Travis Industries AGP FS User manual

AGP FS
Pellet Stove ꞏ
• Horizontal or Vertical Vent
• Freestanding Stove
• Mobile Home Approved
• Class A Chimney Retrofit
• Hearth Stove into Existing
Masonry Chimney, Masonry
Fireplace, or Z.C. Fireplace
-- Please read this entire manual before
installation and use of this pellet fuel-
burning room heater. Failure to follow
these instructions could result in property
damage, bodily injury, or even death.
-- Contact local building or fire officials
about restrictions and installation
inspection requirements in your area.
-- Save these instructions.
Tested and Listed by:
ASTM E1509 ULC-S627
French language manuals at lopistoves.com.
Manuels de langue Française à lopistoves.com
Installer: After installation give this manual to the home-
owner and explain the operation of this stove.
Consumer: Retain this manual for future reference.
$10.00 Copyright 2022, T.I.
Part # 100-01566 4/11/22
Travis Industries, Inc.
www.travisproducts.com
12521 Harbour Reach Drive SW
Mukilteo, WA 98275

2Introduction
© Travis Industries 4/11/22- 1566 AGP Stove
Introduction
We welcome you as a new owner of an AGP pellet stove. In purchasing an AGP pellet stove you
have joined the growing ranks of concerned individuals whose selection of an energy system reflects
both a concern for the environment and aesthetics. The AGP pellet stove is one of the finest home
heaters the world over. This manual will explain the installation, operation, and maintenance of this
pellet-burning heater. Please familiarize yourself with this Owner's Manual before operating your
heater and save the manual for future reference. Included are helpful hints and suggestions which
will make the installation and operation of your new heater an easier and more enjoyable experience.
We offer our continual support and guidance to help you achieve the maximum benefit and enjoyment
from your heater.
Important Information
No other AGP pellet stove has the same serial number
as yours. The serial number is on the safety label on
the back of the appliance.
This serial number will be needed in case you require
service of any type.
Model: AGP FS Pellet Stove
Serial Number:
Purchase Date:
Purchased From:
Register your warranty online at:
traviswarranty.com
Save Your Bill of Sale.
To receive full warranty coverage, you will need to
show evidence of the date you purchased your
heater.
We suggest that you attach your Bill of Sale to this
page so that you will have all the information you
need in one place should the need for service or
information occur.

Table of Contents 3
© Travis Industries 4/11/22- 1566 AGP Stove

Introduction ..............................................................2
Important Information..............................................2
Heating Specifications.............................................7
Dimensions...............................................................7
Electrical Specifications..........................................7
Fuel............................................................................7
Emissions .................................................................7
Efficiency ..................................................................7
Before You Begin .....................................................8
Packing List..............................................................8
Items Required .........................................................8
Installation Options..................................................8
Planning the Installation..........................................9
Stove Placement ......................................................9
Floor Protection Requirements...............................9
Electrical Requirements ..........................................9
Clearances..............................................................10
Straight Installations............................................10
Corner Installations .............................................10
Venting the Pellet Stove ........................................11
Maximum Venting Distance ................................11
Pellet Vent Type..................................................12
Installing the Pellet Vent .....................................12
Pellet Vent Termination.......................................12
Mobile Home Requirements..................................13
Outside Air (Used for Combustion Use Part
#99200136) ..............................................................13
Alcove Installation Requirements.........................14
Restrictor Adjustment ...........................................14
Installation Examples ............................................15
Installation Example: Direct "Through-the-wall"
Installation...........................................................15
Installation Example: Interior Vertical Installation 16
Installation Example: Class “A” Chimney Retrofit17
Installation Example: Masonry Fireplace Hearth
Stove...................................................................18
Installation Example: Zero-Clearance (Metal)
Fireplace Hearth Stove .......................................19
Installation Example: Freestanding Masonry
Chimney..............................................................20
Safety Notice ..........................................................21
Location of Controls ..............................................21
Loading Pellets.......................................................22
Starting the Heater for the First Time...................22
Curing the Paint ..................................................22
Manual Mode ..........................................................23
To Start ...................................................................23
To Shut Down .........................................................23
To Adjust the Heat ..................................................23
To Adjust Heat Output.............................................24
Auto-Fan .................................................................24
TSTAT (Thermostat) Mode ....................................25
To Start the Stove in TSTAT Mode .........................25
To Adjust the Heat Output.......................................25
To Shut Down .........................................................25
Changing the TSTAT Program............................26
How to Tell Which TSTAT Program You Are In ......26
Switching Between Program 1, 2, and 3 .................26
Thermostat Program 1 ............................................26
Thermostat Program 2 ............................................26
Thermostat Program 3 ............................................26
Start-Up Sequence (Igniter)...................................27
Power Outages .......................................................27
Manual Mode ..........................................................27
TSTAT Mode...........................................................27
Stove Maintenance.................................................28
Troubleshooting Table ..........................................42
Replacement Parts.................................................42
Door Parts...........................................................42
Wiring Diagram.......................................................43
Thermostat Installation (Optional)........................44
Outside Air Kit ........................................................44

4 Safety Precautions
© Travis Industries 4/11/22- 1566 AGP Stove
HOT WHILE IN OPERATION.
KEEP CHILDREN, CLOTHING,
AND FURNITURE AWAY.
CONTACT MAY CAUSE SKIN
BURNS.
Educate all children of the danger of
a high-temperature heater. Young
children should be supervised when
they are in the same room as the
heater.
Contact your local building officials
to obtain a permit and information
on any installation restrictions or
inspection requirements in your
area. Notify your insurance
company of this appliance as well.
Do not operate the heater if you
smell smoke coming from the
heater. Press the “STOP” button,
monitor your heater, and call your
dealer.
Never use gasoline, gasoline-type
lantern fuel, kerosene, charcoal
lighter fluid, or similar liquids to start
or “freshen up” a fire in this heater.
Keep all such liquids well away from
the heater while it is in use.
Do not store solid fuel or place such
fuel within heater installation
clearances or within the space
required for charging and ash
removal.
Do not unplug the heater if you
suspect a malfunction. Press the
“STOP” button and periodically
inspect the heater.
Do not alter this appliance in any
way
Ashes should be placed in a metal
container with a tight-fitting lid. The
closed container of ashes should be
placed on a noncombustible floor or
on the ground, well away from all
combustible materials, pending final
disposal. If the ashes are disposed of
by burial in soil or otherwise locally
dispersed, they should be retained in
the closed container until all cinders
have been thoroughly cooled.
Never try to repair or replace any
part of the heater unless
instructions are given in this
manual. All other work should be
done by a trained technician.
Do not alter this appliance in any
way.
The viewing door and ashpan must
be closed and latched during
operation.
This unit must be properly installed
to prevent the possibility of a house
fire. The instructions must be strictly
adhered to. Do not use makeshift
methods or compromise in the
installation.
This heater is designed and approved
for pelletized wood fuel only.
Ok
Gas
ASHES

Safety Precautions 5
© Travis Industries 4/11/22- 1566 AGP Stove
Allow the appliance to cool
completely before carrying out any
maintenance or cleaning.
Maintain the door and glass seal
and keep them in good condition.
Do not operate this heater with
broken or missing glass.
Do not slam the door or strike the
glass.
Notify your dealer to replace the
glass if the glass on this appliance
is broken or damaged.
Do not operate the heater if the
flame becomes dark and sooty or if
the fire platform overfills with
pellets. Press the “STOP” button
and periodically inspect the heater.
Do not place clothing or other
flammable items on or near this
appliance.
The heater will not operate during a
power outage.
This heater must be connected to a
standard115 V., 60 Hz grounded
electrical outlet. Do not use an
adapter plug or sever the grounding
plug. Do not route the electrical cord
underneath, in front of, or over the
heater.
Keep foreign objects out of the
hopper.
The exhaust system must be
completely airtight and properly
installed. The pellet vent joints must
be sealed with RTV 500F. (260C.)
silicone sealant.
Your heater requires periodic
maintenance and cleaning (see
"Stove Maintenance"). Failure to
maintain your heater may lead to
accumulation of soot, creosote, and
ash, and smoke spillage or fire in
your home.
When installed in a mobile home,
the heater must be bolted to the
floor, have outside air, and NOT BE
INSTALLED IN THE BEDROOM
(per H.U.D. requirements). Check
with local building officials.




6 Safety Precautions
© Travis Industries 4/11/22- 1566 AGP Stove
Do not throw this manual away.
This manual has important
operating and maintenance
instructions that you will need at a
later time. Always follow the
instructions in this manual.
Disconnect the power before
performing any maintenance.
The exhaust system should be
checked at least twice a year for
any build-up of soot or creosote.
Travis Industries, Inc. grants no
warranty, implied or stated, for
the installation or maintenance of
your appliance, and assumes no
responsibility for any
consequential damage(s).
DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST VENTING SYSTEM OF THIS UNIT.
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE.
INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER.
Soot and Flyash: Formation and Need for Removal – The products of combustion will contain
small particles of flyash. The flyash will collect in the exhaust venting system and restrict the
flow of the flue gases. Incomplete combustion, such as occurs during startup, shutdown, or
incorrect operation of the room heater will lead to some soot formation which will collect in
the exhaust venting system. The exhaust venting system should be inspected at least twice
every year to determine if cleaning is necessary.
NEVER USE SUBSTITUTE MATERIALS FOR ANY PURPOSE ON THIS APPLIANCE.
Establish a routine for fuel, wood burner, and firing techniques. Check for creosote build-up
daily until you know how often to clean the appliance for safe operation. Be aware that the
hotter the fire, the less creosote is deposited, and weekly cleaning may be necessary in mild
weather even though monthly cleaning may be enough in the coldest months. Contact your
municipal or provincial fire authority for information on how to handle a chimney fire. Have a
clearly understood plan in place for how to handle a chimney fire.
Do not burn this stove if unburned pellets are in the ashpan. These should be removed as they
may ignite.
Smoke and CO Detectors: Make sure your home has a working smoke detector, especially near any bedrooms. We
recommend having a smoke and/or CO detector in the same room as the wood heater for additional safety.
Proposition 65 Warning: Fuels used in gas, woodburning or oil fired appliances, and the products of combustion of such fuels,
contain chemicals known to the State of California to cause cancer, birth defects, and other reproductive harm.
California Health & Safety Code Sec. 25249.6
This wood heater has a manufacturer-set minimum low burn rate that must not be altered. It is against federal regulations to
alter this setting otherwise operate this wood heater in a manner inconsistent with operating instructions in this Manual.
U.S. and Foreign Patents Pending.
This
Manual

Installation (For Qualified Installers Only) 7
© Travis Industries 4/11/22- 1566 AGP Stove
Heating Specifications
Approximate Maximum Heating Capacity (in square feet)*............................................ 800 to 2,000 Sq. Feet
BTUs Per Hour (net input).............................................................................................. 12,806 to 43,428
BTUs Per Hour (net output) ........................................................................................... 8,959 to 34,738
Overall Efficiency (LHV)................................................................................................. 80.8%
Overall Efficiency (HHV) ................................................................................................75.6%
Burn Rate (Pounds per Hour)**......................................................................................1.4 to 5
Maximum Burn Time on Low Burn** .............................................................................. 57 Hours
Hopper Capacity ............................................................................................................ 80 Pounds
Turn-Down Ratio............................................................................................................ 71%
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside temperature. It is also affected by the fuel
size, quality, and moisture level.
** Small pellet size will decrease the stated burn rates and burn times. Differences of plus or minus 20% depending on fuel quality may occur.
Dimensions
Electrical Specifications
Electrical Rating ......................................................................................................115 Volts, 3 Amps, 60 Hz
Watts during Start-Up Sequence ............................................................................350 (approximately)
Watts during Operation ...........................................................................................250 (approximately)
Fuel
This heater is designed and approved for pelletized wood fuel only (all grades). Travis Industries Inc.
recommends using only fuel that is certified by the Pellet Fuels Institute (PFI).
Emissions
This heater meets the 2020 U.S. EPA’s emission limits for pellet stoves. Report# 0028PS108E
Tested to ASTM E2779-10, ASTM 2515-11, CSA B415.1-10 this heater has been shown to deliver heat
at rates ranging from 8,959 to 34,738 BTU/hr and an emission value of 1.80g/h.BTU/hr.
Efficiency
This model was tested for efficiency using method B415.1-10 and was determined to have a weighted
average higher heating Value (HHV) Overall Heating Efficiency (OHE) of 75.6%. Overall efficiency of the
heater may be lower if the heater is operated with the heat exchange blower is on low.
3" (77mm) Dia. Exhaust
(centered on appliance)
1.75" (45mm) Dia. Air Intake
16.5"
(420mm)
3.5" (89mm)
24.25" (616mm)
25.25"
(642mm)
17.5"
(445mm)
3" (77mm)
Dia. Exhaust
1.75" (45mm)
Dia. Air Intake
33"
(839mm)
42.25"
(1074mm)
7.25" (185mm)
5.75" (147mm)

8Installation (For Qualified Installers Only)
© Travis Industries 4/11/22- 1566 AGP Stove
Before You Begin
READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE THIS HEATER. FAILURE TO
FOLLOW THE INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN
DEATH.
Check with local building officials for any permits required for the installation of this pellet heater and
notify your insurance company before proceeding with the installation.
Packing List
Items Required
Pellet Vent chimney or chimney liner materials (dependent upon installation location)
Installation Options
Residential or Mobile Home (see the section "Mobile Home Requirements")
Alcove Compatible (see the section "Alcove Installation")
Horizontal or Vertical Vent
Outside Air Compatible
Vent with L-Vent, L-Vent Fireplace Liner, or Type “A” Chimney (with adapter)
Cleaning tool
Brush
Bottle Brush
Fuses
Burn Platform
Wedge

Installation (For Qualified Installers Only) 9
© Travis Industries 4/11/22- 1566 AGP Stove
Planning the Installation
HINT: Have an authorized Travis Industries dealer install this heater. If you install the
heater yourself, have your dealer review your installation plans.
HINT: Sketch out a detailed plan of the installation including dimensions. Then verify the
dimensions with the requirements listed in this manual.
HINT: When determining the location of the stove, locate the wall studs (for horizontal
penetrations) and ceiling trusses (for vertical penetrations). You may wish to adjust
the stove position slightly to ensure the vent does not intersect with a framing
member.
The location of your wood heater in your home will decide how effectively the heat produced will
spread throughout your house. Attention to the home design with consideration of natural convection
and air circulation should be taken into account when choosing the placement of your heater within
the home.
Stove Placement
The stove must be placed so that no combustibles are within, or can swing within (e.g. drapes,
doors), 36" (915mm) of the front of the heater.
If the stove is placed in a location where the ceiling height is less than 7' (2.134 M), it must follow
the requirements in the section "Alcove Installation Requirements".
HINT: REDUCING CLEARANCES - Clearances may be reduced by methods specified in
NFPA 211, listed wall shields, pipe shields, or other means approved by local
building or fire officials.
Heater and floor protection must be installed on a level, secure floor.
Floor Protection Requirements
The heater must be installed on a non-combustible floor protector extending the full width and
depth of the heater and extending 6" (153mm) in front and sides of fuel loading or ash removal
doors (minimum .018" thick - 26 gauge).
Must extend under and 2" (51mm) to each side and rear of a "Tee" (if used).
Electrical Requirements
This heater requires a standard 120 volt, 60 Hz grounded electrical outlet. Do not use an
adapter plug or sever the grounding plug.
This heater requires correct polarity. The line (hot) is on the right and has a smaller plug. The
neutral (common) is on the left and has a larger plug. Use a circuit tester (available at hardware
stores) or contact an electrician to verify correct polarity and ground.
WARNING: Connection to a reverse polarity or un-grounded circuit may damage your heater’s
circuit board. This may cause a safety hazard, improper operation, and void your warranty.
Do not route the electrical cord underneath, in front of, or over the heater.

10 Installation (For Qualified Installers Only)
© Travis Industries 4/11/22- 1566 AGP Stove
Clearances
Straight Installations
Corner Installations
* Install the vent at the clearance specified by the vent manufacturer.
NOTE:If an interior vertical vent is used, the stove to back wall dimension is determined by the
vent being used. This dimension will vary depending on the brand of pellet vent used. To
determine the distance from the back wall to the stove, connect the "Tee" and add the vent
clearance.
** The floor protection must extend 2” (51mm) beyond the pipe – all vent clearances must be met.

Installation (For Qualified Installers Only) 11
© Travis Industries 4/11/22- 1566 AGP Stove
Venting the Pellet Stove
INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER.
DO NOT CONNECT THE PELLET VENT TO A VENT SERVING ANY OTHER APPLIANCE OR
STOVE.
DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST VENTING SYSTEM OF THIS UNIT.
USE AN APPROVED WALL THIMBLE WHEN PASSING THE VENT THROUGH WALLS AND
A CEILING SUPPORT/FIRE STOP SPACER WHEN PASSING THE VENT THROUGH
CEILINGS (MAKE SURE TO MAINTAIN CLEARANCE TO ANY COMBUSTIBLES).
No more than one tee and 180° of elbows (one tee with two 90° elbows, one tee with one 90° and
two 45° elbows, etc.).
Maximum Venting Distance
The vent must have a support
bracket every 5' (1.524 M) of pellet
vent when on the exterior of a
structure.
NOTE: Travis Industries
recommends a minimum vertical
vent of 5’ to ensure adequate draft
during a power outage.
0 Feet
5 Feet
10 Feet
(max.)
0 Feet
5 Feet
10 Feet
15 Feet
20 Feet
25 Feet
30 Feet
The vent height and run
must not exceed the
distance s hown in the
shaded region shown to the
right.
NO TE : T o a chieve optimum
performance, we
recommend keeping the
vent as short as possible
(horizontal run especially).
V enting into this s ha ded
area may require restrictor
adjustments. See the
section “R es trictor
Adjus tment” for details .
35 Feet
40 Feet
(max.)

12 Installation (For Qualified Installers Only)
© Travis Industries 4/11/22- 1566 AGP Stove
Pellet Vent Type
Must be 3" (76mm) or 4” (102mm) diameter Type "L" (except for masonry fireplace installations) -
or - connect the vent to a factory-built type "A" chimney. All vent joints (including adapters,
elbows, etc.) must be sealed (typically 500° F. RTV silicone is used).
Installing the Pellet Vent
Horizontal sections must have a 1/4" (6.4mm) rise every 12" (305mm) of travel.
Pellet vent connections must be sealed airtight with 500° F. RTV silicone and screwed together
with at least 3 sheet metal screws (unless the vent manufacturer’s requirements specify
otherwise).
Pellet Vent Termination
The vent must terminate on the exterior of the dwelling. Horizontal terminations must protrude a
minimum of 12" (305mm) from the wall. Vertical terminations must protrude a minimum of 24"
(610mm) from the roof surface. In addition, all clearances listed below must be met.
Must have an approved cap (to prevent water from entering) or a 45° downturn with a rodent
screen.
If the termination is located on a windy side of the house an approved house shield is
recommended to prevent soot from building up on the side of the house.
Must not be located where it will become plugged by snow or other material.
A Minimum 4' (1220mm) clearance below or beside any door or window that opens.
(This clearance may be reduced to18” if using outside air (see page 13) – we recommend
the door or window be kept closed during operation.
Minimum 1’ (458mm) clearance below or beside any window that does not open.
B Minimum 1' (458mm) clearance above any door or window that opens
C Minimum 2' (610mm) clearance from any adjacent building
D Minimum 7' (2.134 M) clearance above any grade when adjacent to public walkways
NOTE: Vent may not terminate in covered walkway or breezeway.
E Minimum 2' (610mm) clearance above any grass, plants, or other combustible materials
F Minimum 3' (915mm) clearance from any forced air intake of any other appliance
G Minimum 2' (610mm) clearance below eaves or overhangs
H Minimum 1' (458mm) clearance horizontally from a combustible wall
X Must be a minimum of 2' (610mm) above the roof
Seal each vent section (including
adapters, elbows, etc...) by
injecting a liberal amount of 500°
F. RTV silicone into the gap
between sections.
500° F. RTV
Silicone
H
G
A
D
F
NOTE: Measure clearances to the nearest edge of the exhaust hood.
A
E
B
C
F
X
H
Install the vent at the clearance specified by the
vent manufacturer.

Installation (For Qualified Installers Only) 13
© Travis Industries 4/11/22- 1566 AGP Stove
Mobile Home Requirements
The stove must be vented using an approved listed pellet vent (sometimes referred to as “L” or “PL”
vent pipe).
The appliance, venting system, and hearth system (if applicable) must be installed in accordance with
the terms of their listing and their manufacturer’s instructions.
Outside Air Kit (sku# 99200139) must be used to duct combustion air directly into the appliance. The
kit is available through your dealer.
The stove must be secured to the floor of the manufactured home. Travis Industries manufactures a
kit (sku# 98900509) for securing the appliance. The kit is available through your dealer.
The appliance must be plugged into a properly grounded outlet.
DO NOT INSTALL IN SLEEPING ROOM.
THE STRUCTURAL INTEGRITY OF THE MANUFACTURED HOME FLOOR, WALL, AND
CEILING/ROOF MUST BE MAINTAINED.
Outside Air (Used for Combustion  Use Part #99200136)
Outside air is strongly recommended. The use of outside air reduces noise levels inside
the house and prevents smoke spillage into the home during power outages.
Must not be drawn from an enclosed space (garage, unventilated crawl space).
Must not be over 48” (1220mm) long
Must be made with 1-¾” (45mm) diameter or larger metal or aluminum duct with a metal screen
attached to the end to keep out rodents (P.V.C. or other combustible materials may not be used).
We recommend the Travis Industries Outside Air Kit (part # 99200136).
Must not terminate above or within 1' (305mm) of the chimney termination.
Must have a rain cap or down-turned elbow to prevent water from entering.
Must be located so that it will not become plugged by snow or other material.
1-3/4” Air Duct
A screen is required to prevent
animals from entering.
Outside air entrance must be placed so it
does not become blocked b
y
snow
.
Air may be drawn from a ventilated crawl space.
IDB1265

14 Installation (For Qualified Installers Only)
© Travis Industries 4/11/22- 1566 AGP Stove
Alcove Installation Requirements
When the pellet stove is placed in a location where the ceiling height is less than 7' (2.134 M) tall, it is
considered an alcove installation. Because of the reduced height, the requirements listed below must be
met.
Minimum height is 60"
Minimum width is 36-9/16"
Maximum depth is 48"
Minimum clearance of 6" on each side and 3" on back
Minimum clearance of 3” for horizontal venting
Minimum clearance of 2” from the pipe for vertical venting
Restrictor Adjustment
For installations with a tall flue, the restrictor may be needed to adjust airflow to the fire platform. This
keeps the fire platform and glass as clean as possible.
For low heat output settings, the restrictor may need to be closed or near closed to limit the amount of
air. This prevents the stove from burning the pellet fuel faster than it is fed.
For medium heat output settings, the restrictor may need to be opened to a medium position.
For high heat output settings, the restrictor will need to be opened to a high position. This prevents the
fire platform from over-filling with pellets and becoming clogged with ash clumps.
Keeping your fire platform clean is the most important step to maintaining a safe and efficient stove.
Check and clean your fire platform daily until you find the correct restrictor settings and appropriate fire
platform cleaning interval.
Not Enough Air
If clinkers (ashes that solidify into a clump)
develop or the flame appears lazy and slow
to blow the ash out of the fire platform,
push the restrictor in until the flame
becomes active and the fire platform holes
remain clean.
NOTE: If the restrictor is fully in, yet the fire
platform does not remain clean, the stove
needs to be cleaned and checked for air
leaks (see “Maintenance” section of this
manual).
Too Much Air
If the flames are too active (small, flickering
flames), move the restrictor rod out until
the flame slows down.
NOTE: It is acceptable to have “glowing
embers” jump out of the fire platform.
Another symptom of too much air is the
heater “blowing the fire out” – a condition in
which the pellets burn faster than they are
fed (this is most common on low heat
settings).
More Air
Less Air

Installation (For Qualified Installers Only) 15
© Travis Industries 4/11/22- 1566 AGP Stove
Installation Examples
Installation Example: Direct "Through-the-wall" Installation
NOTE: Travis Industries recommends a minimum vertical vent of 5’ to ensure adequate draft during a
power outage.
Install the vent at the clearance specified by the vent manufacturer.

16 Installation (For Qualified Installers Only)
© Travis Industries 4/11/22- 1566 AGP Stove
Installation Example: Interior Vertical Installation
* Install vent at clearance specified by the vent manufacturer.

Installation (For Qualified Installers Only) 17
© Travis Industries 4/11/22- 1566 AGP Stove
Installation Example: Class “A” Chimney Retrofit
* Install vent at clearance specified by the vent manufacturer.

18 Installation (For Qualified Installers Only)
© Travis Industries 4/11/22- 1566 AGP Stove
Installation Example: Masonry Fireplace Hearth Stove
“L” Vent Flex
Section
Outside air
may be
drawn from
the ash
cleanout. 6” Min.
“L” Vent
Storm Collar
Vertical Cap
Cover Plate (non-combustible)
Silicone
Seal the cover
plate with silicone.
NOTE: you may need a short horizontal section here to
clear the lintel and allow the hopper lid to open.
Lintel
Seal each vent
section (including
adapters, elbows,
etc...) by injecting a
liberal amount of
500° F. RTV
silicone into the gap
500°F.RTV
Silicone
Allow room for the
hopper lid to open
between sections,
unless otherwise
specified by the
manufacturer.

Installation (For Qualified Installers Only) 19
© Travis Industries 4/11/22- 1566 AGP Stove
Installation Example: Zero-Clearance (Metal) Fireplace Hearth Stove
“L” Vent Flex
Section
6” Min.
“L” Vent
Storm Collar
Vertical Cap Cover Plate (non-combustible)
Silicone
Seal the cover
plate with silicone.
NOTE: you may need a short horizontal section here to
clear the lintel and allow the hopper lid to open.
Allow room for the
hopper lid to open
Seal each vent
section (including
adapters, elbows,
etc...) by injecting a
liberal amount of
500° F. RTV
silicone into the gap
500°F.RTV
Silicone
between sections,
unless otherwise
specified by the
manufacturer.

20 Installation (For Qualified Installers Only)
© Travis Industries 4/11/22- 1566 AGP Stove
Installation Example: Freestanding Masonry Chimney
* Install vent at clearance specified by the vent manufacturer.
6” Min.
“L” Vent
Sections
“L” Vent
Storm Collar
Vertical Cap
Cover Plate (non-combustible)
Silicone
Seal the cover
plate with silicone.
Clean-Out Access
Seal each vent
section (including
adapters, elbows,
etc...) by injecting a
liberal amount of
500° F. RTV
silicone into the gap
500°F.RTV
Sili con e
“L” Vent Flex
Section
Vent
Clearance*
between sections,
unless otherwise
specified by the
manufacturer.
