TP-Link DS-PMA-C+ V1 User manual

Remove the TransceiverInstall the Transceiver
©2021 TP-Link 7106509235 REV1.0.0
1. Wear an ESD-preventive wrist or ankle strap to prevent ESD damage to
the transceiver.
2. Insert the transceiver into the slot and rmly press it into place.
3. Remove the protective dust plug from the transceiver.
4. Plug a ber-optic cable into the transceiver. Note that the transceiver
works without any additional conguration.
1. Wear an ESD-preventive wrist or ankle strap to prevent ESD damage to
the transceiver.
2. Disconnect the network ber-optic cable from the transceiver.
4. Reinstall the protective dust plug in the transceiver’s optical bores and
place it on antistatic mat or a static shielding bag.
3. Pull the safety latch downwards to release the transceiver, and then
pull it out from the slot.
Installation Guide
Note:
1. Do not touch the output pins on the transceiver with your hand.
2. Always keep the protective dust plug on the transceiver’s optical bores until you are ready to make a connection.
Caution:
DO NOT point or stare directly into the beam or into the optical port of the transceiver when it is operating, as this can injure your eyesight.
SFP GPON Class C+ Module
For technical support and other information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
If you have any suggestions or needs on the product guides,
welcome to email [e-mail].
To ask questions, find answers, and communicate with TP-Link
users or engineers, please visit https://community.tp-link.com
to join TP-Link Community.

Connection
Environmental and Physical Specications
Product Operating Temperature 0˚C to 70˚C (32˚F to 158˚F)
Storage Temperature -40˚C to 85˚C (-40˚F to 185˚F)
Storage Humidity 5% to 95% RH, Non-condensing
Operating Humidity 5% to 95% RH, Non-condensing
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device.
Avoid using this product during an electrical storm. There may be a remote
risk of electric shock from lightning.
Do not point or stare directly into the beam or into the optical port of the
transceiver when it is operating, as this can injure your eyesight.
TP-Link hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of directives 2014/30/EU,
2014/35/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at
https://www.tp-link.com/en/support/ce/
EU Declaration of Conformity
TP-Link hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of the Electromagnetic
Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations
2016.
The original UKCA declaration of conformity may be found at
https://www.tp-link.com/uk/ukca
UKCA Declaration of Conformity
OLT ONU
DS-PMA-C+
Fiber
Specications
Port Type
Fiber Type
Data Rate
Wave Length
Cable
Normal
Max. Cable Length
Power Support
Safety & Emission
Tx: 1490 nm
Rx: 1310 nm
ITU-T G.984.2 Amendment 2
Single-mode Fiber
9/125 um Single-mode
20 km
Tx: 2488.32 Mbit/s
SC/UPC
3.3 V
FCC 47 CFR Part 15, Class B
Standards and Protocols
DS-PMA-C+
General Specications
Ye s
Ye s
DDM
SFP-MSA
Ye sHot Swappable
Rx: 1244.16 Mbit/s
CE, Class B
PON Port
