Toshiba STRATA CIX Owner's manual

726+,%$ Digital Solutions Division
November 2004
Strata CIX and CTX
Telephone Button Programming Manual

Publication Information
Toshiba America Information Systems, Inc., Digital
Solutions Division, reserves the right, without prior
notice, to revise this information publication for any
reason, including, but not limited to, utilization of new
advances in the state of technical arts or to simply
change the design of this document.
Further, Toshiba America Information Systems, Inc.,
Digital Solutions Division, also reserves the right,
without prior notice, to make such changes in
equipment design or components as engineering or
manufacturing methods may warrant.
CIX-PM-PHONE-VA
Version A, November 2004
Strata CIX and CTX
General End User Information
The Strata CIX, CTX28, CTX100 and CTX670 Digital
Business Telephone Systems are registered in
accordance with the provisions of Part 68 of the
Federal Communications Commissionís Rules and
Regulations.
Refer to the General Description or Installation and
Maintenance Manual for your system for information
on:
♦FCC Requirements
♦FCC registration Number
♦Part 68 complaience
♦Ringer Equivalence number
♦Network connection information
♦USOC jack required
♦Network Requirements
♦Authorized Network Parts
♦Radio Frequency Interference
♦UL Requirements
♦Important Music-on-Hold requirements
♦Industry Canada label identifies certified
equipment
This system is listed with Underwriters Laboratory.
THE SPECIFICATIONS AND INFORMATION
PROVIDED HEREIN ARE FOR INFORMATIONAL
PURPOSES ONLY AND ARE NOT A WARRANTY OF
ACTUAL PERFORMANCE, WHETHER EXPRESSED
OR IMPLIED. THE SPECIFICATIONS AND
INFORMATION ARE SUBJECT TO CHANGE
WITHOUT NOTICE. ACTUAL PERFORMANCE MAY
VARY BASED ON INDIVIDUAL CONFIGURATIONS,
USE OF COLLATERAL EQUIPMENT, OR OTHER
FACTORS.
© Copyright 2004
Toshiba America Information Systems, Inc.
Digital Solutions Division
All rights reserved. No part of this manual, covered by the copyrights hereon, may be reproduced in any form or by
any meansó graphic, electronic, or mechanical, including recording, taping, photocopying, or information retrieval
systemsó without express written permission of the publisher of this material.
Strata and SmartMedia are registered trademarks of Toshiba Corporation.
Stratagy is a registered trademark of Toshiba America Information Systems, Inc.
Windows is a registered trademark of Microsoft
Trademarks, registered trademarks, and service marks are the property of their respective owners

Strata CIX/CTX Telephone Button Programming 11/04 i
Contents
Chapter 1 – Telephone Button Programming
Record Sheet Overview......................................................................................................................1-1
Telephone Button Overview ...............................................................................................................1-2
Telephone Button Commands ..................................................................................................... 1-3
Button Programming Examples..........................................................................................................1-5
Program 100 ................................................................................................................................ 1-5
Program 200 ................................................................................................................................ 1-5
Program 204 ................................................................................................................................ 1-6
Program 205 ................................................................................................................................ 1-6
Program 208 ................................................................................................................................ 1-6
Button Programming Procedure.........................................................................................................1-7
100 Series Programs ....................................................................................................................... 1-11
200 Series Programs........................................................................................................................1-28
300 Series Programs........................................................................................................................1-53
400 Series Programs........................................................................................................................1-73
500 Series Programs........................................................................................................................1-74
600 Series Programs ....................................................................................................................... 1-91
800 Series Programs........................................................................................................................1-94
900 Series Programs........................................................................................................................1-97
System Initialize.........................................................................................................................1-97
Display Version..........................................................................................................................1-98
Set Time and Date...................................................................................................................1-100
ISDN Trace Location................................................................................................................1-102
All ISDN Trunk Trace...............................................................................................................1-103
Event Trace Side Change........................................................................................................1-103
System Admin Log...................................................................................................................1-104
Format/Unmount SmartMedia..................................................................................................1-105
MAC Address (System Serial Number)....................................................................................1-106
Data Backup.............................................................................................................................1-106
Program Update.......................................................................................................................1-108
Make Busy Control...................................................................................................................1-108
Regional Selection...................................................................................................................1-110
IP Configuration .......................................................................................................................1-111
Chapter 2 – System Error Codes
Common Error Code Table ................................................................................................................2-1
System Programming Error Codes.....................................................................................................2-2
Station Programming Error Codes .....................................................................................................2-5
Trunk Programming Error Codes .....................................................................................................2-13
Attendant Position Programming Error Codes .................................................................................2-20
Service Programming Error Codes...................................................................................................2-21
Networking Programming Error Codes.............................................................................................2-26
Equipment Programming Error Codes .............................................................................................2-27

This page is intentionally left blank.

Strata CIX/CTX Telephone Button Programming 11/04 1-1
Telephone Button
Programming
Telephone Button Programming 1
This chapter discusses the button programming interface provided with Strata CIX / CTX. This chapter also
includes Button Programming examples, procedures, and tables to program 100~800 series programs.
This chapter has tables that list programs sequentially by program number. Tables found below a program
table contain required information for the above program.
Important!
If you do not program button sequences correctly, the DKT LCD will display an error
code. Refer to Chapter 2–System Error Codes.
Record Sheet Overview
Fill out the Record Sheets (see Figure 1-1 as an example), then enter this data using a 20-button LCD
digital (DKT) telephone.
6378
66 BETA
Station
Assignment
DKT Parameters Record Sheet
PDN: _____________________
Station Type Ext. Ring Repeat Continuous DTMF Ring Over Busy Cycles
Key Strip Pattern Not Used Display Language Attd. Overflow Dest.
Key Strip Type Ringing Line Preference Adapter Trunk Test and Verify
Add-on Modules Off-hook Preference Blind Transfer Auto Line Hold
Tone/Voice First Ringing Preference. Mail Box Selection
OCA Type Text Message Display MIC Init. Value
Handsfree MIC Call History Memory Microphone
Handsfree Tone DTMF Back Tone Speaker Mode Tones
PDN: _____________________
Station Type Ext. Ring Repeat Continuous DTMF Ring Over Busy Cycles
Key Strip Pattern Not Used Display Language Attd. Overflow Dest.
Key Strip Type Ringing Line Preference Adapter Trunk Test and Verify
Add-on Modules Off-hook Preference Blind Transfer Auto Line Hold
Tone/Voice First Ringing Preference. Mail Box Selection
OCA Type Text Message Display MIC Init. Value
Handsfree MIC Call History Memory Microphone
Handsfree Tone DTMF Back Tone Speaker Mode Tones
PDN: _____________________
Station Type Ext. Ring Repeat Continuous DTMF Ring Over Busy Cycles
Key Strip Pattern Not Used Display Language Attd. Overflow Dest.
Key Strip Type Ringing Line Preference Adapter Trunk Test and Verify
Add-on Modules Off-hook Preference Blind Transfer Auto Line Hold
Tone/Voice First Ringing Preference. Mail Box Selection
OCA Type Text Message Display MIC Init. Value
Handsfree MIC Call History Memory Microphone
Handsfree Tone DTMF Back Tone Speaker Mode Tones
PDN: _____________________
Station Type Ext. Ring Repeat Continuous DTMF Ring Over Busy Cycles
Key Strip Pattern Not Used Display Language Attd. Overflow Dest.
Record Sheet
Provides a list of
available features. The
sheet is used to record
the assignment of
features or the operation
of each program. Each
sheet provides space to
record data. This data
will be referred to when
programming the
system.
Figure 1-1 System Record Sheet Sample

Telephone Button Programming
Telephone Button Overview
1-2 Strata CIX/CTX Telephone Button Programming 11/04
Telephone Button Overview
Strata CTX programmers can access programming mode from any DKT LCD telephone, except DKTs
connected to an RDSU. A 20-button telephone (shown below) is required to ensure full access to all
programming parameters. The telephone button programming interface enables limited programming
capabilities over ranges of stations or trunks.
Note Telephones connected to an RDSU cannot be used to program Strata CTX.
Figure 1-2 shows the telephone button pad for the DKT3020-series digital telephone or IPT1020-SD.
Figure 1-2 DKT3010/3020 and IPT1020-SD Button Telephones
6929
Msg Spdial
RedialMic
Spkr Cnf/Trn Hold
FB01
FB02
FB03
FB04
FB05
FB06
FB07
FB08
FB09
FB10
FB11
FB12
FB13
FB14
FB15
FB16
FB17
FB18
FB19
FB20
FB01
FB02
FB03
FB04
FB05
FB06
FB07
FB08
FB09
FB10
Page
Mode
Scroll Feature
FB buttons for 20-button phones
IPT1020-SD, DKT3020-S, DKT3020-SD
FB buttons for
10-button phones
DKT3010-S, DKT3010-SD
Vol
ZQ

Telephone Button Programming
Telephone Button Overview
Strata CIX/CTX Telephone Button Programming 11/04 1-3
Telephone Button
Programming
Telephone Button Commands
1. Use the following buttons to execute the commands:
•Hold ñ Enter.
•Page/Scroll ñ Scroll up or down.
•Spkr ñ This delimiter moves cursors between sub-parameter values.
•Vol▲ñ Escape. Vol▲displays as &on the LCD. Press Vol▲to program #or *in dialing
sequences.
•Vol▼ñ Back space for line editing.
•# # Hold ñ Cancel.
•*ñ Use this button between values to specify a range of objects to be programmed (e.g.,
1001*1005 enables programming of stations 1001 through 1005).
•**ñ Use this button between values to specify a set of objects to be programmed (e.g.,
1001**1005**1012 enables programming of stations 1001, 1005 and 1012).
•Off-hook ñ lift and replace the handset to immediately exit programming mode.
2. Keep the following in mind as you maneuver through Strata CTX programs.
•Default and/or current settings are displayed on the telephone LCD with an asterisk.
•Some Strata CTX Programs have more than 20 programmable parameters. To toggle from
parameters FB01~FB20 and FB21~FB40 press the Scroll or Page button after entering Program
Mode.
•To view parameter options on your telephone LCD, press the desired FB button and press the
Scroll or Page button.
•Each parameter shows a number to the left (e.g., 2:DISABLE). Program the desired parameter by
pressing the number button (in this example 2) that corresponds to your desired parameter.
•To enter data, use the number keys.
•To submit your program entry press Hold. To confirm a submitted entry, press Hold again.
•To exit a program press # # Hold.
•To enter the #character in your data string press the Vol▲and the #button simultaneously. An &
sign appears in your LCD. Press the #button, then enter the remaining data.
•If you get an error code, press Hold (twice) to continue programming. See ìSystem Error Codesî on
page 2-1 for error code details.
Programming Parameters
Programs can have between one and 40 programmable parameters, each represented by the FBnn
buttons. The LEDs light up for each FBnn button that features a programmable parameter. Each
parameter is programmed by entering values into the LCD from the telephone button pad.
1. At the SELECT PARAM prompt, press the appropriate FBnn button.
2. Enter the appropriate value from the telephone button pad using the Parameter Fields tables supplied
with each program.
3. Press Hold to submit.
4. Press another FBnn button to program more parameters
… or press Hold again to program.
Programming Sub-parameters
Some commands enable programming of Sub-parameters to further refine Strata CTX settings. Internet or
Network IP addresses are entered using sub-parameter data. IP addresses are displayed as four three-
digit values, or Octets, separated by ìperiodsî (e.g., 192.168.255.253). Your programming telephoneís
LCD is only capable of displaying the IP information three digits, or one Octet, at a time.

Telephone Button Programming
Telephone Button Overview
1-4 Strata CIX/CTX Telephone Button Programming 11/04
For example, selecting FB01 in Program 916 displays the first Octet, 192, on the LCD. To view or change
the next Octet (in this example 168) in the IP Address, press the Spkr button. Pressing Spkr again,
displays the following Octet (in this example 255).
The following is an example from Program 200, FB04. FB04 is broken down into three sub-parameters as
follows COS DAY1, COS DAY2 and COS NIGHT.
1. At the SELECT PARAM prompt, press FB04.
2. At the COS DAY1= prompt, enter a value from 1~32.
3. Press Spkr.
4. At the COS DAY2= prompt, enter a value from 1~32.
5. Press Spkr.
6. At the COS NIGHT= prompt, enter a value from 1~32.
7. Press Hold to submit.
8. Press another FBnn button to program more parameters
… or press Hold again to program a new DN.
Note To change one of the sub-parameters, you must proceed through all three sub-parameters before
pressing Hold. For example, to change the value of COS DAY1, you must change the COS DAY1
value, then press Spkr twice, and finally, press Hold.

Telephone Button Programming
Button Programming Examples
Strata CIX/CTX Telephone Button Programming 11/04 1-5
Telephone Button
Programming
Button Programming Examples
The following examples show you how to use the Strata CTX button programming interface. Toshiba highly
recommends the use of Strata CTX WinAdmin to meet the demands of your telephone system
programming.
Suppose a customer needed to assign a DKT Station to a PDN. Based on the Identify Program Sequences
in Chapter 1 of the Programming Manual Volume 1, you can immediately identify the Program numbers
and sequence required to complete this basic task. Login to the Button Programming Mode using the
directions on Page -7 and follow the steps below.
Program 100
Reference ìProgram 100î on page 11. For this example, an eight station BDKU PCB is assigned to Slot 01/
Cabinet 01 (xxyy).
1. Enter programming mode. See ìStep 1: Enter Program Mode on page 1-7."
2. At the PROG= prompt enter 100 and press Hold.
3. At the EQUIP= prompt enter 0101 (xxyy) and press Hold.
“Program 100” on page 11 tells us that a three digit PCB code (nnn) is required. From the table, “PCB
Codes” on page 1-12, we can derive that the PCB code for a BDKU is “017.” Furthermore, the
“Program 100” table shows us the button sequence required for programming a BDKU in the fourth
row of the table.
4. Press FB01. Enter 017 and press Hold.
“Program 100” on page 11 also informs us that an “n” value is required to complete the PCB
assignment. These “n” values are listed in the column titled “Value(s).” When you look in the fourth
row of the “Value(s)” column there are five “n” value choices. For this example, select “2. 8 DKT no
OCA.”
5. Press FB03. Enter 2and press Hold twice.
6. Press ##Hold to return to the PROG= prompt.
Program 200
Reference ì200 Series Programsî on page 1-28. A DKT assignment (DN = 1000) is made to Circuit 01,
Slot 01, and Cabinet 01 for the BDKU card installed in Step 1 above.
1. Enter programming mode. See ìStep 1: Enter Program Mode on page 1-7."
2. At the PROG= prompt enter 200 and press Hold.
3. At the DN= prompt enter 1000 (n) and press Hold.
4. Press FB01. At the EQUIP= prompt enter 010101 (xxyyzz) and press Hold.
5. Press FB02. Press 1to select a DKT and press Hold.
6. Press FB03. Press 1to select Extension as the Circuit Type and press Hold.
For this example, only the above FBs need to be assigned. Press Hold again before proceeding to the
next step.
7. Press ##Hold to return to the PROG= prompt.
Note Additional assignments can be made to fine tune this DKT assignment. If specific assignments are
not made, the system automatically assigns the default value.

Telephone Button Programming
Button Programming Examples
1-6 Strata CIX/CTX Telephone Button Programming 11/04
Program 204
Reference ìProgram 204î on page 34 and review Summary column field descriptions. This program
enables you to setup the DKT parameters.
1. Enter programming mode. See ìStep 1: Enter Program Mode on page 1-7."
2. At the PROG= prompt enter 204 and press Hold.
3. At the DN= prompt enter 1000 (n) and press Hold.
4. Press FB01. Press 1to select a Extension and press Hold.
5. Press FB02. Press 3to select Pattern 3 for this DKT and press Hold.
For this example, we are using a 20-button DKT. There are three button patterns to choose from for
each type of digital telephone.
Only the above FBs need to be assigned. Press Hold again before proceeding to the next step.
6. Press ##Hold to return to the PROG= prompt.
Note Additional assignments can be made to fine tune DKT parameters. See Summary column for field
descriptions and default values. If specific assignments are not made, the system automatically
assigns the default value.
Program 205
Reference ìProgram 205î on page 39 and ìFeature/Button Code Parameter Assignmentsî on page 1-41.
This program assigns features and parameters to the FB buttons on your DKT telephone. In this example,
the FB10 button on your DKT will be programmed to act as a GCO button.
1. Enter programming mode. See ìStep 1: Enter Program Mode on page 1-7."
2. At the PROG= prompt enter 205 and press Hold.
3. At the DN= prompt enter 1000 (n) and press Hold.
4. Press FB10. Enter 130 to assign a GCO and press Spkr.
To select the n1, n2, n3, n4 and n5 values required in “Program 205” on page 39, see “GCO” in the
table titled “Feature/Button Code Parameter Assignments” on page 1-41.
5. Enter 1to assign a GCO number and press Spkr.
6. Enter 1to assign a GCO index and press Spkr.
7. Enter 2to enable immediate ringing for this GCO and press Spkr.
8. Enter 1to assign a soft ring tone to this GCO and press Spkr.
9. Enter 900 to assign an Owner DN to this GCO number and press Hold twice.
10.Press ##Hold to return to the PROG= prompt.
Note Press ##Hold again to exit Button Programming Mode.
Program 208
Reference ìProgram 208î on page 46. This program assigns timing parameters to Primary DNs.
1. Enter programming mode. See ìStep 1: Enter Program Mode on page 1-7."
2. At the PROG= prompt enter 208 and press Hold.
3. At the DN= prompt enter 1000 (n) and press Hold.
4. Press FB01. Press 10 to set the number of ABR attempts and press Hold.
5. Press FB02. Press 60 to set ABR to attempt redials in 60 second increments and press Hold.
6. Press FB03. Press 20 to set the ABR Recall Timer and press Hold.

Telephone Button Programming
Button Programming Procedure
Strata CIX/CTX Telephone Button Programming 11/04 1-7
Telephone Button
Programming
7. Press FB04. Press 60 to set the Hold Recall Timer and press Hold.
8. Press FB05. Press 15 to set the First Interdigit Timer and press Hold.
9. Press FB06. Press 5to set the Second Interdigit Timer and press Hold.
10.Press FB07. Press 32 to set the Ring Transfer No Answer Timer and press Hold twice.
11.Press ##Hold to return to the PROG= prompt.
Now that you are more familiar with the Strata CTX button programming interface, begin programming your
Strata CTX system starting with Step 1 below.
Button Programming Procedure
Step 1: Enter Program Mode
Enter the button sequence displayed below to enter the CTX670 programming interface from a DKT
station.
1. Log in by pressing: Hold ✱#✱#1✱2✱3✱.
2. At the PASSWORD= prompt, enter your password. Default is 0000.
3. Press Hold.
Step 2: Enter Program Number
1. At the PROG= prompt enter the three digit program code (e.g., 200) and press Hold.
2. Programmable parameters are identified by the FB LEDs that are illuminated on the DKT. Go to
ìChoose a Button Sequenceî on page 1-7 Press on the related FBnn button to program a parameter.
… or if there are no illuminated FB LEDs, continue to Step 3.
Step 3: Enter FB00 Parameters
FB00 parameters designate a specific station, trunk, or circuit to be programmed. The FB00 prompt (e.g.,
EQUIP=, DN=, INDEX=, etc.) appears automatically in the LCD screen.
1. At the FB00 prompt, enter the desired value using the telephone number pad.
2. Press Hold.
Step 4: Choose a Button Sequence
➤Select the button sequences based on the programs required for programming the Strata CTX from the
Telephone. For 100~900 series programs, refer to pages 11~97.
Program Listings
This table is a list of programs found in this chapter.
Program
Number Program Name
100 Card Slot Assignment
102 Flexible Access Codes
103 Class of Service
104 System Timers
105 System Parameters
106 Day/Night Mode Day of Week Mapping

Telephone Button Programming
Button Programming Procedure
1-8Strata CIX/CTX Telephone Button Programming 11/04
107 PAD Table Assignment
108 PAD Group Assignment
109 Music on Hold
110 Password Assignment
111 Destination Restriction Level
112 Day/Night Mode Calendar
113 Day/Night Mode Daily Schedule
114 PAD Conference Table Assignment
115 Advisory Messages
116 Data Initialize
117 Public Dial Plan Digit
200 Station Data
201 Station Delete
202 ISDN BRI Station
203 Change DN
204 DKT Parameters
205 DKT Feature Keys
206 Phantom DNs
207 One Touch Assignment
208 Station Timer Assignments
209 Hunting Group Assignments
210 Group Call Pickup
213 ADM Feature Keys
214 DSS Console Assignment
215 DSS Feature Keys
216 Emergency Ringdown Assignment
217 ISDN Station Data
218 Station Hunt Group Assignment (Member Assignments)
300 Trunk Assignment
301 Trunk Delete
302 PRI Trunks
303 ISDN Trunk Delete
304 Incoming Line Group Assignment
305 ILG Delete
306 Outgoing Line Group Assignment
307 OLG Delete
308 Trunk Timers
309 Direct Inward Dialing
310 DIT Assignment
311 MOH Source
312 DID Delete
313 Caller ID Assignment
315 T1 Trunk Card
316 Shared D Channel
Program
Number Program Name

Telephone Button Programming
Button Programming Procedure
Strata CIX/CTX Telephone Button Programming 11/04 1-9
Telephone Button
Programming
317 ISDN BRI Trunk
318 DID Intercept Assignment
319 Intercept Treatment
320 B Channel Position ISDN Primary Trunk
321 Calling Number Identification
322 ISDN Calling Number Table
323 Call by Call Service
324 CBC Time Zones
400 Emergency Call Destination Assignment
404 Attendant Group Assignment
500 System Call Forward Assignment
501 System Speed Dial Assignment
502 Terminal Paging Group Assignment
503 Paging Devices Group Assignment
504 System Call Forward Operation Status
506 Verified Account Codes
507 Door Phone Assignment
508 Door Lock Control Assignment
509 DR Override by System Speed Dial
510 COS Override Assignment
512 SMDR for System Assignment
513 SMDR for ILG Assignment
514 SMDR for OLG Assignment
515 View BIOU Control Relay Assignment
516 Station Speed Dial
520 LCR Local Route Plan
521 LCR Route Plan Digit Analysis Assignment
522 LCR Exception Number Route Plans
523 LCR Route Plan Schedule Assignment
524 Route Table to Route Definition Assignment
525 LCR Route Definition Assignment
526 Modified Digits Table Assignment
527 LCR Holiday Table Assignment
528 LCR Public Day of Week Mapping Table
529 LCR Route Plan Time Zone Assignment
530 DR LCR Screening Table Assignment
531 DR Screening Table for OLG
532 DR Table Allow/Deny Definition
533 DR Level Table Assignment
534 DRL Exception Table Assignment
540 Pilot DN Assignment
541 Pilot DN Delete
550 Enhanced 911 Emergency Call Group Number
570 Account Code Digit Length
Program
Number Program Name

Telephone Button Programming
Button Programming Procedure
1-10 Strata CIX/CTX Telephone Button Programming 11/04
Programming Tables
The programming tables in this chapter appear sequentially, beginning with the 100 series programs and
ending with the 900 series programs. Tables immediately following a program table are provided for
reference. For example, the PCB Code table shown after the Program 100 table gives important PCB
codes needed in Program 100.
571 Exception Numbers for Forced Account Codes
573 Delete Door Phone
576 Door Phone Night Ring Over External Page
577 Caller History
579 System Voice Mail Data
580 Voice Mail Port Data
650 Behind Connection Assignment
651 Private Routing Plan Analysis Table Assignment
653 Private Route Choice Table Assignment
654 Private Route Definition Table Assignment
655 Private Digit Modification Table Assignment
656 Node ID Assignment
657 Network COS Mapping Table Assignment
658/659/660 Network DRL Mapping Tables
801 Network Jack LAN Device Assignment
803 IO Logical Device Assignment
804 RS232C Data Assignment
900 System Initialize
901 Display Version
902 Set Time and Date
903 Event Trace Control
904 ISDN Trace Location
905 All ISDN Trunk Trace
906 Event Trace Side Change
907 System Admin Log
908 Format/Unmount SmartMedia
909 MAC Address (System Serial Number)
910 Data Backup
911 Program Update
912 Make Busy Control
915 Regional Selection
916 IP Configuration
Program
Number Program Name

Telephone Button Programming
100 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04 1-11
Telephone Button
Programming
100 Series Programs
Table 1-1 Program 100
Button Sequence Value(s) Summary
100 Card Slot Assignment
100, Hold
100-00 Card Slot Assignment
xxyy, Hold
xx =
yy = Cabinet: 01~02 (Basic CTX670 and CTX100)
01~07 Expanded CTX670
Slot: 01~8 (CTX100)
01-10 (CTX670)
Equipment Number
100-01 PCB Type
FB01, nnn, Hold,
Hold
nnn = 3 digit PCB Code (See
table below). Valid Codes:
000, 001, 002, 005, 006,
009, 010, 011, 013.
Assign one of the following:
ï BIOU1 or BIOU2 Page/MOH/BGM Relay Control.
ï RSTU or PSTU w/ 8 standard phones.
ï All Analog CO Line OCBs.
ï BVPU with 4 VoIP circuits.
ï RBSU/RBSS with 4 BRI S/T interface.
ï Delete PCB
100-02 PDKU/RDTU/RPTU
Options
FB01, nnn, Hold,
FB02, n, Hold,
Hold
nnn =
n =
3 digit PCB Code. Valid
Codes: 017, 018
1. None
2. DKT no OCA or 8 Ch
3. DKT w/ OCA or 16 Ch
4. 24 Ch (n/a for PDKU)
5. 30 Ch (n/a for PDKU)
Assign one of the following:
ï PDKU with OCA toggle
ï RDTU or RPTU, T1 or PRI Channel
100-03 BDKU/BDKA Options
FB01, nnn, Hold,
FB03, n, Hold,
Hold
nnn =
n =
3 digit PCB Code Valid
Codes: 003, 007, 014
1. None
2. 8 DKT no OCA
3. 8 DKT w/ OCA
4. 16 DKT no OCA
5. 16 DKT w/ OCA
Assign BDKU or BDKS
100-04 BRI TEI Options
FB01, nnn, Hold,
FB04, n, Hold,
Hold
nnn =
n =
3 digit PCB Code. Valid
Codes: 012, 013, 015, 016
1. None
2. 8 DKT no OCA
3. 8 DKT w/ OCA
4. 16 DKT no OCA
5. 16 DKT w/ OCA
Assign RBUU/RBUS or RBSU/RBSS.

Telephone Button Programming
100 Series Programs
1-12 Strata CIX/CTX Telephone Button Programming 11/04
Note These three-digit Feature Index Numbers should not be confused with the Program 205 three-digit
Button Codes.
Table 1-2 PCB Codes
Code PCB Type Assigned
Name Circuit/Type Code PCB Type Assigned Name Circuit/Type
000 None No Card or
Delete Card n/a 011 EMU REMU
BVPU 4 Circuits
001 COU RCOU
RGLU2
4 Loop Lines
4 Gnd./Loop Lines 012 BSU RBSU 2 S/T interfaces
002 STU RSTU2 8 Stations 013 BSU_BSS RBSU+RBSS 4 S/T interfaces
003 DKU PDKU2
RWIU
8 Stations
8 or 32 wireless 014 PTU RPTU 8, 16 and 24 PRI Lines
004 Not used n/a n/a 015 BUU RBUU 2 U Interfaces
005 8COU RCOU+RCOS 8 Loop CO Lines 016 BUU_BUS RBUU+RBUS 4 U Interfaces
006 DDU RDDU 4 DID Lines 017 NEW_DKU_8 BDKU1 8 Stations
007 DTU RDTU2 8, 16, 24 and 30 channel
T1 018 NEW_DKU_16 BDKU1+BDKS1 16 Stations
008 DSU RDSU 4 Standard Ports
4 Digital Ports 019 IOU1 BIOU Page/MOH/BGM Relay
009 CIU RCIU2 4 or 8 Circuit Caller ID 020 IOU2 BIOU Page/MOH/BGM Relay
010 MCU RMCU 2 or 4 E911 CAMA Lines
Table 1-3 Program 102
Button Sequence Value(s) Summary
102 Flexible Access Plan
102, Hold
Assigns feature access codes, individual line access codes and
outgoing line group (OLG) access codes to the Flexible Numbering
Plan.
Does not include PDNs, PhDNs, Pilot numbers, or Hunt Group pilot
numbers.
102-00
Access Code
n, Hold,
n = Up to 5-digit Flexible
Numbering Plan Enter the digits to be dialed (0~9,#,*) to access a Feature or an Outgoing Line Group (OLG).
To delete, select `No Data` in `01 Feature Name`. Conflict with an
assigned DN will produce an error.
102-01 FB01, nnn, Hold nnn = 3 digit Feature Code (551
should be selected for a
Flexible Numbering OLG)
Select the Feature to which the access code is being assigned.
Note To assign an access code to an Outgoing Line Group (OLG),
select ìLine Group access code - one access code for each
OLG.î To assign the prefix digit(s) for the access code of
individual lines, select ìLine access code - leading digit(s) to
access individual lines.î Example: If #7 is selected as the line
access prefix, the users willdial #7xxx to access an individual
line (where xxx is the line number).
102-02 FB02, n1, Hold, Hold n1 = 0~32 (CTX100)
0~50 (CTX670 Basic)
0~128 (CTX670
Expanded)
Enter the Outgoing Line Group number to which the OLG access
code is being assigned.
Table 1-4 Flexible Numbering Plan Default Settings
Flexible Numbering Feature Feature
Index
Default
Access Code
Programmed
Value
No Data
ABR - Activate 150 #441
ABR - Cancel 151 #442
Call Park Orbits - Activate 170 #33
Call Park Orbits - Park Answer (Retrieve Parked Call) 173 #32
System Orbit Number 174 7000~7019
DND -Local Activation 180#6091

Telephone Button Programming
100 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04 1-13
Telephone Button
Programming
DND -Local Cancellation 181#6092
DND -Remote Activation 182#6191
DND -Remote Cancellation 183#6192
Door Lock Control -Unlock 190 #12
Door Phones -Call 191 #15
Flash -short 200 #450
Flash -long 210 #451
Group Paging -Invoke All Group Paging 220 #30
Group Paging -Invoke Individual Group Paging 230 #31
Answer for External Group Paging 232 #5#36
Emergency Page -Invoke All Emergency Paging 240 #37
Emergency Page -Invoke Individual Emergency Paging 250 #38
Originate Call by Terminal Speed Dial (Index: 00-99) 260 *1
Originate Call by System Speed Dial (Index: 000-099) 261 *2
Originate Call by System Speed Dial (Index: 100-199) 262 *3
Originate Call by System Speed Dial (Index: 200-299) 263 *4
Originate Call by System Speed Dial (Index: 300-399) 264 *5
Originate Call by System Speed Dial (Index: 400-499) 265 *6
Originate Call by System Speed Dial (Index: 500-599) 266 *7
Originate Call by System Speed Dial (Index: 600-699) 267 *8
Originate Call by System Speed Dial (Index: 700-799) 268*9
Register Speed Dial 269 #66
Call Forward (CF-A; Any Call) - Activation 340 #6011
Call Forward (CF-B; Any Call) - Activation 341 #6021
Call Forward (CF-NA; Any Call) - Activation 342 #6031
Call Forward (CF-B/NA; Any Call) - Activation 343 #6041
Call Forward (CF-A; External Call) - Activation 350 #6013
Call Forward CF-B; External Call) - Activation 351 #6023
Call Forward (CF-NA; External Call) - Activation 352 #6033
Call Forward (CF-B/NA; External Call) - Activation 353 #6043
Call Forward (CF-A; Any Call) - Remote Activation 360 #6012
Call Forward (CF-B; Any Call) - Remote Activation 361 #6022
Call Forward (CF-NA; Any Call) - Remote Activation 362 #6032
Call Forward (CF-B/NA; Any Call) - Remote Activation 363 #6042
Call Forward (CF-A; External Call) - Remote Activation 370 #6014
Call Forward (CF-B; External Call) - Remote Activation 371 #6024
Call Forward (CF-NA; External Call) - Remote Activation 372 #6034
Call Forward (CF-B/NA; External Call) - Remote Activation 373 #6044
Call Forward (Any Call) - Cancellation 380#6051
Call Forward (External Call) - Cancellation 390 #6053
Call Forward (Any Call) - Remote Cancellation 400 #6052
Call Forward (External Call) - Remote Cancellation 410 #6054
Change Password for Remote Activation/Cancellation 420 #670
Input Account Code 530 #46
Change DISA Security Code 540 #658
Outgoing Call by Directing Individual Trunk 550 #7
Table 1-4 Flexible Numbering Plan Default Settings (continued)
Flexible Numbering Feature Feature
Index
Default
Access Code
Programmed
Value

Telephone Button Programming
100 Series Programs
1-14 Strata CIX/CTX Telephone Button Programming 11/04
Outgoing Call by Directing Outgoing Line Group 551 None
Three Way Conferencing (Override to Tandem Connection) 560 #494
Enter User Programming Mode 570 #9876
LCR -Outgoing Call 5809
Set Voice Mail Message Waiting (activate MW without ringing for VM) 591 #63
Release Received Message Waiting 592 #409
Release Sent Message Waiting (Cancel MW without ringing for VM)) 593 #64
MW Answer access code (Retrieve Received Message Waiting) 594 #408
Cancel ACB 600 #431
Start BGM 610 #490
Stop BGM 611 #491
Start BGM for External Paging Device 612 #492
Stop BGM for External Paging Device 613 #493
Built-in modem 630 #19
Night Ring Answer 640 #5#39
Travelling Class Override Code Input Number 650 #471
Change Travelling Class Override Code 651 #69
Activate System Call Forward 670 #620
Cancel System Call Forward 671 #621
Call Pickup for Incoming Call -Group Pickup 680#5#34
Call Pickup for Incoming Call -Directed Terminal 681#5#5
Call Pickup for Incoming Call -Directed Group 682#5#32
Call Pickup for Incoming Call -Directed DN 683#5#22
Call Pickup for Incoming Call -Any External Call 684#5#9
Call Pickup for On-Hold Call -Directed CO Retrieve 685#5#73
Call Pickup for On-Hold Call -Local Retrieve 686#5#71
Call Pickup for On-Hold Call -Remote Retrieve 687#5#72
Call Pickup for On-Hold Call -Directed DN Retrieve 688 #5#74
Transfer to Voice Mail 690 #407
Repeat Last Number Dialed 700 *0
Volume Control for BEEP 710 #6101
Change LCD Display Language 720 #495
Advisory Message - Activation 730 #411
Advisory Message - Cancellation 731 #412
Emergency Call 740 #911
Attendant Console Group Access Code 750 0
Private Network Access Code 760 8
Node ID (Coordinated Directory Number Prefix) 770 None
Substitution of Dial * 780441
Substitution of Dial # 781440
Originate Call with Sub Address -Outgoing Call/Internal Call 782##
Application starting access code 800 #18
Voice Mail Call Monitor Off 870 #963
System Date Adjust Code (Release 1.02, MA227 or higher) 910 #651
System Time Adjust Code (Release 1.02, MA227 or higher) 911 #652
Table 1-4 Flexible Numbering Plan Default Settings (continued)
Flexible Numbering Feature Feature
Index
Default
Access Code
Programmed
Value

Telephone Button Programming
100 Series Programs
Strata CIX/CTX Telephone Button Programming 11/04 1-15
Telephone Button
Programming
Table 1-5 Programs 103~107
Button Sequence Value(s) Summary
103 Class Of Service
103, Hold
Class of Service assignments are a registration of feature capabilities
the user is entitled to use. Each assignment is defined as Enabled or
Disabled for privileges/permissions granted. Privileges enable users
to perform a feature while permissions allow others to use some
feature when calling your phone.
103-00 COS Number
n, Hold,
n = 1~32 (COS Number) Class of Service assignments are made for userís of telephones,
attendant consoles, and incoming calls based upon the line the call
arrives or in some cases on a call-by-call basis when using DISA or
Tie Line with QSIG interfaces. For telephone users, the class of
service assignments are made for each of the Day/Night Modes to
allow different services during different parts of the day.
103-01 Auto Busy Redial
FB01, n1, Hold Hold n1 = 1. Enable (default)
2. Disable The privilege to invoke Automatic Busy Redial after dialing a busy outside destination.
103-02 Call Forward
Override
FB02, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) If enabled, stations with this COS will not forward when calling stations that have System or Station Call Forward activated. This
includes when dialing from the dial pad or DSS button located on the
telephone or DSS console.
103-03 Call Transfer w/
Camp-on
FB03, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable Allows a call transferred by this station to camp on to a busy destination.
103-04 Change DISA Codes
FB04, n1, Hold Hold n1 = 1. Enable
2. Disable (default) The privilege to change the DISA Security Code.
103-05 DND Override -
Calling Party
FB05, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) Allows a caller to override the Do Not Disturb status of a called party.
103-06 DND Override -
Called Party
FB06, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable Allows calling parties with DND Override privileges to override this station's DND status.
103-07 Do Not Disturb
FB07, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to place this phone in Do Not Disturb.
103-08 Remote Set/Reset
DND
FB08, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) The privilege of setting/resetting Do Not Disturb on other phones.
103-09 Executive Override
FB09, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) The privilege to invoke an Executive Override on a call.
103-10 Executive Override
Allowed
FB10, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable Permission for others to use Executive Override when calling this station.
103-11 Offhook Camp-on
FB11, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to use Off-hook Camp-on when encountering a busy destination.
103-12 Group Pickup
FB12, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to pick up a call ringing on a station in one's own group.
103-13 Directed Station
Pickup
FB13, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to pick a specified ringing station.
103-14 Directed Group Call
Pickup
FB14, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to pick up a ringing station in a specified group.
103-15 Directed DN Call
Pickup
FB15, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to pick a specified DN.

Telephone Button Programming
100 Series Programs
1-16 Strata CIX/CTX Telephone Button Programming 11/04
103-16 Ext Call Pickup
FB16, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to pick up any incoming trunk call.
103-17 Directed CO Call
Pickup
FB17, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to pick up a specified incoming trunk call.
103-18 Remote Retrieve Call
Pickup
FB18, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to retrieve any call placed on Hold on a designated terminal (PDN).
103-19 DN Retrieve Call
Pickup
FB19, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to retrieve a held call on another DN.
103-20 Handsfree Override
FB20, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable Permission for others to change this phone from Ringing to Hands Free Answerback.
103-21 Privacy Override
FB21, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) The privilege to override a private call.
103-23 Invoke Emergency
Page
FB23, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to use the Emergency Page feature.
103-24 Join Feature
FB24, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to use the Join feature (Attendant Feature).
103-25 Through Dialing
FB25, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to perform Through Dialing (Attendant Feature).
103-26 Tandem CO
Connection
FB26, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) The privilege to set up a Trunk-to-Trunk connection.
103-27 Day/Night Control
FB27, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) The privilege to change Day/Night Mode.
103-28 Ext BGM Control
FB28, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) The privilege to turn on/off background music over external speakers.
103-29 LCR Feature
FB29, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to use Least Cost Routing.
103-30 Individual Trunk
Access
FB30, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to dial individual trunk access codes to access specific lines.
103-31 Trunk Access Allowed
FB31, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to access trunk groups by trunk access codes.
103-32 Forced Account
Codes
FB32, n1, Hold Hold
n1 = 1. Enable
2. Disable The privilege to use Forced Account Codes for placing external calls.
103-33 Verified Account
Codes
FB33, n1, Hold Hold
n1 = 1. Enable
2. Disable The privilege to have Account Codes verified before an external call is placed.
103-34 Allow Short Hook
Flash
FB34, n1, Hold Hold
n1 = 1. Enable (default)
2. Disable The privilege to use a Short Flash signal over outside lines.
103-35 Allow Long Hook
Flash
FB35, n1, Hold Hold
n1 = 1. Enable
2. Disable (default) The privilege to use a Long Flash signal over outside lines.
Table 1-5 Programs 103~107 (continued)
Button Sequence Value(s) Summary
