TrailFX A7100S/T User manual

Visit www.trailfx.com or Call [phone] for Warranty Information / Tech Support / Product Updates.
Keystone Automotive Operations Inc. All Rights Reserved. 12/02/2022-R01 Page-1-4
APPLICATION: 2022-2023 TOYOTA TUNDRA DOUBLE CAB
Assembly, Installation, Operation and
Maintenance Instructions
5" Oval Straight Side Bar
Part Number:
A7100S/T
60 - 180 minutes
Dealer / Installer:
Provide a copy of these instructions to the end user of this product. These instructions
provide important operating and safety information for proper usage of this product.
Demonstrate the proper use of the product with the end user. Have the end user
demonstrate that they understand the proper use of the product.
End User:
Read
and follow all instructions included in this manual. Ask your Dealer / Installer for
assistance if you do not understand the proper use of the product. Never remove any
decals from the product. Failure to follow these instructions can result in injury or death.
WARNING
PARTS LIST
Qty Part Description Qty Part Description
1
Driver/Left Sidebar
3
Passenger/Right Rear Mounting Brackets
1
Passenger/Right Sidebar
16
8
mm x30mm Hex Bolts
1
Driver/Left Front Mounting Bracket
16
8
mm x25mm Combo Bolts
1
Passenger/Right Front Mounting Bracket
16
8
mm Lock Washers
3
Driver/Left Rear Mounting Brackets
16
8
mm x24mm OD x 2mm Flat Washers
TORQUE SPECIFICATION
Size Torque Size Torque
08 MM
20.0 ft/lbs
FRONT
(3) Passenger/Right Rear
Mounting Brackets (3) Driver/Left Rear Mounting Bracket
Driver/Left
Front Mounting
Bracket
Passenger/Right
Front Mounting
Bracket
Driver/Left
Sidebar
Approx. 19inches
between
threaded holes
Approx. 22inches
between
threaded holes
Approx. 10inches
between
threaded holes

Visit www.trailfx.com or Call [phone] for Warranty Information / Tech Support / Product Updates.
Keystone Automotive Operations Inc. All Rights Reserved. 12/02/2022-R01 Page-2-4
INSTALLATION PROCEDURE:
1. REMOVE CONTENTS FROM BOX. VERIFY ALL PARTS ARE PRESENT. READ INSTRUCTIONS CAREFULLY. USE
ILLUSTRATION TO IDENTIFY BRACKETS AND SIDE STEPS.
2. Starting on the Driver/Left front of the vehicle, remove the plastic plugs or hex bolts covering the (2) threaded holes in the
floor panel, (Figure 1).
3. Select Driver/Left Front Mounting Bracket, (Figure 2). Attach the Bracket to the panel with (2) 8mm Hex Bolts, (2) 8mm
Lock Washers and (2) 8mm Flat Washers, (Figure 2). Do not tighten hardware.
4. Next, move to the second mounting location, (Figure 3). Select (1) Driver/Left Rear Mounting Bracket. Repeat Step 3 to
attach the Bracket to the floor panel, (Figure 4).
5. Continue to the rear mounting location, (Figure 5). Repeat Step 3 to attach (1) Driver/Left Rear Mounting Bracket to the
floor panel
6. Select the Driver/Left Sidebar. Place the Sidebar onto the cradles of the Mounting Brackets. IMPORTANT: Do not rotate or
slide the Sidebar front to back or damage to the finish may result. Attach the Sidebar to the Mounting Brackets with (8)
8mm Combo Bolts, (Figure 6). Do not tighten hardware.
7. Level and adjust the Sidebar as necessary and fully tighten all hardware.
8. Repeat Steps 2—7to attach the Passenger/Right Sidebar.
9. Do periodic inspections to the installation to make sure that all hardware is secure and tight
To protect your investment, Do not use any type of polish or wax that may contain abrasives that could damage the finish. Mild soap may
be used also to clean Sidebars.
INSTALLATION IMAGES: Driver/Left Side Installation Pictured
Remove plastic plugs or
factory hex bolts (if equipped)
(Fig 1) Driver/Left front mounting location
Front
(Fig 3) Driver/Left 2nd mounting location
Front
(Fig 2) Attach Driver/Left Front Mounting
Bracket to the floor panel
(2) 8mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers

Visit www.trailfx.com or Call [phone] for Warranty Information / Tech Support / Product Updates.
Keystone Automotive Operations Inc. All Rights Reserved. 12/02/2022-R01 Page-3-4
PRODUCT CARE
•Periodically check the product to ensure all fasteners are tight and components are intact.
•Regular waxing is recommended to protect the finish of the product.
•Use ONLY Non-Abrasive automotive wax. Use of any soap, polish or wax that contains an abrasive is detrimental and can
scratch the finish leading to corrosion.
•Aluminum polish may be used to polish small scratches and scuffs for Stainless Steel finish.
•Mild soap may be used to clean the product for both Stainless Steel and Black finish.
FAQ’s
1. Hardware and mounting brackets are not aligning properly
Ensure that hardware is being used on the correct side of vehicle. In some cases, the hardware may appear the same for driver and
passenger side but may alter the alignment of mounting location. Check mounting brackets for both sides.
2. Products are thumping / rattling after Installation
Ensure that all required mounting brackets / hardware’s are installed & tightened correctly.
Suggest using white Lithium / regular grease between metal-to-metal contact.
3. Missing / Excess Hardware
Recheck hardware count as per the part list.
4. Product not installing properly
Ensure the Year / Make / Model as well as cab and bed dimensions are correct for the application. Review all steps for installation to
ensure they were followed correctly.
5. Who should be contacted for questions regarding product / installation assistance?
www.trailfx.com / su[email protected] or 1-[phone]
(Fig 5) Driver/Left rear mounting locations
(Fig 6) Attach Driver/Left Sidebar to the
Mounting Brackets
(Fig 4) Attach Driver/Left Rear
Mounting Bracket to the floor panel
(2) 8mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers
Rear
(2) 8mm
Combo Bolts

Visit www.trailfx.com or Call [phone] for Warranty Information / Tech Support / Product Updates.
Keystone Automotive Operations Inc. All Rights Reserved. 12/02/2022-R01 Page-4-4
Warranty Terms:
Black Powder Coated: 3 Year Limited Warranty
Stainless Steel Polished: Limited Lifetime Warranty
TrailFX and KeystoneAutomotive Operations Inc. make no guarantees or warranties for products not
manufactured by Keystone Automotive Operations Inc. Such products are covered solely under any
applicable warranty of the manufacturer. It is always recommended that the operating instructions and
warranty instructions provided by the manufacturer are followed.
KeystoneAutomotive Operations Inc. warrants its products to be free from manufacturing and material
defects to the original purchaser for the length of warranty stated above from the date of retail purchase.
If any products are found to have a manufacturing or material defect, the product will be replaced or
repaired at the option of TrailFX and KeystoneAutomotive Operations Inc. with proof of purchase by the
original purchaser. The original purchaser shall pay all transportation and shipping costs associated with
the return of the defective product and the defective product shall become the property of Keystone
Automotive Operations Inc.
The Warranty applies to KeystoneAutomotive Operations Inc. products used for individual and
recreational purposes. Commercial usage of the Keystone Automotive Operations Inc. products limits the
warranty to 90-days from date of purchase.
The Warranty applies only to Keystone Automotive Operations Inc. products which are found to be
defective in manufacturing or material. This warranty does not apply to normal wear and tear of the finish
placed on Keystone Automotive Operations Inc. products.
TrailFX and KeystoneAutomotive Operations Inc. are not responsible for any labor costs incurred for
removal or replacement of the defective product.
TrailFX and KeystoneAutomotive Operations Inc. are not responsible for repair or replacement of any
product under the limited warranty where the product was improperly installed, misapplied, altered,
abused, neglected, overloaded, misused or damaged as a result of an accident, including any use of the
product not in accordance with all product operating and safety instructions.
Without limiting the generality of the foregoing, TrailFX and KeystoneAutomotive
Operations Inc. shall under no circumstances be liable for any incidental or consequential loss or damage
whatsoever arising out of, or in any way relating to any such breach of warranty or claimed defect in, or
non-performance of the products. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above exclusion or limitation may not apply to you.
This limited warranty gives you specific legal rights, and you may also have other rights that vary from
state to state.
