Tractel FABA AW1 User manual

Horizontal
Anchorage System
www.tractel.com
This manual must be readily available to assembly staff at all times.
Other copies can be obtained on request.
Original installation manual
System AW1

Page 2 of 16 Original installation manual Anchorage System AW1 Issued 04/13
Date of issue
April 2013
Copyright
The copyright of this operating manual remains with
TRACTEL Greifzug GmbH.
Notes on this installation manual
Manufacturer's address
TRACTEL Greifzug GmbH
Scheidtbachstrasse 19-21
51469 Bergisch Gladbach
Postfach 20 04 40
51434 Bergisch Gladbach
Tel: [phone]
Fax: [phone] + 70
Contents
1. Definitions and symbols used
1.1 Definitions .................................................................................................................................. 4
1.2 Symbols used ............................................................................................................................ 4
1.3 Safety instructions...................................................................................................................... 5
2. Presentation
2.1 Delivery state and scope of the anchorage system.................................................................... 6
2.1.1 Delivery state of the system ............................................................................................... 6
2.1.2 Scope of delivery................................................................................................................ 6
2.1.3 Documentation ................................................................................................................... 6
2.2 Product description ................................................................................................................... 6
2.2.1 Intended use ...................................................................................................................... 6
2.2.2 Working procedure ............................................................................................................ 6
2.2.3 Limits of the anchorage system.......................................................................................... 7
2.3 Guidelines and specifications..................................................................................................... 7
2.3.1 Commissioning................................................................................................................... 7
2.3.2 Maintenance and inspection............................................................................................... 7
2.3.3 Legal requirements............................................................................................................. 7
3. Components
3.1 General view
3.1.1 System design assembly on the side or suspended........................................................... 8
3.1.2 System design (custom production) suspended assembly ................................................ 8
3.2 Components......................................................................................................................9 – 10
3.2.1 Guide rail............................................................................................................................ 9
3.2.2 Joint connector................................................................................................................... 9
3.2.3 Clamps and support brackets............................................................................................. 9
3.2.4 Catches ............................................................................................................................ 10
3.2.5 Bends............................................................................................................................... 10
3.2.6 Junctions .......................................................................................................................... 10
3.3 Technical data and weights
3.3.1 General information.......................................................................................................... 11
3.4 Products forming part of the anchorage system
3.4.1 Anchorage device............................................................................................................. 11
4. Other accessories
4.1 Personal protective equipment against falls............................................................................. 11
5. Inspection book ............................................................................................................................ 11
6. Installation and maintenance
6.1 Important notes on the guide rail assembly.............................................................................. 11
6.2 Tools and equipment required .................................................................................................. 12
6.3 Check the scope of supply
6.4 Assembly of the components ................................................................................................... 12
6.4.1 Fixing clamps........................................................................................................................ 12
6.4.2 Clamps for I-120 beam .........................................................................................................12
6.4.3 Support bracket for side assembly .......................................................................................13
6.4.4 Support bracket for ceiling assembly....................................................................................13
6.4.5 Guide rail .............................................................................................................................. 13
6.4.6 Joint connector ..................................................................................................................... 13
6.4.7 Fixed catch ........................................................................................................................... 14
6.4.8 Detachable catch .................................................................................................................. 14
6.4.9 Bends.................................................................................................................................... 14
6.4.10 Junction .............................................................................................................................. 14
6.5. Inspection prior to initial commissioning ........................................................................................14

Issued 04/13 Original installation manual Anchorage System AW1 Page 3 of 16
7. Rescue................................................................................................................................................... 15
8. Use, misuse and handling
11.1 Authorized use........................................................................................................................ 15
11.2 Predictable misuse or handling .............................................................................................. 15
10. Transport and storage of the anchorage system ..................................................................... 15
11. Servicing and troubleshooting.
12. Ordering spare parts .................................................................................................................. 15

Page 4 of 16 Original installation manual Anchorage System AW1 Issued 04/13
1. Definitions and symbols used
1.1 Definitions
The terms used in this manual have the following meanings:
"Anchorage system": Safety equipment
"Qualified person": An authorized specialist is considered to be someone who has undergone specialist training
and has sufficient knowledge in the field of anchorage systems and is familiar with the relevant government
industrial safety and accident prevention regulations, directives and the recognized technical regulations of
other EU member statesto the degree that they are capable of evaluating the safe working condition and proper
application of anchorage systems (BGG 906)
"Operator": Person or department that is assigned with the use of the product for the purpose that it is intended.
"Fitter": Person or department that is responsible for the assembly of the elements of the products received,
installation to operational readiness, disassembly, deinstallation and also transportation for the purpose of
storage and holding.
"User": Qualified person that is responsible for the maintenance work described and permitted in this manual and
is competent and familiar with the use of the product.
"PPE": Personal protective equipment, e.g. safety shoes, gloves
"PPE against falls": Personal protective equipment against falls, e.g. safety harness, lanyard
Symbol Signal word Designation Possible damage caused
if ignored
SAFETY INSTRUCTIONS
Danger
Potential threat of danger:Death, severe or minor injuries!
Attention!
Potentially dangerous situation:Damage to the equipment or the
surrounding area
DIRECTIVES
None Note on written instructions /
documentation
None
None Instructions covering the wearing of
personal protective equipment (PPE)
against falls
Death, severe or minor injuries!
None Instructions about reading the
documentation
Death, severe or minor injuries!
Other notes
Important
Important! Useful tips for optimal operation None
1.2 Symbols used
The symbols used in this manual have the following meanings:

Issued 04/13 Original installation manual Anchorage System AW1 Page 5 of 16
1.3 Safety instructions
l) If faults or damages are found during operation or any
circumstances arise, which would endanger safety:
Stop working immediately and inform the supervisor
or contractor!
m) Damaged parts may not be used and must be
replaced.
n) If load bearing parts are being repaired or replaced,
a qualified person must check the operating safety
of the system.
o) Guarantee claims lodged against the manufacturer and
the CE approval will be invalidated if replacement parts
other than original replacement parts are used.
p) It is forbidden to make any modifications, retrofits
or conversions to the anchorage system without the
manufacturer's written authorization.
q) The manufacturer will not accept any liability for damages
resulting from modifications and conversions made to
the devices, or from the use of non-original parts that
have not been authorized by the manufacturer.
a) Only those personnel that are familiar with the
assembly and / or operation of the anchorage
system and its suspension should be assigned.
They must have been authorized by the contractor
to carry out the respective tasks.
b) The assembly personnel assigned must be healthy
and at least 18 years of age. They must know the
relevant accident prevention regulations
and have received the corresponding
training. They must have read and
understood this installation manual.
They must have received training in
the use of "Personal protective equipment against
falls".
c) A copy of this installation manual must be
provided and readily available to operating and
maintenance personnel at all times.
d) If more than one person is entrusted with the
above-mentioned tasks, the contractor must
appoint a supervisor who is authorized to issue
instructions.
e) During operation all persons moving on the
anchorage system must wear
personal protective equipment
against falls from a height which
they must fasten to the rigging points
provided for this purpose.
The clearance beneath the anchorage system
must be left free.
f) During operation, communication means such as
a mobile telephone must be carried in case of an
emergency.
g) Only technically sound anchorage systems,
anchorage devices and rigging must be used.
h) Before beginning installation check that all parts
are present and in perfect condition.
i) The user has to be mentally and physically eligible
for working at heights.
k) Prior to installing the anchorage system, make
sure that the sub-construction has an adequate
load bearing capacity.
Death, severe or minor injuries caused by incorrect handling
➜ Observe the details in this manual
Danger

Page 6 of 16 Original installation manual Anchorage System AW1 Issued 04/13
2. Presentation
2.1 Delivery state and scope of the anchorage
system
2.1.1 Delivery state of the anchorage system
The anchorage system is supplied disassembled.
2.1.2 Scope of delivery
The following accessories are not included in the scope of
supply:
– Guide rails (Fig. 1)
– Joint connector (Fig. 2)
– Clamps for I-120 beam (Fig. 3a) (optional)
– Fixing clamps (Fig. 3b)
– Detachable catch (Fig. 4a)
– Fixed catch (Fig. 4b)
– Optional: Guide rails as peripheral rail (Fig. 5a)
– Optional: Guide rails for right-angled bends (Fig. 5b)
– Optional: Guide rails for other bend routes (Fig. 5c)
– Optional: Junctions (Fig. 6)
The scope of delivery depends on the customers requirements.
2.1.3 Documentation
The following documents are supplied along with the anchorage
system:
– Original installation manual
– Original inspection book
– Manufacturer's declaration
– If applicable, project designation (in case of customized
production according to customer requirements)
2.2.1 Intended use
The FABA™anchoring system is a "permanently installed
anchorage system with a fixed horizontal guide rail" according to
EN 795, Class D and is designed to protect the user from falling from
a height. It is fixed directly onto the structure or a sub-construction
using support brackets which are appropriate for the subsurface.
The max. distance between support brackets for the anchorage
system is 1.50 m. FABA™anchorage systems must not be used
by more than three persons at the same time. The load-bearing
capacity of the subsurface has to be at least 12 kN for each
support bracket.
2.2.2 Working procedure
The anchorage device W3 travels in the guide rail which is connected
to the personal safety equipment (PPE) to protect against falls from
a height as a travelling rigging point. The anchorage device follows
the user as it is travelling along the system without the user having
to manually handle the anchorage device. In the case of a fall, the
anchorage device secures the fall protection system and prevents
the user from falling any further.
Fig. 1 Guide rail
Fig. 2 Joint connector
Fig. 3 Clamps and support brackets
Fig. 4 Catches
Fig. 6 Junctions
Fig. 5 Bends (examples)
a)
b)
a)
b)
a)
b)
c)
2.2 Product description

Issued 04/13 Original installation manual Anchorage System AW1 Page 7 of 16
2.2.3 Limits of the anchorage system
The FABA™ anchorage system AW1 is designed for the protection against falls from a height on horizontal walkways
only. It must not be used on inclinations. The FABA™anchorage system AW1 must not be used by more than three
persons at the same time. Transporting loads using the anchorage system is not permitted.
The FABA™anchorage system AW1 must be used only in conjunction with approved personal protective equipment
against falls (according to EEC 89/686/CE and national regulations).
Before each use, the user should carry out a visual inspection of the anchorage system and the associated PPE
against falls in order to ensure that they are in good condition for use, compatible, and correctly in place and
connected.
The necessary clearance to be maintained above the base must be obtained from the respective operating
instructions of the harness together with the PPE against falls. Before using the safety harness in conjunction with
another PPE against falls each time, the necessary clearance must be ensured beneath the system so that the
person does not hit the ground in event of a fall.
2.3 Guidelines and specifications
2.3.1 Commissioning
Following professional installation, the FABA™anchorage system AW1 must be inspected and cleared for use by a
technical expert. The results of the inspection must be documented in the inspection book.
Moreover, the regulations and legal guidelines as stated in 2.3.3 apply. Other national regulations must be
observed.
2.3.2 Maintenance and inspection
Only persons authorized by TRACTEL Greifzug GmbH are allowed to perform maintenance and inspection on the
anchorage system (see definition and chapter 10).
2.3.3 Legal requirements
89/686/EEC Council Directive on Personal Protective Equipment
EN 795 Anchorage systems
EN 354 Lanyards
EN 355 Energy absorbers
EN 358 Restraint systems
EN 360 Retractable type fall arresters
EN 361 Full body harnesses
EN 362 Connectors
EN 363 Arrest systems
EN 365 Instructions for use and marking
BGR 198 Regulations for the use of personal protective equipment against falls from a height
BGR 199 Regulations for the use of personal protective equipment for arresting and rescuing
BGG 906 Basic regulations for the selection, instruction and certification of competence of
technical experts in personal protective equipment against falls from a height
ArbSchG Law on the implementation of protective measures to improve the safety and health
of employees at work (Occupational safety act)
PSA-BV Ordinance on safety and health protection during use of personal protective
equipment at work (Ordinance on the use of PPE)
ArbStättV Ordinance on working premises

Page 8 of 16 Original installation manual Anchorage System AW1 Issued 04/13
3. Components
3.1 System design
3.1.1 System design assembly on the side or suspended (Fig. 7)
3.1.2 System design (custom production) suspended assembly (Fig. 8)
Fig. 7
Fig. 8
4
10
2912
11
max. 1,500 mm
8
mm
B
B
1
9
6
1. Guide rail
2. Support bracket for guide rail on the subsurface
3. Catch
4. Joint connector
5. I-120 sub-construction
6. Support bracket for wall assembly
7. I-120 support bracket
8. Guide rail support bracket spacing
9. Support bracket for ceiling assembly
10. Anchorage device W3
11. Junction
12. 90° bend

Issued 04/13 Original installation manual Anchorage System AW1 Page 9 of 16
3.2 Components
3.2.1 Guide rail
3.2.2 Joint connectors
3.2.3 Clamps and support brackets
Fig. 9
Fig. 11a
Fig. 11b
Fig. 11c
Fig. 11d
Fig. 10
The guide rail (Fig. 9) is used for mounting the anchorage
device W3.
Length: 1,000 mm – 6,000 mm
Weight depending on the length: 3.8 kg – 22.7 kg
Material: steel, hot-galvanized or INOX 1.4571
The joint connectors (Fig. 10) are used to make the joint
between two guide rail sections.
Kit: 2 bolt nuts, 4 screws M8 and 2 pressure pieces.
Weight per kit: 0.27 kg
Material: INOX 1.4571
The clamps and support brackets (Fig. 11a – d) are used to
fix the guide rail (Fig. ) to the different subsurfaces.
The fixing clamps (Fig. 11a) are used to fix the guide rail
to the different sub-constructions on which a push-through
assembly can be carried out.
Weight: 0.95 kg
Material: steel, hot-galvanized or INOX 1.4571
The clamps for the I-120 beam (Fig. 11b) are used for fixing
the rail to the supporting construction (I-120 beam).
Weight: 1.0 kg
Material: steel, hot-galvanized steel
The support bracket for fixing to the side (Fig. 11c) allows
the guide rail (Fig. 9) to be fixed with the fixing clamps on
the side, e.g. to a wall, using anchor fittings (Fig. 11a). The
slot points to the side.
Weight: 1.0 kg
Material: steel, hot-galvanized or INOX 1.4571
The support bracket for ceiling assembly (Fig. 11d) allows
the guide rail to be mounted, e.g. under the ceiling, using
anchor fittings. Fixing clamp (Fig. 11a) is also required here.
The slot points downwards.
Weight: 1.0 kg
Material: steel, hot-galvanized or INOX 1.4571

Page 10 of 16 Original installation manual Anchorage System AW1 Issued 04/13
3.2.5 Bends
3.2.6 Junction
3.2.4 Catches
Fig. 13 a
Fig. 12 b
Fig. 13 b
Fig. 13 c
Fig. 13 d
Fig. 14
Fig. 12 a The catches (Fig. 12 a – b) prevent the anchorage
device running out of the system unintentionally.
The fixed catch (Fig. 12a) is installed fixed.
The anchorage device cannot be removed.
Kit: Length of pipe, screw M 8, self-locking nut
Weight: 0.1 kg
Material: INOX 1.4571
The detachable catch (Fig. 12 b) is installed at the
ends of the anchorage device from which it should
be removed.
Kit: Bolt, spring, 2 washers, cotter pin, cover cap
Weight: 0.1 kg
Material: INOX 1.4571
The bends (Fig. 13 a – d) are required for changing the
direction within a system.
Fig. 13 a – d shows an overview of the possible bends.
Other bend routes are possible.
These are customized designs that are produced especially
according to your desires.
The junctions (Fig. 14) are used to make a joint between
two guide rails that cross each other at an angle of 90°.
The crossing rails can be used without having to remove
the anchorage device.
The junction is a customized design that can be produced
according to your requirements.

Issued 04/13 Original installation manual Anchorage System AW1 Page 11 of 16
3.4 Products forming part of the anchorage system
3.4.1 Anchorage device W3
5. Inspection book
An inspection book must be implemented in which the following details must be provided:
– Testing, maintenance and troubleshooting
– Fault report
The inspection book for the system is supplied and must be stored by the system operator.
The anchorage device W3 (Fig. 15) is inserted at one end of the
guide rail of the system. It is used to secure persons. Only one
person per anchorage device can be secured on the anchorage
system using PPE against falls. A maximum of three persons may
be secured on the system at the same time.
The anchorage device accompanies the user over the complete
path by running along automatically.
4. Other accessories
4.1 Personal protective equipment against falls
Each person attached to the anchorage system must remain secured with their PPE against falls at all times. This PPE
is not included in the scope of delivery of the anchorage system. It must however, fulfil all standards and guidelines.
The PPE against falls that is intended for securing on the anchorage system must provide the user with the possibility
to move freely along the entire anchorage system and without impairing their freedom of movement in any way. Exiting
the anchorage system is only permitted at a place where it is safe to stand without falling.
6. Installation and maintenance
6.1 Important notes on the guide rail assembly
– When using anchor fastenings, only use those
authorized by the building authorities. Ask the
manufacturer of the anchor fitting you wish to use
whether it is suitable for the respective subsurface
conditions.
– Check that the subsurface or building has a sufficient
load-bearing capacity prior to installation.
– This must be checked by a qualified specialist engineer.
– The possible fall distance must be reduced to a
minimum.
– There must be a sufficient clearance underneath the
anchorage system.
– The guide rails must be installed horizontally without any
inclinations.
Fig. 15
3.3 Technical data and weights
3.3.1 General information
The technical data and weights can be found in the description of the individual components.
– The distance of the support brackets must not exceed
1,500 mm.
– The last support bracket at the end of the guide rail
must be mounted 125 mm before the end.
– In the area of the joint connectors, two support
brackets must be mounted each at a distance of
125 mm to the joining point.
– In the area of the junctions, two support brackets must
be mounted at a distance of 250 mm to the centre of
the junction.

Page 12 of 16 Original installation manual Anchorage System AW1 Issued 04/13
6.2 Tools and equipment required
Wrench M8, M10, M12
Torque wrench M8, M10, M12 up to 100Nm
Measuring instrument Spirit level, tape measure or folding rule
PPE against falls from a
height for fitters
– Authorized safety harness
– Safety rope with shock absorber
– Lanyard
– Helmet
– Gloves
– Safety shoes
6.3 Check the scope of delivery
Prior to the installation, the scope of delivery has to be checked for completeness using the delivery note and,
where necessary, the project drawing.
The components must not be deformed or damaged in any way.
Do not try to repair or use any damaged components. They must be replaced with original parts only.
16.4.1 Fixing clamps (Fig. 16 – 17a)
1. The fixing clamps (Pos. 2 of the general view) is fixed
to the sub-construction using an M12 screw (2).
2. The M12 screw (2) is guided through the middle, anti-
twist protected hole (1) of the clamp.
3. Fix the M12 screw above the sub-construction with a
spring washer and a self-locking nut.
Torque for the screw connection: M12 (2) = 60 Nm
M 8 (3) = 18 Nm
Fig. 16
Fig. 17 a
6.4 Assembly of the individual components
2
6.4.2 Clamp for the supporting construction (I-120 beam)
(Fig. 17 b)
1
Fig. 17 b
1. The clamps (Pos. 7) are placed on the I-120 beam
already installed on-site and pre-assembled hand tight.
2. After inserting the guide rail (see 6.4.5), the screws (1)
are screwed tight.
Torque for the screw connection: M10 = 35 Nm
3

Issued 04/13 Original installation manual Anchorage System AW1 Page 13 of 16
6.4.4 Support brackets for assembly of the guide rail
on the ceiling (Fig. 17 e)
6.4.3 Support bracket for assembly of the guide rail on
the side (Fig. 17 c)
1
2
1
Fig. 17 d
Fig. 17 c
Fig. 17 f
Fig. 17 e
1. The support bracket (Pos. 6) is fixed to the concrete wall
(concrete strength, min B25) using anchor fittings approved for
use by the building authorities.
2. Then mount the fixing clamps as described under point 6.4.1.
The anchor fastenings must have a load bearing capacity of
12 kN (Fig. 17d).
1. The support bracket (Pos. 9) is fixed overhead to the ceiling
using two anchor fittings approved for use by the building
authorities.
2. Then the fixing clamps are mounted to the support bracket
as described under point 6.4.1.
The anchor fastenings must have a load bearing capacity of
12 kN (Fig. 17f).
6.4.5 Guide rail (Fig. 18 and 19 a and b)
6.4.6 Joint connector (Fig. 20 a – c)
1. The guide rail (Pos. 1) is inserted at an angle into one side
of the fastening clamp (1).
2. Secure by pressing into the support bracket.
3. Then the guide rail is fixed in place by tightening the two
screws M8 (2).
Torque for the screw connection: M8 = 18 Nm
First it is pre-assembled on one end of the rail:
1. The pressure piece is placed on the guide rail from outside
and screw bolt from the inside.
2. Then the screw is screwed into the screw bolt hand tight from
the outside.
3. The second guide rail is pushed in-between the screw bolt and
the pressure piece of the joint connector on the other guide rail.
4. Then the M8 screws are guided through the holes in the guide
rail and screwed into the screw bolts.
Torque for the screw connection: M8 = 18 Nm
Fig. 18 a Fig. 18 b
Fig. 19 a Fig. 19 b
Fig. 20 a
Fig. 20 c
Fig. 20 b
2
1

Page 14 of 16 Original installation manual Anchorage System AW1 Issued 04/13
6.4.7 Fixed catch (Fig. 21)
6.4.8 Detachable catch (Fig. 22)
The length of pipe for the fixed catch (Fig. 21) is inserted
into the end of the guide rail and the M8 x 80 screw is
pushed through the holes in the guide rail from the outside
and through the length of pipe.
Then the screw is locked using a self-locking nut according
to DIN 985.
Torque for the screw connection: M8 = 18 Nm
The bolt of the detachable catch (Fig. 22) is guided from
the inside through a hole at the end of the guide rail.
On the outside of the guide rail, first a washer, then a
spring and finally another washer are pushed on the bolt.
Then the washer and the spring are secured using a cotter
pin. The cotter pin must be bent over at the ends so that it
is secured against slipping out. Then the protective cover
is attached to the end of the bolt.
Fig. 21
Fig. 22
6.4.9 Bends (Fig. 23 a – b)
The bends are connected to the guide rails using joint
connectors (Fig. 12).
The support brackets are mounted as described under
point 6.4.1-6.4.4. At least two support brackets must be
mounted per bend.
Then the bends are fixed in the support brackets as
described in point 6.4.5 and joined together with the joint
connectors as described under point 6.4.6.
Torque for the screw connection: M8 = 18 Nm
Fig. 23 b
Fig. 23 a
6.4.10 Junction (Fig. 24 a + b)
The guide rails are mounted at right angles under the ceiling
as previously described under point 6.4.5.
The junctions (Pos. 11) are mounted to the ends of the rails
with joint connectors as described under point 6.4.6.
Open junction connections that do not have rails connected
to them must be secured with a fixed catch that belongs to
the junction.
Torque for the screw connection: M8 = 18 Nm
Fig. 24 a
Fig. 24 b
6.3 Inspection prior to initial commissioning
Write down the results of this inspection and store them in a safe place.
An authorized specialist must carry out and document the inspections according to the inspection book.

Issued 04/13 Original installation manual Anchorage System AW1 Page 15 of 16
8. Use, misuse and handling
7. Rescue
8.1 Authorized use
The anchorage system complies with the state of the art and also complies with the safety regulations applicable
when it was launched onto the market in the scope of its authorized use.
The design can prevent neither predictable misuse nor the residual dangers without restricting the authorized
functionality.
Information about potential dangers is provided via special warning notices either directly on the anchorage system
and / or in the technical documentation.
The anchorage system must be operated according to the specifications in the technical documentation.
Any non-authorized use or activities on the anchorage system not described in this manual are prohibited misuse
outside the statutory limits for liability of TRACTEL Greifzug GmbH.
8.2 Predictable misuse or handling
Your safety is guaranteed if the anchorage system is used according to the specifications in the technical
documentation. Any unauthorized use endangers your safety and must be avoided in all cases.
• Never anchor more than three persons on the anchorage system at the same time and always maintain
the minimum clearance to the impact area.
• Never use another anchorage device or similar element on the guide rail other than the original FABATM
anchorage device W3.
• Never test the anchorage system by having it fall on purpose.
• Never attempt to forcefully pull the anchorage device over an obstacle in the guide rail.
• Never use an anchorage system for which the last inspection was more than 12 months ago (date of the
last inspection).
• Never attach anything other than PPE against falls to the anchorage device
• Never use the anchorage system prior to training or when ill
• Never use vertically
• Never use in inclinations
• Never use without having clearance under the system
• Never use the anchorage system if you are pregnant
• Never use an anchorage system if the labelling is not fitted or is illegible.
• Never use PPE against falls that is not approved according to the EEC guideline 89/686/CE
• Never use the anchorage system if there is no rescue or emergency plan available
• Never use the anchorage system outside the permissible temperature ranges (-30°C and +60°C)
A rescue plan must always be drawn up before starting work. The rescue plan, which must be tailored with regard
to the respective working situation, must list the measures and the apparatus that will be used to ensure that, in
the event of an accident, the person is rescued within 15 minutes. The person's life will be endangered if rescue
operations last longer than this.
9. Transport and storage of the anchorage system
10. Servicing and troubleshooting
11. Ordering spare parts
During transport and storage of the anchorage system, ensure that none of the components are damaged.
Damaged parts may only be replaced with new original parts.
The anchorage system must be checked every 24 months by means of an inspection book.
In event of faults during operation or falls, this inspection must be carried out before reusing the system. Damaged
parts may only be replaced with original parts.
For ordering spare parts, please use the respective component catalogue for the anchorage system.
For ordering, please contact your authorized specialist dealer or a member of the globally active Tractel Group
(see last page).

D
USA
CDN
SGP
UAE
CN
PL
F
L
GB
EI
NL
P
www.tractel.com
RUS
G824.2_MA_FABA_HLS.indd • 500 570 • 04/13 • © TRACTEL Greifzug GmbH 2013
Scheidtbachstr. 19-21 • 51469 Bergisch Gladbach
Postfach 20 04 40 • 51434 Bergisch Gladbach
Tel. +49 / 2202 / 1004-0 • Fax +49 / 2202 / 1004-707
TRACTEL Greifzug GmbH
D
RN 19 Saint-Hilaire-sous-Romilly • B.P. 38
10102 Romilly-sur-Seine
Tel. +33 / 3 / 25.21.07.00 • Fax +33 / 3 / 25.21.07.11
TRACTEL S.A.S.
F
3, Rue du Fort Dumoulin • B.P. 1113
1011 Luxembourg
Tel. +352 / 43.42.421 • Fax +352 / 43.42.42.200
TRACTEL Secalt S.A.
L
Old Lane, Halfway
Sheffield S20 3GA
Tel. +44 / 114 / 248.22.66 • Fax +44 / 114 / 247.33.50
TRACTEL UK Ltd.
GB
Carretera del Medio 265
08907 L`Hospitalet (Barcelona)
Tel. +34 / 93 / 335.11.00 • Fax +34 / 93 / 336.39.16
TRACTEL Ibérica S.A.
E
Viale Europa 50
20093 Cologno Monzese (MI)
Tel. +39 / 2 / 254.47.86 • Fax +39 / 2 / 254.71.39
TRACTEL Italiana S.p.A.
I
Paardeweide 38
4824 EH Breda
Tel. +31 / 76 / 543.51.35 • Fax +31 / 76 / 543.51.36
TRACTEL Benelux B.V.
NL
Alto do Outeiro Armazém 1 Trajouce
2785-086 S. Domingos de Rana
Tel. +351 / 21 / 444.20.50 • Fax +351 / 21 / 445.19.24
LUSOTRACTEL LDA
P
Paardeweide 38
4824 EH Breda
Tel. +31 / 76 / 543.51.35
TRACTEL Benelux B.V.
DK
51, Morgan Dr.
Norwood MA 02062
Tel. +1 / 781 / 401.32.88 • Fax +1 / 781 / 826.36.42
TRACTEL Inc.
USA
1615 Warden Avenue Scarborough
Ontario M1R 2TR
Tel. +1 / 416 / 298.88.22 • Fax +1 / 416 / 298.10.53
TRACTEL Ltd.
CDN
50 Woodlands Industrial Parc E
Singapore 757824
Tel. +65 / 757 / 3113 • Fax +65 / 757 / 3003
TRACTEL Singapore Plc.
SGP
P.O. Box 25768
Dubai / United Arab Emirates
Tel. +971 / 4 / 343.07.03 • Fax +971 / 4 / 343.07.12
Secalt S.A. (Dubai Branch)
Middle East
UAE
Secalt Tractel Mechanical Equip. Tech. Co. Ltd.
Unit A09
399 Cal Lun Road
Zhangjiang
Hi-Tech Park
SHANGHAI 201203
T : 86 / 21 / 632 25 570 • Fax : 81 / 21 / 535 30 982
TRACTEL China
CN
ul. Bysławska 82
04-993 Warszawa
Tel. [phone] • Fax [phone]
TRACTEL Polska sp. z o.o.
PL
ul. Petrovka, 27
Moscow
107031 Russia
T : 7 495 989 5135 • Fax : [phone]
TRACTEL Russia O.O.O
RUS
