READ AND SAVE THESE
INSTRUCTIONS
Attention:
Pictures in the IM are for
reference only.
Air Purifier
CAF-Y36PH(W)
16157100A00965

READ AND SAVE THESE
INSTRUCTIONS
Attention:
Pictures in the IM are for
reference only.
Air Purifier
CAF-Y36PH(W)

Statement
With the technological innovation and improvement of the product, the product manual contents of the same model as this product may be changed,
and the updated part will not further notify.
All the illustrations shown in this manual are based on the appearance of the standard model purifier. They are for illustrative purposes only. The
actual appearance of the purifier is subject to the purchased product.
Due to product improvement, some of the parameters may be changed. The changed parameters have no retroactive effect on this product. Please
refer to the product nameplate parameters.
If there is any change in the content of this manual, our company will make announcement through the official website of the company without further
notice one by one, and unless otherwise stated in the notice of announcement, the content of the change shall not be retroactive to this product in
principle.
1
READ AND SAVE THESE INSTRUCTIONS

2
IMPORTANT SAFETY INSTRUCTIONS
Caution
Read Rules for Safe Operation and Instructions Carefully.
WARNING
9. Do not use this unit near gas appliances or fireplaces.
10. When cleaning theunit, or when the unit is not in use, be sure
to unplug the unit. Electrical shock and/or fire from a short circuit
may occur as a result.
11. If the power cord is damaged, it must be replaced by the
manufacturer, its service agent, a Toshiba Service Center or
similarly qualified person in order to avoid a hazard.
12. Do not operate when using aerosol insecticides or in rooms
where there is oily residue, incense, sparks from lit cigarettes,
chemical fumes in the air, or in locations where the unit may get
wet, such as a bathroom.
13. Be cautious when cleaning the unit. Strong corrosive cleans-
ers may damage the exterior
14. Only a Toshiba Authorized Service Center should service this
air purifier. Contact the nearest Service Center for any problems,
adjustments, or repairs.
15. When carrying or removing the unit, hold the unit by handle.
16. If this air purifier should cause interference to radio or
television reception, try to correct the interference by one or more
of the following measures:
1) Reorient or relocate the receiving antenna of radio or TV
2) Increase the separation distance between the unit and radio/TV
receiver.
3) Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected
4) Consult the dealer or an experienced radio/TV technician for
help.
- This appliance has a polarized plug (one blade is wider than the
other).
To reduce the risk of electric shock, this plug is intended to fit in a
polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to defeat this safety feature.
- To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This
Air Purifier With Any Solid-State Speed Control Device.
- Skin or eye damage may result from directly viewing the light
produced by the lamp in this apparatus. Always disconnect power
before relamping or servicing. Never replace the UV lamp without
authorized technician!
1. Read all safety instructions before using the unit.
2. Use only a 220-240 volt outlet.
3. Please place the unit on the ground when using.
4. Do not use the unit if the power cord or plug is damaged or the
connection to the wall outlet is loosened.
5. Periodically remove dust from the plug.
6. Do not insert fingers or foreign objects into the air intake or air
outlet.
7. When removing the power plug, always hold the plug and never
pull on the cord. Electrical shock and/or fire from a short circuit
may occur as a result.
8. Do not remove the plug when your hands are wet.

3
Lifting handle
Back cover
Status Display and
Control Panel
Lifting handle
Air outlet
Power cord
Activated carbon
Filter HEPA Filter
PRODUCT INTRODUCTION

4
1
3
2
1Remove the back cover
Grasp the position of wedging block
and pull outwards to remove the
back cover
3Install the back cover
Hold the drawstring at both
of Filter assembly and
remove the Filter assembly.
Disassemble the
packaging bag of the
Filter.
Install the Filter assembly.
The activated carbon Filter
is on the outside
2Install the Filter
Please make sure that the front side of filter elements installed correctly.
Simultaneously slide the two left
and right buckles at the bottom of
the back cover into the machine
body with both hands
Press the top with both hands
simultaneously and insert the
top two buckles into the
machine body. At this time, the
installation is in place.
INSTALLATION

5
Purification volume button
Press this button to adjust the
volume of purification, with low,
medium and high grades
The status of the purification
volume can be intuitively indicated
by threeindicators: LOW, MED,
and HIGH.
UV button
Press this button to turn on the
UV lamp when the switch is on,
then press to off
On/off button
Press this button to start.
Press again, it will shut down.
This product will default to the
last working gear each time you
turn on the machine.
This product uses a certain algorithm to
calculate the life of the Filter with the
opening time accumulated as a
reference value.
When the filter life is reached, the UV
indicator will flash, at this time to remind
the user to replace the filter;
After the filter replacement is completed,
long press the UV button for 3 seconds
to reset the filter status; after reset, the
UV indicator will no longer flash.
Control and Status Display Panel
Speed light
UV light
USAGE

6
Correct placement
In order to achieve better cleaning effect and avoid the influence
of metal shielding effect on communication, please ensure that the
air purifier is more than 30cm away from the wall and other obstructions
when using it, and maintain a distance of more than 50cm from the
metal/appliance.
more than 30cm
more than 30cm
more than 50cm
Filter cleaning/replacement
When the UV light on the display panel flashes,
it prompts you to replace the filter
Please select a filter that matches the model of the
machine for replacement. Please purchase from your
local authorized dealer.
For more details on the installation of the filter,
please see the “installation” section.
Press the UV button for 3 seconds,
the filter resets and restarts the timer
Cleaning
WARNING: RISK OF ELECTRIC SHOCK
These servicing instructions are for use by qualified personnel
only. To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating instructions
unless you are qualified to do so!
- It is recommended to clean the filter twice a week and replace the filter half a
year (adjust the cleaning and replacement cycle according to the use environ-
ment);
- Can not wash the filter;
- Smaller soft brushes or household vacuum cleaners are recommended for filter
cleaning.
- When using the brush to clean, it should be brushed horizontally along the filter
to avoid vertical brush, so as not to damage the filter;
- When cleaning with a vacuum cleaner, keep the suction outlet 5-10mm away
from the surface of the filter so as not to damage the filter.
- When used under the strong odor produced by cigarettes, barbecues, etc., the
filter may have an odor in a matter of weeks or months. Please clean and dry
filter (2-5 days). If you still cannot eliminate the odor, replace the filter.
USAGE MAINTENANCE

7
1. The performance parameters in the table are measured before delivery and are
for reference only.
2. Due to product improvement, the following parameters may be changed and
shall refer to the product nameplate parameters.
3. The applicable area is according to the theoretical value calculated by
(0.07 ~ 0.12) x CADR particulate matter; with the use of different environments
or outdoor pollution and other factors, the applicable area will also change.
4. Purifying principle: The air purifier blows air into the machine and filters the air
through the built-in filter core. It can mainly play the role of filtering dust (such as
PM2.5), formaldehyde, odor, sterilization and others.
Model
High-grade CADRparticles
Rated voltage (V-)
Rated frequency (Hz)
Rated power (W)
Noise [dB]
CAF-Y36PH(W)
210
230
60
58
Dimensions (mm) 256x175x675
32-52
TECHNICAL PARAMETERS

8
Before you ask for maintenance, please check according to the table below.
Problems
encountered Reasons Solutions
Purifier cannot run
The effect is bad to
eliminate smoke and
odor
Filter cleaning light does
not extinguish
It is hard to eliminate the
odor and smoke
- It is possible that the power cord is not plugged
or poor contact with power cord
- May not turn on the power switch
- It is possible that the filter is not installed in
place and safety switch is not triggered
- Please connect power and make good
contact
- Please turn on the power switch
- Please properly install the filter and buckle
the back cover
- Please properly install the filter assembly
- Please replace the new filter assembly
- Please remove foreign matter from the air
inlet
- After cleaning the filter assembly, long press
the "UV" button for 3 seconds
- Please remove the packaging bag outside
the filter assembly
- It is possible that the filter assembly is not installed well
- It is possible that the filter assembly has reached the
end of life
- It is possible that the air inlet is blocked by foreign
matter
- It may be that the "UV" button is not long pressed for
3 seconds after the filter assembly is replaced.
- It may be that the filter assembly is also wrapped in a
packaging bag
Please send it to repair in case of the following:
1. If the operation is abnormal or the machine does
not operate, and the above method is invalid;
2. Substances or water from the outside have
entered and abnormal operation has occurred.
FAULT SELF-DETECTION
