Toyotomi AC-20 User manual

AC – 20
GB OPERATING MANUAL ..............................PAGE 2
D GEBRAUCHSANWEISUNG............................PAGE 12
F MANUAL D’UTILISATION ............................PAGE 22
NL GEBRUIKSAANWIJZING .............................PAGE 32
E INSTRUCCIONES DE USO ............................PAGE 42
I ISTRUZIONI D’USO .................................PAGE 52
DK BRUGERVEJLEDNING ...............................PAGE 62

1 Read the diRections foR Use fiRst.
2 in case of anY doUbt, contact YoUR dealeR.
3 befoRe YoU staRt Reading, consUlt the main components list on the last page.
4
2
Thank you for choosing a “TOYOTOMI” product!
Toyotomi products are used by satisfied customers worldwide. In order to
assure the comfortable and safe use of our products by customers in each
country, our products conform to the safety standards not only in Japan but
also in every country around the world we do business with.
Toyotomi tailors its products to satisfy its customer’s needs by always
pursuing our business philosophy, “sharing joys in daily living”. We will
continue to research, develop and manufacture products that match people’s
lifestyle for efficiency, safety and comfort.
We hope that you’ll enjoy your Toyotomi appliance for years to come!
We invite you to read this instruction manual first, to ensure the maximum
lifetime for this appliance.
Get to know us better… visit us at www.toyotomi.eu for our full line of
products.

4
3
1 Read the diRections foR Use fiRst.
2 in case of anY doUbt, contact YoUR dealeR.
3 befoRe YoU staRt Reading, consUlt the main components list on the last page.
WHAT YOU NEED TO KNOW IN ADVANCE
GENERAL
Take the following actions to obtain an optimum result.
•Placetheairpurifierinanelevatedlocation(e.g.onatableorcupboard)in
ordertoallowittofiltersmallparticlessuchassmoke.Placetheairpurifiernear
oronthegroundtoenableittofilterlargedustparticlessuchaspollen.
•Alwaysmaintainafreespaceof30cmaroundthedevice.
•Readtheseinstructionscarefullyandfollowthedirections.
SAFETY REGULATIONS
•Theinstallationmustbecompletelyinaccordancewithlocalregulations,ordi-
nancesandstandards.
•Thedeviceissuitableexclusivelyforuseindryplaces,indoors.
•Checkthemainsvoltage.Thisdeviceissuitableexclusivelyforearthedsockets–
connectionvoltage230Volt/50Hz.
•ThedeviceMUSTalwayshaveanearthedconnection.Youmayabsolutelynot
connectthedeviceifthepowersupplyisnotearthed.
•Theplugmustalwaysbeeasilyaccessiblewhenthedeviceisconnected.
•Donotconnectthedevicewithanextensioncord.
•Neverusethedevicewithadamagedcordorplug.
•Thedevicemustbeconnectedtothepowersupplywithanearthedplug.Ensure
thatthepowercordisnotentangledorrolledup.
•Alwaysswitchthedeviceoffbeforepullingtheplugoutfromthewalloutlet.
Whenyoupullouttheplugfromthesocket,griptheplugtoavoiddamaging
thecord.
•Itisforbiddenforchildrentoplaywiththedevice.Thedevicemayonlybeused
byadults.
•Itisdangerousandforbiddentomodifythedevice.
•Itisforbiddentocoverthedeviceortoinsertforeignobjectsintothedeviceasa
fireorelectricshockcouldoccur.
•Donotmakethedevicewet.
•Avoidusingspraycans(insectspray,hairspray,etc.)inthevicinityoftheairpuri-
fier.Thismaydamagethedeviceand/orcausefires.
•Thedevicemaynotbeusedinhumidroomssuchasbathrooms.
•Adamagedelectricitycablemayonlybereplacedbythesupplierornauthori-
sedperson/servicepoint.
TIPS FOR SAFE USAGE
•Keepplasticbagsandotherpackagingmaterialsoutofreachofchildren.
•Thedevicewasdevelopedtopurifyairandnotforanyotherapplication.
•Alwayscontactyoursupplierifrepairormaintenanceisrequired.
•Donotplacethedeviceinthevicinityofheatsources,materials,installations,or
nearcurtains,thatmaycauseafirehazardorinenvironmentswhereexplosions
mayoccur.
•Alwaysswitchthedeviceoffandremovetheplugfromthesocketbeforeclea-
ning it.
•Thefloormustbestableandlevel.

4
4
MANUAL
A INSTALLATION
1Removethefrontpanel onbothsidesofthedevice.
2Take the filters ,,outofthedeviceandremovethepackaging.
3RemovetheAntivirusFilterfromthemainunit.
4RemovetheScreenfilterfromthemainunit.
5Removethewashablefilterinthebagfromthemainunit.
NOTE:Takethewashablefilteroutoftheplasticbag,beforeuse,andsetiton
the main unit.
Ifitisinstalledpackedintheplasticbag,itcannotproducethe
purifyingeffect.
Whenhandlingthewashablefilter,thedeodorizingingredient(black
powder)maysticktohandsifyoutouchthedeodorizingsection(black
meshface)onthefilterorwheninsertinghandsinthebag.Thisis
normalbecauseabundantamountofblackpowderisusedtoassist
thedeodorizingperformancesufficientlyandapplythedeodorizing
ingredienthomogeneously.
6Takethewashablefilteroutofthebag,andinstallitonthemainunithaving
thewavedfaceorientedtowardthefrontofmainunitandthemeshfaceto
theinside.
Itshouldbettertoinsertfirstthebottomfaceofwashablefilterandthenits
upper face.
Front panel
Screen filter
Screen filter
Antivirus filter
Washable filter

Nail
Fitting section of main
unit
Front panel Front panel
!
4
5
Front panel
7TaketheAntivirusFilteroutoftheplasticbag.
LaydownthemainunitandinstalltheAntivirusFilteronthemainunit.
8Aligningthenails(6places)ofprefilterwiththeslits(6places)onthemain
unit,installtheScreenfilter.
9Attachthefrontpanelbyhookingthenails(4places)onthetopintothe
recessesinthedevice.Nowclickthebottomleftandrightofthefrontpanel
into position.
10 Thedeviceisnowreadyforuse.
ATTENTION!
TheSemiHEPAfiltermustbeinsertedcorrectlyinordertoguaranteethatitwill
functioncorrectly.
Screen filter
Nail
Slit on main unit
Antivirus filter
Washable filter
