Travis Industries Allegiance User manual

Featuring the Burner
• Direct Vent Freestanding Stove
• Natural Gas or Propane
• Vent Horizontally or Vertically
• Standard Residential
• Mobile Home Approved
Tested and Listed by
Omni-Test Laboratories, Inc.
Beaverton, Oregon
Report # 028 – S – 43 - 5
ANSIZ21.88
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installationand servicemustbeperformedbyaqualifiedinstaller,service agencyorthegassupplier.
Allegiance Owner's Manual
Installer: After installation give this manual to the home-owner and
explain operation of this heater.
Copyright 2005, T.I. $10.00 93508123 4041220 4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275

Introduction 1
Travis Industries 4041220 93508123
Introduction
We welcome you as a new owner of an Allegiance Stove. In purchasing this heater you have joined
the growing ranks of concerned individuals whose selection of an energy system reflects both a
concern for the environment and aesthetics. The Allegiance is one of the finest home heaters the
world over. This manual will explain the installation, operation, and maintenance of this gas-burning
heater. Please familiarize yourself with the Owner’s Manual before operating your heater and save the
manual for future reference. Included are helpful hints and suggestions which will make the
installation and operation of your new heater an easier and more enjoyable experience. We offer our
continual support and guidance to help you achieve the maximum benefit and enjoyment from your
heater.
Important Information
No other Allegiance has the same serial number as
yours. It can be found on the back of the heater.
This serial number will be needed in case you require
service of any type.
Model: Allegiance EF
Serial Number:
Purchase Date:
Purchased From:
Mail your Warranty Card
Today, and Save Your Bill of
Sale.
To receive full warranty coverage,
you will need to show evidence of
the date you purchased your
heater. Do not mail your Bill of
Sale to us.
We suggest that you attach your
Bill of Sale to this page so that you
will have all the information you
need in one place should the need
for service or information occur.

2Safety Precautions
Travis Industries 4041220 93508123
• IF YOU SMELL GAS:
* Do not light any appliance
* Extinguish any open flame
* Do not touch any electrical switch or plug or unplug anything
* Open windows and vacate building
* Call gas supplier from neighbor’s house, if not reached, call fire department
• This unit must be installed by a qualified installer to prevent the possibility of an
explosion. Your dealer will know the requirements in your area and can inform you of
those people considered qualified. The room heater should be inspected before use
and at least annually by a qualified service person. More frequent cleaning may be
required due to excessive lint from carpeting, bedding material, etc.
• The instructions in this manual must be strictly adhered to. Do not use makeshift
methods or compromise in the installation. Improper installation will void the warranty
and safety listing.
For LPG only | Pout 11” W.C.
Look for this label:
If the label is present, the
heater is equipped for LP
(propane). If the label is
absent, the heater is equipped
for NG (natural gas).
•This heater is either approved for natural
gas (NG) or propane (LP). Burning the
incorrect fuel will void the warranty and
safety listing and may cause an extreme
safety hazard. Check the label above
the gas control valve to make sure it
matches the fuel being used. Direct
questions about the type of fuel used to
your dealer.
Ok
•Contact your local building
officials to obtain a permit
and information on any
installation restrictions or
inspection requirements in
your area. Notify your
insurance company of this
heater as well.
•If the flame becomes sooty,
dark orange in color, or
extremely tall, do not
operate the heater. Call
your dealer and arrange for
proper servicing.
•It is imperative that control
compartments, screens, or
circulating air passageways
of the heater be kept clean
and free of obstructions.
These areas provide the air
necessary for safe
operation. ?•Do not operate the heater if
it is not operating properly in
any fashion or if you are
uncertain. Call your dealer
for a full explanation of your
heater and what to expect.
Gas
•Do not store or use gasoline
or other flammable liquids in
the vicinity of this heater.
AAAAA
AAAAA
AAAAA
AAAAA
AA
AA
•Do not operate if any portion
of the heater was
submerged in water or if any
corrosion occurs.

Safety Precautions 3
Travis Industries 4041220 93508123
•Do not place clothing or
other flammable items on or
near the heater. Because
this heater can be controlled
by a thermostat there is a
possibility of the heater
turning on and igniting any
items placed on or near it.
AA
AA
AA
AA
A
•Light the heater using the
built-in piezo igniter. Do not
use matches or any other
external device to light your
heater.
•Never remove, replace,
modify or substitute any part
of the heater unless
•The door (glass) should only
be opened while lighting the
pilot or conducting service.
Damaged glass must be
replaced.
•Any safety screen or guard
removed for servicing must
be replaced prior to
operating the heater.
instructions are given in this
manual. All other work must
be done by a trained
technician. Don’t modify or
replace orifices.
•Allow the heater to cool
before carrying out any
maintenance or cleaning.
•Operate the heater
according to the instructions
included in this manual.
•If the main burners do not
start correctly turn the gas
off at the gas control valve
and call your dealer for
service.
•The pilot flame must contact
the thermopile and
thermocouple (see the
illustration to the left). If it
does not, turn the gas
control valve to “OFF”and
call your dealer.
AA
AA
AA
AA
•This unit is not for use with
solid fuel
•Do not place anything inside
the firebox (except the
included fiber logs).
•If the fiber logs become
damaged, replace with
Travis Industries log set.
This
Manual
•Do not throw this manual
away. This manual has
important operating and
maintenance instructions
that you will need at a later
time. Always follow the
instructions in this manual.
•Do not touch the hot
surfaces of the heater.
Educate all children of the
danger of a high-
temperature heater. Young
children should be
supervised when they are in
the same room as the
heater.
•Plug the heater into a 120V
grounded electrical outlet.
Do not remove the
grounding plug.
•Don’t route the electrical
cord in front of, over, or
under the heater
•Instruct everyone in the
house how to shut gas off to
the appliance and at the gas
main shutoff valve. The gas
main shutoff valve is usually
next to the gas meter or
propane tank and requires a
wrench to shut off.
•Travis Industries, Inc.
grants no warranty,
implied or stated, for
the installation or
maintenance of your
heater, and assumes
no responsibility of any
consequential
damage(s).

4Table of Contents
Travis Industries 4041220 93508123
Introduction
Introduction......................................................1
Important Information .........................................1
Safety Precautions
Safety Precautions............................................2
Specifications
Installation Options............................................5
Features ..........................................................5
Heating Specifications........................................5
Dimensions.......................................................5
Electrical Specifications (for optional blower)...........5
Fuel.................................................................5
Installation
Installation Warnings..........................................6
Packing List......................................................6
Installation Preparation.......................................6
Stove Clearances ..............................................6
Mobile Home Requirements..................................6
Heater Placement Requirements...........................7
Floor Protection Requirements..............................7
Gas Line Installation...........................................7
Gas Inlet Pressure ........................................7
Vent Requirements.............................................8
Approved Vent Configurations..............................9
Restrictor Position.........................................9
Elbows........................................................9
Measuring Vent Lengths.................................9
Vertical Term’s with 0, 2, or 4 45°Elbows............10
Horizontal Terminations with 1 90°Elbow............11
Horizontal Term's with Two Elbows....................12
Horizontal Term's with Three 90°Elbows.............13
Vertical Term’s with Two 90°Elbows ..................14
Vertical Term’s with Three 90°Elbows................15
Horizontal Vent Termination Requirements..............16
Vertical Vent Termination Requirements .................16
Finalizing the Installation.....................................17
Opening the Door...............................................19
Log Set and Coal Installation................................20
Operation
Safety Notice....................................................21
Location of Controls ...........................................21
Starting the Pilot Flame .......................................22
Starting the Heater for the First Time......................23
Turning the Heater On and Off ..............................23
Adjusting the Flame Height...................................23
Adjusting the Blower Speed..................................24
Normal Operating Sounds....................................24
Normal Operating Odors......................................24
Maintenance
Cleaning Your Heater..........................................25
Yearly Service Procedure....................................25
Troubleshooting Steps........................................26
How this Heater Works........................................27
Wiring Diagram ..................................................28
Safety Label
Safety Label .....................................................29
Warranty
Warranty..........................................................30
Optional Equipment
LP Conversion Instructions..................................31
Blower .............................................................34
Gold Door.........................................................36
Gold Grill..........................................................37
Firebrick...........................................................37
Installation Addenda
Interior Masonry Chimney....................................38
Class A Chimney Retrofit.....................................39
Index
Index...............................................................40

Specifications 5
Travis Industries 4041220 93508123
Features:
- Ember Fyre™Burner for "Wood Fire" Look
- Works During Power Outages (millivolt system)
- High Efficiency
- Optional Thermostat or Remote Control
- Optional Blower for Quicker Heat Distribution
- Convenient Operating Controls
- Variable-Rate Heat Output
- Low Maintenance
Installation Options:
- Freestanding Stove
- Horizontal or Vertical Vent
- Residential or Mobile Home
- Straight or Corner Placement
- Bedroom Approved
Heating Specifications:
Approximate Heating Capacity (in square feet)*............500 - 1,500 with Blower, 500 to 1,200 Without
Maximum Input" (in BTU’s per hour)...........................................................31,000
Input Rate on "LO" (in BTU’s per hour)......................................................18,500 (LP) 23,000 (NG)
Steady State Efficiency............................................................................up to 86.5%
AFUE (without blower).............................................................................Up to 67.2%
•Heating capacity will vary depending on the home’s floor plan, degree of insulation, and the outside
temperature.
** Efficiency rating is a product of thermal efficiency rating determined under continuous operation independent
of installed system.
Dimensions:
28-5/8"
15-5/8"
22-1/8"
Weight: 165 Lbs.
4" from back edge of top
The starter
section is 1/2"
above the top.
Measure
Clearances to
the Stove Top
Electrical Specifications (for optional blower)
Electrical Rating.........................................................115 Volts, .8 Amps, 60 Hz (92 watts on high)
Fuel:
This heater is shipped in natural gas (NG) configuration but may be converted to propane (LP) using
the included LP conversion kit. The sticker on top of the gas control valve will verify the correct fuel.

6Installation (for qualified installers only)
Travis Industries 4041220 93508123
Installation Warnings
!Failure to follow all of the requirements may result in property damage, bodily injury, or even death.
!This heater must be installed by a qualified installer who has gone through a training program for the
installation of direct vent gas appliances.
!This appliance must be installed in accordance with all local codes, if any; if not, follow current ANSI
Z223.1 or NFPA 54 in the USA .
!In Manufactured or Mobile Homes this appliance must be installed to the applicable Mobile Home
Standards: CAN/CSA Z240 MH, the Manufactured Home Construction and Safety Standard, Title 24
CFR, Criteria for Manufactured Home Installations, Sites and Communities, and/or ANSI/NFPA 501A.
This appliance may be installed in Manufactured Housing only after the home is site located.
!This appliance is designed for natural gas or propane (LP). Check the sticker on top of the gas control
valve.
!All exhaust gases must be vented outside the structure of the living-area. Combustion air is drawn from
outside the living-area structure.
!Notify your insurance company before hooking up this appliance.
!The requirements below are divided into sections - all requirements must be met simultaneously.
Packing List
•Allegiance •Owner’s Manual •Log Set with Embers •Propane Conversion Kit
Installation Preparation
HINT: If converting to LP, convert the appliance prior to installation.
HINT: Install the logs last - they are fragile.
HINT: When determining the location of the stove, locate the wall studs (for horizontal penetrations)
and ceiling trusses (for vertical penetrations). You may wish to adjust the stove position
slightly to ensure the vent does not intersect with a framing member.
HINT: Fumes and smoke from the paint curing and oil burning off the steel may occur the first time
you start this heater. This is normal. We recommend you open windows to vent the room.
Stove Clearances
10"
Min.
5" Min.
With this clearance
the vent is 5-5/8”from
the back wall, 17-7/8”
from the side wall.
Straight
Installations Corner Installations
With this clearance, the vent
is 12-3/8”from the wall.
45°
5" Min.
Measure
Clearances to
the Stove Top
Measure
Clearances to
the Stove Top
Mobile Home Requirements
•When the stove is installed in a mobile home, it must be bolted to the floor and the
appliance grounded (use the optional blower with a grounded circuit or other suitable
grounding method - current ANSI/NFPA 70 or CSA C22.1).

Installation (for qualified installers only) 7
Travis Industries 4041220 93508123
Heater Placement Requirements
•Heater must be installed on a level surface capable of supporting the heater and vent
•Due to the high temperature of the heater, it should be located out of traffic and away from
furniture and draperies.
?When placed in a location where the floor to ceiling height is under 7 feet, the installation is
considered an alcove and must meet the following requirements:
•The alcove floor to ceiling height must be at least 58”tall
•The alcove must not be more than 45”deep before the ceiling returns to 7’
•The alcove must be at least 46-3/4”wide
•The heater must not be placed so the vents below or above the door, along the sides of heater, or
along the back of the heater can become blocked.
•This heater may be placed in a bedroom. Please be aware of the large amount of heat this
appliance produces when determining a location.
Floor Protection Requirements
•When the stove is installed directly on carpeting, vinyl or other combustible material other than
wood flooring or a high pressure laminate wood floor, the stove must be installed on a metal or
wood protection panel extending the full width and depth of the heater (Minimum 22-1/8”wide by
15-5/8”deep).
Gas Line Installation
!The gas line must be installed in accordance with all local codes, if any; if not, follow current ANSI
Z223.1 or NFPA 54.
!The heater and gas control valve must be disconnected from the gas
supply piping during any pressure testing of that system at test
pressures in excess of 1/2 psig (3.45 kPA). For pressures under 1/2
psig (3.45 kPA), isolate the gas supply piping by closing the manual
shutoff valve.
•This heater is designed for natural gas but can be converted to propane.
Check sticker on top of gas control valve to verify correct fuel.
•Leak test all gas line joints and the gas control valve prior to and after
starting the heater.
•The gas inlet accepts a 3/8”F.P.T. Fitting
•The location of the gas inlet is shown below
•A manual shutoff valve is required for installation (it must be located
within 3’of the heater). T-Handle gas cocks are required in
Massachusetts in compliance with code 248CMR.
•Installation must be performed by a qualified installer, service agency or
the gas supplier (In Massachusetts a licensed plumber/gasfitter).
Gas Inlet Pressure
AA
AA
A
A
AA
AA
A
A
6-1/8"
1/4"
2-7/8"
•With the heater off, the inlet pressure must meet the requirements listed in the table below
?If the pressure is not sufficient, make sure the piping used is large enough and the total gas load
for the residence does not exceed the amount supplied.
?The supply regulator (the regulator that attaches directly to the residence inlet or to the propane
tank) should supply gas at the suggested input pressure listed below. Contact the local gas
supplier if the regulator is at an improper pressure.
Standard Input Pressure
Natural Gas 7”W.C. (1.74 Kpa)
Propane 13”W.C. (2.73 Kpa)

8Installation (for qualified installers only)
Travis Industries 4041220 93508123
Vent Requirements
!Always maintain the required 1”(25 mm) clearance (air space) to combustible materials to prevent a fire
hazard. Do not fill air spaces with insulation.
!The gas appliance and vent system must be vented directly to the outside of the building, and never
be attached to a chimney serving a separate solid fuel or gas-burning appliance. Each direct vent gas
appliance must use it’s own separate vent system.
Altitude Considerations
This heater has been tested at altitudes
ranging from sea level to 8,000 feet
(2,400 M). In this testing we have found
that the heater, with its standard orifice,
burns correctly with just an air shutter
adjustment.
!Failure to adjust the air shutter properly
may lead to improper combustion which
can create a safety hazard. Consult your
dealer or installer if you suspect an
improperly adjusted air shutter.
•When the vent passes through a wall,
a wall thimble is required. When the
vent passes through a ceiling, a
support box or firestop is required.
When the vent passes through the
roof, a roof flashing and storm collar
are required. Follow the instructions
provided with the vent for installing
these items.
Use a firestop spacer whenever
passing through a ceiling
(Duravent Part #963)
Vertical Termination
(Duravent Part # 991)
Use a roof flashing and storm collar
whenever passing through the roof
(Duravent Part #953 & #943 or #943S)
8-5/8"
(220 mm)
Use a support box
on exposed vent
Vertical Vent
Requirements
Use a wall thimble
whenever passing
through a wall
(Duravent Part #942)
Horizontal Termination
(Duravent Part #984)
Maintain a minimum 1" (25 mm)
clearance from vent to any combustible
(vent is 6 5/8" (170 mm) diameter)
Minimum
Framing for
wall thimble
Horizontal Vent
Requirements
Minimum framing
for fire stop
8-5/8"
(220 mm)
Maintain a minimum 1"
(25 mm) clearance from
vent to any combustible
(vent is 6 5/8" (170 mm)
diameter)
•Use of of the following 6-5/8" diameter co-axial gas direct vent systems:
Manuafacturer Series
Simpson Dura-Vent Model GS
Selkirk Hearth Products Direct-Temp
American Metal Products Ameri-Vent
NOTE: Always use the high-wind cap for the type of vent you are using (if applicable)
•Slide the vent sections together and turn 1/4 turn until the sections lock in place.
•Screws are not required to secure the vent. However, three screws may be used to secure
vent sections together if desired.
•High temperature sealant is recommended at the appliance starter section connection (use
high-temperature silicone or Mill-Pac®).
•If disassembly is required, at time of re-assembly check to see if the vent creates a tight fit. If
it does not, apply high temperature sealant to the joints of the affected sections.
•Horizontal sections require a 1/4" rise every 12" of travel
•Horizontal sections require non-combustible support every three feet (e.g.: plumbing tape)

Installation (for qualified installers only) 9
Travis Industries 4041220 93508123
Approved Vent Configurations
Restrictor Position
•A vent restrictor is built
into the appliance to
control the flow rate of
exhaust gases. This
ensures proper flames
for the wide variety of
vent configurations. The
restrictor consists of a
butterfly valve in the air
inlet and an adjustment
plate with index holes
used to hold the valve in
a fixed position.
Depending upon the
vent configuration, you
may be required to adjust
the restrictor position.
The charts for approved
vent configurations
describe which position
the vent restrictor must
be in.
Loosen the four screws
holding the stove top in
place.
a
b
Lift the stove top off the top. If
the vent is attached, you may
prop the stove top with wood
to allow access to the
restrictor.
To Adjust the Restrictor
To Access the Restrictor
Slide the restrictor
adjustment rod in.
b
Replace the cotter pin through
the correct hole on the restrictor
adjustment rod.
c
This restrictor is
in position # 6
NOTE:
The restrictor is
shipped in
position #1.
Lift the cotter pin out.
a
Restrictor
Positions
# 2
# 4
# 6
# 3
# 5
# 1
AAAA
AAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAAAAAAA
AAA
AAAAAAA
AAAAAAA
AAAAAAA
AAAAAAA
1/4" Nutdriver
Elbows
•3 Elbow
maximum
(or four 45°
elbows)
Measuring
Vent Lengths
Vent Horizontal Run
(measure from the closest
edge of the starter section to
the end of the termination)
Vent Height is
calculated to the top of
the vent on horizontal
terminations and to the
top of the termination on
vertical terminations.
Vent
Height
The starter
section is 1/2"
above the top

10 Installation (for qualified installers only)
Travis Industries 4041220 93508123
Approved Venting Configurations for Vertical Terminations with
Zero, Two, or Four 45° Elbows
•10’Minimum System
Height
(with or without offsets)
•40’Maximum System
Height
•24’Maximum Offset
•The termination must fall
within the shaded area
shown in the chart. Use
the indicated restrictor
position.
•If using offsets, use the
table below to calculate the
vertical rise and horizontal
offset
Offset
Length
Horizontal
Offset
Vertical
Rise
Offset Length Hor. Offset Vert. Rise
None 5”1’
1’Section 1’1’7”
2’Section 1’9”2’4”
3’Section 2’5”3’
4’Section 3’2”3’8”
4’+ 1’Section 3’9”4’4”
4’+ 2’Section 4’6”5’
4’+ 3’Section 5’2”5’9”
4’+ 4’Section 6’6’9”
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAA
5 feet
10 feet
15 feet
20 feet
25 feet
30 feet
0 feet
40' (max)
5 feet
0 feet
0 feet
5 feet
10 feet
15 feet
20 feet
25 feet
30 feet
40' (max)
Restrictor
Position # 5
NOTE:
Restrictor positions are based
upon lab tests. The ideal
restrictor position may vary
slightly, especially when the
termination is near a
demarkation line.
Restrictor
Position # 6
10 feet
15 feet
20 feet
24 ' (max)
0 feet
5 feet
10 feet
15 feet
20 feet
24 ' (max)
35 feet35 feet

Installation (for qualified installers only) 11
Travis Industries 4041220 93508123
Approved Venting Configurations with a Horizontal Termination
and One 90° Elbow
•If using a Snorkel Termination (14”or 36”) add the snorkel height to the vertical height (snorkel
terminations are used primarily for basement installations).
•The termination must fall within the shaded area shown in the chart. Use the indicated restrictor
position.
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
5 feet
10 feet
15 feet
19' (max)
0 feet
5 feet
0 feet
0 feet
5 feet
10 feet
15 feet
Restrictor Position # 5
NOTE:
Restrictor positions are based
upon lab tests. The ideal
restrictor position may vary
slightly, especially when the
termination is near a
demarkation line.
Restrictor
Position # 1
10 feet
15 feet
20 feet
24 ' (max)
0 feet
5 feet
10 feet
15 feet
20 feet
24 ' (max)
19' (max)
NOTE:
Horizontal sections require a 1/4"
rise every 12" of travel.
NATURAL GAS: Min. 2' Section Required
PROPANE (LP): Min. 3' Section Required

12 Installation (for qualified installers only)
Travis Industries 4041220 93508123
Approved Venting Configurations with a Horizontal Termination
and Two Elbows (one 90° vertical and one 90° or 45° horizontal elbow)
•If using a Snorkel Termination (14”or 36”) add the snorkel height to the vertical height (snorkel
terminations are used primarily for basement installations).
•The termination must fall within the shaded area shown in the chart. Use the indicated restrictor
position.
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
5 feet
10' (min)
15 feet
19' (max)
0 feet
5 feet
0 feet
0 feet
5 feet
10' (min)
15 feet
Restrictor
Position # 5
NOTE:
Restrictor positions are based upon lab
tests. The ideal restrictor position may vary
slightly, especially when the termination is
near a demarkation line.
Restrictor
Position # 1
10 feet
15 feet
20 feet
24 ' (max)
0 feet
5 feet
10 feet
15 feet
20 feet
24 ' (max)
19' (max)
NOTE:
Horizontal sections require a 1/4"
rise every 12" of travel.
This is considered a horizontal
elbow (it does not matter
whether it turns right or left).
It may be a 90°or 45°elbow.
This is considered a
vertical elbows
Horizontal length (max. 24') is calculated
by adding both lengths of horizontal run
(Horizontal Length = H1 + H2).
H1
H2
NATURAL GAS: Min. 2' Section Required
PROPANE (LP): Min. 3' Section Required

Installation (for qualified installers only) 13
Travis Industries 4041220 93508123
Approved Venting Configurations with a Horizontal Termination
and Three 90° Elbows (all vertical)
•If using a Snorkel Termination (14”or 36”) add the snorkel height to the vertical height (snorkel
terminations are used primarily for basement installations).
•The termination must fall within the shaded area shown in the chart. Use the indicated restrictor
position.
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAAA
5 feet
10' (min)
15 feet
21' (max)
0 feet
5 feet
0 feet
0 feet
5 feet
10' (min)
15 feet
Restrictor
Position # 5
NOTE:
Restrictor positions are based
upon lab tests. The ideal restrictor
position may vary slightly,
especially when the termination is
near a demarkation line.
Restrictor
Position # 1
10 feet
15 feet
20 feet
24 ' (max)
0 feet
5 feet
10 feet
15 feet
20 feet
24 ' (max)
21' (max)
NOTE:
Horizontal sections require a 1/4"
rise every 12" of travel.
This is a horizontal elbow -
NOT ALLOWED FOR THIS
VENT CONFIGURATION
These are
vertical elbows.

14 Installation (for qualified installers only)
Travis Industries 4041220 93508123
Approved Venting Configurations for Vertical Terminations with
Two 90° Elbows
•The termination must fall within the shaded area shown in the chart. Use the indicated restrictor
position.
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
5 feet
10' (min)
15 feet
20 feet
25 feet
30 feet
0 feet
40' (max)
5 feet
0 feet
0 feet
5 feet
10' (min)
15 feet
20 feet
25 feet
30 feet
40' (max)
Restrictor
Position # 5
NOTE:
Restrictor positions are
based upon lab tests. The
ideal restrictor position may
vary slightly, especially
when the termination is near
a demarkation line.
Restrictor
Position # 6
10 feet
15 feet
20 feet
24 ' (max)
0 feet
5 feet
10 feet
15 feet
20 feet
24 ' (max)
35 feet35 feet
Restrictor
Position # 1
NOTE:
Horizontal sections require a 1/4"
rise every 12" of travel.
This is a horizontal elbow -
NOT ALLOWED FOR THIS
VENT CONFIGURATION
These are
vertical elbows.

Installation (for qualified installers only) 15
Travis Industries 4041220 93508123
Approved Venting Configurations for Vertical Terminations with
Three 90° Elbows (Two 90° Vertical and One 45° or 90° Horizontal Elbow)
•The termination must fall within the shaded area shown in the chart. Use the indicated restrictor
position.
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAA
5 feet
10' (min)
15 feet
20 feet
25 feet
30 feet
0 feet
40' (max)
5 feet
0 feet
0 feet
5 feet
10' (min)
15 feet
20 feet
25 feet
30 feet
40' (max)
Restrictor
Position # 5
NOTE:
Restrictor positions are based
upon lab tests. The ideal
restrictor position may vary
slightly, especially when the
termination is near a demarkation
line.
10 feet
15 feet
20 feet
24 ' (max)
0 feet
5 feet
10 feet
15 feet
20 feet
24 ' (max)
35 feet35 feet
Restrictor
Position # 1
NOTE:
Horizontal sections require a
1/4" rise every 12" of travel.
This is considered a horizontal
elbow (it does not matter
whether it turns right or left).
It may be a 45°or 90°elbow.
This is considered a
vertical elbow
Horizontal length (max. 24') is calculated
by adding both lengths of horizontal run
(Horizontal Length = H1 + H2).
H1
H2 This is considered a
vertical elbow

16 Installation (for qualified installers only)
Travis Industries 4041220 93508123
Vent Termination Requirements (see illustration below)
! Venting terminals shall not be recessed into a wall or siding.
A Minimum 9" clearance from any door or window
B Minimum 12" above any grade, veranda, porch, deck or balcony
C Minimum 12" from outside corner walls
D Minimum 12" from inside corner walls
E Minimum 11" clearance below unventilated soffits or roof surfaces
Minimum 18" clearance below ventilated soffits
Minimum 6" clearance from roof eaves
NOTE: Vinyl surfaces require 24"
11”Min.
6”Min.
Roof
Surface
Roof
Eaves
F Minimum 18" clearance below a veranda, porch, deck or balcony (must have two open sides)
G Minimum 48" clearance from any adjacent building
H Minimum 84" clearance above any grade when adjacent to public walkways or driveways
NOTE: may not be used over a walkway or driveway shared by an adjacent building
I Minimum 48" clearance from any mechanical air supply inlet.
J Minimum 36" clearance above and 48”below and to the sides of non-mechanical air supply inlet
K Minimum 36" from the area above the meter/regulator (vent outlet)
L Minimum 36" from the meter/regulator (vent outlet)
M Minimum 12”above the roof line (for vertical terminations)
N Minimum 24”horizontal clearance to any surface (such as an exterior wall) –for vertical terminations
C
B
H
E
GA
D
F
L
KJ
I
NOTE: Measure clearances to the nearest edge of the exhaust hood.
A
E
E
M
N
•Use the vinyl siding standoff (#1250) when installing on an exterior with vinyl siding.
•Vent termination must not be located where it will become plugged by snow or other material
•These clearances meet UMC-1994 and the CNA/CGA-B149 code standards.

Installation (for qualified installers only) 17
Travis Industries 4041220 93508123
Finalizing the Installation
!Turn the gas control valve to “OFF”prior to conducting any service.
1Open the door (see page 16)
2Install the log set and coals (see page 17).
!We recommend you purge the gas line at this time (with the door open). This allows gas to be
detected once it enters the firebox, ensuring gas does not build up.
3Close and secure the door (see page 16)
4Turn on gas to the heater. Leak test all gas joints prior to starting the appliance. Start the pilot. Start
the main burner. Leak test all gas joints again.
5Check the pilot flame to make sure it looks like the illustration to the below. Adjust the pilot flame if
necessary.
Standard
Screwdriver
The pilot flame must contact the thermocouple and
thermopile (see the illustration below). Adjust the pilot up or
down as necessary.
To adjust the pilot flame, turn this screw (NOTE: if totally
unscrewed gas will come out of this port). Clockwise
lowers the flame while counter-clockwise raises it.
6Let the heater burn for thirty minutes. Adjust the air shutter, if necessary, to achieve the correct
looking flame (see the illustration to on the following page).
•The air shutter adjusts the amount of air that mixes with the gas before it exits the burner holes. It is
used to fine-tune the flame for differences in altitude and vent configuration.
!If the air shutter is in its fully open position, yet the flames remain sooty, shut off gas to the heater and
contact your dealer for a remedy.
NOTE: If the air shutter is all the way
open, yet the flames remain sooty, shut
off gas to the fireplace and contact a
qualified gas service technician.
Correct
Flames should be blue at the
base, yellow-orange on the top.
If the flames are over 14" tall or sooty on
the ends, open the air shutter.
Not Enough Air If the flames are all blue and
short, close the air shutter.
Too Much Air
NOTE: The logs must be installed correctly to
monitor the flame while adjusting the air shutter.
Air Shutter Control
Pushing to the right gives the flame less air
(making it more orange). Pushing to the
left gives the flame more air, making it
more blue. For fine adjustments use a
screwdriver to tap the air shutter.
ADJUSTING THE AIR SHUTTER

18 Installation (for qualified installers only)
Travis Industries 4041220 93508123
!If the vent configuration is installed incorrectly the vent may cause the flames inside the heater to lift or
“ghost”–a dangerous situation. Inspect the flames after installation to insure proper performance. If
the vent configuration is correct, yet the flames are lifting or ghosting, shut off gas to the heater and
contact the dealer for information on remedying the problem.
The flames should burn right off
the top of the burner ports (if they
are too blue, adjust the air control).
If the flames are lifting, yet the
vent configuration is correct,
contact your dealer.
Burner Pan Burner Ports
(holes)
If the flames are ghosting, yet the
vent configuration is correct,
contact your dealer.
7Turn the flame adjust knob to its highest position - the flames should be a maximum 9”to 10”tall.
Check the flame on low position. The flames should burn off of each burner hole. If the heater does
not work correctly, contact your dealer for a remedy.
8 Give this manual to the home owner and fully explain the operation of this heater.
