Tritton Kunai User manual

User Guide
[ENGLISH/08-12]

[2]
Package Contents .................................................. 3
Connecting the Microphone ......................................... 4
In-line Controls .................................................... 6
Connect To
Nintendo 3DSTM ................................................. 7
Wii U GamePadTM ................................................ 8
Speaker Tags ...................................................... 9
Troubleshooting ................................................... 10
Warranty ......................................................... 11
Technical Support ................................................. 12
Table of Contents

[3]
Package Contents
Quick Start Guide
Kunai Headset
In-line Audio Controller with Breakaway
Removable Microphone

[4]
Connecting the Microphone
1. Line up the arrows on the microphone and the headset.

[5]
Connecting the Microphone
2. Insert the microphone into the port on the left earcup of the headset.
Firmly push it into place, and then twist it clockwise to lock it in place.
3. Reverse the above steps to remove the microphone.
4. With the microphone removed, insert the included microphone connector
plug to cover the port.

[6]
In-line Controls
Game Audio Volume: Use to adjust
the volume of the game audio.
Mic Mute: Slide the mic mute switch
so that others cannot hear you. The
orange area behind the switch will
show when the mic is muted.

[7]
Connect to Nintendo 3DSTM
Plug the 3.5mm stereo audio connector into the 3.5mm headset jack located
on the bottom of the Nintendo 3DS.

[8]
Connect to Wii U GamePadTM
Plug the 3.5mm stereo audio connector into the 3.5mm headset jack located
on the top of the Wii U GamePad.
AA
BB
XX
YY
SELECTSELECT HOMEHOME STARTSTART MICMIC BATTERYBATTERY POWERPOWER

[9]
Speaker Tags
1. The speaker tags are held in place with magnets. Remove them by pulling
on the slots located at the top of the speaker plates.
2. To replace the speaker tags, line up the tabs on the speaker tag with the
holes at the bottom of the earcup, and then tilt the speaker tag forward so that
the magnets hold it in place.
Replacement and customized speaker tags are available at trittonaudio.com

[10]
Troubleshooting
Microphone isn’t working:
• Make sure that the microphone is properly inserted into the microphone port.
• Check that the 3.5mm stereo audio connector is rmly plugged into the
headset jack on the Nintendo 3DS or Wii U GamePad.
• Make sure that the mic mute switch is not set to mute.
• Make sure that the mic mute option on the Nintendo 3DS or Wii U GamePad
is not enabled.
No Sound:
• Check that the volume on the in-line controller is not turned all the way down.
• Check that the volume on the Nintendo 3DS or Wii U GamePad is not turned
all the way down.
• Check that the 3.5mm stereo audio connector is rmly plugged into the
headset jack on the Nintendo 3DS or Wii U GamePad.

[11]
WARRANTY
2-YEAR LIMITED WARRANTY
Mad Catz warrants this product to be free from defects in materials and workmanship for the
warranty period. This non-transferable, two- (2) year limited warranty is only to you, the rst end-user
purchaser. If a defect covered by this warranty occurs AND you provide proof of purchase, Mad Catz,
at its option, will repair or replace the product at no charge.
The Mad Catz two- (2) year limited warranty is available to North American and European customers.
Your sole and exclusive remedy is repair or replacement of your Mad Catz product. In no event shall
Mad Catz liability exceed the original purchase price of the product. This warranty does not apply
to: (a) normal wear and tear or abusive use; (b) industrial, professional or commercial use; (c) if the
product has been tampered with or modied.
NORTH AMERICA AND EUROPE
To receive warranty service, you must:
Obtain a Return Authorization Number from Mad Catz Technical Support via ONE
of the following methods:
a. Submit a Ticket at http://support.madcatz.com
b. Call the Mad Catz Tech Support Center nearest you:
North America: 1-800-659-2287 (USA) or 1-619-683-2815 (outside USA)
United Kingdom: 08450 508418
Europe (outside UK): [phone]
France: 01 82 88 01 80
Germany: 089-21094818
Spain: 93 181 63 94
Once you have your unique Return Authorization Number, do the following:
1. Ship the product to Mad Catz at your expense for service.
2. Enclose a copy of the original sales receipt showing a purchase date.
3. Enclose a full return address with daytime and evening phone numbers.

[12]
TECHNICAL SUPPORT
Online Support: http://support.madcatz.com
North American telephone, available Monday through Friday
(excluding holidays): 1-800-659-2287 (USA only) or 1-619-683-2815 (outside USA).
United Kingdom telephone, available Monday through Friday
(excluding bank holidays): 08450 508418.
European telephone (outside UK), available Monday through Friday
(excluding bank holidays): [phone].

[13]
CAUTIONS
• Long-term exposure to loud music or other sounds in headphones may cause hearing damage. It is best
to avoid extreme volume levels when using headphones, especially for extended periods.
• Use this unit only as intended.
• To prevent re or shock hazard, do not expose this unit to rain or moisture. Do not use within 30’ of any
water such as swimming pools, bathtubs, or sinks.
• To avoid electrical shock, do not disassemble. Refer servicing to qualied personnel only.
• Never insert objects of any kind, other than authorized items, into the product as they may touch
dangerous voltage points or short out parts that could result in re or electrical shock.
• Stop using this unit immediately if you begin to feel tired or if you experience discomfort or pain in your
hands and/or arms while operating the unit. If the condition persists, consult a doctor.
• Avoid prolonged use of this unit. Take breaks every 30 minutes.
• Route all cords so that they are not likely to be walked on or tripped over. Make sure that cords are not
placed in a position or areas where they may become pinched or damaged.
• Do not wrap cords around any part of anyone’s body.
• Do not allow children to play with cords.
• This product contains small parts that may cause choking if swallowed. Not intended for use by children
under 3 years of age.
United States and Canada:
As required, certain of these class B digital devices (the headsets) have been tested by Mad Catz, Inc., 7480
Mission Valley Road, Suite 101, San Diego, CA 92108, and found to comply with part 15 of the FCC rules and
the Canadian RSS-210 which sets forth limits designed to provide reasonable protection against harmful
interference in a residential installation. These device(s) use, generate and can radiate radio frequency
energy and, if not assembled, installed and used in accordance with the instructions, may cause harmful
interference to radio communications. There is no guarantee that interference will not occur in any particular
location or use. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC Part 15 section 15.105
Warning: Any changes or modications made on the system not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.

[14]
CAUTIONS
Exposure to Radio Frequency Radiation:
The radiated output power of the headset is well within FCC radio frequency exposure limits for this
type of device when unaltered and used as described in our instructions and the controller operates
within guidelines found in radio frequency safety standards, which reect the consensus of the scientic
community and therefore, the manufacturer believes the device’s internal wireless radio is safe for use by
consumers. The level of energy emitted is far less than the electromagnetic energy emitted by wireless
devices such as mobile phones. However, the use of wireless radios may be restricted in some situations
(e.g., on airplanes). If you are unsure of restrictions that may apply in any situation, you must ask for
authorization before turning on, connecting or using the controller.
EU DECLARATION OF CONFORMITY:
As required, certain of these products have been tested and conform to the requirements of the European
Union Directives 2002/95/EC, 2002/96/EC, and 2004/108/EC. Authorized signatory of the manufacturer is Mad
Catz, Inc., 7480 Mission Valley Road, Suite 101, San Diego, CA 92108.
08/12

[15]
[ENGLISH/08-12]
WWW.TRITTONAUDIO.COM
©2012 Mad Catz, Inc. 7480 Mission Valley Road, Suite 101, San Diego, CA 92108 U.S.A. Mad Catz, TRITTON, Kunai, the Mad Catz logo
and the TRITTON logo are trademarks or registered trademarks of Mad Catz, Interactive, Inc., its subsidiaries and afliates. The shape
and design of this product are a trade dress of Mad Catz Interactive, Inc., its subsidiaries and afliates. All other product names and
images are trademarks or registered trademarks of their respective owners. Made in China. All rights reserved. Product features, ap-
pearance and specications may be subject to change without notice. Please retain this information for future reference.
TM and © 2012 Nintendo. Licensed by Nintendo.
©2012 Mad Catz Europe, Ltd. 1-2 Shenley Pavilions, Chalkdell Drive. Shenley Woods, Milton Keynes, Buckinghamshire MK5 6LB,
Royaume-Uni (UK). Mad Catz, TRITTON, Kunai, le logo Mad Catz et le logo TRITTON sont des marques de commerce ou des marques
déposées de Mad Catz Interactive, Inc., de ses liales et sociétés afliées. La forme et le design de ce produit sont caractéristiques de
la marque Mad Catz Interactive, Inc., de ses liales et sociétés afliées. Tous les autres noms et images de produits sont des marques
de commerce ou des marques déposées de leurs propriétaires respectifs. Fabriqué en Chine. Tous droits réservés. L’aspect, les fonc-
tionnalités et les spécications du produit peuvent changer sans préavis. Veuillez conserver cette notice pour référence ultérieure.
TM et © 2012 Nintendo. Sous licence par Nintendo.
©2012 Mad Catz Europe, Ltd. 1-2 Shenley Pavilions, Chalkdell Drive. Shenley Woods, Milton Keynes, Buckinghamshire MK5 6LB, Reino
Unido (UK). Mad Catz, TRITTON, Kunai, el logotipo de Mad Catz y el logotipo de TRITTON son marcas comerciales o marcas com-
erciales registradas de Mad Catz Interactive, Inc., sus subsidiarias y aliados. La forma y el diseño de este producto son un vestido
comercial de Mad Catz Interactive, Inc., sus subsidiarias y aliados. El resto de nombres y de las imágenes del producto son marcas
registradas o marcas registradas de sus dueños respectivos. Hecho en China. Reservados todos los derechos. Las características,
el aspecto y las especicaciones del producto pueden ser objeto de modicación sin previo aviso. Por favor guarde esta información
para su consulta en el futuro.
TM y © 2012 Nintendo. Con licencia de Nintendo.
Mad Catz is a publicly traded company on the TSX/NYSE MKT, symbol MCZ.
Les actions de Mad Catz sont cotées en bourse sur le TSX/NYSE MKT sous le symbole MCZ.
