Faster, more versatile printers at the register — that’s how to keep customers moving. And that’s what the Series 90PLUS was designed
to do. With an industry-leading speed of 12.5 lines per second, and multi-function print capability all in one smartly designed, incredibly
quiet unit, the Series 90PLUS could be the most exible receipt printer available. Like other Ithaca brand printers, the 90PLUS utilizes
Oki® technology, known worldwide for quality, reliability and a snap-in/snap-out, user-friendly cartridge design. Perfect for POS and
banking—you can print on the face of a check, validate the back, and use the built-in slip path for oversized forms. The 90PLUS’s
standard 2-year warranty offers extended maintenance options. And, of course, the Series 90PLUS is backed by our solid reputation
for quality and reliability.


Printing style: Condensed
Pitch (char./in.): 17.1
Characters/line (maximum): 48
Print speed (lines/sec.): 12.5 @ 10 char./line; 5.9 @ 40 char./line

Dimensions (in mm.): 185.42 W x 311.15 D x 152.40 H
Dimensions (in inches): 7.3 W x 12.25 D x 6.0 H
Weight: 10 lbs. (4.5 Kg)
Shipping Weight: 13 lbs. (5.9 Kg)

93PLUS Receipt/Journal/17-line Validation/Slip
94PLUS Receipt/17-line Validation/Slip

RS232C: Bi-Directional Serial (9-pin)
IEEE1284: Bi-Directional Parallel (25-pin)

WindowsTM 95/98/2000/Me, NT 4.0, OPOS

n Adjustable Paper Width Options: 76.2 mm, 82.5 mm (3.0 in., 3.25 in.)
n Banking Validation: 10 lines, drop-in
n Concurrent and Independent Validation (Up to 17 Lines Under Software
Control): M93, M94
n Auto-Cut: Partial Cut leaves a 1 mm (.04 in.) tab in center of receipt.
n Journal Lock

n Rotated Print (4-90° rotations)
n Programmable Top of Form
n Automatic Forms Detection and Feed Under Software Control
n Top of Form to Top of Print Line: 15.8 mm (.625 in.)
n Bottom of Form to Bottom of Print Line: 15.8 mm (.625 in.)

Internal Universal AC Power: 90 VAC to 264 VAC (self-ranging), 47 to 63 Hz

Printer in full operation (using all available features)*
MCBF: 4,000,000 to 5,000,000 Print Lines
(depending on model)
MTBF: 22,000 to 30,000 Hours
(depending on model)
Printhead: 200,000,000 Characters
Auto-Cutter: 1,000,000 Cuts
*Reliability data is based on our standard test conditions simulating a
normal retail operating environment.

Temperature: Operating: 0 to +50 °C (32 to +122 °F)
Humidity: Operating: 10 to 90% RH (non condensing)

FCC Class A CSA 950 CEMark UL 1950 VDE 950

We offer convenient one-stop shopping for all your printer needs-paper,
spare parts, manuals, printer servicing/refurbishment and more. For more
information, call us at 1-877-748-4222 or visit transact-tech.com.

n Print Speed: 12.5 lps. (340 cps.)—On Standard Test Receipt
n Standard Warranty: Two Years (Extended Maintenance Plan Available)
n Cash Drawer Drivers: Dual with Status (RJ11)
n Print Zone: Width: 71 mm (2.8 in.)—Operator Visible
n Data Buffer: Up to 6K Congurable
n Custom Logo Print Buffer: (Non-volatile Memory, 2000 Bytes)
n CPI: 4, 5, 6, 7.5, 8, 8.5, 10, 12, 15, 17.1, 20, 24
n Portrait or Landscape Printing
n APA Bit Map Graphics
n Emulations: Ithaca/IBM, Epson ESC/POS*
n 67 Language Code Pages
n Optical Paper Low Switch (Software Sense and Adjustable)
n Concealed Cable Entry
n Forms Insertion: Front (Slip) or Top (Validation)
n Display Pass-Thru (Serial Only)
n Bar Codes: Code 39, Interleaved 2 of 5, UPC-A & UPC-E, EAN8 & EAN13,
Code 128
n Interface Parameters: Software Congurable via Buttons or Interface Port
* Automatic Status Back feature available as an option.

Paper Roll (one-ply):
n Width: 82.5 mm (3.25 in.) or optional 76 mm (3 in.)
n Diameter: 89 mm (3.5 in.)
n Length Per Roll: 73.1 m (240 ft.)
n One-Ply Maximum Thickness: .11mm (.0045 in.)
Paper Roll (two-ply):
n Width: 82.5 mm (3.25 in.)
n Diameter: 89 mm (3.5 in.)
n Length Per Roll: 38.1 m (125 ft.)
n Maximum Thickness Per Ply: .09 mm (.0035 in.)
Paper Roll (Three-Ply):
n Width: 82.5 mm (3.25 in.)
n Diameter: 89 mm (3.5 in.)
n Length Per Roll: 26m (85 ft.)
n Maximum Thickness Per Ply: .25 mm (.01 in.)
Inserted Forms (1 original and up to 3 copies):
n Minimum form size: 63.5 mm W x 85.73 mm L (2.5 in. W x 3.375 in. L)
n Single sheet thickness: .09 mm - .41 mm (.0035 in - .016 in.)
n Multi-part form maximum thickness: .41 mm (.016 in.)
Ribbons: 3-4.5 Million Character Life
n Ithaca or Genuine Oki Snap-on Ribbon Cassette (Black or Purple)

