Toshiba RemotEye III User manual

RemotEye III Quick Installation Guide
Windows Users
Document No.: 63761-002
Date: August 2015

RemotEye III Quick Installation Guide – 63761-001

RemotEye III Quick Installation Guide – 63761-002 1
Installing RemotEye III
Follow these steps to install the RemotEye III internal
card.
1) Slide the RemotEye III internal printed circuit
board into the extension option slot of the UPS.
Secure the printed circuit board using the UPS-
supplied screws.(See Figure 1)
Figure 1: RemotEye III Circuit Card
Configuration
RemotEye III must be configured for proper operation on its network.
Configuring the RemotEye III via Terminal
The RemotEye III can be configured by directly connecting to the device.
Hardware Setup
Direct configuration is accomplished through the provided PC cable. Follow these steps to setup
the hardware for direct RemotEye III configuration:
a) Connect the DB9 female end of the PC cable to the terminal or workstation COM port.
b) Connect the RJ45 end of the PC cable to the COM port of the RemotEye III/Internal.
Software Setup
The direct configuration is accomplished by using the RS232 communication protocol.
The direct communication can be performed from a workstation running Terminal
Emulator Software (TES)
Connecting to the RemotEye III via Terminal
A direct configuration session can easily be established once the hardware and software are
properly set up. Follow these steps to begin configuration:
Terminal Emulator Example
To configure the RemotEye III from a Windows platform, use Hyperterminal. Hyperterminal is a
standard terminal emulator packaged with any Windows operating system. Launch the
Hyperterminal program by navigating to:
Start →Programs →Accessories →Communications →Hyperterminal →Hyperterminal,
and follow the prompts.
Figure 1: RemotEye III

2 RemotEye III Quick Installation Guide – 63761-002
Enter a name and select an icon for the application at the Connection Dialog box.
Select a direct connection to an appropriate com port listed in the pull-down menu.
Ensure that the Properties dialog box is setup as follows:
Baud Rate —9600
Data Bits — 8
Parity — None
Stop Bits — 1
Flow Control —- None
Press [Enter] and the RemotEye III version and Password field will be displayed (See Figure 2).
Enter the password (default is “ADMIN”) and press [Enter] to display the RemotEye III Main
Menu.
Default Password (case sensitive): ADMIN
+====================================================================+
| [ TIC RemotEye III Login Menu ] |
+====================================================================+
Enter Password: ******
The seven options provided in the RemotEye III Main Menu provide access to all system
RemotEye III configuration parameters. These options (see the Main Menu Description on
Figure 3: Console Main Menu) and their submenus are discussed in more detail in the next
section.
+====================================================================+
| [ TIC RemotEye III Main Menu ] |
+====================================================================+
1. TIC RemotEye Configuration
2. SNMP Communities
3. SNMPV3 USM Table
4. Trap Receiver Table
5. Reset Configuration To Default
6. Save and Exit
7. Save and Restart Agent
Please Enter Your Choice =>
Figure 3: Console Main Menu
Figure 2: Console Login Screen

RemotEye III Quick Installation Guide – 63761-002 3
Toshiba RemotEye III Configuration
Main Menu →(1) Toshiba RemotEye III Configuration (see Figure 4: Console Configuration
Menu Description).
+==================================================================+
| [ TIC RemotEye III Configuration Menu ] |
+==================================================================+
1. System Group
2. Control Group
3. Parameter Group
4. Email Group
5. EMD Group
0. Return to previous menu
Please Enter Your Choice =>
Figure 4: Console Configuration Menu Description
System Group
Main Menu →(1)Toshiba RemotEye III Configuration →(1) System Group (see Figure 5:
Console System Group Menu Description).
The System Group provides access to the system settings listed below. The settings may be
viewed or changed from this screen. When using the Dynamic Host Configuration Protocol
(DHCP), items 1 – 3 will be retrieved automatically.
+====================================================================+
| [ System Group Menu ] |
+====================================================================+
RemotEye III Agent Version : TIC RemotEye III v1.00
Ethernet address : 00 E0 D8 08 80 0D
1. Ip Address : 172.18.1.63
2. Gateway Address : 172.18.1.1
3. Network Mask : 255.255.240.0
4. Date and Time
0. Return to previous menu
Please Enter Your Choice =>
Figure 5: Console System Group Menu Description
Making the Network Connection
Each Ethernet network is different. Therefore, the following steps should be used as an outline
for connecting the RemotEye III to a network:
1. Connect one end of a Category 5 cable to the NETWORK RJ45 receptacle of
RemotEye III.
2. Connect the other end of the Category 5 cable to a designated network switch or hub. A
network administrator will allocate an available port.
3. Verify a network link has been established. Confirm the leftmost green LED is
illuminated

4 RemotEye III Quick Installation Guide – 63761-002
Connecting to the RemotEye III via HTTP
A web session can be established once the hardware and software have been prepared. Follow
these steps to begin configuration:
1. Launch the web browser.
2. Enter the URL for RemotEye III in the browser’s address field. For example,
http://10.0.37.189. The home page of the RemotEye III will be displayed once a
connection is established (See figure 6).
Default: Login: TOSHIBA
Password (case sensitive): ADMIN
Figure 6: RemotEye III HTTP Page

RemotEye III Quick Installation Guide – 63761-002 5
Upgrading RemotEye III Firmware from Windows via Network
Figure 7: Tugrade, RemotEye Upgrade Utility via Network
Table 1Tupgrade Toolbar Functions
Toolbar ID
Icon Name
Description/Function
1
Set IP
Manually set found device IP address, subnet mask and gateway
2
Acquire
Get all device parameters. This generates a config file.
3
Browse
Use default browser to open homepage of selected device
4
Add
Pop-up Add dialog to add one device
5
Delete
Delete one or more selected devices.
6
Edit
Pop-up Edit dialog to modify a device configuration.
7
Discover
Discover all RemotEye devices on the network.
8
Open file
Open the location (directory) of uploaded file.
9
Upgrade Firmware
Upgrade firmware after unit selected and file uploaded
To perform a firmware upgrade, RemotEye III must be connected to the same network as the workstation
from which the upgrade file is to be sent. In the RemotEye III make sure the Network Upgrade Control is
enabled, under RemotEye III Control, and that users have the Admin login string information and
Password.
Here is the way to manually Upgrade RemotEye Firmware:
1) Web Interface: Go to RemotEye III Management

RemotEye III Control menu then Enable
Network Upgrade Control.
Note: To enable the Network Upgrade Control user has to change the security level to
administrator by logging in as Administrator.
2) Open the Tupgrade application software and click on the Discover icon. If no RemotEye devices
auto populate the list, press on the + icon and enter the IP, Username, and Password. If it still does
not appear check your network security and your computer firewall.
3) Select the check box right next to the RemotEye that will be updated.
4) Select the Edit button and enter the Username and Password.
5) Select the Open File button and select the firmware to be uploaded.
6) Select the Upgrade Firmware button to start the upgrade process.
7) When the upload is complete, the RemotEye will automatically reboot.

6 RemotEye III Quick Installation Guide – 63761-002
User Manual
The full RemotEye III User Manual (P/N 62330) is provided on the enclosed CD in
electronic (PDF) format.
Contacting the TOSHIBA Customer Support Center
TOSHIBA’s Customer Support Center can be contacted to obtain help in resolving any
RemotEye III system problem that you may experience or to provide application
information.
The Support Center can be reached at 877-867-8773 (toll free) or 713-466-0277. The
center is open from 8 a.m. to 5 p.m. (CST), Monday through Friday.
You may also contact TOSHIBA by writing to:
TOSHIBA International Corporation
13131 West Little York Road
Houston, Texas 77041-9990.
For further information on TOSHIBA’s products and services, please visit our website at
HTTP://WWW.TOSHIBA.COM/IND.
