Tsun TSOL-M350 User manual

TSOL-M350
TSOL-M400
TSOL-M800
TSOL-M1600
TSUNESS Co., Ltd.
STORE THE FUTURE
User Manual

and other TSUNESS trademarks are trademarks of TSUNESS Co., Ltd. All other
trademarks and trade names mentioned in this document are the property of their
respective holders.
TSUNESS Co., Ltd makes no representations, express or implied, with respect to this
documentation or any of the equipment and / or software it may describe, including
(with no limitation) any implied warranties of utility, merchantability, or fitness for any
particular purpose.
All such warranties are expressly disclaimed. Neither TSUNESS nor its distributors or
dealers shall be liable for any indirect, incidental, or consequential damages under any
circumstances. (The exclusion of implied warranties may not apply in all cases under
some statutes, and thus the above exclusion may not apply.)
Specifications are subject to change without notice. Every attempt has been made to
make this document complete, accurate and up-to-date. Readers are cautioned,
however, that TSUNESS reserves the right to make changes without notice and shall not
be responsible for any damages, including indirect, incidental or consequential
damages, caused by reliance on the material presented, including, but not limited to,
omissions, typographical errors, arithmetical errors or listing errors in the content
material.
All trademarks are recognized even if these are not marked separately. Missing
designations do not mean that a product or brand is not a registered trademark. All
trademarks are recognized as the property of their respective owners.
Product information is subject to change without notice. User documentation is updated
frequently; Check www.tsun-ess.com-for the latest information. To ensure optimal
reliability and to meet warranty requirements, the TSUNESS-Microinverter must be
installed according to the instructions in this manual. For warranty text refer to
www.tsun-ess.com.
TSOL-M350/M400/M800/M1600
www.tsun-ess.com
Trademarks and Permissions
Audience
This manual is intended for use by professional installation and maintenance personnel.
© 2018 TSUNESS Co., Ltd. All rights reserved.

www.tsun-ess.com
CONTENT
Read This First 1
4
Important Safety Information 1
Product Label 2
Warning 3
System Introduction
Product Description 5
Installation of Micro Inverter 7
Check Installation Environment 7
Installation Position 8
Step 1. Make an Installation Map 8
Step 2. Install Micro Inverter 9
Step 3. Connect AC Cable 10
Step 4. Connect AC End Cable 12
Step 5. Connect PV Module 15
Step 6. Start the System 16
Maintenance Guide 17
Routine Maintenance 17
Storage and Dismantling 18
Warranty 19
Distributor Responsibility 20
Exclusions 19
Miscellaneous 21
Contact 21
TSOL-M350/M400/M800/M1600

1
www.tsun-ess.com
Dear customer, thank you for choosing the TSOL micro inverter from TSUNESS. We hope
you will find our products meet your needs for renewable energy. Meantime, we
appreciate your feedback regarding our products.
A solar micro inverter, or simply micro inverter, is a plug-and-play device used in photo-
voltaics, that converts direct current (DC) generated by a single solar module to
alternating current (AC). The main advantage is that small amounts of shading, debris or
snow lines on any single solar module, or even a complete module failure, do not
disproportionately reduce the output of the entire array. Each micro inverter harvests
optimum power by performing maximum power point tracking (MPPT) for its connected
module. Simplicity in system design, lower amperage wires, simplified stock manage-
ment, and added safety are other factors introduced with the micro inverter solution.
This manual contains important instructions for TSOL-M350/400/800/1600micro
inverters and must be read in its entirety before installing or commissioning the
equipment. For safety, only qualified technicians, who have received training or have
demonstrated skills can install and maintain this micro inverter under the guide of this
document.
During installation, testing and inspection, adherence to all the handling and safety
instructions is mandatory. Failure to do so may result in injury or loss of life and damage
to the equipment.
Read This First
Important Safety Information
TSOL-M350/M400/M800/M1600

The following safety symbols are used in this document. Familiarise yourself with the
symbols and their meaning before installing or operating the system.
Indicates a hazardous situation that can result in deadly
electric shock hazards, other serious physical injury, or fire
hazards.
Indicates directions which must be fully under-stood and
followed in their entirety in order to avoid potential safety
hazards including equipment damage or personal injury.
This points out that the described operation must not be
carried out. The reader should stop, use caution and fully
understand the operations explained before proceeding.
To comply with European Directive 2012/19/EU on waste
Electrical and Electronic Equipment and its implementa-
tion as national law, electrical equipment that has
reached the end of its life must be collected separately
and returned to an approved recycling facility. Any device
no longer required must be returned to an authorized
dealer or approved collection and recycling facility.
Do not come within 8 inches (20cm) of the micro-inverter
for any length of time while it is in operation.
The inverter can become hot during operation. Avoid
contact with metal surfaces during operation.
The inverter complies with the requirements of the Low
Voltage Directive for the European Union.
Please read the installation manual first before installa-
tion, operation and maintenance.
2
The symbols on the micro-inverter are list below and illustrated in detail.
WARNING
DANGER
CAUTION
Symbol Usage
Danger to life due to high voltage in the micro inverter.
CAUTION
CE MARK
TREATMENT
DANGER
OF HIGH
VOLTAGES
BEWARE OF
HOT SURFACE
READ
MANUAL FIRST
Symbol Usage
www.tsun-ess.com
Product Label
TSOL-M350/M400/M800/M1600

Only qualified personnel should install, troubleshoot, or replace TSOL micro
inverters or the cable and accessories.
Ensure that all AC and DC are correctly wired and that none of the wires are
pinched or damaged.
When the photovoltaic array is exposed to light, it supplies a DC voltage to the
inverter.
The DC conductors of this photovoltaic system are ungrounded and may be
energized.
Always de-energize the AC branch circuit before servicing. Never disconnect
the DC connectors under load.
Do not use the equipment if any operating anomalies are found. Avoid tempo-
rary repairs.
Do not install the equipment in adverse environment conditions such as
flammable, explosive, corrosive, extreme high or low temperature, and humid.
Do not use the equipment when the safety devices do not work or are disabled.
Be aware that installation of this equipment includes risk of electric shock. Do
not install the AC junction box without first removing AC power from the
system.
Do not connect micro-inverters to the grid or energize the AC circuit(s) until you
have completed all of the installation procedures and have received prior
approval from the electrical utility company. Only qualified personnel should
connect this system to the utility grid.
Before installation, check the unit to ensure absence of any transport or
handling damage, which could affect insulation integrity or safety clearances.
Choose installation location carefully and adhere to specified cooling require-
ments. Unauthorized removal of necessary protections, improper use, incorrect
installation and operation may lead to serious safety and shock hazards or
equipment damage.
3
Warning
!
!
!
!
!
!
!
!
!
!
www.tsun-ess.com
TSOL-M350/M400/M800/M1600

All repairs should be carried out using only approved spare parts, which must
be installed in accordance with their intended use and by a licensed contractor
or authorized TSUNESS service representative. Tampering with or opening the
TSOL micro inverter will void the warranty.
The TSOL micro inverter is not protected from damage due to moisture trapped
in cabling systems. Never mate micro-inverters to cables that have been left
disconnected and exposed to wet conditions. This voids the TSUNESS warranty.
The maximum open circuit voltage of the PV module must not exceed the
specified maximum input DC voltage of the TSOL micro inverter.
You must match the DC operating voltage range of the PV module with the
allowable input voltage range of the TSOL micro-inverter.
Make sure protective sealing caps have been installed on all unused AC
connectors. Unused AC connectors are live when the system is energized by the
grid. Do not reuse sealing caps.
4
!
!
!
!
!
www.tsun-ess.com
DC
AC
Distribution Board
Meter
EarthNeutral
To Grid
GroundGround
PV1 PV2 PV3 PVn+1
TSOL-M400 TSOL-M400
PV1PV2PV3PVn+1
TSOL-M350 TSOL-M350 TSOL-M350 TSOL-M350 TSOL-M400 TSOL-M400
The TSOL-M350/M400/M800/M1600 micro inverter is used in grid-tied applications,
comprised of three key elements:
Talent web-based monitoring and analysis system.
*More information can be found in the document Talent-MG2 Monitoring System User Manual.
TSOL-M350/M400/M800/M1600 Micro inverter.
Talent-MG2 Micro inverter Monitor Device.
System Introduction
TSOL-M350/M400/M800/M1600

*More information can be found in the document TSOL-M Series Micro inverter Accessories Instroduction.
5
Product Description
www.tsun-ess.com
Item
A
B
C
D
E
Description
DC
connectors
Female
AC Connector
Male
AC Connector
LED
Mounting Hole
BEC
D
A
BEC
D
AA
BEC
D
AA
DC
AC
Distribution Board
Meter
EarthNeutral
To Grid
Ground
PV1 PV2 PVn PVn+1
TSOL-M800 TSOL-M800
Ground
Ground
PV1 PV4 PV1 PV4
PV2 PV3
TSOL-M1600
PV2 PV3
PV4
TSOL-M1600
TSOL-M350/M400/M800/M1600

6
Model
Input Data (DC)
Recommended Input Power (W)
TSOL-M400
280~440
33~48
11.5
15
350
1.52
1.59
220/230/240 ，L/N/PE
50/60
<3%
96.7%
96.5%
99.9%
<50
178 x 153 x 28
1.98
TSOL-M800
2 * 280~440
33~48
700
3.04
3.19
>0.99
96.7%
96.5%
99.9%
250 x 170 x 28
3
IP 67
Natural Convection
-40°C to 85°C
-40°C to 65°C
0-100 % condensing
2000
2.4G RF
TSOL-M1600
4 * 300~470
36~48
1500
6.52
6.82
96.7%
96.5%
99.9%
280 x 176 x 33
3.75
TSOL-M350
240~380
32~48
16~60
60
10.5
300
1.3
1.45
16 73 18
96.7%
96.5%
99.9%
178 x153 x 28
1.98
Mppt Voltage Range (V)
Operating Voltage Range (V)
Max. Input Voltage (V)
Max. Input Current (A)
Max. Input Short Circuit Current（A）
Output Data (AC)
Max. Continous Output Power (W)
Nominal Output Current (A)
Nominal Output Current (A)
Power Factor
Output Current Harmonic Distortion
Maximum Units Per 20A Branch
Efficiency
Peak Inverter Efficiency
CEC Weighted Efficiency
Nominal Mppt Efficiency
Night Time Power Consumption(mW)
Mechanical Data
Dimensions (W×H×D mm)
Weight [kg]
Type of Enclosure
Cooling
Environmental Data
Ambient Temperature Range
Internal Temperature Range
Relative Humidity
Max. Altitude Without Derating [m]
Monitor
Nominal Output Voltage (V)
Nominal Frequency (Hz)
※ The AC voltage and frequency range may vary depending on specific country grid.try grid.
www.tsun-ess.com
TSOL-M350/M400/M800/M1600

WARNING: BEFORE INSTALLATION, CHECK THE UNIT TO ENSURE ABSENCE OF ANY
TRANSPORT OR HANDLING DAMAGE, WHICH COULD AFFECT INSULATION INTEG-
RITY OR SAFETY CLEARANCES.
Choose installation location carefully and adhere to specified cooling requirements.
Unauthorized removal of necessary protections, improper use, incorrect installation and
operation may lead to serious safety and shock hazards or equipment damage.
The installation must be carried out with the equipment disconnected from the grid
(power disconnect switch open) and with the photovoltaic modules shaded or isolated.
To avoid unwanted power derating due to an increase in the internal temperature of the
inverter, do not expose it to direct sunlight.
To avoid overheating, always make sure the flow of air around the inverter is not
blocked.
Avoid electromagnetic interference that can compromise the correct operation of
electronic equipment.
For the safety of personnel and equipment, make sure the PV array is connected and
grounded with other conductor casing.
7
Installation of Micro Inverter
Check Installation Environment
Do not install in places where gasses or flammable substances may be present.
www.tsun-ess.com
Install only on structures specifically designed for photovoltaic modules (supplied by
installation technicians).
Install micro inverter underneath the photovoltaic modules so that they work in the shade.
If this condition cannot be met, the inverter could undergo derating.
Installation Position
When choosing the position of installation, comply with the following conditions:
TSOL-M350/M400/M800/M1600

8
www.tsun-ess.com
Use the blank installation map in the package to record the location of micro-inverters
according to the system design. Each cell of the map corresponds to one PV module.
The row of the table corresponds the shorter side of PV module
and the column of the table corresponds the longer side of PV
module. The direction on the upper left corner means the actual
installation orientation.
CAUTION
CAUTION
If there are more than one installation site, please make the
installation map separately and give a clearly description about
the installation site.
There are two SN labels on the backside of micro-inverter. Pick up one and stick the SN
label to the corresponding cell of the installation map according to the actual installa-
tion. As TSOL-M800 and M1600 are connected to several PV modules, the SN label
should be sticked as shown below.
Step 1. Make an installation map
Figure the SN label of micro-inverter
The finished installation map is shown as below:
Figure The installation map (TSOL-M350/M400)
A
B
C
1 2 3 4 5 6 7
012345678912032156 012345678912032156 012345678912032156 012345678912032156
012345678912032156 012345678912032156 012345678912032156 012345678912032156
TSOL-M350/M400/M800/M1600
012345678912032156
012345678912032156

9
CAUTION
In order to provide a better after-sale service, please make the
installation map carefully and keep the drawing in good
condition.
CAUTION
The distance between every two micro-inverters should meet the
length of AC cables. The length of AC cables are shown as
below:
Figure The installation map (TSOL-M800)
Figure The installation map (TSOL-M1600)
www.tsun-ess.com
Step 2. Install micro-inverter
Mark the approximate center of PV module on the frame and install the micro-inverter
with the LED side facing outside.
Model
TSOL-M350/400
TSOL-M800/1600 2.08m
1.25m
Length
A
B
C
1 2 3 4 5 6 7
012345678912032156 012345678912032156
012345678912032156 012345678912032156
A
B
C
1 2 3 4 5 6
7
012345678912032156 012345678912032156
TSOL-M350/M400/M800/M1600

10
www.tsun-ess.com
WARNING
Micro-inverter should be installed in a suitable position with
good ventilation and no directly sunshine.
Using two pairs of screws and nuts to fix the bracket holes of the micro-inverter onto the
frame.
Figure Installation example
Step 3. Connect AC cable
Every micro-inverter could be connected to the other one by its AC cables.
CAUTION
There are no screws and nuts in the package.
CAUTION According to the max current of the AC cables, there is a max
installation quantity for the micro-inverter in each cable
section.
Model
TSOL-M350
TSOL-M400
TSOL-M800
TSOL-M1600
16 pcs
18 pcs
7 pcs
3 pcs
Quantities for each cable section
TSOL-M350/M400/M800/M1600

11
www.tsun-ess.com
Figure Connect the AC cable
Plug the female AC connector of one microinverter into a male AC connector of
another micro-inverter to form a continuous AC branch circuit.
CAUTION If the AC cable is too short for installation, use an Intercon-
nection Cable (TSOL-MC200-G2, 2m) to connect two
TSOL-M1600 which are installed in one line or two
TSOL-M350/400 which are installed in two different lines.
Use Nylon cable ties to fix the AC cables onto the frame.
Figure Fix the AC cables
Figure TSOL-M1600 installed in one line
TSOL-M350/M400/M800/M1600

12
www.tsun-ess.com
Figure TSOL-M350/400 installed in two different lines
Connect the cable to the right port of the connector. The definition of the port is shown
below:
Separate the AC connector as shown below.
WARNING
Use a Connector Protective Cap (TSOL-MP-F/M) to make sure the
unused AC connector to be closed.
Figure Separate the AC connector
Step 4. Connect AC end cable
Figure Connector Protective Cap
TSOL-M350/M400/M800/M1600

13
www.tsun-ess.com
Figure Definition of the port
Figure 230/400V three-phase WYE power grid and connection of each port
If the micro-inverter is connected to 220/380 V or 230/400V or 240/415V three-phase WYE
power grid, connect the live line to port L and connect the neutral line to port N, as the
connection of single-phase power grid.
If the micro-inverter is connected to 110/220 V or 115/230V or 120/240V two-phase
split power grid, connect two live lines to port L and port N.
Figure Two-phase split power grid and connection of each port
U
t
L1
L2
L1
N
L2
240 V
U
t
L1
L2
L3
L1
L2
L3
N
230 V
PE
N
L
L: Live (Brown/Red)
N: Neutral (Blue/Black)
PE: Ground (Yellow-Green)
TSOL-M350/M400/M800/M1600

14
www.tsun-ess.com
Figure Reassemble the AC connector
Figure 127/220V three-phase WYE power grid and connection of each port
Reassemble the AC connector as shown below.
If the micro-inverter is connected to 127/220 V or 120/208V three-phase WYE power grid,
connect one live line to port L and connect another live line to port N.
Plug the AC connector of the AC end cable into the micro-inverter.
WARNING
Use AWG 12 (4 mm²) cable for AC end cable.
DANGER Make sure each cable is connected to the right port.
L1
L2
L3
N
220 V
TSOL-M350/M400/M800/M1600

15
www.tsun-ess.com
Figure Connect the AC connector
DANGER
To prevent electrical hazards, Make sure the micro-inverter
system is disconnected from the home distribution network and
the AC breaker is open.
Figure Connect the DC connector
Step 5. Connect PV module
CAUTION
There are no cables for the AC end cable in the package. The
installation technician is responsible for selecting a kind of AC
cable and connecting the micro-inverter system into the home
distribution network correctly.
DANGER
When the PV module is exposed to light, it will supply a DC
voltage to the micro-inverter.
Connect the DC cables of the PV module to the DC connectors of micro-inverter.
TSOL-M350/M400/M800/M1600

16
www.tsun-ess.com
Step 6. Start the System
CAUTION
If the DC cable is too short for installation, use a DC Extension
Cable to connect two PV modules to TSOL-M1600 which are
installed in one line.
Figure TSOL-M1600 installed in one line
While installation is all finished, turn on the main utility-grid AC circuit breaker. Your
system will start producing power after about a two-minute wait time.
The LED will flash green and red at start up. The definition of LED is shown as below.
LED
Fast Flashing Green
Slow Flashing Green
Flashing Red
Solid Red
Working normally but no communication
with the monitoring system
The power grid is abnormal
GFDI Fault
Working normally and communicate
with the monitoring system
Quantities for each cable section
TSOL-M350/M400/M800/M1600

17
For cleaning, DO NOT use rags made of filamentary material or corrosive
products that may corrode parts of the equipment or generate electro static
charges.
Avoid temporary repairs. All repairs should be carried out using only genuine
spare parts.
Maintenance Guide
Routine Maintenance
Only authorized personnel are allowed to carry out the maintenance operations
and are responsible for reporting any anomalies.
Always use the personal protective equipment provided by the employer when
carrying out maintenance.
During normal operation, check that the environmental and logistic conditions
are appropriate. Make sure that the conditions have not changed over time and
that the equipment is not exposed to adverse weather conditions and has not
been covered with foreign bodies.
DO NOT use the equipment if any problems are found, and restore the normal
conditions after the fault has been corrected.
Conduct an annual inspection on various components, and clean the
equipment with a vacuum cleaner or special brushes.
Firmware version can be checked by using the monitoring system.
Do not attempt to dismantle the Micro-inverter or make any internal repairs! In
order to preserving the integrity of safety and insulation, the Micro inverters are
not designed to allow internal repairs!
Maintenance operations must be carried out with the equipment disconnected
from the grid (AC power switch off) and the photovoltaic modules shaded or
isolated, unless otherwise indicated.
www.tsun-ess.com
TSOL-M350/M400/M800/M1600
