Tsun TSOL-MS2000 User manual

TSOL-MS1600/MS1800/MS2000
V1.0
-
1 -
TSOL-MS2000
TSOL-MS1800
TSOL-MS1600

TSOL-MS1600/MS1800/MS2000
V1.0
-
2 -
Trademarks and Permissions
TSUN and other TSUNESS trademarks are trademarks of TSUNESS Co., Ltd. All other
trademarks and trade names mentioned in this document are the property of their respective
holders.
TSUNESS Co., Ltd makes no representations, express or implied, with respect to this
documentation or any of the equipment and / or software it may describe, including (with no
limitation) any implied warranties of utility, merchantability, or fitness for any particular
purpose.
All such warranties are expressly disclaimed. Neither TSUNESS nor its distributors or dealers
shall be liable for any indirect, incidental, or consequential damages under any circumstances.
(The exclusion of implied warranties may not apply in all cases under some statutes, and thus
the above exclusion may not apply.)
Specifications are subject to change without notice. Every attempt has been made to make this
document complete, accurate and up-to-date. Readers are cautioned, however, that TSUNESS
reserves the right to make changes without notice and shall not be responsible for any
damages, including indirect, incidental or consequential damages, caused by reliance on the
material presented, including, but not limited to, omissions, typographical errors, arithmetical
errors or listing errors in the content material.
All trademarks are recognized even if these are not marked separately. Missing designations do
not mean that a product or brand is not a registered trademark. All trademarks are recognized
as the property of their respective owners.
Product information is subject to change without notice. User documentation is updated
frequently; Check www.tsun-ess.com-for the latest information. To ensure optimal reliability
and to meet warranty requirements, the TSUN Microinverter must be installed according to the
instructions in this manual. For warranty text refer to www.tsun-ess.com.
© 2022 TSUNESS Co., Ltd All rights reserved.
Audience
This manual is intended for use by professional installation and maintenance personnel.

TSOL-MS1600/MS1800/MS2000
V1.0
-
3 -
Content
Trademarks and Permissions ............................................................................................................................................- 1 -
Audience...........................................................................................................................................................................- 2 -
Content..............................................................................................................................................................................- 3 -
Read This First..................................................................................................................................................................- 4 -
Important Safety Information..................................................................................................................................................................- 4 -
Product Label..........................................................................................................................................................................................- 4 -
System Introduction..........................................................................................................................................................- 6 -
Product Description ................................................................................................................................................................................- 7 -
Datasheet ................................................................................................................................................................................................- 7 -
Microinverter Installation .................................................................................................................................................- 8 -
Pre-installation Check.............................................................................................................................................................................- 8 -
Installation Steps.....................................................................................................................................................................................- 9 -
Talent Monitoring System...............................................................................................................................................- 15 -
Installer.................................................................................................................................................................................................- 15 -
End User ...............................................................................................................................................................................................- 16 -
Remote Active Power Control........................................................................................................................................- 17 -
Self-Test Function for Italy.............................................................................................................................................- 18 -
Fault Code and Troubleshooting.....................................................................................................................................- 19 -
Maintenance Guide.........................................................................................................................................................- 20 -
Routine Maintenance ............................................................................................................................................................................- 20 -
Storage and Dismantling.......................................................................................................................................................................- 20 -
Recycling and Disposal ..................................................................................................................................................- 21 -
Warranty Service.............................................................................................................................................................- 21 -
Exclusions.............................................................................................................................................................................................- 21 -
Distributor Responsibility.....................................................................................................................................................................- 22 -

TSOL-MS1600/MS1800/MS2000
V1.0
-
4 -
Read This First
Dear customer, thank you for choosing the G3 Plus series microinverter from TSUN. We hope
you will find our products meet your needs for renewable energy. Meantime, we appreciate
your feedback regarding our products.
A solar microinverter, or simply microinverter, is a plug-and-play device used in photovoltaics,
that converts direct current (DC) generated by a single solar module to alternating current
(AC). The main advantage is that small amounts of shading, debris or snow lines on any single
solar module, or even a complete module failure, do not disproportionately reduce the output
of the entire array. Each microinverter harvests optimum power by performing maximum
power point tracking (MPPT) for its connected module. Simplicity in system design, lower
amperage wires, simplified stock management, and added safety are other factors introduced
with the microinverter solution.
This manual contains important instructions for TSOL-MS2000/MS1800/MS1600
microinverters and must be read in its entirety before installing or commissioning the
equipment. For safety, only qualified technicians, who have received training or have
demonstrated skills can install and maintain this microinverter under the guide of this
document.
Important Safety Information
During installation, testing and inspection, adherence to all the handling and safety instructions
is mandatory. Failure to do so may result in injury or loss of life and damage to the equipment.
Product Label
The following safety symbols are used in this document. Familiarize yourself with the symbols
and their meaning before installing or operating the system.
DANGER
· DANGER indicates a hazardous situation that can result in deadly electric shock hazards,
other serious physical injury, or fire hazards.
WARNING
· WARNING indicates directions which must be fully understood and followed in their
entirety in order to avoid potential safety hazards including equipment da
mage or personal
injury.

TSOL-MS1600/MS1800/MS2000
V1.0
-
5 -
CAUTION
· CAUTION indicates that the described operation must not be carried out. The reader should
stop use and fully understand the operations explained before proceeding.
The symbols on the microinverter are list below and illustrated in detail.
Symbol
Description
This device is directly connected to public grid, thus all wor
k to the
inverter shall only be carried out by qualified personnel.
The components inside the inverter will release a lot of h
eat during
operation. Do not touch metal plate housing during operating.
Please read the installation manual first before installation, op
eration and
maintenance.
This device SHALL NOT be disposed of in residential waste.
This device fulfills the requirements of the Radio Equipment Directive.
This device complies the RoHS Directive.
This device fulfills the requirements of INMETRO.
This device fulfills the requirements of ANATEL, the certificate number
is
11057-23-15833.

TSOL-MS1600/MS1800/MS2000
V1.0
-
6 -
System Introduction
The TSOL- MS2000/MS1800/MS1600 microinverter is used in grid-tied applications,
comprised of two key elements:
 TSOL- MS2000/MS1800/MS1600 Microinverter.
 Talent monitoring system.
The microinverter converts the DC electricity generated by solar panels into AC electricity
which is in accordance with the requirements of public grid and send the AC into the grid,
reduce the load pressure of the grid.
The microinverter is integrated with Wi-Fi module and connect to the home Wi-Fi router
directly. User can monitor the power generation of the system by Talent monitoring App.

TSOL-MS1600/MS1800/MS2000
V1.0
-
7 -
Product Description
A Mounting Hole D AC Cable
B Grounding Hole E Antenna
C
DC Cables
F
Status Light
Datasheet
Model TSOL-MS1600 TSOL-MS1800 TSOL-MS2000
Input Data (DC)
Recommended Module Power (W) 300 - 700+ 300 - 700+ 300 - 700+
Start-up Voltage per Input (V) 22
Rated Input Voltage (V) 42
MPPT Voltage Range per Input (V) 16~60
Max. Input Voltage per Input (V) 60
Max. Short-circuit Current per Input
(A) 25 25 25
Max. Input Current per Input (A) 16 16 16
Quantity of MPPT 4
Max. Inverter Back-feed Current to
the Array (A) 0
Output Data (AC)
Max. Output Power (VA) 1600 1800 2000
Nominal Continuous Output Power
(W) 1600 1800 2000
Nominal Output Current (A) 7 7.8 8.7
Max. Output Current (A) 8 9 10
Nominal Output Voltage/Range (V)* 220/230/240, 175 – 270, L/N/PE
Nominal Frequency (Hz)* 50/60
Power Factor >0.99 default，0.8 leading … 0.8 lagging
Output Current Harmonic Distortion <3%
Efficiency

TSOL-MS1600/MS1800/MS2000
V1.0
-
8 -
Peak Inverter Efficiency 96.7% 96.7% 96.7%
CEC Weighted Efficiency 96.5% 96.5% 96.5%
Nominal Mppt Efficiency 99.9% 99.9% 99.9%
Nighttime Power Consumption <50mW <50mW <50mW
Protection
Anti-Islanding protection Integrated
Insulation monitoring Integrated
AC surge protection TYPE II
AC overcurrent protection
Integrated
AC short-circuit protection
Integrated
AC overvoltage protection
Integrated
Over-heat protection
Integrated
Mechanical Data
Dimensions (W×H×D mm) 331 * 261 * 44
Weight [kg] 5.5
General Data
Display LED indicators; TSUNAPP+WEB
Communication built-in WiFi module
Type of Isolation
Galvanically Isolated HF Transformer
Type of Enclosure IP67
Cooling Natural convection
Operating Ambient Temperature
Range -40 ~ +65 (derating of over 50°C Ambient Temperature)
Relative Humidity 100%
Max. Operating Altitude Without
Derating [m] 2000
※The AC voltage and frequency range may vary depending on specific country grid.
TSUNESS Co., Ltd declares that the radio equipment (Micro inverter) is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at the following internet
address: https://www.tsun-ess.com/File/$random-2023-07-15-061950--45dN$MQ
OPERATING FREQUENCY (the maximum transmitted power)
2412MHz—2472MHz(EIRP ＜20dBm)
2402MHz—2480MHz(EIRP ＜10dBm)
Microinverter Installation
Pre-installation Check
Check the Package
Although TSUN’s microinverters have surpassed stringent testing and are checked before they leave

TSOL-MS1600/MS1800/MS2000
V1.0
-
9 -
the factory, it is uncertain that the microinverters may suffer damages during transportation. Please
check the package for any obvious signs of damage, and if such evidence is present, do not open the
package and contact your dealer as soon as possible.
Check the Installation Environment and Position
When choosing the position of installation, comply with the following conditions:
To avoid unwanted power derating due to an increase in the internal temperature of the inverter,
do not expose it to direct sunlight.
To avoid overheating, always make sure the flow of air around the inverter is not blocked.
Do not install in places where gasses or flammable substances may be present.
Avoid electromagnetic interference that can compromise the correct operation of electronic
equipment.
It’s recommended to install microinverter on structures underneath the photovoltaic modules so
that they work in the shade without touching the rooftop.
Use a mobile phone to check the Wi-Fi signal strength at the micro inverter installation position. If
the Wi-Fi signal is weak, try to install the micro inverter in another place with better signal, or
move the Wi-Fi router or repeater closer.
Installation Steps
DANGER
·Only qualified personnel should install, troubleshoot, or replace G3 Plus micro inverters or
the cable and accessories.
·Before installation, check the
unit to ensure absence of any transport or handling damage,
which could affect insulation integrity or safety clearances.
·Unauthorized removal of necessary protections
, improper use, incorrect installation and
operation may lead to serious safety and shock hazards or equipment damage.
·Be aware that installation of this equipment includes risk of electric shock.
Step 1. Fix the microinverter.
DANGER
·Do not install the equipment in adverse environment conditions such as flammable,
explosive, corrosive, extreme high or low temperature, and humid.
WARNING
·Choose installation location carefully and adhere to specified cooling requirements.
Micro-inverter should be installed in a suitable position with good venti
lation and no directly
sunshine.
CAUTION

TSOL-MS1600/MS1800/MS2000
V1.0
-
10
-
·There are no screws and nuts in the package.
·The distance between every two micro-inverters should meet the length of AC cab
les. The
length of AC cable is 2.5m.
Choose the best installation position. Use two pairs of screws and nuts to fix the microinverter on the
frame. Make sure that the label of microinverter should be upside.
Step 2. Connect the ground cable
WARNING
·Ensure that all the microinverters are well grounded.
·Use ɸ6 screw for the ground port.
Connect the ground cable to the enclosure of the microinverter.

TSOL-MS1600/MS1800/MS2000
V1.0
-
11
-
Step 3. Connect the AC cable of two microinverters
WARNING
·According to the max current of the AC cables, there is a max installation quantity for the
micro-inverter in each cable section.
Model
Quantities for each cable section
TSOL-MS1600 5
TSOL-MS1800
4
TSOL-MS2000 3
Every micro-inverter could be connected to the other one by its AC cables.
Plug the female AC connector of one microinverter into a male AC connector of another
micro-inverter to form a continuous AC branch circuit.
Use Nylon cable ties to fix the AC cables onto the frame.
Use a Connector Protective Cap to make sure the unused AC connector to be closed.

TSOL-MS1600/MS1800/MS2000
V1.0
-
12
-
Step 4. Connect the AC end cable of each cable section
DANGER
·Do not install the AC junction box without first removing AC power from the system.
·To prevent electrical hazards, make sure the micro-inverter system is
disconnected from the
home distribution network and the AC breaker is open.
WARNING
·Ensure that all AC cables are correctly wired and that none of the wires are pinched or
damaged.
·Use AWG 12 ( 4 mm²) cable for AC end cable.
CAUTION
·The installation technician is responsible for selecting a kind of AC cable and connecting the
micro-inverter system into the home distribution network correctly.
·The AC connecters may be provided by different suppliers. The port definitions are subject to
actual objects.
Take out the AC connector from the package. Separate the AC connector as shown below.
Get the AC cable through the shell of AC connecter and connect the cable to the right port.
The definition of the port is shown below:

TSOL-MS1600/MS1800/MS2000
V1.0
-
13
-
Reassemble the AC connector as shown below.
Plug the AC connector into the microinverter and connect the AC cable to the AC distribution box.
Step 5. Connect the DC cable
DANGER
·When photovoltaic panels are exposed to light, it provides a DC voltage to the inverter.
WARNING
·Ensure that all DC cables are correctly wired and that none of the wires are pinched or
damaged.
·The maximum open circuit vol
tage of the PV module must not exceed the specified
L: Live (Brown/Red)
N: Neutral (Blue/Black)
PE: Ground (Yellow-Green)

TSOL-MS1600/MS1800/MS2000
V1.0
-
14
-
maximum input DC voltage of the micro inverter.
CAUTION
·If the DC cable is too short for installation, use a DC Extension Cable to connect PV modules
to the microinverter.
·Use MC4 compatible DC connectors in the inverter side of DC extension cable, or get the
DC
connectors form TSUN.
·Contact PV module manufacturers for the requirements of DC connectors in the module
side
of DC extension cable.
Install the PV modules and connect the DC cable to the microinverter.
Step 6. Make an installation map
CAUTION
·If there are more than one installation site, please make the installation map separately and
give a clear description about the installation site.
·The row of the table corresponds the shorter side of PV module
and the column of the table
corresponds the longer side of PV module.
The direction on the upper left corner means the
actual installation orientation.
Take out the SN labels and installation map from the package. Paste the SN labels on the installation
map as below and complete the information of the solar plant.

TSOL-MS1600/MS1800/MS2000
V1.0
-
15
-
Step 7. Start the System
DANGER
·Only qualified personnel should connect this system to the utility grid.
CAUTION
·Do not connect the microinverter(s) to the grid, nor energize the AC circuit(s) until you have
completed all installation procedures and have received
prior approval from the electricity
utility company.
While installation is all finished, turn on the main utility-grid AC circuit breaker. Your system will
start producing power after about a two-minute wait time.
The LED will flash green and red on startup. The LED definition is shown below:
Status Indicates
Flashing Green (0.2-0.8 ) Working normally
Flashing Green (0.2-3.8) Wi-Fi abnormally
Flashing Red Working abnormally
Solid Red Fault
Talent Monitoring System
G3 Plus series microinverter has integrated monitoring module inside. The microinverter will
directly connect the router (Wi-Fi Version). Users can use the Talent APP or enter the Talent website
to monitor the microinverter.
Installer
Ask for an installer account from the distributor or TSUN.
Visit www.talent-monitoring.com to find the Talent Portal monitoring platform.

TSOL-MS1600/MS1800/MS2000
V1.0
-
16
-
Visit “Google Play” or “Apple Store” and “Talent Pro”. Download and install it in the mobile
phone.
Visit https://www.tsun-ess.com/File/2023-04-19-025439-@an-a4kS or Scan the QR code below to
find the latest User Guidance of Talent monitoring system.
User Guidance of Talent monitoring system
End User
Visit “Google Play” or “Apple Store” and “Talent Home”. Download and install it in the mobile
phone.

TSOL-MS1600/MS1800/MS2000
V1.0
-
17
-
CAUTION
·End User can also use Talent Portal or Talent Pro, but we recommend Talent Home as it is
easy to navigate.
Register a new account in Talent Home.
Visit https://www.tsun-ess.com/File/2023-04-11-062134-9@Bx_$$S or Scan the QR code below to
find the latest User Guidance of Talent Home.
User Guidance of Talent Home
Remote Active Power Control
In some countries, it might be required that the generating plants should be equipped with a logic
interface (input port) to cease the output of active power or limit active power to a regulated level.
This logic input can be the RS485 port, Ethernet port, and so on. TSUN microinverter provide a extra
power control device which contains a RS485 port for this remote active power control. For more
information, refer to the “User manual of TSUN power control device”.

TSOL-MS1600/MS1800/MS2000
V1.0
-
18
-
Self-Test Function for Italy
TSUN microinverter and Talent monitoring system provide a Self-test function for Italy market. For
more information, refer to the “User Guidance of Self-test Function”.

TSOL-MS1600/MS1800/MS2000
V1.0
-
19
-
Fault Code and Troubleshooting
Code Fault Information Troubleshooting
1 PV1VoltOver_Fault Check the voltage of PV module and make sure that the
voltage is below the maximum DC input voltage of the
microinverter.
If this fault appears continuously, please contact the TSUN
service.
2 PV2VoltOver_Fault
3 PV3VoltOver_Fault
4 PV4VoltOver_Fault
5 PV1VoltLow_Fault This warning mostly appears in the morning or at dusk. It’s
normal and will disappear automatically.
If this warning appears in the daytime, please check the
connection of PV module.
If this fault appears continuously, please contact the TSUN
service.
6 PV2VoltLow_Fault
7 PV3VoltLow_Fault
8 PV4VoltLow_Fault
9 PV1CurrOver_Fault
Disconnect the AC power to restart the microinverter.
If this fault appears continuously, please contact the TSUN
service.
10 PV2 CurrOver_Fault
11 PV3 CurrOver_Fault
12 PV4 CurrOver_Fault
13 No Utility
The AC power grid is disconnected. Check the AC power
grid.
If this fault appears continuously, please contact the TSUN
service.
14 GridVoltOverRating The AC power grid is abnormal. This fault will disappear
automatically when theAC power grid is normal.
If this fault appears continuously, please contact the TSUN
service.
15 GridVoltUnderRating
16 GridFreqOverRating
17 GridFreqUnderRating
18 OverTemp
Check the installation of microinverter. Make sure the
microinverter has a good heat dissipation。
If this fault appears continuously, please contact the TSUN
service.
19 GFDI_Fault
This is an internal fault. Disconnect theAC power to restart
the microinverter.
If this fault appears continuously, please contact the TSUN
service.
20 Fault 01 - 08 Disconnect the AC power to restart the microinverter.
If this fault appears continuously, please contact the TSUN
service.

TSOL-MS1600/MS1800/MS2000
V1.0
-
20
-
Maintenance Guide
Routine Maintenance
Only authorized personnel are allowed to carry out the maintenance operations and are
responsible for reporting any anomalies.
Always use the personal protective equipment provided by the employer when carrying out
maintenance.
During normal operation, check that the environmental and logistic conditions are appropriate.
Make sure that the conditions have not changed over time and that the equipment is not exposed
to adverse weather conditions and has not been covered with foreign bodies.
DO NOT use the equipment if any problems are found, and restore the normal conditions after
the fault has been corrected.
Conduct an annual inspection on various components, and clean the equipment with a vacuum
cleaner or special brushes.
Firmware version can be checked by using the monitoring system.
Always de-energize the AC branch circuit before servicing.
Do not attempt to dismantle the Micro-inverter or make any internal repairs! In order to
preserving the integrity of safety and insulation, the Micro inverters are not designed to allow
internal repairs!
Maintenance operations must be carried out with the equipment disconnected from the grid (AC
power switch off) and the photovoltaic modules shaded or isolated, unless otherwise indicated.
For cleaning, DO NOT use rags made of filamentary material or corrosive products that may
corrode parts of the equipment or generate electrostatic charges.
Avoid temporary repairs. All repairs should be carried out using only genuine spare parts.
Storage and Dismantling
If the equipment is not used immediately or is stored for long periods, check whether it is
correctly packed. The equipment must be stored in well-ventilated indoor areas that do not have
characteristics that might damage the components of the equipment.
Take a complete inspection when restarting after a long time or prolonged stop.
Please dispose the equipment properly after scrapping, as component parts are potentially
harmful to the environment, in accordance with the regulations in force in the country of
installation.
