STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • (636)240-2400 • Fax (636)272-2408 • (800)325-6152 • Intl. Fax# (001)636-272-7546 • www.truemfg.com
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
WARRANTY
One year warranty on
all parts and labor.
(U.S.A. only) TR2HRT-2S-2S TFQY97E TFQY97S TFQY97P TFQY973
TR2HRT-2S-2S
DESIGN
• True’s solid door roll-thru heated
cabinets are designed with enduring
quality that protects your long term
investment.
HEATER SYSTEM
• Cabinet is designed to provide holding
temperatures of 80°F to 180°F (26.6°C
to 82.2°C). Heating system controlled
by exterior on/off switch and
temperature control dial.
• Two (2) stainless steel (for corrosion
resistance), finned tube heating
elements (1000 watts each) per section
for uniform generation of electric
heat. Cabinet comes with a total of
4000 watts.
• Equipped with low-velocity fans to
assure even temperature distribution
throughout the cabinet. Fans are
controlled by exterior on/off switch.
• Manually controlled vent located
on top of the cabinet for positive
humidity control.
• 12" x 20" (305 mm x 508 mm) pan for
water included, if additional humidity
required.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel
doors, front, back and bottom.
Stainless steel sides.
• Interior - 300 series stainless steel liner
and floor.
• Stainless steel breaker caps.
• Insulation - entire cabinet structure
and solid doors are foamed-in-
place using high density, CFC free,
polyurethane insulation.
• One (1) heavy gauge stainless steel
ramp (per door).
• Designed to accept roll-in racks
(inboard castors) with maximum
dimensions of 27"L x 29"D x 66"H
(686 mm x 737 mm x 1677 mm).
DOORS
• 300 series stainless steel exterior and
liner. Doors open within cabinet
dimension.
• Door locks standard.
• Wiper gaskets for positive seal,
reversible.
• Lifetime guaranteed recessed door
handles. Each door fitted with 12"
(305 mm) long recessed handle that
is foamed-in-place with a sheet
metal interlock to ensure permanent
attachment.
• Three (3) lifetime guaranteed, cam-
lift hinges per door. Full 180° open
capability with a stay open feature at
120°.
• Magnetic door gaskets of one piece
construction, removable without tools
for ease of cleaning.
• Doors are field reversible.
LIGHTING
• Incandescent interior lighting; lights
activated by exterior on/off switch.
Safety shielded.
MODEL FEATURES
• Exterior dial thermometer; accurate
direct reading of internal cabinet
temperature.
• Designed to hold warm baked or
cooked food. Cabinet is not designed
to heat ambient or cold product.
• Interior bumpers protect cabinet walls
from abuse caused by roll-in carts.
• NSF-4 compliant for open food
product.
ELECTRICAL
• True requires that a sole use circuit be
dedicated for the unit.
• Unit comes with 4 feed wires
(including ground) to be hardwired
at installation site to a 115/208-240/60
Hz. single phase, 20 amp dedicated
outlet.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒Metal door handles (factory installed).
❒Electronic temperature control
(factory installed).
❒Correctional facilities options.
ELEVATION PLAN VIEW
TR Specifications Series:
Roll-Thru Solid Door
Heated Cabinet
833/4"
(2128 mm)
843/4"
(2153 mm)
367/8"
(937 mm)
30"
(762 mm)
68"
(1728 mm)
30"
(762 mm)
Feed Wire Location
1"
(26 mm)
Feed Wire
Location
967/8"
(2461 mm)
11/32"
(27 mm)
Front of Cabinet
RIGHT VIEW
453/8"
(1153 mm)
41/4"
(108 mm)
41/4"
(108 mm)
Feed Wire Location
