Tsun TSOL-MS400 User manual

Balcony Microinverter
V1.0
-
1 -
TSOL-MS400
TSOL-MS800
TSOL-MS2000

Balcony Microinverter
V1.0
-
2 -
Trademarks and Permissions
TSUN and other TSUNESS trademarks are trademarks of TSUNESS Co., Ltd. All other
trademarks and trade names mentioned in this document are the property of their respective
holders.
TSUNESS Co., Ltd makes no representations express or implied, concerning this
documentation or any of the equipment and / or software it may describe, including (with no
limitation) any implied warranties of utility, merchantability, or fitness for any particular
purpose.
All such warranties are expressly disclaimed. Neither TSUNESS nor its distributors or dealers
shall be liable for any indirect, incidental, or consequential damages under any circumstances.
(The exclusion of implied warranties may not apply in all cases under some statutes, and thus
the above exclusion may not apply.)
Specifications are subject to change without notice. Every attempt has been made to make this
document complete, accurate, and up-to-date. Readers are cautioned, however, that TSUNESS
reserves the right to make changes without notice and shall not be responsible for any
damages, including indirect, incidental, or consequential damages, caused by reliance on the
material presented, including, but not limited to, omissions, typographical errors, arithmetical
errors or listing errors in the content material.
All trademarks are recognized even if these are not marked separately. Missing designations do
not mean that a product or brand is not a registered trademark. All trademarks are recognized
as the property of their respective owners.
Product information is subject to change without notice. User documentation is updated
frequently; Check www.tsun-ess.com for the latest information. To ensure optimal reliability
and meet warranty requirements, the TSUN Microinverter must be installed according to the
instructions in this manual. For warranty text refer to www.tsun-ess.com.
© 2022 TSUNESS Co., Ltd All rights reserved.
Audience
This manual is intended for use by professional installation and maintenance personnel.

Balcony Microinverter
V1.0
-
3 -
Content
Trademarks and Permissions ............................................................................................................................................- 1 -
Audience...........................................................................................................................................................................- 2 -
Content..............................................................................................................................................................................- 3 -
Read This First..................................................................................................................................................................- 4 -
Important Safety Information..................................................................................................................................................................- 4 -
Product Label..........................................................................................................................................................................................- 4 -
System Introduction..........................................................................................................................................................- 5 -
Product Description ................................................................................................................................................................................- 7 -
Datasheet ................................................................................................................................................................................................- 8 -
Microinverter Installation .................................................................................................................................................- 9 -
Pre-installation Check.............................................................................................................................................................................- 9 -
Installation Steps...................................................................................................................................................................................- 10 -
TSUN Monitoring System..............................................................................................................................................- 15 -
Installer.................................................................................................................................................................................................- 15 -
End User ...............................................................................................................................................................................................- 16 -
Remote Active Power Control ........................................................................................................................................- 17 -
Self-Test Function for Italy.............................................................................................................................................- 17 -
Fault Code and Troubleshooting.....................................................................................................................................- 18 -
Maintenance Guide.........................................................................................................................................................- 19 -
Routine Maintenance ............................................................................................................................................................................- 19 -
Storage and Dismantling.......................................................................................................................................................................- 19 -
Recycling and Disposal ..................................................................................................................................................- 20 -
Warranty Service.............................................................................................................................................................- 20 -
Exclusions.............................................................................................................................................................................................- 20 -
Distributor Responsibility.....................................................................................................................................................................- 21 -

Balcony Microinverter
V1.0
-
4 -
Read This First
Dear customer, thank you for choosing the Balcony microinverter from TSUN. We hope you
will find our products meet your needs for renewable energy. Meantime, we appreciate your
feedback regarding our products.
A solar microinverter, or simply microinverter, is a plug-and-play device used in photovoltaics,
that converts direct current (DC) generated by a single solar module to alternating current
(AC). The main advantage is that small amounts of shading, debris, or snow lines on any single
solar module, or even a complete module failure, do not disproportionately reduce the output
of the entire array. Each microinverter harvests optimum power by performing maximum
power point tracking (MPPT) for its connected module. Simplicity in system design, lower
amperage wires, simplified stock management, and added safety are other factors introduced
with the microinverter solution.
This manual contains important instructions for Balcony microinverters and must be read in
their entirety before installing or commissioning the equipment. For safety, only qualified
technicians, who have received training or have demonstrated skills can install and maintain
this microinverter under the guide of this document.
Important Safety Information
During installation, testing, and inspection, adherence to all the handling and safety
instructions is mandatory. Failure to do so may result in injury or loss of life and damage to the
equipment.
Product Label
The following safety symbols are used in this document. Familiarize yourself with the symbols
and their meaning before installing or operating the system.
DANGER
· DANGER indicates a hazardous situation that can result in deadly electric shock hazards,
other serious physical injury, or fire hazards.
WARNING
· WARNING indicates directions that must be fully understood and followed in their entirety
in order to avoid potential safety hazards including equipment damage or personal injury.
CAUTION
· CAUTION indicates that the described operation must not be carried out. The reader should
stop using and fully understand the operations explained before proceeding.

Balcony Microinverter
V1.0
-
5 -
The symbols on the microinverter are listed below and illustrated in detail.
Symbol Description
This device is directly connected to the public grid, thus all
work to the
inverter shall only be carried out by qualified personnel.
The components inside the inverter will release a lot of
heat during
operation. Do not touch metal plate housing during operation.
Please read the installation manual first before installation, operation,
and
maintenance.
This device SHALL NOT be disposed of in residential waste.
This device fulfills the requirements of the Radio Equipment Directive.
This device complies with the RoHS Directive.
System Introduction
The Balcony microinverter is used in grid-tied applications, comprised of two key elements:
 Balcony Microinverter.
 TSUN monitoring system.
The microinverter converts the DC electricity generated by solar panels into AC electricity
which is in accordance with the requirements of the public grid and sends the AC into the grid,
reducing the load pressure of the grid.
TSOL- MS400

Balcony Microinverter
V1.0
-
6 -
TSOL- MS800
TSOL- MS2000
The microinverter is integrated with the Wi-Fi module and connects to the home Wi-Fi router
directly. Users can monitor the power generation of the system by TSUN monitoring App.

Balcony Microinverter
V1.0
-
7 -
Product Description
TSOL- MS400
TSOL- MS800
TSOL- MS2000
A
Mounting Hole
D
AC Cable
B Grounding Hole E Antenna
C DC Cables F Status Light

Balcony Microinverter
V1.0
-
8 -
Datasheet
Model TSOL-MS400 TSOL-MS800 TSOL-MS2000
Input Data (DC)
Recommended Module Power (W) 300 ~ 550 300 ~ 550 300 - 700+
Start-up Voltage per Input (V) 22
Rated Input Voltage (V) 42
MPPT Voltage Range per Input (V) 16~60
Max. Input Voltage per Input (V) 60
Max. Short-circuit Current per Input
(A) 20 20 25
Max. Input Current per Input (A) 14 14 16
Quantity of MPPT 1 2 4
Max. Inverter Back-feed Current to
the Array (A) 0 0 0
Output Data (AC)
Max. Output Power (VA) 400 800 2000
Nominal Continuous Output Power
(W) 400 800 2000
Nominal Output Current (A) 1.74 3.48 8.7
Max. Output Current (A) 2 4 10
Nominal Output Voltage/Range (V)* 220/230/240, 175 – 270, L/N/PE
Nominal Frequency (Hz)* 50/60
Power Factor >0.99 default，0.8 leading … 0.8 lagging
Output Current Harmonic Distortion <3%
Efficiency
Peak Inverter Efficiency 96.7% 96.7% 96.7%
CEC Weighted Efficiency 96.5% 96.5% 96.5%
Nominal Mppt Efficiency 99.9% 99.9% 99.9%
Nighttime Power Consumption <50mW <50mW <50mW
Protection
Anti-Islanding protection Integrated
Insulation monitoring Integrated
AC surge protection
TYPE II
AC overcurrent protection
Integrated
AC short-circuit protection
Integrated
AC overvoltage protection
Integrated
Over-heat protection Integrated
Mechanical Data
Dimensions (W×H×D mm) 178 * 153 * 28 250 * 170 * 28 331 * 261 * 44
Weight [kg] 1.98 3 5.5
General Data
Display LED indicators; TSUN APP+WEB
Communication
built-in WiFi module
Type of Isolation
Galvanically Isolated HF Transformer

Balcony Microinverter
V1.0
-
9 -
Type of Enclosure IP67
Cooling Natural convection
Operating Ambient Temperature
Range -40 ~ +65 (derating of over 50°C Ambient Temperature)
Relative Humidity 100%
Max. Operating Altitude Without
Derating [m] 2000
※The AC voltage and frequency range may vary depending on specific country grid.
TSUNESS Co., Ltd declares that the radio equipment (Micro inverter) is in complies with Directive
2014/53/EU. The full text of the EU Declaration of Conformity is available at the following internet
address:
https://www.tsun-ess.com/File/$random-2023-07-03-091204-@2a$-97Z
https://www.tsun-ess.com/File/$random-2023-07-15-061950--45dN$MQ
OPERATING FREQUENCY (the maximum transmitted power)
2412MHz—2472MHz(EIRP ＜20dBm)
2402MHz—2480MHz(EIRP ＜10dBm)
Microinverter Installation
Pre-installation Check
Check the Package
Although TSUN’s microinverters have surpassed stringent testing and are checked before they leave
the factory, it is uncertain that the microinverters may suffer damage during transportation. Please
check the package for any obvious signs of damage, and if such evidence is present, do not open the
package and contact your dealer as soon as possible.
Check the Installation Environment and Position
When choosing the position of installation, comply with the following conditions:
To avoid unwanted power derating due to an increase in the internal temperature of the inverter,
do not expose it to direct sunlight.
To avoid overheating, always make sure the flow of air around the inverter is not blocked.
Do not install in places where gasses or flammable substances may be present.
Avoid electromagnetic interference that can compromise the correct operation of electronic
equipment.
It’s recommended to install microinverter on structures underneath the photovoltaic modules so
that they work in the shade.

Balcony Microinverter
V1.0
-
10
-
Use a mobile phone to check the Wi-Fi signal strength at the installation position. If the Wi-Fi
signal is bad, try to install the microinverter in another position or move the Wi-Fi router.
Installation Steps
DANGER
·Before installation, check the unit to ensure the absence of any transport or handling damage,
which could affect insulation integrity or safety clearances.
·Unauthorized removal of necessary protections, improper use, incorrect installation,
and
operation may lead to serious safety and shock hazards or equipment damage.
·Be aware that installation of this equipment includes the risk of electric shock.
Step 1. Install the bracket.
WARNING
·Choose the installation location carefully and adhere to specified cooling requirements.
Micro-inverter should be installed in a s
uitable position with good ventilation and no direct
sunshine.
Balcony Installation
Choose a suitable location and use a stainless steel strap with a buckle to secure the bracket to
the railing.
Wall Installation
Fix the bracket to the wall with screws in a suitable position.

Balcony Microinverter
V1.0
-
11
-
Step 2. Connect the ground cable
DANGER
·Do not install the equipment in adverse environment conditions such as flammable,
explosive, corrosive, extreme high or low temperature, and humid.
Balcony Installation
Using two pairs of screws and nuts to fix the micrioinverter on the frame. Make sure that the
label of microinverter should be upside.
Wall Installation
Using two pairs of screws and nuts to fix the micrioinverter on the frame. Make sure that the
label of microinverter should be upside.

Balcony Microinverter
V1.0
-
12
-
Step 3. Connect the ground cable.
WARNING
·Ensure that all the microinverters are well grounded.
·Use ɸ6 screw for the ground port.
Connect the ground cable to the enclosure of the microinverter.
Step 4. Connect AC end cable
WARNING
·Ensure that all AC cables are correctly wired and that none of the wires are pinched or damaged.
·Use AWG 16 (1.5 mm²) cable for AC end cable.
CAUTION
.The AC connecters may be provided by different suppliers. The port definitions are subject to actual
objects.
Separate the AC connector as shown below.
Get the AC cable through the shell of AC connector and connect the cable to the right port.
The definition of the port is shown below:

Balcony Microinverter
V1.0
-
13
-
Reassemble the AC connector as shown below.
Plug the AC connector into the microinverter and connect the AC cable to the AC distribution box.
Step 5. Connect the DC cable
DANGER
·When the photovoltaic array is exposed to light, it provides a DC voltage to the inverter.
WARNING
·Ensure that all DC cables are correctly wired and that none of the wires are pinched or
damaged.
·The maximum open circuit voltage of the PV module must not exceed the specified
maximum input DC voltage of the TSOL microinverter.
CAUTION
·If the DC cable is too short for installation, use a DC Extension Cable to connect PV modules
to the microinverter.
L: Live (Brown/Red)
N: Neutral (Blue/Black)
PE: Ground (Yellow-Green)

Balcony Microinverter
V1.0
-
14
-
·Use MC4 compatible DC connectors in the inverter side of the DC extension cable, or get the
DC connectors from TSUN.
·Contact PV module manufacturers for the requirements of the
DC connectors in the module
side of DC extension cable.
Install the PV modules and connect the DC cable to the microinverter.
Step 6. Start the System
CAUTION
·Do not connect micro-inverters to the grid or energize the AC circuit(s) until you have
completed all the installation procedures and have received prior approval from the electrical
utility company.
While installation is all finished, After plugging in the socket and connecting to the power supply.
Your system will start producing power after about a two-minute wait time.
The LED will flash green and red at start-up. The definition of LED is shown below.
Status Indicates
Flashing Green (0.2-0.8 ) Working normally
Flashing Green (0.2-3.8) WiFi abnormally
Flashing Red Working abnormally
Solid Red Fault

Balcony Microinverter
V1.0
-
15
-
TSUN Monitoring System
The Balcony microinverter has an integrated monitoring module inside. The microinverter will
directly connect to the router (Wi-Fi Version). Users can use the TSUN Smart APP or enter the
TSUN website to monitor the microinverter.
Installer
Ask for an installer account from the distributor or TSUN.
Visit pro.talent-monitoring.com to find the TSUN Monitoring and Management Portal platform.
Visit “Google Play” or “Apple Store” and “TSUN SMART”. Download and install it in the mobile
phone.
TSUN Smart
Visit https://www.tsun-ess.com/File/$random-2023-09-16-090226-V_oc_7$B or Scan the QR code
below to find the latest User Guidance of TSUN Monitoring System.

Balcony Microinverter
V1.0
-
16
-
User Guidance of TSUN Monitoring System
End User
Visit “Google Play” or “Apple Store” and “TSUN SMART”. Download and install it in the mobile
phone.
TSUN Smart
Register a new account in TSUN SMART.
Visit https://www.tsun-ess.com/File/$random-2023-09-16-090024-_912he0N or Scan the QR code
below to find the latest User Guidance of TSUN SMART.
User Guidance of TSUN Smart

Balcony Microinverter
V1.0
-
17
-
Remote Active Power Control
In some countries, it might be required that the generating plants should be equipped with a logic
interface (input port) to cease the output of active power or limit active power to a regulated level.
This logic input can be the RS485 port, Ethernet port, and so on. TSUN microinverter provides an
extra power control device that contains an RS485 port for this remote active power control. For
more information, refer to the “User Manual of TSUN power control device”.
Self-Test Function for Italy
TSUN microinverter and TSUN monitoring system provide a Self-test function for the Italy market.
For more information, refer to the “User Guidance of Self-test Function”.

Balcony Microinverter
V1.0
-
18
-
Fault Code and Troubleshooting
Code Fault Information Troubleshooting
1 PV1VoltOver_Fault
Check the voltage of the PV module and make sure that the
voltage is below the maximum DC input voltage of the
microinverter.
If this fault appears continuously, please contact the TSUN
service.
2 PV2VoltOver_Fault
3 PV1VoltLow_Fault
This warning mostly appears in the morning or at dusk. It’s
normal and will disappear automatically.
If this warning appears in the daytime, please check the
connection of the PV module.
If this fault appears continuously, please contact the TSUN
service.
4 PV2VoltLow_Fault
5 PV1CurrOver_Fault
Disconnect the AC power to restart the microinverter.
If this fault appears continuously, please contact the TSUN
service.
6 PV2 CurrOver_Fault
7 No Utility
The AC power grid is disconnected. Check the AC power
grid.
If this fault appears continuously, please contact the TSUN
service.
8 GridVoltOverRating The AC power grid is abnormal. This fault will disappear
automatically when the AC power grid is normal.
If this fault appears continuously, please contact the TSUN
service.
9 GridVoltUnderRating
10 GridFreqOverRating
11 GridFreqUnderRating
12 OverTemp
Check the installation of the microinverter. Make sure the
microinverter has good heat dissipation。
If this fault appears continuously, please contact the TSUN
service.
13 GFDI_Fault
This is an internal fault. Disconnect the AC power to restart
the microinverter.
If this fault appears continuously, please contact the TSUN
service.
14 Fault 01 - 08 Disconnect the AC power to restart the microinverter.
If this fault appears continuously, please contact the TSUN
service.

Balcony Microinverter
V1.0
-
19
-
Maintenance Guide
Routine Maintenance
Only authorized personnel are allowed to carry out the maintenance operations and are
responsible for reporting any anomalies.
Always use the personal protective equipment provided by the employer when carrying out
maintenance.
During normal operation, check that the environmental and logistic conditions are appropriate.
Make sure that the conditions have not changed over time and that the equipment is not exposed
to adverse weather conditions and has not been covered with foreign bodies.
DO NOT use the equipment if any problems are found and restore the normal conditions after
the fault has been corrected.
Conduct an annual inspection on various components and clean the equipment with a vacuum
cleaner or special brushes.
Firmware version can be checked by using the monitoring system.
Always de-energize the AC branch circuit before servicing.
Do not attempt to dismantle the Micro-inverter or make any internal repairs! To preserve the
integrity of safety and insulation, the Micro inverters are not designed to allow internal repairs!
Maintenance operations must be carried out with the equipment disconnected from the grid (AC
power switch off) and the photovoltaic modules shaded or isolated unless otherwise indicated.
For cleaning, DO NOT use rags made of filamentary material or corrosive products that may
corrode parts of the equipment or generate electrostatic charges.
Avoid temporary repairs. All repairs should be carried out using only genuine spare parts.
Storage and Dismantling
If the equipment is not used immediately or is stored for long periods, check whether it is
correctly packed. The equipment must be stored in well-ventilated indoor areas that do not have
characteristics that might damage the components of the equipment.
Take a complete inspection when restarting after a long time or prolonged stop.
Please dispose of the equipment properly after scrapping, as component parts are potentially
harmful to the environment, following the regulations in force in the country of installation.

Balcony Microinverter
V1.0
-
20
-
Recycling and Disposal
This device should not be disposed of as residential waste. A Microinverter that has reached the end
of its life is not required to be returned to the dealer. Users must find an approved collection and
recycling facility in the area.
Warranty Service
This Warranty is subject to the following conditions:
The products must have been installed and correctly commissioned by an authorized and
licensed installer. Proof may be required of correct commissioning of the Product (such as a
certificate of compliance). Claims for failures due to incorrect installation or commissioning are
not covered under this Warranty.
Where a Product or part thereof is replaced or repaired under this Warranty, the balance of the
original Warranty period will apply. The replacement product or part(s) do not carry a new
voluntary warranty.
The product must have its original serial number and rating labels intact and readable.
This Warranty does not extend to any product that has been completely or partially disassembled
or modified, except where such disassembly is carried out by TSUNESS
The terms of this Warranty cannot be amended except in writing by one of our authorized
officers.
There must have been a commissioning report signed by the end user and the installer for
product commissioning and handling instructions.
Exclusions
(a) TSUNESS makes no warranties, either expressed or implied, orally, or in writing, concerning
any other warranty coverage except those expressly stated in this limited Factory Warranty.
(b) The Factory Warranty does not cover damages that occur due to:
Transport damage;
Installation or commissioning through any person who is not an Authorized, Certified Dealer;
Failure to observe the user manual, maintenance regulations, and intervals;
Modifications, changes, or attempted repairs, except as conducted by an Authorized Dealer;
Incorrect use or inappropriate operation;
Insufficient ventilation of the Covered Product;
Failure to observe the applicable safety regulations;
Force majeure.
(c) This factory warranty does not cover cosmetic defects which do not directly influence energy
production, or degrade form, fit, and function.
(d) Claims that go beyond the scope of this limited Factory Warranty, in particular claims for
