Travis Industries Avalon Tree of Life GS2 User manual

Featuring the Burner
• Direct Vent Freestanding Stove
• Natural Gas or Propane
• Vent Horizontally or Vertically
• Standard Residential
• Mobile Home Approved
Tested and Listed by
ANSI Z21.88 CSA 2.33
WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This appliance may be installed in an
aftermarket permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the
type(s) of gas indicated on the rating
plate. A conversion kit is supplied with
the appliance.
· Tree of Life 2 ·
Owner’s Manual
Installer: After installation give this manual to the homeowner and
explain the operation of this heater.
©Copyright 2013, T.I. $10.00 100-01313 4121128
www.travisproducts.com
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275

2Introduction
© Travis Industries 4121128 100-01313
Introduction
Wewelcome youas a new owner of an Avalon Tree of Life stove. In purchasinga Tree of Life you
have joined the growing ranksof concernedindividuals whose selection of anenergy systemreflects
both a concernforthe environment and aesthetics. The Tree of Life isone of the finesthome heaters
the world over. This manual will explain the installation, operation, and maintenance of thisstove.
Please familiarizeyourselfwith the Owner's Manual before operatingyourheater and save the manual
forfuture reference. Includedare helpful hints and suggestions that will make the operationand
maintenance of yournew stove an easier andmore enjoyable experience. Weofferour continual
support and guidanceto help youachievethe maximum benefitand enjoyment fromyourheater.
Important Information
No other Tree of Life Stove has the same serial
number as yours. The serial number is on the listing
plate chained to the gas control valve.
This serial number will be needed in case you require
service of any type.
Model: Avalon Tree of Life GS2
Serial Number:
Purchase Date:
Purchased From:
Mail your WarrantyCardToday,and
Save Your Bill of Sale.
To receivefull warranty coverage, youwill
need to show evidenceof the date you
purchasedyour heater. Donot mail your
Bill of Sale to us.
Wesuggest that youattach your Bill of Sale
to this page sothat youwill have all the
informationyouneed in one place should
the need forservice or informationoccur.
Listing Details
Massachusetts Approval
This manual has been submitted to the Massachusetts Board of State Examiners of Plumbers and Gas
Fitters.
National Fireplace Institute

Table of Contents 3
© Travis Industries 4121128 100-01313
Introduction ..................................................2
Important Information...................................2
Listing Details...............................................2
IAS (ICBO) ApprovalError! Bookmark not defined.
Features: ..................................................................6
Installation Options:.................................................6
Heating Specifications..................................6
Dimensions & Weight ...................................6
Electrical Specifications (for optional blower)6
Fuel...............................................................6
Packing List..................................................7
Additional Items Required ............................7
Installation Overview ....................................7
Stove Clearances..........................................8
Mobile Home Requirements..........................8
Heater Placement Requirements ..................9
Floor Protection Requirements.....................9
Electrical Requirements................................9
Optional Wall Switch or Thermostat
Installation..................................................10
Gas Line Installation...................................11
Gas Inlet Pressure.................................................11
Vent Requirements .....................................12
Altitude Considerations..........................................12
Approved Vent .......................................................12
Vent Installation .....................................................12
Approved Vent Configurations ...................13
Restrictor Position..................................................13
Measuring Vent Lengths .......................................13
Vertical Terminations with Zero, Two, or Four
45° Elbows..................................................14
Horizontal Termination with One 90° Elbow15
Horizontal Termination with Two Elbows
(one 90° vertical and one 90° or 45°
horizontal elbow) ........................................16
Horizontal Termination with Three 90°
Elbows (all vertical) ....................................17
Vertical Terminations with Two 90° Elbows 18
Vertical Terminations with Three 90° Elbows
(Two90° Vertical and One 45° or 90°
Horizontal Elbow) .......................................19
Vent Termination Requirements (see
illustration below) .......................................20
Class A Chimney Conversion Kit................21
Interior Masonry Chimney Conversions .....22
Steps for Finalizing the Installation ............23
Air Shutter Adjustment...........................................24
Face and Glass Removal ............................25
Log Installation...........................................27
Ember Placement ..................................................27
Rear Log Placement..............................................27
Left Log Placement................................................28
Right Log Placement .............................................28
Right Twig Placement............................................29
Left Twig Placement..............................................29
Front Ember Chunk Placement.............................30
Rockwool Installation.............................................30
Before You Begin........................................31
Location of Controls - See explanation below31
Starting the Stove for the First Time...........32
Turning the Stove On and Off .....................32
Comfort Control..........................................32
Adjusting the Flame Height ........................32
Accent Light ...............................................33
Adjusting the Optional Blower Speed.........33
Continuous Pilot / GreenSmart™ Pilot Switch33
Normal Operating Sounds ..........................34
Normal Operating Odors.............................34
Maintaining Your Stove's Appearance........35
Painted Surfaces....................................................35
Enamel Surfaces....................................................35
Patina Surfaces......................................................35
Glass.......................................................................35
Battery Replacement ..................................35
Power Backup Batteries........................................35
Control Panel Light Battery ...................................35
Accent Light Replacement..........................36
Yearly Service Procedure ...........................36
Troubleshooting Table................................37
Replacement Parts List...............................37
Safety Label................................................38
CONDITIONS & EXCLUSIONS.....................39
IF WARRANTY SERVICE IS NEEDED:.........39
LP Conversion Instructions........................40
GS2 Remote Installation .............................43
Packing List............................................................43
Warnings ................................................................43
Remote Control / Pilot Warnings...........................43
Base Wiring Diagram.............................................44
GS2 Remote Wiring Diagram................................45
Installation..............................................................46
Order of Installation .............................................51
Wiring the Blower to the GSR2 IFC (Bypassing the
Rheostat)............................................................51

4Safety Precautions
© Travis Industries 4121128 100-01313
•IF YOU SMELL GAS:
* Do not light any appliance
* Extinguish any open flame
* Do not touch any electrical switch or plug or unplug anything
* Open windows and vacate building
* Call gas supplier from neighbor's house, if not reached, call fire department
•This unit must be installed by a qualified installer to prevent the possibility of
an explosion. Your dealer will know therequirements in your area and can
inform you of those people considered qualified. The room heater should be
inspected before use and at least annually by a qualified service person. More
frequent cleaning may be required due to excessive lint from carpeting,
bedding material, etc.
•The instructions in this manual must be strictly adhered to. Do not use makeshift
methods or compromise in the installation. Improper installation will void the warranty
and safety listing.
•
This heater is either approved for natural gas (NG) or for propane (LP). Burning
the incorrectfuel will void the warranty and safety listing and may cause an
extreme safety hazard. Directquestions about the type of fuel used to your dealer.
Check for a label on the flame adjust knob on the gas control valve (this is the best
place to check). You may also check for a label on the gas control valve body.
•Contact your local building
officialsto obtain a permit
and information on any
installation restrictions or
inspection requirements in
your area. Notify your
insurance company of this
heater as well.
•If the flame becomes sooty,
dark orange in color, or
extremely tall, do not
operate the heater. Call
your dealer and arrange for
proper servicing.
•It is imperative that control
compartments, screens, or
circulating air passageways
of the heater be kept clean
and free of obstructions.
These areas provide the air
necessary for safe
operation.
•Do not operate the heater if
it is not operating properly in
any fashion or if you are
uncertain. Call your dealer
for a full explanation of your
heater and what to expect.
•Do not store or use gasoline
or other flammable liquids in
the vicinity of this heater.
•Do not use this appliance if
any part has been under
water. Immediately call a
qualified service technician
to inspect the appliance and
to replace any part of the
control system and any gas
control which has been
under water.

Safety Precautions 5
© Travis Industries 4121128 100-01313
•Do not place clothing or
other flammable items on or
near the heater. Because
this heater can be controlled
by a thermostat there is a
possibility of the heater
turning on and igniting any
items placed on or near it.
•Light the heater using the
built-in igniter. Do not use
matches or any other
external device to light your
heater.
•Allow the heater to cool
before carryingout any
maintenance or cleaning.
•The viewing glass should be
opened only for lighting the
pilot or conducting service.
•Any safety screen or guard
removed for servicing must
be replaced prior to
operating the heater.
•Do not operate with the
glass removed or damaged.
•Never remove, replace,
modify or substitute any part
of the heater unless
instructions are given in this
manual. All other work must
be done by a trained
technician. Don't modify or
replace orifices.
•Operate the heater
accordingto the instructions
included in this manual.
•If the main burners do not
start correctly turn the gas
off at the gas control valve
and call your dealer for
service.
•Instruct everyone in the
house how to shut gas off to
the appliance and at the gas
main shutoff valve. The gas
main shutoff valve is usually
next to the gas meter or
propane tank and requires a
wrench to shut off.
•This unit is not for use with
solid fuel
•Do not place anything inside
the firebox(except the
included fiber logs).
•If the fiber logs become
damaged, replace with
Travis Industries log set.
•Do not throw this manual
away. This manual has
important operating and
maintenance instructions
that you will need at a later
time. Always follow the
instructions in this manual.
•Travis Industries, Inc.
grants no warranty,
implied or stated, for the
installation or
maintenance of your
heater, and assumes no
responsibility of any
consequential damage(s).
•Plug the heater into a 120V
grounded electrical outlet.
Do not remove the
grounding plug.
•Don’t route the electrical
cord in front of, over, or
under the heater
Young children should be carefully supervised when they are in the same room as the
appliance. Toddlers, young children and others may be susceptible to accidental
contact burns. A physicalbarrier is recommended if there areat riskindividuals in the
house. To restrict accessto a fireplaceor stove, install an adjustable safety gate to
keep toddlers, young children and other at riskindividuals out of the room and away
from hot surfaces.

6
Specifications
© Travis Industries 4121128 100-01313
Features:
- Ember Fyre™ Burner for "Wood Fire" Look
- Works During Power Outages (battery backup system)
- High Efficiency
- Optional Thermostat or Remote Control
- Optional Blower for Quicker Heat Distribution
- Convenient Operating Controls
- Variable-Rate Heat Output
- Accent Light
Installation Options:
- Freestanding Stove
- Horizontal or Vertical Vent
- Residential or Mobile Home
- Straight or Corner Placement
- Bedroom Approved
Heating Specifications
Approximate Heating Capacity (in square feet)*...........500 - 1,500 with Blower, 500 to 1,200 Without
Maximum Input........................................................................................31,000
•Heating capacity will vary depending on the home’s floor plan, degree of insulation, and the outside temperature.
Dimensions & Weight
Electrical Specifications (for optional blower)
Electrical Rating.........................................................115 Volts, 1.5 Amps, 60 Hz (180 watt)
Fuel
This heater is shipped in natural gas (NG) configuration but may be converted to propane (LP) using
the included LP conversion kit. The sticker on top of the gas control valve will verify the correctfuel.

Installation (for qualified installers only) 7
© Travis Industries 4121128 100-01313
Installation Warnings
! Failure to follow all of the requirements may result in property damage, bodily injury, or even
death.
! This heater must be installed by a qualified installer who has gone througha training program
for the installation of direct vent gas appliances.
! This appliance must be installed in accordance with all local codes, if any; if not, in U.S.A.
follow ANSI Z223.1 and NFPA 54(88), in Canada follow CSA B149.1.
! In Manufactured or Mobile Homes must conform with: In USA, Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280; In Canada, CSA Z240.4 and Gas-
Equipped Recreational Vehicles and Mobile Housing. This appliance may be installed in
Manufactured Housing only after the home is site located.
! This stove is designed to operate on natural gas or propane (LP).
! All exhaust gases must be vented outside the structure of the living area. Combustion air is
drawn from outside the living area structure.
! Notify your insurance company before hooking up this stove.
! The requirements listed below are divided into sections. All requirements must be met
simultaneously. The order of installation is not rigid –the qualified installer should follow the
procedure best suited for the installation.
Packing List
•Propane Conversion Kit
•Log Set
•Touch-Up Paint
Additional Items Required
•Vent (see “Venting Requirements” for details)
•Gas Line Equipment (shutoff valve, pipe, etc.)
Installation Overview

8
Installation (for qualified installers only)
© Travis Industries 4121128 100-01313
Installation Hints
If converting to LP, convert the appliance prior to installation.
Install the logs last - they are fragile.
When determining the location of the stove, locate the wall studs (forhorizontal penetrations) and
ceiling trusses (for vertical penetrations). You may wish to adjust the stove position slightly to ensure
the vent does not intersect with a framing member.
Fumes and smoke from the paint curingand oil burning off the steel may occurthe first time youstart
this heater. This is normal. We recommend you open windows to vent the room.
Stove Clearances
Mobile Home Requirements
•When the stove is installed in a mobile home, it must be bolted to the floor and the appliance
grounded (use the optional blower with a grounded circuitor other suitable grounding method -
current ANSI/NFPA 70 or CSA C22.1).

Installation (for qualified installers only) 9
© Travis Industries 4121128 100-01313
Heater Placement Requirements
•Heater must be installed on a level surface capable of supporting the heater and vent
•Due to the high temperature, the heater should be located out of trafficand away from furniture
and draperies.
•When placed ina location where the floor to ceiling height is under 7 feet, the installation is
considered an alcove and must meet the following requirements:
-The alcove floor to ceiling height must be at least 58” tall
-The alcove must not be more than 45” deep before the ceiling returns to 7’
-The alcove must be at least 46-3/4” wide
•The heater must not be placed so the vents below or above the door, along the sides of heater, or
along the back of the heater can become blocked.
•This heater may be placed in abedroom. Please be aware of the large amount of heat this
appliance produces when determining a location.
Floor Protection Requirements
•When the stove is installed directly on carpeting, vinyl or other combustible material other than
wood flooring or a high pressure laminate wood floor, the stove must be installed on a metal or
wood protection panel extending the full width and depth of the heater (Minimum 26-3/4” wide by
19” deep).
Electrical Requirements
Plug the stove into a grounded receptacle supplying a minimum 1.5 amps (115 Volts, 60 Hz, 180
watts).
The appliance, when installed, must be electrically grounded in accordancewith local codes or, in
the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian
Electrical Code, CSA C22.1.

10
Installation (for qualified installers only)
© Travis Industries 4121128 100-01313
Optional Wall Switch or Thermostat Installation
Do not connect 110-120 VAC to the gas control valve or wiring system of this stove. The switch must be
installed by a qualified installer.
Caution: Label all wires prior to disconnection when servicing controls. Wiringerrors can cause
improper and dangerous operation.
Note: When using a GreenSmart™ remote, use the receiver for on/off operation (do not use a wall
switch or thermostat).
Warning: Make sure all wiring is secure and does not contact hot or moving components.
The wall switch (or thermostat) may bypass the fireplace on/off switch or be installed in parallel or series
configuration (see below).
Parallel Connection Series Connection
On / Off Switch
ON
On / Off Switch
OFF
On / Off Switch
ON
On / Off Switch
OFF
Thermostat / External
Switch ON
Heater is ON
Heater is ON
Thermostat /
External Switch ON
Heater is ON
Heater is OFF
Thermostat / External
Switch OFF
Heater is ON
Heater is OFF
Thermostat /
External Switch OFF
Heater is OFF
Heater is OFF
To wire the heater in parallel, follow the directions below:
To wire the heater in series, follow the directions below:

Installation (for qualified installers only) 11
© Travis Industries 4121128 100-01313
Gas Line Installation
! The gas line must be installed in accordancewith all local codes, if any; if not, follow current ANSI
Z223.1 or NFPA 54 in the USA and the current CSA B149.1 in Canada.
! The heater and gas control valve must be disconnected from the gas supply piping during any
pressure testing of that system at test pressures in excess of 1/2 psig (3.45kPA). For pressures
under 1/2 psig (3.45 kPA), isolate the gas supply piping by closing the manual shutoff valve.
•This heater is designed for natural gas but canbe converted to propane. Check the sticker on
top of the gas control valve to verify the correctfuel is used (see page 4).
•Leak-test all gas line joints and the gas control valve prior to and after starting the heater.
•The location of the gas inlet is shown below.
•A manual shutoff valve is required for installation (it must be located within 3’ of the heater).
T-Handle gas cocksare requiredin Massachusetts in compliance with code 248CMR.
•This stove is shipped with a 24” long, 3/8” diameter flex gas line attached to an elbow on the gas
control valve (see illustration below for location). The flex accepts a 3/8” flare fitting.
Gas Inlet Pressure
•Withthe heater off,the inlet pressure must meet the requirements listed in the table below.
•If the pressure is not sufficient, make sure the piping used islarge enough and the total gas load
for the residence does not exceed the amount supplied.
•The supply regulator (the regulator that attaches directly to the residence inlet or to the propane
tank) should supply gas at the suggested input pressure listed below. Contact the local gas
supplier if the regulator is at an improper pressure.
Standard Input Pressure
Natural Gas
7” W.C. (1.74 Kpa)
Propane
13” W.C. (3.23 Kpa)

12
Installation (for qualified installers only)
© Travis Industries 4121128 100-01313
Vent Requirements
•The gas appliance and vent system must be vented directly to the outside of the building, and never
be attached to a chimney serving a separate solid fuel or gas-burning appliance. Each directvent
gas appliance must use its own separate vent system.
In addition to the requirements listed here, follow the requirements provided with the vent.
When the vent passes through a wall a wall thimble is required. Whenthe vent passes through a
ceiling a support box or firestop is required. When the vent passes through the roof, a roof flashing
and storm collar are required. Follow the instructions provided with the vent for installing these items.
NOTE: Wall thimbles may have different dimensions than what isrequired by this heater.
•The vent must maintain the required 1" clearance to combustible materials to prevent a fire. Do not
fill air spaces with insulation.
Altitude Considerations
•Failure to adjust the air shutter
properly may lead to improper
combustion which can createa
safety hazard. Consult your dealer
or installer if you suspect an
improperly adjusted air shutter.
•This heater has been tested at
altitudes ranging from sea level to
6,000 feet (1,800 M). Inthis
testing we have found that the
heater, with its standard orifice,
burns correctly with just an air
shutter adjustment.
Approved Vent
Use 6-5/8" (168mm) diameter Simpson Dura-Vent Direct-VentPro (or GS)*.
* Other vent may be approved with this stove. Check with the vent manufacturer for details.
Always use the high-wind cap(or high-wind sconcecap, part # 46DVA-HSCH).
Installation instructions for Simpson Dura-Vent may be found at www.duravent.com
Vent Installation
•Slide the vent sections together and turn 1/4 turn until the sections lock in place.
•Screws are not requiredto secure the vent. However, three screws may be used to
secure vent sections together if desired.
•High temperature sealant is recommended at the appliance starter section connection
(use high-temperature silicone or Mill-Pac®).
•If disassembly is required, at time of re-assembly checkto see if the vent creates a tight
fit. If it does not, apply high temperature sealant to the joints of the affected sections.
•Horizontal sections require a 1/4" rise every 12" of travel
•Horizontal sections require non-combustible support every three feet (e.g.: plumbing tape)

Installation (for qualified installers only) 13
© Travis Industries 4121128 100-01313
Approved Vent Configurations
Restrictor Position
•A restrictor is built into the appliance to control the flow rate of exhaust gases. This ensures
proper flames for the wide variety of vent configurations. Depending upon the vent configuration,
youmay be required to adjust the restrictor position. The charts for approved vent configurations
describe which position the vent restrictor must be in.
Measuring Vent Lengths

14
Installation (for qualified installers only)
© Travis Industries 4121128 100-01313
Vertical Terminations with Zero, Two, or Four 45° Elbows
•10’ Minimum System
Height
(with or without offsets)
•40’ Maximum System
Height
•24’ Maximum Offset
•The termination must fall
within the shaded area
shown inthe chart. Use
the indicated restrictor
position.

Installation (for qualified installers only) 15
© Travis Industries 4121128 100-01313
Horizontal Termination with One 90° Elbow
•If using a Snorkel Termination (14” or 36”) add the snorkel height to the vertical height (snorkel
terminations are used primarily for basement installations).
•The terminationmust fallwithin the shadedareashown inthe chart. Usetheindicated restrictorposition.

16
Installation (for qualified installers only)
© Travis Industries 4121128 100-01313
Horizontal Termination with Two Elbows
(one 90° vertical and one 90° or 45° horizontal elbow)
•If using a Snorkel Termination (14” or 36”) add the snorkel height to the vertical height (snorkel
terminations are used primarily for basement installations).
•The terminationmust fallwithin the shadedareashown inthe chart. Usetheindicatedrestrictorposition.

Installation (for qualified installers only) 17
© Travis Industries 4121128 100-01313
Horizontal Termination with Three 90° Elbows (all vertical)
•If using a Snorkel Termination (14” or 36”) add the snorkel height to the vertical height (snorkel
terminations are used primarily for basement installations).
•The terminationmust fallwithin the shaded areashown inthe chart. Usetheindicatedrestrictorposition.

18
Installation (for qualified installers only)
© Travis Industries 4121128 100-01313
Vertical Terminations with Two 90° Elbows
•The terminationmust fallwithin the shadedareashown inthe chart. Usetheindicated restrictorposition.

Installation (for qualified installers only) 19
© Travis Industries 4121128 100-01313
Vertical Terminations with Three 90° Elbows
(Two90° Vertical and One 45° or 90° Horizontal Elbow)
•The terminationmust fallwithin the shadedareashown inthe chart. Usethe indicatedrestrictorposition.

20
Installation (for qualified installers only)
© Travis Industries 4121128 100-01313
Vent Termination Requirements (see illustration below)
! Venting terminals shall not be recessed into a wall or siding.
A Minimum 9" (229mm) clearance from any door or window
B Minimum 12" (305mm) above any grade, veranda, porch, deck or balcony
C Minimum 1" (25mm) from outside corner walls
NOTE:Clearance in accordance with local installation codes and the requirements
of the gas supplier.
D Minimum 12" (305mm) from inside corner walls
NOTE:Clearance in accordance with local installation codes and the requirements
of the gas supplier.
E Minimum 11" (279mm) clearance below unventilated soffits or roof surfaces
Minimum 18" (457mm) clearance below ventilated soffits
Minimum 6" (152mm) clearance below roof eaves
NOTE:Vinyl surfaces require 24" (610mm)
NOTE:Clearance in accordance with local installation codes and the requirements of the gas supplier.
F Minimum 12" (305mm) clearance below a veranda, porch, deck or balcony
NOTE: Permitted only if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor.
NOTE:Clearance in accordance with local installation codes and the requirements of the gas supplier.
G Minimum 48" (1219mm) clearance from any adjacent building
H Minimum 84" (2134mm) clearance above any grade when adjacent to public walkways or driveways
NOTE: may not be used over a walkway or driveway shared by an adjacent building
I Minimum 9" (229mm) clearance to any non-mechanical air supply inlet to the building or the combustion air inlet
to any other appliance.
J Minimum 36" (914mm) clearance above any mechanical air supply inlet if within 10’ (3M) horizontally
K Minimum 36" (914mm) from the area above the meter/regulator (vent outlet) - this extends 15’ (4.5M) above the regulator
NOTE:Clearance in accordance with local installation codes and the requirements of the gas supplier.
L Minimum 36" (914mm) from the meter/regulator (vent outlet)
NOTE:Clearance in accordance with local installation codes and the requirements of the gas supplier.
M Minimum 12” (305mm) above the roof line (for vertical terminations)
N Minimum 24” (610mm) horizontal clearance to any surface (such as an exterior wall) – for vertical terminations
•Use the vinyl siding standoff when installing on an exterior with vinyl siding.
•Vent termination must not be located where it will become plugged by snow or other material
