Toshiba ETB003Z User manual

E6581339⑥
Expansion IO Card Option 1
ETB003Z Instruction manual
NOTE
1. Make sure that this instruction manual is delivered to the end user of the
expansion IO card option.
this manual before installing or operating the inverter unit, and store it in a
© Toshiba Schneider Inverter Corporation 2005
All rights reserved.
NOTICE
1. Make sure that this instruction manual is delivered to the end user of the expansion
IO card option.
2. Read this manual before installing or operating the expansion IO card option. Keep
it in a safe place for reference.
3. All information contained in this manual are subject to change without notice.
Please confirm the latest information on our web site “www.inverter.co.jp”.

E6581339⑥
1
Safety precautions
On the inverter and in its instruction manual, important information is contained for
preventing injuries to users and damages to assets and for proper use of the device.
Read the instruction manual attached to VF-AS1/PS1 along with this instruction manual
for completely understanding the safety precautions and adhere to the contents of these
manuals.
Explanation of markings
Marking Meaning of marking
Warning Indicates that errors in operation may lead to death or serious injury.
Caution
Indicates that errors in operation may lead to injury (*1) to people or that these errors
may cause damage to physical property. (*2)
(*1) Such things as injury, burns or shock that will not require hospitalization or long periods of
outpatient treatment.
(*2) Physical property damage refers to wide-ranging damage to assets and materials.
Meanings of symbols
Marking Meaning of marking
Indicates prohibition (Don't do it).
What is prohibited will be described in or near the symbol in either text or picture
form.
Indicates something mandatory (must be done).
What is mandatory will be described in or near the symbol in either text or picture
form.
Indicates danger or warning.
What is dangerous, or what the warning should be applied to will be described in or
near the symbol in either text or picture form.
1

E6581339⑥
2
■ Limitation of use
Safety precaution
▼ Never use this unit with any device other than TOSVERT VF-AS1/PS1 series inverters. Doing so may
cause an accident.
■ General Operation
Warning
Disassembly
prohibited
▼ Never disassemble, modify or repair.
Doing so could result in electric shock, fire and injury. For repairs, call your sales
agency.
Prohibited
▼ Do not attach this option to any inverter other than the VF-AS1/PS1.
Doing so could result in electric shock or fire.
▼ Don't place or insert any kind of object into the ETB003Z (electrical wire cuttings, rods,
wires).
Doing so could result in electric shock or fire.
▼ Do not allow water or any other fluid to come in contact with the ETB003Z.
Doing so could result in electric shock or fire.
Mandatory
▼If the inverter begins to emit smoke or an unusual odor, or unusual sounds, immediately
turn off the VF-AS1/PS1.
If the equipment is continued in operation in such a state, the result may be fire. Call
your local sales agency for repairs.
▼Do not touch the sharp portions (such as leads of parts on the board, the corner of
board, or etc.) on this option. It may lead to injuries.
Caution
Mandatory
▼This option is an electrostatic discharge sensitive device. Handle it, where the
environment is protected against electrostatic electricity.
Otherwise, permanent damage to device will result.
■ Transportation & installation
Warning
Prohibited
▼Do not apply a dropping shock or other physical shocks.
Otherwise, damage or malfunction will result.
▼Do not install or operate the inverter if it is damaged or any part of it is missing.
Operating a defective inverter may lead to electric shocks or fire.
For repairs, call your sales/repair agency.
▼ Do not put any flammable material near the product.
It may catch fire due to the product sparking in the case of a malfunction.
Mandatory
▼ Use this product under the environmental conditions prescribed in the instruction
manual.
Usage it under any other conditions may result in malfunction.
▼ An emergency stop device must be installed that fits with system specifications
(e.g. shut off input power then engage mechanical brake).
Operation cannot be stopped immediately by the inverter or this unit alone, thus risking
an accident or injuries.

E6581339⑥
3
■ Wiring
Caution
Mandatory
▼ Electrical construction work must be done by a qualified expert.
Installation or connection of input power by someone who does not have that expert
knowledge may result in fire or electric shock.
▼ Shut off power when installing and wiring this option.
Wait at least 15 minutes and check to make sure that the charge lamp (VF-AS1/PS1)
is no longer lit.
▼ Tighten the screws on the terminal block to the specified torque (Refer to Section 2.2).
If the screws are not tightened to the specified torque, it may lead to fire.
■ Operations
Warning
Prohibited
▼ Do not pull on any cable itself.
Doing so could result in damage or malfunction.
▼ Do not touch switches when the hands are wet and do not try to clean the inverter with
a damp cloth.
Doing so could result in electric shock.
Mandatory
▼ Use this option under the environment specified in the instruction manual.
Usage under the environment other than them may cause damages or malfunctions or
an accident.
▼ Use an additional safety device with your VF-AS1/PS1 or system to prevent a serious
accident due to the unit malfunctions.
Usage without an additional safety device may cause an accident.
■ Disposal
Caution
Mandatory
▼ For safety's sake, do not dispose of the disused inverter yourself but ask an industrial
waste disposal agent (*).
If the collection, transport and disposal of industrial waste is done by someone who is
not licensed for that job, it is a punishable violation of the law. (Laws in regard to
cleaning and processing of waste materials)
(*) Persons who specialize in the processing of waste and known as “industrial waste
product collectors and transporters” or “industrial waste disposal persons.”
■ Notes on use
Notes
▼ Do not install the inverter where the temperature or the humidity will change rapidly.
▼ Keep a distance of 20cm or more between the inverter's power cable and the data
transmission cable.
Or the inverter might malfunction because of noise.
▼ Insert a magnetic contactor or similar device between the VF-AS1/PS1 and the power
supply to ensure that power is turned off if an emergency stop command is entered
through the network.

E6581339⑥
4
Introduction
Thank you for purchasing a “Expansion IO card option 1” for industrial inverter
TOSVERT VF-AS1/PS1 inverter.
By the use of this option, the expansion of input/output terminal is possible. This
instruction manual describes connecting method and usage of the “Expansion IO card
option”. Read this manual carefully before using the unit.
Keep this manual near at hand of the operator who uses the “Expansion IO card option”
for future reference in the maintenance and inspection.
 Type of expansion IO option card
E T B 0 0 3 Z －0
 Confirmation on accessories
Following accessory parts are included in the expansion IO card option.
Upon unpacking, confirm on the following parts.
Expansion IO card option unit
(1) Instruction manual of expansion IO card option (this manual)
E6581339(English)
Without cable
Revision number
Model number of expansion IO card option
Expansion IO card option
Manual

E6581339⑥
5
Contents
1. Name and function of each section .............................................................................6
1.1 Appearance .......................................................................................................................................6
1.2 Name of each section (terminal) .......................................................................................................6
2. Installing the IO card option in the VF-AS1/PS1..........................................................7
2.1 Connection to the inverter .................................................................................................................7
2.2 Wiring ................................................................................................................................................8
3. Functional description ............................................................................................... 10
3.1 Multi-function output terminal ..........................................................................................................10
3.2 Multi-function input terminal ............................................................................................................11
3.3 -10V power supply...........................................................................................................................11
3.4 External thermal trip input (TH1+, TH1-).........................................................................................12
4. External diagram ....................................................................................................... 13
5. Specification .............................................................................................................. 14
6. Warranty.................................................................................................................... 15

E6581339⑥
6
1. Name and function of each section
Following figure shows appearance and name of each section of the expansion IO card
option.
1.1 Appearance
1.2 Name of each section (terminal)
R1A Programmable relay output 1
R1B Programmable relay output 1
T
B
1 R1C Programmable relay output 1
N10 Analog input setting power output -10V
P24/PLC Common terminal of extension terminal input
LI1 Extension terminal input LI1
LI2 Extension terminal input LI2
LI3 Extension terminal input LI3
LI4 Extension terminal input LI4
T
B
2
CC Digital signal equipotential (0V)
TH1+ PTC input terminal (+)
TH1- PTC input terminal (-)
OUT3 Extension terminal output OUT3
OUT4 Extension terminal output OUT4
NO1 Output 3 and 4 common terminal
T
B
3
CC Digital signal equipotential (0V)
Inverter cover hook for the fixation
SINK/SOURCE Select SW
SINK(INT)
SOURCE
SINK(PLC)
TB1
TB2
TB3

E6581339⑥
7
2. Installing the IO card option in the VF-AS1/PS1
2.1 Connection to the inverter
(1) Turn off input power before installing.
Mandatory
Turn off the input power of VF-AS1/PS1 and wait for at least 15 minutes and then check
that the CHARGE lamp on VF-AS1/PS1 is no longer lit.
(2) Securing the option to the inverter
a) Insert a flat-blade screwdriver in each of the two holes at the upper part of the front
panel, release the panel mounting tab by pushing the screwdriver down, and
remove the front panel cover.
b) Install the option in the inverter by fitting the tabs on the lower side of the option into
the slots at the lower part of the inverter front panel.
c) Make sure the option is securely attached to the inverter. Then, check whether the
plastic bosses on the inverter case have fitted in the holes at the upper and lower
parts of the option*.
d) Insert the tabs at the lower part of the front cover into the slots at the lower part of
the inverter to attach the front cover to the inverter.
a)
b)
c)
d)
* When installing this option to below capacities,
remove the Add-on type option case.
VFAS1: 200V 55, 75kW
400V 90 - 500kW
VFPS1: 200V 55 - 90kW
400V 90 - 630kW

E6581339⑥
8
2.2 Wiring
When conducting wiring, follow the instructions below.
• Use shield wire for control signal line and ground the unit with shield wire
(Use twisted pair shield cable for wiring of the analog monitor output.)
• Never bind the signal line and main circuit connection wire together.
• Fix the communication cables after connected.
Terminal Block Applicable wire size The wire length of
peel off the end
Using screwdriver
(The blade tip)
Tightening
torque
TB1 0.2 to 2.5 mm2About 7mm
0.6mm thickness
and 3.5mm width. 0.5 to 0.6 N・m
TB2 and TB3 0.2 to 1.5mm2About 5mm
0.4mm thickness
and 2.5mm width. 0.22 to 0.25 N・m
 < Input/output terminal interface >
Terminal
symbol Function Electrical specification Internal circuit
R1A
R1B
R1C
Relay contact
point output
Configuration of 1C contact point
250Vac - 2A (cosφ=1)
250Vac - 1A (cosφ=0.4)
30Vdc - 1A
R1A
R1B
R1C
Ry
LI1
LI2
LI3
LI4
Contact point
input Changeover
of sink or source
No voltage contact input
24Vdc - 5mA
Sink input (common voltage 24V)
ON ：less than 10Vdc
OFF ：16Vdc or more
Source input
ON ：11Vdc or more
OFF ：less than 5Vdc
Note:
Even when an external power supply is
used (in sink logic mode i.e. when
SINK(PLC) is selected), connect
the reference potential-side (0V side)
cable from the power supply
to the CC terminal.
24V power supply
24Vdc power output (when SW1 is
in any position other than PLC)
24V internal output terminal
24Vdc - 60mA max
PLC/
P24 Common terminal
for external power
supply
If SW1 is turned to the PLC position,
this terminal can be used as a common
terminal when an external power
supply is used.
SINK Logic（SW=SINK(INT)）
SW
2.2k ohm
2.2k ohm
CC
LI1
LI2
LI3
LI4
SOURCE
P24/
PLC
SINK(PLC)
SINK
(INT) P24
SINK Logic (SW=SINK(PLC))
SW
2.2k ohm
2.2k ohm
CC
LI1
LI2
LI3
LI4
SOURCE
P24/
PLC
SINK(PLC)
SINK
(INT) P24
SOURCE Logic (SW=SOURCE)
SW
SOURCE
2.2k ohm
P24/
PLC
2.2k ohm
CC
LI1
LI2
LI3
LI4
SINK(PLC)
SINK
(INT)
P24
Lan current signal.
Chose low current contacts to
avoid poor attaching.

E6581339⑥
9
Terminal
symbol Function Electrical specification Internal circuit
TH1+
TH1- Thermal trip input
The resistance between TH1+ and TH1-
Tripping value: about under 70 ohm
or about over 2.5k ohm
Reset value: about 1.6k ohm
Voltage
detection
circuit
3k ohm
TH1+
P5
TH1-
N10 -10V power upply DC-10V - 10mA Ｎ10 OP
100 ohm
OUT3
OUT4
NO1
Multifunction
programmable
open collector
output.
Open collector output
Drive current
External power supply used: 50mA
Internal power supply used: 20mA
Drive voltage
12V min - 30V max
Isolated other circuit.
20 ohmOUT3
OUT4 20 ohm
NO1
CC Common to
input/output
Digital signal equipotential (0V) erminal
for the control circuit
