Travis Industries Avalon User manual

Featuring the Burner
• Direct Vent Freestanding Stove
• Natural Gas or Propane
• Vent Horizontally or Vertically
• Standard Residential
• Mobile Home Approved
Tested and Listed by
Omni-Test Laboratories, Inc.
Beaverton, Oregon
Report # 028–S–14-1
ANSIZ21.88,CSA2.33M98,CAN/CGA2.17-M91
WARNING: If the information in these instructions is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service mustbe performed by a qualified installer,service agency or the gas
supplier.
This appliance may be installed as an OEM installation in a manufactured (mobile) home and
must be installed in accordance with the manufacturer’s instructions and the manufactured
home construction and safety standard, Title 24 CFR, Part 3280 or Standard for Installation in
Mobile Homes, CAN/CSA Z240 MH.
This appliance is only for use with the type(s) of gas indicated on the rating plate. A conversion
kit is supplied with the appliance.
SalishOwner’s Manual
Installer: After installation give this manual to the home-
owner and explain operation of this stove.
$10.00 Copyright 2000, T.I. Part # 93508122
10850 117th Place N.E. Kirkland, WA 98033

Introduction 1
Travis Industries 93508122 141100
Introduction
We welcome you as a new owner of a Salish Stove (DVL FS). In purchasing this heater you have
joined the growing ranks of concerned individuals whose selection of an energy system reflects both
a concern for the environment and aesthetics. The Salish is one of the finest home heaters the world
over. This manual will explain the installation, operation, and maintenance of this gas-burning heater.
Please familiarize yourself with the Owner’s Manual before operating your heater and save the manual
for future reference. Included are helpful hints and suggestions which will make the installation and
operation of your new heater an easier and more enjoyable experience. We offer our continual
support and guidance to help you achieve the maximum benefit and enjoyment from your heater.
Important Information
No other Salish 2000 has the same serial number as
yours. It can be found inside the right side panel.
This serial number will be needed in case you require
service of any type.
Model: Salish 2000
Serial Number:
Purchase Date:
Purchased From:
Mail your Warranty Card
Today, and Save Your Bill of
Sale.
To receive full warranty coverage,
you will need to show evidence of
the date you purchased your
heater. Do not mail your Bill of
Sale to us.
We suggest that you attach your
Bill of Sale to this page so that you
will have all the information you
need in one place should the need
for service or information occur.

2Safety Precautions
Travis Industries 93508122 141100
• IF YOU SMELL GAS:
* Do not light any appliance
* Extinguish any open flame
* Do not touch any electrical switch or plug or unplug anything
* Open windows and vacate building
* Call gas supplier from neighbor’s house, if not reached, call fire department
• This unit must be installed by a qualified installer to prevent the possibility of an
explosion. Your dealer will know the requirements in your area and can inform you of
those people considered qualified. The room heater should be inspected before use
and at least annually by a qualified service person. More frequent cleaning may be
required due to excessive lint from carpeting, bedding material, etc.
• The instructions in this manual must be strictly adhered to. Do not use makeshift
methods or compromise in the installation. Improper installation will void the warranty
and safety listing.
For LPG only | Pout 11” W.C.
Look for this label:
If the label is present, the
heater is equipped for LP
(propane). If the label is
absent, the heater is equipped
for NG (natural gas).
•This heater is either approved for
natural gas (NG) or propane (LP).
Burning the incorrect fuel will void the
warranty and safety listing and may
cause an extreme safety hazard.
Check the label above the gas control
valve to make sure it matches the fuel
being used. Direct questions about
the type of fuel used to your dealer.
Ok
•Contact your local building
officials to obtain a permit
and information on any
installation restrictions or
inspection requirements in
your area. Notify your
insurance company of this
heater as well.
•If the flame becomes sooty,
dark orange in color, or
extremely tall, do not
operate the heater. Call
your dealer and arrange for
proper servicing.
•It is imperative that control
compartments, screens, or
circulating air passageways
of the heater be kept clean
and free of obstructions.
These areas provide the air
necessary for safe
operation. ?•Do not operate the heater if
it is not operating properly in
any fashion or if you are
uncertain. Call your dealer
for a full explanation of your
heater and what to expect.
Gas
•Do not store or use gasoline
or other flammable liquids in
the vicinity of this heater.
•Keep all furniture or other
combustible items at least
36”away from the front of
the heater.
AAAA
AAAA
AAAA
AAAA
A
•Do not operate if any portion
of the heater was
submerged in water or if any
corrosion occurs.

Safety Precautions 3
Travis Industries 93508122 141100
•Do not place clothing or
other flammable items on or
near the heater. Because
this heater can be controlled
by a thermostat there is a
possibility of the heater
turning on and igniting any
items placed on or near it.
AA
AA
AA
AA
A
•Light the heater using the
built-in piezo igniter. Do not
use matches or any other
external device to light your
heater.
•Never remove, replace,
modify or substitute any part
of the heater unless
instructions are given in this
•The door (glass) should only
be opened while lighting the
pilot or conducting service.
Damaged glass must be
replaced.
•Any safety screen or guard
removed for servicing must
be replaced prior to
operating the heater.
manual. All other work must
be done by a trained
technician. Don’t modify or
replace orifices.
•Allow the heater to cool
before carrying out any
maintenance or cleaning.
•Operate the heater
according to the instructions
included in this manual.
•If the main burners do not
start correctly turn the gas
off at the gas control valve
and call your dealer for
service.
•The pilot flame must contact
the thermopile and
thermocouple (see the
illustration to the left). If it
does not, turn the gas
control valve to “OFF”and
call your dealer.
A
A
•This unit is not for use with
solid fuel
•Do not place anything inside
the firebox (except the
included fiber logs).
•If the fiber logs become
damaged, replace with
Travis Industries log set.
This
Manual
•Do not throw this manual
away. This manual has
important operating and
maintenance instructions
that you will need at a later
time. Always follow the
instructions in this manual.
•Do not touch the hot
surfaces of the heater.
Educate all children of the
danger of a high-
temperature heater. Young
children should be
supervised when they are in
the same room as the
heater.
•Plug the heater into a 120V
grounded electrical outlet.
Do not remove the
grounding plug.
•Don’t route the electrical
cord in front of, over, or
under the heater
•Instruct everyone in the
house how to shut gas off to
the appliance and at the gas
main shutoff valve. The gas
main shutoff valve is usually
next to the gas meter or
propane tank and requires a
wrench to shut off.
•Travis Industries, Inc.
grants no warranty,
implied or stated, for
the installation or
maintenance of your
heater, and assumes
no responsibility of any
consequential
damage(s).

4Table of Contents
Travis Industries 93508122 141100
Introduction
Introduction......................................................1
Important Information .........................................1
Safety Precautions
Safety Precautions............................................2
Specifications
Installation Options............................................5
Features ..........................................................5
Heating Specifications........................................5
Dimensions.......................................................5
Electrical Specifications......................................5
Fuel.................................................................5
Installation
Installation Warnings..........................................6
Packing List......................................................6
Installation Preparation.......................................6
Stove Clearances ..............................................6
Mobile Home Requirements..................................6
Heater Placement Requirements...........................7
Floor Protection Requirements..............................7
Gas Line Installation...........................................7
Gas Inlet Pressure ........................................7
Vent Requirements.............................................8
Altitude Considerations ..................................8
Approved Vent Configurations..............................9
Restrictor Position.........................................9
Elbows........................................................9
Measuring Vent Lengths.................................9
Vertical Term’s with (or without) 2 45°Elbows ......10
Horizontal Terminations..................................11
Vertical Term’s with Two 90°Elbows ..................12
Termination Requirements ...................................13
Finalizing the Installation.....................................14
Opening the Door...............................................16
Log Set and Coal Installation................................17
Operation
Safety Notice....................................................20
Location of Controls ...........................................20
Starting the Pilot Flame .......................................21
Starting the Heater for the First Time......................22
Turning the Heater On and Off ..............................22
Adjusting the Flame Height...................................22
Adjusting the Blower Speed..................................23
Normal Operating Sounds....................................23
Maintenance
Cleaning Your Heater..........................................24
Yearly Service Procedure....................................24
Troubleshooting Steps........................................25
How this Heater Works........................................26
Wiring Diagram ..................................................27
Replacement Parts.............................................27
Safety Label
Safety Label .....................................................28
Warranty
Warranty..........................................................29
Optional Equipment & Addenda
LP Conversion Instructions..................................30
Fireback...........................................................33
Wall Thermostat.................................................34
Remote Thermostat............................................35
Gold Door.........................................................35
Gold Grill..........................................................35
Gold Trivet........................................................36
Installation Addenda
Class A Chimney Conversion Kit ...........................37
Interior Masonry Chimney Conversions ..................37
Index
Index...............................................................38

Specifications 5
Travis Industries 93508122 141100
Installation Options:
•Freestanding Stove
•Residential or Mobile Home
•Horizontal or Vertical Vent
Features:
•Ember Fyre ™Burner for "Wood Fire" Look
•Works During Power Outages
•Optional Thermostat or Remote Control
•Variable-Rate Heat Output
•Blower Standard
Heating Specifications:
Approximate Heating Capacity (in square feet)*......1,200 to 2,000 With Blower, 800 to 1,600 Without
Maximum BTU Input Per Hour...............................43,000 (NG & LP)
Minimum BTU Output on Low (with blowers on).....23,384 (NG) 20,800 (LP)
Steady State Efficiency............................................................................up to 78% (NG), 81% (LP)
AFUE......................................................................................................71% (NG), 73.7% (LP)
* Heating capacity will vary depending on the home’s floor plan, degree of insulation, and the outside
temperature.
** Efficiency rating is a product of thermal efficiency rating determined under continuous operation independent
of installed system. To measure the net BTU’s, multiply the BTU input by the efficiency percentage.
Dimensions:
Fuel:
This heater is shipped in
natural gas (NG)
configuration but may be
converted to propane (LP)
using the included LP
conversion kit. The sticker
on top of the gas control
valve will verify the correct
fuel.
8"
Weight: 240 Lbs
Measure
Clearances
from the
Stove Top
The starter section is 1/4"
above the top.
28"
33"
21-1/2"
Electrical Specifications
Electrical Rating.........................................................115 Volts, 0.8 Amps, 60 Hz (92 watts on high)

6Installation(for qualified installers only)
Travis Industries 93508122 141100
Installation Warnings
!Failure to follow all of the requirements may result in property damage, bodily injury, or even death.
!This heater must be installed by a qualified installer who has gone through a training program for the
installation of direct vent gas appliances.
!This appliance must be installed in accordance with all local codes, if any; if not, follow current ANSI
Z223.1 or NFPA 54 in the USA or the current CGA B149 in Canada.
!In Manufactured or Mobile Homes this appliance must be installed to the applicable Mobile Home
Standards: CAN/CSA Z240 MH, the Manufactured Home Construction and Safety Standard, Title 24
CFR, Criteria for Manufactured Home Installations, Sites and Communities, and/or ANSI/NFPA 501A.
This appliance may be installed in Manufactured Housing only after the home is site located.
!This appliance is designed for natural gas or propane (LP). Check the sticker on top of the gas control
valve.
!All exhaust gases must be vented outside the structure of the living-area. Combustion air is drawn from
outside the living-area structure.
!Notify your insurance company before hooking up this appliance.
!The requirements below are divided into sections - all requirements must be met simultaneously.
Packing List
•Log Set with Coals •Log Pins •Propane Conversion Kit •Latch Tool
Installation Preparation
HINT: If converting to LP, convert the appliance prior to installation.
HINT: Install the logs last - they are fragile.
HINT: When determining the location of the stove, locate the wall studs (for horizontal penetrations)
and ceiling trusses (for vertical penetrations). You may wish to adjust the stove position
slightly to ensure the vent does not intersect with a framing member.
HINT: Fumes and smoke from the paint curing and oil burning off the steel may occur the first time
you start this heater. This is normal. We recommend you open windows to vent the room.
Stove Clearances
10" Min.
4" Min.
With this clearance the
vent is 9" from the
back wall, 20-1/2" from
the side wall.
Straight Installations Corner Installations
With this clearance, the vent
is 12" from the wall.
45°
4" Min.
Mobile Home Requirements
•When the stove is installed in a mobile home, it must be bolted to the floor and the
appliance grounded (use the blower with a grounded circuit or other suitable grounding
method - current ANSI/NFPA 70 or CSA C22.1).

Installation(for qualified installers only) 7
Travis Industries 93508122 141100
Heater Placement Requirements
•Heater must be installed on a level surface capable of supporting the heater and vent
•Due to the high temperature of the heater, it should be located out of traffic and away from
furniture and draperies. Heater must be placed so no combustibles are within, or can swing within
36”of the front of the heater (e.g. drapes, doors)
?When placed in a location where the floor to ceiling height is under 7 feet, the installation is
considered an alcove and must meet the following requirements:
•The alcove floor to ceiling height must be at least 60”tall
•The alcove must not be more than 48”deep before the ceiling returns to 7’
•The alcove must be at least 48”wide
•The heater must not be placed so the vents below or above the door, along the sides of heater, or
along the back of the heater can become blocked.
•This heater may be placed in a bedroom. Please be aware of the large amount of heat this
appliance produces when determining a location.
Floor Protection Requirements
•When the stove is installed directly on carpeting, vinyl or other combustible material other than
wood flooring or a high pressure laminate wood floor, the stove must be installed on a metal or
wood protection panel extending the full width and depth of the heater (Minimum 27-3/8”wide by
20-3/8”deep).
Gas Line Installation
!The gas line must be installed in accordance with all local codes, if any; if not, follow current ANSI
Z223.1 or NFPA 54 in the USA and the current CGA B149 in Canada.
!The heater and gas control valve must be disconnected from the gas supply piping during any
pressure testing of that system at test pressures in excess of 1/2 psig (3.45 kPA). For pressures
under 1/2 psig (3.45 kPA), isolate the gas supply piping by closing the manual shutoff valve.
•This heater is designed for natural gas but can be converted to
propane. Check the sticker on the top of the gas control valve
to make sure the correct fuel is used.
•Leak test all gas line joints and the gas control valve prior to and
after starting the heater.
•The gas inlet accepts a 3/8”F.P.T. Fitting
•The location of the gas inlet is shown below
•A manual shutoff valve is required for installation (it must be
located within 3’of the heater). T-Handle gas cocks are required
in Massachusetts in compliance with code 248CMR.
•Installation must be performed by a qualified installer, service
agency or the gas supplier (In Massachusetts a licensed
plumber/gasfitter).
Gas Inlet Pressure
AA
18-3/8"
9-3/8”
Center
of
Heater From
Front of
Heater
3”
•With the heater off, the inlet pressure must meet the requirements listed in the table below
?If the pressure is not sufficient, make sure the piping used is large enough and the total gas load
for the residence does not exceed the amount supplied.
?The supply regulator (the regulator that attaches directly to the residence inlet or to the propane
tank) should supply gas at the suggested input pressure listed below. Contact the local gas
supplier if the regulator is at an improper pressure.
Standard Input Pressure
Natural Gas 7”W.C. (1.74 Kpa)
Propane 13”W.C. (3.23 Kpa)

8Installation(for qualified installers only)
Travis Industries 93508122 141100
Vent Requirements
!Always maintain the required 1”clearance (air space) to combustible materials to prevent a fire hazard.
Do not fill air spaces with insulation.
!The gas appliance and vent system must be vented directly to the outside of the building, and never
be attached to a chimney serving a separate solid fuel or gas-burning appliance. Each direct vent gas
appliance must use it’s own separate vent system.
•This appliance is equipped only for
altitudes 0-2000 feet. However, our
in-house testing has shown that the
unit operated at altitudes to 8000 ft.
!Failure to adjust the air shutter
properly may lead to improper
combustion which can create a safety
hazard. Consult your dealer or
installer if you suspect an improperly
adjusted air shutter.
•When the vent passes through a wall,
a wall thimble is required. When the
vent passes through a ceiling, a
support box or firestop is required.
When the vent passes through the
roof, a roof flashing and storm collar
are required. Follow the instructions
provided with the vent (from
Duravent®) for installing these items.
Use a firestop spacer whenever
passing through a ceiling
(Duravent Part #963)
Vertical Termination
(Duravent Part # 991)
Use a roof flashing and storm collar
whenever passing through the roof
(Duravent Part #953 & #943 or #943S)
8-5/8"
Use a support box
on exposed vent
Vertical Vent
Requirements
Use a wall thimble
whenever passing
through a wall
(Duravent Part #942)
Horizontal Termination
(Duravent Part #984)
Maintain a minimum 1" clearance
from vent to any combustible
(vent is 6 5/8" diameter)
Minimum
Framing for
wall thimble
Horizontal Vent
Requirements
Minimum framing
for fire stop
8-5/8"
Maintain a minimum 1"
clearance from vent to
any combustible (vent
is 6 5/8" diameter)
•Use Model GS Direct Vent manufactured by Simpson Dura-Vent only (or the Chimney Conversion Kit
- see Addendum #2). Follow the installation instructions included with the vent. For the nearest
Simpson Dura-Vent supplier, call [phone]. Part numbers and descriptions are listed below.
Straight Lengths
908B 6”Pipe Length, Black (interior)
907B 9”Pipe Length, Black (interior)
906 12”Pipe Length, Galvanized
906B 12”Pipe Length, Black (interior)
904 24”Pipe Length, Galvanized
904B 24”Pipe Length, Black (interior)
903 36”Pipe Length, Galvanized
903B 36”Pipe Length, Black (interior)
902 48”Pipe Length, Galvanized
902B 48”Pipe Length, Black (interior)
911B 11”to 14 5/8”Pipe, Adjustable, Black (interior)
Vent Terminations
981 Snorkel Termination (36”rise)
(for basement installations)
982 Snorkel Termination (14”rise)
(for basement installations)
984 Horizontal Square Termination
950 Vinyl Siding Standoff
991 Vertical Termination
Elbows
990 90•Elbow
990B 90•Elbow, Black (interior)
945 45°Elbow
945B 45°Elbow, Black (interior)
Penetration, Support Parts
942 Wall Thimble
940 Optional Wall Thimble Cover
941 Cathedral Ceiling Support Box
943 Flashing, 0/12 to 6/12 Roof Pitch
943S Flashing, 7/12 to 12/12 Roof
Pitch
953 Storm Collar
963 Ceiling Firestop
988 Wall Strap
•Apply a 1/8" bead of high-temperature silicone or Mill-Pac®to the inner
and outer pipe before assembling the sections (on the male, upper
section). This seals the inner pipe from the outer pipe. Slide the sections
together and turn 1/4 turn until the sections lock in place. Install three
metal screws through each joint to lock the outer section in place (see the
instructions included with the vent for further details).
NOTE: You may screw the first section of vent to the appliance.
•Horizontal sections require a 1/4”rise every 12”of travel
+Exterior Vent Diameter = 6-5/8”, Inner Vent Diameter = 4”
•Horizontal sections require non-combustible support every 36”(e.g.: use
plumbing tape)

Installation(for qualified installers only) 9
Travis Industries 93508122 141100
Approved Vent Configurations
Restrictor Position
•A vent restrictor is built into the appliance to control the flow rate of exhaust gases. This ensures
proper flames for the wide variety of vent configurations. Depending upon the vent configuration, you
may be required to adjust the restrictor position. The charts for approved vent configurations describe
which position the vent restrictor must be in.
The restrictor is located
directly above the door,
behind the grill.
To Adjust the Restrictor:
To Access the Restrictor:
1
2
Determine the correct restrictor position (see the charts under
"Approved Vent Configurations" - the factory position is #1).
Lift up the adjustment plate and move it so the correct notch
falls into the slot on the adjustment bracket.
This restrictor is in position 1
(factory setting).
This restrictor is in position 7.
Adjustment
Bracket To adjust, lift up on the
adjustment plate and
push it back.
WARNING: Use a glove to protect
your hand from burns.
Adjustment
Plate
# 8
# 7 # 2
etc.
Measuring
Vent Lengths
Vent Horizontal Run
(measure from the closest
edge of the starter section to
the end of the termination)
Vent Height is
calculated to the
top of the vent on
horizontal
terminations and
to the top of the
termination on
vertical
terminations.
Vent
Height
Elbows add 3" (75 mm) to the
length of the vent system.
Side
View
9-5/8"
(245 mm)
Vent Length
(3', 4', etc.)
(910, 1210 mm)
Vent sections overlap each
other by 1-1/2" (37 mm)
8-3/4" (220 mm) wide
with 1-1/2" (37 mm)
to 3-3/8" (85 mm) of
overlap
The starter
section is
1/4"" above
the top
12-3/8" (310 mm) tall
with 1-1/2" (37 mm)
of overlap
3" (75 mm)
1-1/2" (37 mm)
1-1/2"
(37 mm)

10 Installation(for qualified installers only)
Travis Industries 93508122 141100
Vertical Terminations with 0, 2, or 4 45° Offsets
Offset Length Hor. Offset Vert. Rise
None 5" 1'
1' Section 1' 1' 7"
2' Section 1' 9" 2' 4"
3' Section 2' 5" 3'
4' Section 3' 2" 3' 8"
•The termination must fall within the shaded area shown in the
chart. Use the indicated restrictor position.
Offset
Length
Horizontal
Offset
Vertical
Rise
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
Restrictor
Position # 1
5 feet
10 feet
(min.)
15 feet
20 feet
25 feet
30 feet
0 feet
0 feet
5 feet
12' 8"
(max)
5 feet
0 feet
0 feet
5 feet
12' 8"
(max)
10 feet
(min.)
15 feet
20 feet
25 feet
30 feet
NOTE:
Restrictor positions are based upon
lab tests. The ideal restrictor position
may vary slightly, especially when the
termination is near the demarkation
line.
Four 45°Offsets
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
AAAAAAAAAA
5 feet
10 feet
(min.)
15 feet
20 feet
25 feet
30 feet
0 feet
38' (max)
0 feet
5 feet
12' 8"
(max)
5 feet
0 feet
0 feet
Restrictor
Position # 1
Restrictor
Position # 7
10 feet
(min.)
15 feet
20 feet
30 feet
38' (max)
Zero or Two 45°Offsets
5 feet
NOTE:
The maximum offset
lengths, combined, is
four 4' sections.
NOTE:
Restrictor positions are based upon lab tests. The
ideal restrictor position may vary slightly, especially
when the termination is near the demarkation line.
25 feet
10 feet
10 feet
12' 8"
(max)
10 feet
NOTE:
The maximum offset lengths,
combined, is four 4' sections.
10 feet
35 feet35 feet
38' (max) 38' (max)
Restrictor
Position # 7
35 feet35 feet

Installation(for qualified installers only) 11
Travis Industries 93508122 141100
Approved Venting Configurations with a Horizontal Termination
•If using a Snorkel Termination (14”or 36”) add the snorkel height to the vertical height (snorkel
terminations are used primarily for basement installations).
•The termination must fall within the shaded area shown in the chart. Use restrictor position #1.
Natural Gas (NG)
Installations
Propane (LP)
Installations
AAAAAAAAAAA
AAAAAAAAAAA
AAAAAAAAAAA
AAAAAAAAAAA
AAAAAAAAAAA
5 feet
0 feet
10' (max)
0 feet
5 feet
0 feet
0 feet
NOTE:
Horizontal sections
require a 1/4" rise every
12" of travel.
12 feet
(max)
NOTE:
A minimum 2 foot rise is required
directly off of the stove.
12 feet
(max)
5 feet
10' (max)
5 feet
Use Restrictor Position # 1
(all shaded areas)
AAAAAAAAAAA
AAAAAAAAAAA
AAAAAAAAAAA
AAAAAAAAAAA
AAAAAAAAAAA
5 feet
0 feet
11' (max)
0 feet
5 feet
0 feet
0 feet
NOTE:
Horizontal sections
require a 1/4" rise every
12" of travel.
NOTE:
A minimum 3 foot rise is required
directly off of the stove.
12 feet
(max)
11' (max)
5 feet
Use Restrictor Position # 1
(all shaded areas)
12 feet
(max)
5 feet

12 Installation(for qualified installers only)
Travis Industries 93508122 141100
Vertical Terminations with Two or Three 90° Elbows
•The termination must fall within the shaded area shown in the chart. Use the indicated restrictor
position.
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
5 feet
10 feet
(min.)
15 feet
20 feet
25 feet
30 feet
0 feet
38' (max)
5 feet
10 feet
15 feet
0 feet
5 feet
10 feet
15 feet
25'(max)
15 feet
20 feet
25 feet
30 feet
0 feet
0 feet
NOTE:
Horizontal sections require a
1/4" rise every 12" of travel.
10 feet
(min.)
38' (max)
25'(max)
Restrictor
Position # 7
NOTE:
Restrictor positions
are based upon lab
tests. The ideal
restrictor position
may vary slightly,
especially when the
termination is near a
demarkation line.
5 feet
Restrictor
Position # 1
35 feet 35 feet
20 feet
20 feet
NOTE:
•Horizontal sections require a 1/4" rise
every 12" of travel.
•The maximum vertical height is 38'.
•The maximum horizontal length is 25'.
•One horizontal elbow is allowed. The
horizontal vent length is calculated by
adding the length before and after the
elbow (H1 + H2 = horizontal vent length).
H1
H2
This is considered a horizontal
elbow (it does not matter
whether it turns right or left).
It may be a 45°or 90°elbow.
This is considered a
vertical elbow
Horizontal length is calculated by adding
both lengths of horizontal run
(Horizontal Length = H1 + H2).
H1
H2 This is considered a
vertical elbow

Installation(for qualified installers only) 13
Travis Industries 93508122 141100
Termination Requirements (see the illustration below)
A Minimum 9" clearance from any door or window
B Minimum 12" above any grade, veranda, porch, deck or balcony
C Minimum 12" from outside corner walls
D Minimum 12" from inside corner walls
E Minimum 11" clearance below unventilated soffits or roof surfaces
Minimum 18" clearance below ventilated soffits
Minimum 6" clearance from roof eaves
NOTE: Vinyl surfaces require 24"
11”Min.
6”Min.
Roof
Surface
Roof
Eaves
F Minimum 18" clearance below a veranda, porch, deck or balcony (must have two open sides)
G Minimum 48" clearance from any adjacent building
H Minimum 84" clearance above any grade when adjacent to public walkways or driveways
NOTE: may not be used over a walkway or driveway shared by an adjacent building
I Minimum 48" clearance from any mechanical air supply inlet, 72" for Canada
J Minimum 36" clearance above and 48”below and to the sides of non-mechanical air supply inlet
K Minimum 36" from the area above the meter/regulator (vent outlet)
L Minimum 36" from the meter/regulator (vent outlet)
M Minimum 12”above the roof line (for vertical terminations)
N Minimum 24”horizontal clearance to any surface (such as an exterior wall) –for vertical terminations
C
B
H
E
GA
D
F
L
KJ
I
NOTE: Measure clearances to the nearest edge of the exhaust hood.
A
E
E
M
N
•Use the vinyl siding standoff (#950) when installing on an exterior with vinyl siding.
•Vent termination must not be located where it will become plugged by snow or other material
•These clearances meet UMC-1994 and the CNA/CGA-B149 code standards.

14 Installation(for qualified installers only)
Travis Industries 93508122 141100
Finalizing the Installation
!Turn the gas control valve to “OFF”prior to conducting any service.
1Open the door (see page 16).
2Install the log set and coals (see page 17).
!We recommend you purge the gas line at this time (with the door open). This allows gas to be
detected once it enters the firebox, ensuring gas does not build up.
3Close and secure the door (see page 16).
4Turn on gas to the heater. Leak test all gas joints prior to starting the appliance. Start the pilot. Start
the main burner. Leak test all gas joints again.
5Check the pilot flame to make sure it looks like the illustration below. Adjust the pilot flame if
necessary.
Standard
Screwdriver
The pilot flame must contact the thermocouple and
thermopile (see the illustration below). Adjust the pilot up or
down as necessary.
To adjust the pilot flame, turn this screw (NOTE: if totally
unscrewed gas will come out of this port). Clockwise
lowers the flame while counter-clockwise raises it.
6Let the heater burn
for fifteen minutes.
Adjust the air
shutters, if
necessary, to
achieve the correct
looking flame (see
the illustration
below).
•The air shutter
adjusts the amount
of air that mixes with
the gas before it
exits the burner
holes.
ADJUSTING THE AIR SHUTTERS
Follow the directions below to adjust the front
and rear air shutter independently.
Swing the
left side
door open.
NOTE: If the air control is all the way in, yet the flames remain
sooty, shut off gas to the fireplace and contact a qualified gas
service technician.
Correct
Flames should be blue at the
base, yellow-orange on the top. If the flames are over 12" tall or sooty
on the ends, push the air control in. If the flames are all blue and short, pull the air control out.
Not Enough Air Too Much Air
NOTE: The logs must be installed correctly to
monitor the flame while adjusting the air shutter.
Loosen the nut two turns.
Slide the air shutter rod in or out.
Tighten the nut to
secure the shutter.
a
b
c
3/8" Nutdriver
Front Air
Shutter Control
Rear Air Shutter
Control
OPEN
(more air)
CLOSED
(less air)
OPEN
(more air)
CLOSED
(less air)

Installation(for qualified installers only) 15
Travis Industries 93508122 141100
FINE TUNING THE EMBER-FYRE™BURNER
Each installation is affected by altitude, vent configuration, and fuel quality. Because of this, the restrictor and air
shutter may need to be fine tuned to each installation. Follow the hints below to fine-tune the burner for
optimum performance and aesthetics.
Restrictor Hints:
Set the restrictor to the position suggested in the vent configuration table (pages 10-12). Turn the heater on
and allow it to reach full temperature (15 min.). If the flames indicate there is excessive draft due to altitude or
climate, you may wish to adjust the restrictor to a more restrictive position (higher number). Active, flickering
short flames are an indication of excessive draft. If the flames lift off of the burner holes, this indicates not
enough draft (restrictor is set too high). After adjustments are made the unit must be cooled down to room
temperature and restarted to make sure that the restriction is not so severe that the pilot will drop out when it is
restarted. If the pilot does drop out reduce the restriction until it will operate continuously.
Air Shutter Hints:
• For more glow, open the air shutter, however, this will make the flames more blue.
• For yellow flames, close the air shutter, however, this may create less glow.
The flames should burn right
off the top of the burner ports
(if they are too blue, adjust
the air control).
Lifting flames indicate
insufficient draft (restrictor
is set too high).
Burner Burner Ports
(holes)
Ghosting flames indicate
insufficient air (restrictor set too
high, air shutter shut down, or
other venting error).
Lifting FlamesCorrect Flames
A
A
A
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AAA
AAA
AAA
AAA
A
A
A
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
AAA
AAA
AAA
Ghosting Flames Flickering Flames
Flickering, short flames
indicate excessive draft
(move air shutter to a higher
position).
Warning: If the vent configuration is installed incorrectly the vent may cause the flames inside the heater to lift or
“ghost”–a dangerous situation. Inspect the flames after installation to insure proper performance. If the
vent configuration is correct, yet the flames are lifting or ghosting, shut off gas to the heater and contact
the dealer for information on remedying the problem.
7Turn the flame adjust knob to its highest position - the flames should be a maximum 10”to 12”tall.
Check the flame on low position. The flames should burn off of each burner hole. If the heater does
not work correctly, contact your dealer for a remedy.
8 Give this manual to the home owner and fully explain the operation of this heater.

16 Installation(for qualified installers only)
Travis Industries 93508122 141100
Opening the Door
Open both the top
and bottom latch.
With the pawl free of the
strike, the door may be
swung open.
Swing the left
panel back.
When securing the
door, make sure the
pawl fits over the strike
before tightening.
Strike
Pawl Door
Frame
NOTE: Do not overtighten the pawl by screwing
it in. This will permanently damage the latch.

Installation(for qualified installers only) 17
Travis Industries 93508122 141100
Log Set and Coal Installation
Step 1 Before installing the log set, make sure the burner is seated correctly.
Remove the burner and check the items below (see page 30).
Mixing Tube
O-Ring
Burner Tube
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
Make sure the burner is
fully seated. When in
place, the pilot flame
must align directly
above the burner holes.
AAA
AAA
AAA
AA
AA
AAA
AAA
AAA
AAA
AA
AA
AAAA
AAAA
AAAA
AAAA
AAAA
NOTE:
Make sure the “O”rings seal the burner
tubes to the mixing tubes.
Replace the
burner, making
sure the burner
tubes line up with
the mixing tubes.
HINT:
If the burner does not insert easily, make sure the
screws holding the rear mixing tube in place are
slightly loose. This allows the mixing tube to move
slightly and align with the burner tube.
b
a
AAAA
AAAA
AAAA
AAAA
AAAA
AA
AA
AA
AA
AA
Step 2
AA
AA
AA
AA
AA
AA
AA
AA
a
Place the rear log on the two
platforms at the rear of the
firebox.
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AA
AA
AA
AA
AA
AA
AA
A
A
A
A
A
A
Place the two pins,
included in the hardware
pack, into the burner.
c
These pins
insert into the
holes in the
log.
Place the front left log
stand over this pin.
b

18 Installation(for qualified installers only)
Travis Industries 93508122 141100
Step 3 Install the front logs.
AA
AA
AA
AA
AA
AA
AA
AA
AA
AA
a
These pins insert into
the holes in the log.
Place the left log on
top of the stand.
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAA
AA
AA
AA
AA
AA
AA
AA
AA
A
A
A
A
AA
AA
AA
AA
A
A
A
AA
AA
AA
AA
AA
AA
AA
AA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
Place the right front
log here.
b
1”to 1-1/2”
space
Note how the front left log is
spaced 1/4”to 3/8”off of the
burner holes.
Do not place logs over
burner holes.
Top View
