Trust MAIN SOCKET SWITCH AC-3000 User manual

www.trustsmarthome.com

AC-3000 MAINS SOCKET SWITCH
1
COMPATIBILITY
This receiver works with all Trust SmartHome
transmitters.
FUNCTIONALITY
Wall socket on/o receiver for switching lights or
electronic devices.
WIRELESS RADIO SIGNAL
• The 433.92 MHz radio signal passes through walls, windows and doors.
• Indoor range: up to 30 m. Outdoor range: up to 70 m. (optimal conditions)
• The range is strongly dependent on local conditions, such as the presence of metals. For example,
the thin metal coating in Low-emissivity (Low-E) glass has a negative impact on the range of radio
signals.
• There may be restrictions on the use of this device outside the EU. If applicable, check whether this
device complies with local directives.
TECHNICAL SPECIFICATIONS
• Power supply input
• Maximum load
• RF frequency
• RF range
• Standby power consumption
• Memory addresses
220-240 VAC 50 Hz
3000 Watt
433.92 MHz
Up to 30 m indoor/70 m outdoor (optimal conditions)
0.5 Watt
6
Read these simple guidelines. Not following them may be dangerous and faulty installation will
invalidate any warranty that may apply to this product.

AC-3000 MAINS SOCKET SWITCH
2
MAXIMUM LOAD
Never connect lights or equipment that exceed
the maximum load of the receiver, as it can result
in defects, a short circuit or fire.
SHOCK HAZARD
Exercise caution when installing a receiver.
Voltage may be present, even when a receiver is
switched o.
LIFE-SUPPORT
Never use Trust SmartHome products for life-
support systems or other applications in which
equipment malfunctions can have life-threatening
consequences.
INTERFERENCE
All wireless devices may be subject to
interference, which could aect performance. The
minimum distance between 2 receivers should be
at least 50 cm.
REPAIRING
Do not attempt to repair this product. There are
no user-serviceable parts inside.
WATER-RESISTANCE
This product is not water-resistant. Keep it dry.
Moisture will corrode the inner electronics and
can result in a short circuit, defects and shock
hazard.
CLEANING
Use a dry cloth to clean this product. Do not use
harsh chemicals, cleaning solvents, or strong
detergents.
HANDLING
Do not drop, knock, or shake the device. Rough
handling can break internal circuit boards and fine
mechanics.
ENVIRONMENT
Do not expose the product to excessive heat
or cold, as it can damage or shorten the life of
electronic circuit boards.

AC-3000 MAINS SOCKET SWITCH
3
1. Connect lamp/device and place receiver 2. Activate learn-mode
Press the learn-button on the receiver for
1 second. The learn-mode will be active for
15 seconds, during which the LED-indicator will
blink slowly.
First check if the lamp or device is turned on. Then
plug the lamp or device into the receiver and
plug the receiver into a socket. Do not exceed the
maximum load: 3000 W.
1 sec.

2x

AC-3000 MAINS SOCKET SWITCH
5
(1) Press ON to switch the receiver on.
(2) Press OFF to switch the receiver o.
5. Manual operation with a Trust SmartHome transmitter

AC-3000 MAINS SOCKET SWITCH
8

AC-3000 MAINS SOCKET SWITCH
10
If possible, dispose of this product at a recycling center. Do not dispose of this product with the
household waste. Visit www.trustsmarthome.com for more information.
Warranty
This product is covered by the legal warranty that applies to your country and it begins on the day of
purchase. For additional information, visit: www.trustsmarthome.com/warranty
Copyright
The contents of the “Manual” is subject to copyright protection. Without prior written permission,
reproducing or copying is prohibited. Information in these documents is subject to change without
prior notice. Check www. trustsmarthome.com for updates.
EN 61000-4-4:2004
EN 61000-4-5:2006
EN 61000-4-6:2009
EN 61000-4-11:2004
IEC 1000-2-2:1990
