True FUSE XL-1100 User manual

OWNER’S
MANUAL
Model # FUSE XL-1100
Revision 021820
Fuse XL-1100
Lat Pulldown

Strength
Fuse XL-1100
Page # 2 of 34
True Fitness Technology • O’Fallon, MO • Phone: [phone] • Truetness.com
IMPORTANT:
All products shown are prototype. Actual product delivered may vary.
Product specications, features & soware are subject to change without notice.
For the most up-to-date owner’s manual please visit www.truetness.com.
For documents in additional languages please visit www.truetness.com/resources/document-library/
IMPORTANTE:
Todos los productos mostrados son prototipos. La realidad el producto suministrado puede diferir.
Especicaciones de productos, características y soware están sujetas a cambios sin previo aviso.
Para la más actualizada de este manual del propietario, por favor visite www.truetness.com
Para los documentos en otros idiomas, por favor visite www.truetness.com/resources/document-library/
IMPORTANT: Tous les produits présentés sont prototype. Le produit réel livré peut varier. Spécications du
produit, caractéristiques et logiciels sont sujettes à modication sans préavis. Pour la plus à jour le manuel du
propriétaire s'il vous plaît visitez www.truetness.com. Pour documents dans des langues supplémentaires,
veuillez www.truetness.com/resources/document-library/ de visite
重要提示： 显示所有产品的原型。实际交付的产品可能有所不同产品规格，功能和软件如有更改，恕不另
行通知迄今为止对于大多数的使用说明书，请访问www.true󽘀tness.com 对于其他语言的文档，请访问
www.true󽘀tness.com/resources/document-library/
ھام:
جمیع المنتجات المعروضة ھي النموذج. قد تختلف المنتج الفعلي تسلیمھا.
مواصفات المنتج، والمیزات والبرامج قابلة للتغییر دون إشعار.
لمعظم ما یصل حتى الآن دلیل المالك یرجى زیارة www.truetness.com.
للمستندات في لغات إضافیة، یرجى زیارة www.truetness.com/resources/document-library/
WICHTIG: Alle hier gezeigten Produkte sind Prototypen. Das tatsächliche Produkt ausgeliefert wird, kann
variieren. Produkt-Spezikationen, Funktionen und Soware können sich ohne vorherige Ankündigung
ändern. In den meisten Fällen bis zu Bedienungsanleitung Bisher besuchen Sie bitte www.truetness.com. Für
Dokumente in weiteren Sprachen nden Sie unter www.truetness.com/resources/document-library/
BELANGRIJK: Alle getoonde producten zijn prototype. Daadwerkelijke product geleverd kan verschillen.
Product specicaties, eigenschappen & soware zijn onderhevig aan verandering zonder kennisgeving. Voor
de meest actuele handleiding van de eigenaar kunt u terecht www.truetness.com. Voor documenten in andere
talen kunt u terecht op www.truetness.com/resources/document-library/
:    .  ,   .
 ,        
 .         
 ,  www.truetness.com
.    , ,  www.truetness.com/resources/document-library/

Strength
Fuse XL-1100
Page # 3 of 34
True Fitness Technology • O’Fallon, MO • Phone: [phone] • Truetness.com
A MESSAGE TO OUR CUSTOMERS
Frank Trulaske began TRUE Fitness® over thirty-ve year ago with the simple philosophy of delivering superior
tness products, service, and support. Today, TRUE is the global leader in premium tness equipment for the
commercial and residential markets. Our goal is to be the leader in technology, innovation, performance, safety
and style. TRUE has received many awards for its product over the years and remains the benchmark for the
industry. Fitness facilities and consumers invest in TRUE products for their durable commercial platforms used
in all its products, both commercial and residential alike.
e proud manufacturing tradition of quality and the culture of innovation at TRUE have given rise to a full line
of extraordinary cardio and strength equipment. As a result, people all over the world are beneting from the
TRUE experience. Innovation across the full product line has made TRUE successful and is a trademark of the
TRUE heritage. TRUE’s patented Heart Rate Control technology is just one of the remarkable ways we deliver
simple and superior performance every user can enjoy, and most importantly, use to achieve personal health and
tness goals.
At the heart of our success is the relentless and systematic life testing of both our products and their components.
We have dedicated employees who understand our philosophy is to deliver the best products in the world.
Our goal is to deliver the world’s best premium equipment for our customers’ health and tness solutions.

Strength
Fuse XL-1100
Page # 4 of 34
True Fitness Technology • O’Fallon, MO • Phone: [phone] • Truetness.com
Table of Contents
CHAPTER 1: SAFETY INSTRUCTIONS ..........................................................................................................................5
• COMPLIANCES: ............................................................................................................................9
• COMMERICAL MAINTENANCE SCHEDULE: .....................................................................9
CHAPTER 2: ASSEMBLY GUIDE ...................................................................................................................................10
• MACHINE SPECIFICATIONS: .................................................................................................10
• REQUIRED TOOLS:....................................................................................................................11
• PRE-ASSEMBLY CHECKLIST:..................................................................................................12
• ASSEMBLY STEPS: ......................................................................................................................14
• CARE & MAINTENANCE: ........................................................................................................22
CHAPTER 3: CARE & MAINTENANCE.......................................................................................................................22
• DAILY INSPECTION & MAINTENANCE:.............................................................................22
• WEEKLY INSPECTION & MAINTENANCE:........................................................................22
• OTHER SCHEDULED PREVENTIVE MAINTENANCE: ...................................................23
• CLEANING THE EQUIPMENT: ..............................................................................................23
• CABLE INSPECTION & MAINTENANCE:............................................................................24
CHAPTER 4: CUSTOMER SERVICE..............................................................................................................................26
• CONTACTING SERVICE:..........................................................................................................26
• CONTACTING SALES:...............................................................................................................26
• REPORTING FREIGHT OR PARTS DAMAGE:.....................................................................27
CHAPTER 5: ADDITIONAL INFORMATION:............................................................................................................30

Strength
Fuse XL-1100
Page # 5 of 34
True Fitness Technology • O’Fallon, MO • Phone: [phone] • Truetness.com
CHAPTER 1: SAFETY INSTRUCTIONS
4
FF AACCIILLIITTYY AANNDD UU SSEERR SS AAFFEETTYY PP RREECCAAUUTTIIOONNSS
1. Review and understand all of the warning labels affixed to this machine and on the facility
safety sign.
2. Be certain that the machine operation is understood before it is used. Refer tothe
instructional procedure label affixed to the machine.
3. Make sure all usersare properly trained on how to use this equipment. If this machine is
being used in a commercial setting, end users may not have access tothis owners manual. It is
the responsibility ofthe facility toinstruct users as tothe proper usage of the equipment as well
as making them aware of potential hazards. Maximum user weight is300 lbs (136 kg) unless
otherwise stated in the manual.
4. Use each machine only for the intended exercise. Do not allow anyone to invent exercises not
included on the instructional procedure label or the intended use Label.
5. Do not modify the machine.
6. This equipment meets industry safety standards for stability when used for the intended
exercise. Do not allow straps, resistance bands or other means tobeattached to the framework
of this machine toperform stretching or body weight exercises. This can result in machine
instability and lead to serious crushing injuries.
7. Keep children away from this equipment. Adults should closely supervise use by teenagers.
8. It is recommended that users receive a thorough medical exam before commencing an
exercise program. All medical issues should bereviewed to ensure that weight training will not
aggravate pre-existing medical conditions.
9. If the machine appears damaged or inoperable, contact a facility staff member to place an
“OUT OF ORDER, DO NOT USE” sign on the machine until it is repaired. Only use TRUE
supplied replacement components to service this machine.
10.
I nstruct users not to wearloose or dangling clothes or have headphone wires hanging
when using this equipment.
11. Do notattempt to free anyjammed assemblies byyourself as this maycause injury.
12. On Plate Loaded and Free Weight machines:
12a. Use of spotter(s). Instruct users to seek the advice of the facility staff as to the
appropriate use of spotters when lifting. More than one spotter may be required
depending upon the amount of weight being lifted.
12b. Instruct users to load weight plates evenly and carefully to avoid tipping equipment
and crushing injuries.
12c. If the machine is equipped with safety stops or catches, inspect them and verify their
proper operation before use and make sure they are securely in place before using or
exiting the machine. Be certain members are instructed on how to operate and adjust
all safety mechanisms.
SAFETY
