Trust SECURITY PLUS-LINE ALMDT-2000 User manual

SECURITY PLUS-LINE
ALMDT-2000
ALMDT2000 INFRARED MOTION SENSOR
Item 71114 Version 1.0
Visit www.trust.com
for the latest instructions
USER MANUAL
MULTI LANGUAGE

2
4
1
3
DEL SET
DEL SET
Red LED indicator
DEL SET
SET
2 sec
OTHER

6
8
5
7
Tamper switch
120
DEL SET
DEL
2 sec

9
DEL SET
DEL SET
DEL SET
DEL DEL DEL
2 sec 4 sec
1 sec

1
ALMDT-2000 INFRARED MOTION SENSOR
1. Place batteries
Open the battery slot on the back side of the motion sensor by pushing the pull-tab down and
removing the battery cover. Insert two AA 1,5V Alkaline batteries as shown above. Observe the correct
polarity of the batteries (place plus and minus on the correct side). Close the battery slot.
2. LED indicator
The sensor has a LED indicator in the detection window. The LED behaviour is as followed:
Confirm pair: LED will blink 5 times
Confirm unpair: LED will blink 5 times
Low battery: LED will blink 3x every 6 sec
3. Pairing the ALMDT to Siren
Consult the manual of the Siren to activate the learn mode. Send (while the learn mode of the Siren is
active) a connect-signal by pressing the SET button for 2 seconds with a sharp object on the back of
the sensor. The LED indicator will flash 5x to confirm that the pairing has been done successfully.
4. Mounting the ALMDT
Because the motion sensor is wireless, it can be easily placed in your house. Mount the backplate of
the motion sensor on a flat surface and secure it with screws. (Screws are included).
5. Place ALMDT on the backplate
Place the ALMDT on the backplate. Make sure that the backplate is fitted in the location of the tamper
switch. This is a switch that prevents the sensor from being removed when it is mounted. When the
sensor is removed from the backplate and the Siren is armed the tamper switch will activate the alarm
immediately.
6. Secure the ALMDT
When the ALMDT is placed on the backplate pull it down untill you hear a click to secure it and lock the
tamper switch.
Note: After arming the Siren it is possible to move in front of the sensor for 1 min. It takes ~1.5 minute
before the sensor will be completely active.
EN

ALMDT-2000 INFRARED MOTION SENSOR
2
7. Detection angle
De horizontal detection angle of the sensor is max. ~120° and the vertical detection angle is max ~62°.
Within these angles movements will be detected by the sensor.
Note: After a motion has been detected by the sensor it needs about 6-8 sec to initialize before a
new motion can be detected.
8. Unpairing ALMDT
Consult the manual of the Siren to activate the learn mode. Send (while the learn mode of the Siren is
active) a disconnect-signal by pressing the DEL button with a sharp object on the back of the ALMDT.
The LED indicator will flash 5x to confirm that the unpairing has been done successfully.
Note: When the sensor is not used unpair it from the Siren first before removing it.
9. Delete ALMDT memory
To delete the memory of the ALMDT press the DEL button for 2 seconds with a sharp object (untill the
LED starts to blink). Release the button and press the DEL button again for 4 seconds. (untill the LED
starts to blink fast). Press the DEL button shortly to delete the memory of the ALMDT. The LED will
blink 5x to confirm the memory has been deleted.
EN

SECURITY PLUS-LINE
ALMDT-2000
ALMDT-2000 INFRARED MOTION SENSOR
Item 71114 Version 1.0
Visit www.trust.com
for the latest instructions
IMPORTANT INFORMATION
MULTI LANGUAGE

ALMDT-2000 INFRARED MOTION SENSOR
1
EN
Legal information
CE: Trust declares this device complies with the Directives as listed in Section 2 of this document.
WEEE: Dispose of the device at a recycling centre. More information: www.trust.com
Warranty information: www.trust.com/warranty
WIRELESS SIGNAL
• The 868 MHz signal passes through walls, windows and doors.
• Range up to 120 m (under optimal conditions).
• The range depends on local conditions, such as the presence of metals. The metal particles in for example, double
glazing (HR glass), can provide a reduction in the range of wireless signals.
• There may be restrictions on the use of this device outside the EU. Check, if applicable, whether this device meets local
regulations.
Read these simple instructions. Failure to follow these instructions can be dangerous.
Incorrect installation will void any warranty on this product.
TECHNICAL SPECIFICATIONS
• Battery
• Battery life
• Battery low indication
• Frequency
• RF Range
• Detection range
• Detection angle
2x 1,5V AA alkaline battery (not included)
18 months stand-by
LED will blink 3 times every 6 sec
868 MHz 2-way communication
Up to 120 m (under optimal conditions)
± 15 m
Max. 120⁰ horizontal and Max. 62⁰ vertical
COMPATIBILITY
The sensor works with the
ALSIR-2000.
FUNCTIONALITY
Infrared motion sensor for triggering the ALSIR-2000.
SMARTPHONE/TABLET FUNCTIONS
By combining this product with the OCTOPUS Control station, you can also set your alarm on / o via your tablet and / or
smartphone and receive push notifications when you are not at home.
For more information visit trust.com/71110

ALMDT-2000 INFRARED MOTION SENSOR
2
EN
BATTERY
Remove the battery from the device if it is not used for a
long time. Extreme temperatures reduce the capacity and
lifetime of the battery.
Replace the battery when the LED will blink 3 times every 6
sec. Batteries should not be chopped into pieces or burned.
Dispose of batteries according to local regulations. Deliver
them for the possibility to reuse. Do not throw batteries
away with the normal household waste.
LIFE SUPPORT
Never use Trust SmartHome products for life support
systems or other applications where failures can have life-
threatening consequences.
INTERFERENCE
Interference can aect the operation of all
broadcast transmitters and receivers negatively. The
distance between 2 receivers or transmitters should be at
least 50 cm.
REPAIRS
Do not try to repair this product yourself. The device contains
no serviceable parts for the user.
WATER-RESISTANT
This product is not water-resistant.
CLEANING
Clean this product with a dry cloth. Do not use harsh
chemicals, cleaning solvents or strong detergents.
HANDLING
Do not drop the device, bump the device against something
or shake it. Rough handling can damage internal circuit
boards and fine mechanics.
MEMORY
The sensor can save up to 8 devices in its memory.
PETS
The infrared motion sensor can be triggered by pets.
ENVIRONMENT
The product should not be exposed to extreme heat or
cold. This can damage the circuit boards and batteries or
shorten its life.
DISCLAIMER
This product is a basic deterrent against intruders.
However, it remains the responsibility of the end-user to
adequately protect their home against break-ins. Therefor
Trust cannot be held responsible or liable for any damages
resulting from break-ins, trespassing, unauthorized access
or vandalism.

ALMDT-2000 INFRARED MOTION SENSOR
50
Declaration of conformity
Trust International B.V. declares that the
TrusT smarThome
-product:
model: ALMDT-2000 Infrared motion sensor
item number: 71114
intended use: Indoor
is in compliance with the essential requirements and other relevant provisions of the following directives:
EMC Directive (2014/30/EU), Low Voltage Directive (2014/35/EU), ROHS Directive (2011/65/EC), R&TTE
Directive (1999/5/EC). The product is compatible with the following norms/standards:
Manufacturer/Authorised representative,
H. Donker, Procurement Director
Dordrecht, April 28 2016
EN
Trust International B.V.
LAAN VAN BARCELONA 600
3317DD DORDRECHT
NETHERLANDS
EN 300-220-1 V2.4.1 (2012)
EN 300-220-2 V2.4.2 (2012)
EN 301489-1 V1.9.2 (2011)
EN 301489-3 V1.6.1 (2013)
EN 60950-1: 2006+A11: 2009+A1 2010+A12:
2011+A2 2013
EN 55014-1 : 2006+A1 : 2009+A2: 2011
EN 55014-2: 1997+A1: 2001 +A2: 2008
EN 50581: 2012
