF BOTH FRONT SHROUDS.
16
NOTES:
LOOSELY tighten bolt connections in this step.
STEP 14a

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
TOP CAP
ROW TOP BOOM
1/4" FLAT WASHER (2)
1/4 X 1/2" BOLT (2)
17
STEP 14b
NOTES:
SECURELY tighten bolt connections in this step, and previous step.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
PLACARD
FRONT SHROUD
(RIGHT SIDE)
2-1/4"
(5.7 CM)
57-1/2"
(146 CM)
NOTE
CENTER PLACARD ON
SHROUD SURFACE.
18
STEP 15

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BENCH FRAME
1/2" FLAT WASHER (8)
1/2" X 3" BOLT (4)
ROW BASE
1/2" LOCK NUT (4)
NOTE:
MAKE SURE THE BASE PLATE
SITS FLAT ON THE FLOOR
BEFORE TIGHTENING
19
STEP 16
NOTES:
SECURELY tighten bolt connections in this step.
Some parts have been hidden for illustration clarity.

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
ROW BENCH FRAME
1/2 X 4-1/4" BOLT (3) 1/2" FLAT WASHER (6)
1/2" LOCK NUT (3)
ROW FOOT SUPPORT
20
STEP 17
NOTES:
SECURELY tighten bolt connections in this step.
Some parts have been hidden for illustration clarity.
