The TEW-453APB is a 108Mbps high speed 802.11g
Wireless Access Point that offers advanced wireless security,
network man-agement, and Power-over-Ethernet
capabilities. Wireless security features include TKIP and AES
algorithms for WPA, and also Radius based MAC
authentication. Features for network management include
VLAN, SNMP support, System log support, and Rogue AP for
extra security.
TEW-453APB
108Mbps 802.11g Hot-Spot Access Point
FEATURES
Wi-Fi Compliant with IEEE 802.11g / 802.11b Wireless Devices
One 2dBi Detachable Antenna with Reverse SMA Connector
High-Speed Wireless Access Point with up to 108Mbps Connection
Supports Access Point, AP Client/Repeater and Bridge (PTP or PTMP
up to 8 units) Modes
64/128/152-bit Wired Equivalent Privacy (WEP) with HEX or ASCII
key
Supports WPA/WPA-PSK, AES and TKIP
Allows 802.1x and Non-802.1x Clients Running Simultaneously
Supports Radius-based MAC address authentication and MAC
Address Filter
Supports Client to Client Communication Prevention per ESSID,
Wireless Separation
Multiple Security Profiles (max active 4), SSID Isolation and UAM
(Universal Access Method)
Supports Wireless Separations (between clients)and Worldwide
Wireless Mode (802.11d) Standard
Detects Rogue Access Points with Logs
Easy Configuration with Web Browser (HTTP/HTTPS) or Telnet
Flash Memory for Firmware Upgrade
Range for 802.11b: up to 35~60 meters indoor, 300 meters outdoor
(depends on the environment)
Range for 802.11g: up to 20 meters indoor, 50 meters outdoor
(depends on the environment)
3-Year Warranty
TEW-453APB (03-31-2005)
TRENDnet
TRENDware, USA
What's Next in Networking

RELATED PRODUCT
To Order Please Call:
1-888-326-6061
TEW-441PC
TEW-443PI
TEW-444UB
NETWORKING SOLUTIONS
SPECIFICATIONS
Hardware
Standards :
Wired: IEEE 802.3 (10Base-T), IEEE 802.3u
(100Base-TX) , IEEE 802.3af PoE
Wireless: IEEE 802.11b (11Mbps), IEEE 802.11g
(54Mbps), IEEE 802.1x, IEEE 802.11d
LED Indicators:
Power, Status, LAN and WLAN
Console Port:
RS232 Port (DB9)
Protocols:
TCP/IP, NetBEUI, ARP, DHCP Client, HTTP, NTP,
RADIUS, WINS, Telnet, FTP, HTTPs, SSL
CPU/Radio/RAM/Flash:
Atheros 2312/ Atheros 2112/ 8Mbytes/ 2Mbytes
Client Support:
DHCP Client, WINS Client, Radius Client
•
•
•
•
•
•
•
Power Source:
• 24V DC, 500mA External Power Adapter or
PoE Connection
Weight:
• 0.35 kg. (12.5 oz.)
Dimensions:
• (LxWxH) 141 x 100 x 27 mm
(5.5 x 3.9 x 1.06 inches) (without antennas)
Temperature Operating:
• 0° C~ 40° C (32° F~ 104° F)
Storage:
• -10° C~ 70° C(14° F~ 158° F)
Humidity:
• Max. 95% (non-condensing)
Certification:
• FCC, CE
Wireless
Module Technique:
• 802.11b: CCK, DQPSK, DBPSK ; 802.11g: OFDM
Frequency Range 2.4 ~ 2.497 GHz
Modes:
• Access Point, AP Client/Repeater, Bridge
(PTP or PTMP)
Security:
64/128/152-bit (WEP), 802.1x
WPA-PSK or WPA-802.1x (TKIP, AES,
EAP-MD5, EAP-TLS, EAP-TTLS, PEAP)
Management:
Web Browser (HTTP or HTTPS); SNMP V2, V2C;
Telnet & CLI
Antenna:
1 x 2dBi External Detachable Dipole Antenna with
Female Reverse SMA connector
Output Power Adjustable:
Full (18dBm), Half (15dBm), Quarter (12dBm),
Eighth (9dBm), Minimum (6dBm)
Receiving Sensitivity:
11Mbps 10 – 5 BER @ -86 dBm (typical)
54Mbps 10 – 5 BER @ -71 dBm (typical)
108Mbps 10 – 5 BER @ -68 dBm (typical)
Data Rate (auto fallback):
• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps,
18Mbps, 12Mbps, 9Mbps and 6Mbps
Channels:
• 1~14 Channels (Universal Support)
•
•
•
•
•
•
•
•
TEW-453APB
108Mbps 802.11g Hot-Spot Access Point
TEW-453APB
108Mbps 802.11g Hot-Spot Access Point
TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit ____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2005. All Rights Reserved.
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.TRENDNET.com
ORDERING INFORMATION
TRENDnet
TRENDware, USA
R
100Mbps
108Mbps Wireless
Cable/DSL 4-Port
Broadband Router
(TW100-S4W1CA)
108Mbps 802.11g Hot-Spot
Wireless Access Point
(TEW-453APB)
Hot-Spot
Cable/DSL Modem
Internet
Client with
Wireless PC Card
Client with
Wireless PC Card
Client with
Wireless PC Card Radius Server/
Accounting Server
Admin. with
Wireless PCI Adapter
