Tractel HF 32/2/A Operating instructions

MS 32/2/A R 03/03 1
HF 32/2/A Universal load cell
Including wiring for 2 trip points
equipment in
accordance with
CE directives
Operating
and
maintenance
manual

MS 32/2/A R 03/03 2
GENERAL WARNING 2
INSTALLATION OF HF 32 LOAD CELL 3 – 4 - 5
OPERATION AND ADJUSTMENT OF HF 32 LOAD CELL 6
WIRING OF HF 32 TWO TRIP POINTS 7
GENERAL WARNING
1- Reading and fully understanding the technical data sheets relating to this
equipment is essential for the best use of this high technological material
that you have received . All the technical data sheets are available on
request.
2- Before installing and operating Dynasafe equipment it is essential for the
safe and correct operation of the material that this manual be read and fully
understood and that all the instructions be followed. This manual should be
made available to every operator. Extra copies of this manual will be
supplied on request.
3- The installation and the operation Dynasafe equipment should only be
carried out in accordance with the appropriate health and safety at work
regulations.
4- Never apply to the Dynasafe a load or an effort in excess of the working
load limit, and never use it for an operation for which it is not intended.
5- TRACTEL S.A.S declines any responsibility for the consequences of
dismantling or altering the machine by any unauthorized person.
6- Dynasafe equipment must not be used in explosive atmospheres.
7- Dynasafe equipment must only be used in a system designed for lifting
people after ensuring that the appropriate operating coefficients have be
used in accordance with the current regulations.
8- Prior to the use of Dynasafe equipment with complementary equipment
relaying the signals to an operating system, the user or installer of this
system should carry out a specific risk analysis of the operating functions.
The appropriate measures should be taken to obviate risks identified.

MS 32/2/A R 03/03 3
INSTALLATION OF HF 32/2/A LOAD CELL
Components of the load cell
A- 2 m connecting cable
B- Flat washer.
C- Adjusting pin.
D- Locking ring.
E- Load cell body.
Procedure for installing load cell
Essential condition : the hook of the lifting system should be free of any load.
- Position the adjusting pin as a function of the load range and wire rope diameter (see p. 4).
- Remove the tightening bracket (K).
- Position the load cell on the wire rope near the dead end/fixed point. The connecting cable
should be uppermost.
- Replace the tightening bracket (K) ensuring that it is correctly positioned depending on the
diameter of the wire rope. (See page 4)
-Adjust the tightening screws (J) symetrically (+/- 0.5 kgm) to ensure that there is no risk of
moving the load cell out of line with the wire rope. Excessive tightening may break the
bracket.
- Operate the lifting system up to the upper limit switch and ensure that the sheaving or
bottom block does not foul the load cell. If this happens adjust the upper limit switch so that
there is an appropriate distance between the load cell and the bottom block. Also check that
when the bottom block is in the upper position the load cell is not in contact with the
overhead crane.
- Wire the connecting cable from the load cell t the control box. Ensure that the cable is
secured.
F- Locking nut
G- Tare screw.
H-Traction part.
I- Safety washer.
J- Tightening screw.
K-Tightening bracket.
L-Rubber compression pad.
M-Wire rope.
N- Fixing screws for circuit
breaker.(do not touch)
Fig. 1
































A
B
C
D
E
H
F
G
I
J
K
L
M
N

MS 32/2/A R 03/03 4
INSTALLATION OF HF 32/2/A LOAD CELL
Positioning the adjusting pin as a function of the effort in the wire rope
Important remarks
- Before loading and if no preadjustment has been made in the factory, unscrew the
adjustment screw at the most, because you risk to destroy the transducer.
- To select pin and bracket position, load has priority over wire rope diameter.
- Never remove the locking nut (G) because tare screw (F) could damage the
microswitch.






























For wire rope from 22 mm to 26 mm diameter
and for loads ranging from 500 kg to 6000 kg.
For wire rope from 17 mm diameter and for
loads ranging from 300 kg to 2300 kg.
For wire rope from 18 mm to 22 mm diameter
and for loads ranging from 350 kg to 5000 kg.
Fig. 2

MS 32/2/A R 03/03 5
INSTALLATION OF HF 32/2/A LOAD CELL
Correct positioning of the tightening bracket
depending on the diameter of the wire rope.
Fig. 3
Rubber compression pad
M6 screws * 40 mm (x2)
M6 screws * 50 mm (x2)
17 mm wire rope
without the rubber compression pad,
M6 screws * 40mm (supplied)
18 mm to 25 mm wire rope
without the rubber compression pad,
M6 screws * 50mm (supplied)

MS 32/2/A R 03/03 6
OPERATION AND ADJUSTMENT OF HF 32/2/A LOAD CELL
The switching power is 4A, 220 Vac (0.3A, 250 Vdc). ( It is therefore possible to
connect in series in the upper limit switch circuit).
Adjustment of the safety trip point
Essential conditions : - The load cell must be correctly installed and wired.
- The hook of the lifting system should be free of any load.
Equipment required : - A load (“Pm”) equivalent to 100 % of the working load limit
of the lifting system .
- An additional load equivalent to 10 % of « Pm ».
ACTION EXPLANATION
1Lift the two loads
(100% + 10% of Pm)
by +/- 10 cm.
The additional 10 % load represents the overload value
permitted under the European directives.
If an overload situation is detected in the wire rope ( without
lifting the loads) the preadjustment of the load cell in the
factory is too low for your lifting system.
Solution: release the tare screw (F - see fig. 4) one turn at a
time and restart at the beginning of point 1.
2To adjust the safety
trip point.
Use the tare screw (F).
Warning : incorrect adjustment may damage the circuit –
breaker.
Do not forget the locking nut (G). The switch is a normally
closed contact (NC), requiring the opening of the switch to set
off an overload condition.
Turn clockwise to reduce the value of the trip point.
Turn anticlockwise to increase the value of the trip point
(Black)
Alarm
Control
voltage
Lifting
Contactor
G
Brown)
(Blue)
BROWN/BLUE = NC (Normally closed)
BROWN/BLACK = NO (Normally open)
















Earth
Fig. 4

MS 32/2/A R 03/03 7
INSTALLATION OF HF 32 / . / A . TWO TRIP POINTS














A
B
C
D
E
H
I
J
K
L
M
N
G
F
F'
G'
The individual adjustment of each trip point must be carried out as
explained in this manual for the one trip point models.
WIRING
Components of the load cell
A – Cable connection.
B – Flat washer.
C – Adjust pin.
D – Locking ring
E – Load cell body.
F – Tare screw for trip point N° 1.
G – Locking nut for trip N° 1.
F’ - Tare screw for trip point N° 2.
G’ - Locking nut for trip N° 2.
H –Traction part.
I – Safety washer.
J – Tightening screw.
K – Tightening bracket.
L – Rubber compression pad.
M – Wire rope.
N – Fixing screws for circuit-breaker.
S 1
S 2
Trip point 1( intermediary )
GREEN / BROWN : NC ( 4 A 220 Vac )
WHITE/ BROWN : NO ( 4 A 220 Vac)
Trip point 2 ( Safety )
BLUE / GREY : NC ( 4 A 220 Vac )
PINK / GREY : NO ( 4 A 220 Vac )

MS 32/2/A R 03/03 8
NOTES :
