1. Introduction
Thank you for purchasing the D-650 amalgam mixer. This unit uses
a microprocessor to control its functions. Please read this manual
carefully before you begin to use the mixer.
2. Usage
This D-650 is used to mix dental amalgam, glass ionomer and
cement; dental capsules. Please see the manufacturer instructions
for trituration and time settings on each dental material.
3. Technical data
3.1 Electric safety: Grade 1, Type B
3.2 Power supply: AC 220/110 ±22v, 50Hz/60Hz
3.3 Power consumption: 200VA
3.4 Oscillation freq.: 4250/min
3.5 Fuse: 2A, Ø5 x20mm
3.6 Operating circumstance
3.6.1 Working temperature: 5’C ~ 40’C
3.6.2 RH: ≤ 80%
3.7 Storage circumstance
3.7.1 Temperature: -40’C ~ +55’C
3.7.2 RH: ≤ 80%
4. Production indication
1. Cap 5. Time (+)
2. Start switch 6. Time (-)
3. Vibration Arm 7. Power switch
4. LCD Display 8. Fuse
5. Operating method
5.1 Choose a amalgam capsule
5.2 Activate the capsule, according to manufacturer
instructions.
5.3 Open the transparent protective cover of the unit, and fix
the capsule on the holder of the mixer. Then close the
cover. Do not triturate with the cover open
5.4 Time preset
Press the “Δ” key to set time longer, press the “∇” key to
set timer shorter.
5.5 Press the “Start” button, the mixer will begin to triturate,
the cycle will end at the time specified. If you wish to stop
the cycle before it is completed, press the “Start” button
again.
5.6 Once the trituration cycle is complete, open the cover,
remove the capsule and close the cover.
6. Notice
6.1 Use only Earth grounded receptacle (wall outlet).
6.2 Before pressing the “Start” button; make sure the cover is
closed.
7. Maintenance
Lubricate the rotating parts periodically.
WARNING: At the time of un-boxing; make sure to take off the two
side screws used to secure the triturating arm.
8. Troubleshooting
The LCD has no numeric display
The capsule holder swings loosely
Check the driving rubber band
9. Guarantee
If the unit is not working properly due to product quality, it will be
repaired or replaced free of charge by TPC. This unit comes with a
1 year warranty, which starts from the date when the unit was
purchased from TPC or a dealer, Warranty does not cover fuses or
negligence by the end user. TPC DOES NOT COVER FREIGHT FOR
ANY WARRANTY ISSUES.
10. Cleaning Clean and disinfect cross-contamination surfaces only.
Dampening a cloth with a mild cleaning solution and wiping the
amalgamator is the preferred cleaning method.
