TurboTronic airchef Pro TT-AFO14 User manual

AIR FRYER OVEN
INSTRUCTION MANUAL
TT-AFO14
www.zline-world.com
EN

Thank you for buying airchef Pro - Digital air fryer oven by TurboTronic®.
You will now be able to cook a wide assortment of food in a healthier manner
–with little or no oil!
The air fryer uses hot air, in combination with high-speed air circulation, and a
top grill to prepare your dishes quickly and easily. The ingredients are heated
from all sides, at once, and there is no need to add oil in most cases.
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY.
READ ALL INSTRUCTIONS.
When using electrical appliance, basic safety precautions should
always be followed, including the following:
Read this user manual carefully, before you use the appliance, and keep it
safely for future reference.
WARNINGS
1. NEVER immerse the main body of the appliance in water or any other liquid.
2. NEVER rinse it under the tap.
3. Do not let ingredients be in contact with the heating elements.
4. Do not fill the tray with oil as this may cause a fire hazard.
5. The surface of the appliancemay become hot during operation. Do not touch the
surface of the appliance except the door handle and the buttons. And never touch the
inside of the appliance while it is operating.
6. Check whether the voltage indicated on the appliance corresponds to the local mains
voltage in your country before connecting the appliance to mains socket.
7. Do not use the appliance if the plug, the power cord or the appliance itself is damaged.
8. This appliance is not suitable for children or for people who are either physically or
mentally handicapped or who lack experience and knowledge. Should you want anyone
else to use the appliance, that person should be properly guided on its use.
9. Place the appliance on a horizontal, level and stable surface. Keep the power cord
away from hot surfaces.
10. Do not place the appliance on or near combustible materials such as a tablecloth or
curtains.
11. Do not place the appliance against a wall or against other appliances. Leave at least
10cm free space at the back and sides and 10cm free space above the appliance. Do
not cover the appliance, air inlets and air exhaust openings.
12. Do not let the appliance operate unattended, and always unplug the appliance after
use.

13. During cooking, steam and hot air are released through the air outlet. Keep your hands
and face at a safe distance from the steam and hot air and from the air outlet. And be
careful of steam and hot air when opening the door of the appliance.
14. Immediately unplug the appliance if you see dark smoke coming out of the appliance.
Wait for the smoke emission to stop before opening the door of the appliance.
15. Let the appliance cool down completely (over 30 minutes) before cleaning. Always
remove food residues after each use to prevent smells.
Indicates to read and review instructions to understand operation and use of product.
Indicates the presence of a hazard that can cause personal injury, death or substantial
property damage if the warning included with this symbol is ignored.
Take care to avoid contact with hot surface. Always use hand protection to avoid burns.
For indoor and household use only.
SAVE THESE INSTRUCTIONS
UNIT SPECIFICATIONS
INTRODUCTION
Thank you for buying this top-quality air fryer oven. You will now be able to cook a wide
assortment of food in a healthier manner –with little or no oil!
The air fryer oven uses hot air, in combination with high-speed air circulation, and a top grill
to prepare your dishes quickly and easily. The ingredients are heated from all sides, at
once, and there is no need to add oil in most cases.
Model No.
Supply Power
Power
Capacity
Display
TT-AFO14
220-240V, 50/60Hz
1600W -1800W
14L
LED Touch
Screen

GENERAL DESCRIPTION
A: Control panel
B: Door handle
C: Glass door
D: Power cord
E: Feet
ACCESSORIES IN THE PACKAGE:
CONTROL PANEL:
Take baking tray tong
Oil Tray
Rotisserie
Fork
Mesh basket
Cage
Rack
Filter Tray

A: Return key
B: Touchable Recipe
C: Next key
D: Power
E: Start / pause
F: Light
G: Time/Temperature display
H: Time/Temperature plus
I: Time/ Temperature minus
J: Temperature key
K: Time key
L: Loudspeaker
M: DIY
N: Air Fry
O: Rotisserie

IMPORTANT
Read this user manual carefully, before you use the appliance, and keep it safely
for future reference.
Danger
- Never immerse the housing, which contains electrical components and the
heating elements, in water nor rinse it under the tap.
- Do not let any water or other liquid enter the appliance –to prevent electric
shock.
- Always put the ingredients to be fried in the cavity, to prevent it from coming into
contact with the heating elements.
- Do not cover the air inlet and the air exhaust openings while the appliance is
operating.
- Do not fill the frying tray with oil as this may cause a fire hazard.
- Never touch the inside of the appliance while it is operating.
- Check whether the voltage indicated on the appliance corresponds to the local
mains
voltage in your country before you connect the appliance.
- Do not use the appliance if the plug, the power cord or the appliance itself is
damaged.
- If the power cord is damaged, you must have it replaced at a service center
authorized by similarly qualified persons in order to avoid a hazard.
- This appliance is not suitable for children or for people who are either physically
or mentally handicapped or who lack experience and knowledge. Should you
want anyone else to use the appliance, that person should be properly guided
on its use.
- Keep the appliance and its mains cord out of the reach of children when the
appliance is switched on or is cooling down.
- Keep the mains cord away from hot surfaces.
- Do not plug in the appliance or operate the control panel with wet hands.
- Only connect the appliance to an earthed wall socket. Always make sure that
the plugis inserted into the wall socketproperly.
- Never connect this appliance to an external timer switch.
- Do not place the appliance on or near combustible materials such as a
tablecloth or curtains.
- Do not place the appliance against a wall or against other appliances. Leave at
least 10cm free space at the back and sides and 10cm free space above the
appliance. Do not place anything on top of the appliance.
- Do not use the appliance for any purpose other than described in this manual.

- Do not let the appliance operate unattended.
- During hot air frying, hot steam is released through the air exhaust openings.
Keep your hands and face at a safe distance from the steam and from the air
exhaust openings. Also be careful of hot steam and hot air when you remove
the frying tray from the appliance.
- The surface below the appliance may become hot during use.
- Immediately unplug the appliance if you see dark smoke coming out of the
appliance. Wait for the smoke emission to stop before you remove the food from
the appliance.
Caution
- Place the appliance on a horizontal, level and stable surface.
- This appliance is intended for normal household use only. It is not intended for
use in environments such as staff kitchens, offices, farms or other work
environments. Nor is it intended to be used by clients in hotels or other similar
environments.
- If the appliance is used improperly or if it is not used according to the
instructions in the user manual, the warranty becomes invalid and seller refuses
any liability for any damage that may be caused.
- Always unplug the appliance after use.
- Let the appliance cool down for approx. 30 minutes before you handle or clean
it.
- Remove burnt remnants.
BEFORE FIRST USE
1. Remove all packing material.
2. Remove any stickers or labels from the appliance –other than the rating label.
3. Thoroughly clean the frying accessories, with hot water and some liquid
washing soap using a non-abrasive sponge.
Note: Youcan also clean these parts in the dishwasher.
4. Wipe the inside and outside of the appliance with a moist cloth.
PREPARING FOR USE
1. Place the appliance on a stable, horizontal and level surface that is also heat
resistant.
2. Place the basket in the frying tray properly.
Do not fill the frying tray with oil or any other liquid.

Do not put anything on top of the appliance. This disrupts the airflow and
affects the air-frying result.
USING THE APPLIANCE
1.Turn on the power
On Plugging in the appliance, an alarm will sound and the backlight will come on
indicating the unit is active and is ready for use. The unit will activate the standby
mode after 1 second.
2. Menu selection/Temperature and time adjustment
After plugging in to the standby state, press , the LED displays 180℃and
indicates 15 minutes, at this time, you can select from the different menu options
for cooking by function button ,then touch the START /PAUSE button to
start the cook menu. You can also adjust the time and temperature by using Timer
+/- and Temperature +/- buttonto adjust thesuitable cookingtimeand temperature.
(each function program already has a time and temperature by default, see the
attached table for details.). Users can adjust the more suitable cooking time and
temperature by using Timer +/- and Temperature +/- button, as indicated.
When the timer button is touched, the time on the display flashes, at this time
you can increase or decrease the time by rotating the function button. Once the
required time has been reached, touch the temperature button as indicated by
and the temperature on the display flashes, at this time you can increase or
decrease temperature by rotating the function button,
A. The temperature control range is 50-230℃, you can touch the temperature
button as indicated . The temperature value of the digital screen will
flash, press +/- to increase or decrease the temperature, each time of the + /
- direction will result in the temperature increasing or decreasing 5℃.At
230℃, further press "+”, it will come back to a temperature of 50℃; press "-"
direction at 50℃temperature will cycle back to 230℃. In the process of

temperature control, temperature digital display will flicker on the screen. To
indicate that the temperature has been set as required, it will flicker 5 times.
B. The time range ranges between 01 to 60 min, touch when you need to
adjust the time, the time value of the digital screen will flash, Press “+” to
increase or press “-”decrease time, each time of the + / - direction time will
increase or reduce 1 min. At 60 min if you press to "+" direction, the time will
cycle back to 01 min and at 01 min, if you press "-" direction, the temperature
will cycle back to 60 min. In the process of time control, time digital display
will flicker on the screen. To indicate that the required time as been set, it will
indicate by flickering 5 times.
3. Start, pause/stop
After selecting function, set the right time and right temperature, touch to start
the appliance, the start to flicker to indicate the machine is in operation.
During the machine working process, touching the will result in the machine
stop functioning, the light will stop flickering, and the timer will stop. During
the machine working, touch button will result in the machine stopping with a
indicator beep sound and switching to the standby model.
4. Beeps sounds
When the timer winds down to 00 minutes, the cooking process stops, and the
buzzer indicates the function is done. While the timer is in operation note that the
temperature cannot be changed and the time cannot be readjusted once it has
been set.
5. Delay
When the timer winds down to 00 minutes, the heating process stops and the
machine enters the standby mode after 1 minute.
6. Lighting control
Touching thelight button duringthe working brings theinnerlight on. Touching
the light button again will result in the light switching off.
Opening the cavity door will automatically result in the light coming on and the

cooking process suspends.
7. Rotisserie function
Touch the rotisserie key during the operation will activate the rotisserie
function. Touching the key again will switch off the rotisserie function.
8.Loudspeaker Function
Touching the Loudspeaker button, the machine will be mute and the icon lamp
light. Press again the button the machine will turn on the speaker. The icon lamps
off and the will hear Beeps sounds once
9.DIY
DIY your Time and Temperature
(Temperature range: 50℃~230℃, time range: 1 minute ~1 hour)
10. Air function:
During cooking period, Adjust you Air fans speed to high or low.
Preset chart
Menu
Default time (min)
Default temperature
（℃）
FUNCTI
ON
Air fry
15
180
Chicken
30
180
Rotiss
15
210
Bagel
3
160
Bake
15
170
Roast
10
210
Pizza
15
200
Broil
5
210

Cookies
16
180
Ferment
90
40
Dehydrate
480
80
Keep warm
30
80
Reheat
3
160
Food function reference for each function pairing:
1.Air fry: Crispy food effects such as fried chicken wings, fried chicken legs, fried
fish, etc. Fan on high speed.
2.Chicken: Meat foods that take a longer time such as whole chicken, turkey,
etc. Fan on high speed.
3.Rotiss: Grilled skewers. Fan on low speed.
4.Bagel: Larger size pasta such as bread and bagels. Fan on low speed.
5.Bake: Cake category. Fan on low speed.
6.Roast: Large grams of bone-in meat such as steak, chicken chops, and pork
chops. Fan on high speed.
7.Pizza: Pizza category
8. Broil: Small grams of bone-in meat such as steak, chicken chops, and pork
chops. Fan on high speed.
9.Cookies: Cookies category. Fan on low speed.
CLEANING
Clean the appliance after every use.
1. Remove the mains plug from the wall socket and let the appliance cool down.
Note: open the door to let the appliance cool down more quickly.
2. Wipe the outside of the appliance with a moist cloth.
3. Clean the accessories with hot water, some washing liquid soap and a non-
abrasive sponge.
You can use a washing liquid to remove any remaining dirt.
1. Clean the inside of the appliance with hot water and a non-abrasive sponge.
2. Clean the heating element with a cleaning brush to remove any food residues.
STORAGE

1. Unplug the appliance and let it cool down.
2. Make sure all parts are clean and dry.
TROUBLESHOOTING
Problem
Possible cause
Solution
The air fryer oven
does not work
The appliance is not plugged
into the mains.
Put the mains plug in an earthed wall
socket.
You have not set the timer.
Turn the timer knob to the required
Preparation time to switch on the
appliance.
The ingredients fried
with the
air fryer oven is not
done.
The amount of the ingredients
in the basket is too much.
Put smaller batches of ingredients in the
basket. Smaller batches are fried more
evenly.
The set temperature is too low.
Turn the temperature control knob to the
required temperature setting (see
section 'Settings').
The preparation time is too
short.
Turn the timer knob to the required
preparation time (see section 'Settings').
The ingredients are
fried unevenly in
the air fryer oven
Certain types of the ingredients
need to be shaken halfway
through the preparation time.
Ingredients that lie on top of or across
each other (e.g., fries) need to be
shaken halfway through the preparation
time (see section 'Settings').
Fried snacks are not
crispywhen theycome
out of theairfryer
You used a type of snacks
meant to be prepared in a
traditional deep fryer.
Use oven snacks or lightly brush some
oil onto the snacks for a crispier result.
Whitesmokecomes
out of the appliance
You are preparing greasy
ingredients.
Pay attention that the temperature
is well-controlled to be under 360℃,
when you fry greasyingredients in the air
fryer.

DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2002/96/EC on Waste Electrical and
Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in the normal
unsorted municipal waste stream. Old appliances must be
collected separately in order to optimize the recovery and
recycling of the materials they contain, and reduce the impact
on human health and the environment. The crossed out “wheeled bin” symbol on
the product reminds you of your obligation, that when you dispose of the
appliance, it must be separately collected. Consumers should contact their local
authority or retailer for information concerning the correct disposal of their old
appliance.
LIMITED WARRANTY
Limited Warranty applies to purchases made from authorized retailers of
TurboTronic®.
TurboTronic®Warranty coverage applies to the original owner and to the original
product only and is not transferable.
Problem
Possible cause
Solution
The pan still contains greasy
residues from previous use.
White smoke is caused by grease
heating up in the pan. Make sure you
clean the pan properly after each use.
Freshpotatofries are
fried unevenlyin theair
fryer.
You did not soak the potato
sticks properly before you fried
them.
Soak the potato sticks in a bowl of water
for at least 30 minutes; take them out
and dry them with kitchen paper.
You did not use the right potato
type.
Use fresh potatoes and make sure they
stay firm during frying.
Freshpotatofries are
not crispywhen they
comeoutof the air
fryer.
The crispiness of the fries
depends on the amount of oil and
water in the fries.
Make sure you dry the potato sticks
properly before you coatthemwith oil.
Cut the potato into thinner sticks for a
crispier result.
Add slightly more oil for a crispier result.

TurboTronic®warrants that the unit shall be free from defects in material and
workmanship. Limited Warranty apply only when it is used under normal
household conditions and maintained according to the requirements outlined in
the Owner’s Guide, subject to the following
conditions and exclusions:
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in
TurboTronic®sole discretion, will be repaired or replaced
2. TurboTronic®reserves the right to replace the unit with one of equal or greater
value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as blending vessels, lids, cups,
blades, blender bases, removable pots, racks, pans, etc.), which require regular
maintenance and/or replacement to ensure the proper functioning of your unit,
are not covered by this warranty.
2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse, abuse, negligent handling, failure to perform
required maintenance (e.g., failure to keep the well of the motor base clear of
food spills and other debris), or damage due to mishandling in transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by TurboTronic®. These
defects include damages caused in the process of shipping, altering, or repairing
the TurboTronic®product (or any of its parts) when the repair is performed by a
repair person not authorized by TurboTronic®.
6. Products purchased, used, or operated outside Europe.
Illustrations may differ from actual product.
We are constantly striving to improve our products, therefore the specifications
contained herein are subject to change without notice.
TurboTronic®and Z-Line®are registered trademarks of Z-GLOBAL B.V.B.A®.
PRINTED IN PRC
