Stargazer Spirit XTR
Acrylic Window
OEM INSTALLATION MANUAL

Rev: 09.28.22 Page 2 CCD-0006512
Introduction
The Stargazer Spirit XTR Acrylic Window Skylight can be installed on the roof of a unit to provide ventilation
and allow sunshine in while providing privacy. The inner screen frame options allow for different types
of ventilation and guards against pests. The inner screen assembly is a combination of a flyscreen and shade
for windows that can be pulled across the skylight opening by hand using the two different profiles.
The integrated spring shaft tensions the fabric permanently and gives optimum hold. The Stargazer Spirit
XTR Acrylic Window Skylight is positioned front to rear of unit and is designed for a flat interior roof. For
information on the assembly or individual components of this product, please visit:
https://support.lci1.com/skylights
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.
Failure to follow instructions provided in this manual may result in death, serious personal injury
and/or severe product and property damage, including voiding of the component warranty.
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause
death or serious personal injury if not performed safely and within the parameters
set forth in this manual.
Safety
Read and understand all instructions before installing or operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the
provided instructions may result in death, serious personal injury, severe product and/or property damage,
including voiding of the Lippert limited warranty.
TABLE OF CONTENTS
Introduction 2
Safety 2
Resources Required 3
Prior to Installation 3
Installation 4
Skylight Roof installation 4
Skylight Inner Screen Ceiling Trim and Frame 4
Operation 5
Skylight Open Position 5
Skylight Closed Position 6
Maintenance 7
Notes 7
All windows must be fully closed prior to travel. Failure to close windows prior to
travel could result in product and/or property damage.

Rev: 09.28.22 Page 3 CCD-0006512
Always wear eye protection when performing service, maintenance or installation procedures.
Other safety equipment to consider would be hearing protection, gloves and possibly a full face
shield, depending on the nature of the task.
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause personal injury
and/or product or property damage if not safely adhered to and within the parameters set forth
in this manual.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Resources Required
Prior to Installation
Be sure to check that rough opening measures to the size stated on the Stargazer Skylight label. Be sure that
the opening has proper framework supporting it, ie; aluminum, steel tubing or lumber.
1. Remove all packing material and tape before installation of the Stargazer skylight.
2. Clean the back surface of the outside flange, of the outer frame of the window assembly (Fig. 1A - red line).
3. Install OEM provided inner seal along the back inside perimeter (Fig. 2A - red line) of the outer frame
surface of the window assembly. This helps to create a tight seal once the window is completely
installed inside the roof of the unit.
Fig. 1 Fig. 2
• 1-2 People, depending on task
• Cordless or electric drill or screw gun
• Appropriate drive bits
• Appropriate drill bits
• Caulk gun
• Gunnable self-leveling Lap sealant
• Closed cell foam tape or butyl tape
• Scissors or cutting tool
• Cleaning cloths
• Alcohol based cleaner
• #8 x1 pan quad T-2 self drilling screw w/assembled 5/8"
neo-bond washer – (Approx. 48 for outer roof skylight)
• #8 x 3/4” pan head screws (6 for inner frame / screens)
AA

Rev: 09.28.22 Page 4 CCD-0006512
Installation
Skylight Roof installation
1. Place the skylight window assembly in the rough opening of the unit, centered side to side with the
hinge pins (Fig. 3A) facing towards the front of the unit.
2. Install #8 x1" pan quad T-2 self drilling screws w/assembled 5/8" neo-bond washers (Fig. 4A) in each
pre-drilled hole (Fig. 4B) along the perimeter of the Stargazer Spirit Skylight outer frame.
3. Apply the gunnable self-leveling sealant over each screw (Fig. 5A - green area).
4. Apply the gunnable self-leveling sealant around the perimeter where the skylight frame and roof meet
(Fig. 6A - green area).
Skylight Inner Screen Ceiling Trim and Frame
1. Insert the ceiling trim piece (Fig. 7A) inside the skylight housing (Fig. 7B) with the flange of the trim
(Fig. 7A) flush to the ceiling (Fig. 7C).
2. Place the screen frame (Fig. 8A) centered over the trim in the ceiling.
3. Install six #8 x 3/4” pan head screws (Fig. 9C) through the pre-driled holes (Fig. 9B) of the screen frame,
through the ceiling trim, and into the ceiling.
4. Install six screw caps (Figs. 9D, 10A) over the screw holes in the screen frame.
Fig. 3 Fig. 4
Fig. 5 Fig. 6
A
Front of Unit
Rear of Unit
A
B
A A
Fig. 7 Fig. 8
AA
B
C

Rev: 09.28.22 Page 5 CCD-0006512
Operation
Fig. 10
AAA
AAA
A
C
D
B
Fig. 9
Fig. 13 Fig. 14
A
B
Fig. 11 Fig. 12
A
A
B
BA
All windows must be fully closed prior to travel. Failure to close windows prior to
travel could result in product and/or property damage.
Skylight Open Position
NOTE: DO NOT rapidly slide the profiles of the screen frame assembly. Rapidly sliding the profiles may
cause damage to the screen frame or ceiling of the unit.
1. If applicable, toggle the screen latch (Fig. 11A) to slide the screens (Fig. 11B) back into the screen frame
to be able to access the Stargazer Spirit Skylight's five skylight window latches.
2. Press in on the latch button (Fig. 12A) and swing the latch (Fig. 12B) from the closed position (Fig. 12)
to the open position (Fig. 13A).
NOTE: The Stargazer Spirit XTR Acrylic Window Skylight opens to a maximum 8 degrees. DO NOT force the
skylight window open any farther than it will extend.
3. Push up on the skylight window's handle (Fig. 14A) to open the skylight window.
