TurboTronic airchef Pro TT-AF32DRD User manual

2
AIR FRYER OVEN
INSTRUCTION MANUAL
www.zline-world.com
TT-AF32DRD
www.zline-world.com

3
Thank you for choosing:
AIR FRYER OVEN by TurboTronic®.
Enjoy easy home cooking, produces nutritious healthy food in a convenient and consistent fashion.
This air fryer lets you cook your favorite foods with little to no oil. same great taste. Thanks to
Rapid air technology there is no need to add oil to prepare fried foods. This technique uses the hot
360° air circulating with speed and precision to make healthier versions of your favorite fried foods.
with a temperature range of 25°C –230°C, the fryer allows you to prepare a variety of dishes from
crispy fries to juicy wings with little to no oil, Up to 80% less fat.
Save this instruction
For Household Use Only!
Indicates to read and review instructions to understand operation and use of product.
Indicates the presence of a hazard that can cause personal injury, death or substantial
property damage if the warning included with this symbol is ignored.
Take care to avoid contact with hot surface. Always use hand protection to avoid burns.
For indoor and household use only.

4
IMPORTANT SAFETY INSTRUCTIONS
When using your Electric Oven, basic safety precautions should always be observed, including the following:
Matters needing attention
In order to avoid causing harm and property loss to users and others, please be sure to read carefully and observe the
following:
1. Electric oven belongs to high-power
electrical appliances, which need to be
equipped with special socket. This product
is only for indoor use, do not put in damp
place or outdoor use.
2. It is strictly prohibited to immerse the power
cord, plug or any part of the electric oven
into the water.
3. The power cord shall not touch the hot
surface of the electric oven.
4. Do not put the electric oven near the place
of heat source such as water heater, electric
stove, microwave oven, electric oven all
around should leave the space distance of
11cm.
5. The top of the electric oven must not contact
or cover flammable items (such as curtains,
wallpaper, alcohol and other things) easy to
lead to fire.
6. In the process of use, the product should be
placed out of reach of children, and children
should not be operated or too close to the
electric oven.
7. When the electric oven is working, the
external surface temperature is high.
8. Do not touch the surface of the heating
body.
Hot surfaces symbol as below:
Use heat insulation gloves or a dish taker to
take out food.
9. The electric oven in use, do not use a metal
brush to clean the electric oven, because it
may be in contact with live parts, thereby
causing the risk of electric shock.
10. It is strictly prohibited to plug and unplug the
power cord with wet hands or clean the
socket with wet cloth.
11. Thunderstorm weather or electric oven is
not used for a long time, should pull out the
power plug.
12. Too large food, metal utensils, glass or
plastic utensils do not bake in the electric
oven, so as not to damage the electric oven
or produce danger.
13. Do not put paper, plastic, cloth and other
similar flammable items in the electric oven
heating.
14. Do not put any bags or canned goods,
except for random accessories, do not put
other items in the machine.
15. The electric oven at work, in addition to the
door handle, knob, do not contact other
parts.
16. When moving or overhauling the electric
oven, the power cord plug should be
unplugged first and the operation should be
carried out after the electric oven cools
down.
17. This electric oven is for domestic use only.
Please do not use it for commercial or
industrial use.
18. This appliance cannot be connected to the
timer or independent remote control system
under the way of operation.
19. If the power cord is damaged, in order to
avoid danger, it must be replaced by the
manufacturer, its maintenance department
or similar professional personnel.

5
Product structure

6
Product
structure
wire rack
bake tray
Air fry basket
Rotisserie handle
Rotisserie fork set Tray handle Crumb tray
Accessories: Wire rack *1,
Bake tray *1,
Air fry basket *1,
Rotisserie fork set *1,
Tray handle *1,
Crumb tray *1.
Bake tray: used for meat and other food with juice, cakes, pizzas and small food (such as corn, beans, etc.);
Wire rack: used for baking bread, muffins, frozen waffles, etc.
Air fry basket: for French fries and other food use;
Rotisserie fork set: used for roasting whole chicken or other whole food;
Rotisserie handle: used to take out the fork assembly;
Tray handle: used to take out the baked food, with the baking tray, frying basket use;
Crumb tray: used to receive the residue and oil collapse in the baking process.

Product structure
FIRST KNOB/
BUTTON
Rotate to select
recipes Press
for rotisserie
function
Function
Chart
SECONND
KNOB/
BUTTON
Rotate to adjust
temperature
Press for inner
light
THIRD
KNOB/
BUTTON
Rotate to
adjust time
Press for fan
speed
Available Functions:
TOAST, BAGEL, PIZZA, COOKIES, AIR
FRYER, BAKE, ROAST, BROIL, REHEAT,
SLOW COOKED, DEHYDRATE, PROOF
Recipe
Description
Temperature
range
Time range
Fan level
Rotisserie
TOAST
Default with 6 slices and
darkness level 4
230°C
various
LOW ,Not
Adjustable
X
BAGEL
Default with 6 slices and
darkness level 4
230°C
various
OFF, Not
Adjustable
X
BROIL
Default temperature 230°C.
Default time 10 minutes.
230°C
1-30mins
Default LOW ,
HI
X
BAKE
Default temperature 175°C.
Default time 25 minutes.
80-230°C
1-99mins
Default LOW,
HI/OFF
OFF/ON
ROAST
Default temperature 200°C.
Default time 35 minutes.
170-230°C
1min-1H
Default HI,
LOW/OFF
OFF/ON
PIZZA
Default temperature 180°C.
Default time 16 minutes.
170-230°C
1min-1H
Default LOW,
HI/ OFF
X
PROOF
Default temperature 30°C.
Default time 2 hours.
25-40°C
1min-2H
OFF
X
AIR FRY
Default temperature 200°C.
Default time 20 minutes.
80-230°C
1min-1H
Default HI, LOW
X
REHEAT
Default temperature 120°C.
Default time 6 minutes.
80-230°C
1min-1H
Default
LOW,HI/OFF
X
COOKIES
Default temperature 175°C.
Default time 11 minutes.
80-230°C
1min-1H
Default
LOW,HI/OFF
X
SLOW COOK
Default temperature HIGH.
Default time 4 hours.
HI 135°C LO
130°C
HI 2-12H LO
4-24H
Default LOW,
HI/OFF
X
DEHYDRATE
Default temperature 55°C.
Default time 8 hours.
35-80°C
Up to 72H
LOW ,Not
Adjustable
X

Operating Instruction (Except Rotisserie)
Plug unit in to power on unit
First, rotate the left knob to the desired pre-set recipe. This will pre-program the unit with time and temperature.
Using the middle knob, rotate left or right to adjust the temperature if needed
Using the right knob, rotate left or right to adjust cooking time
Once TIME and TEMP are adjusted, press START/STOP button to begin cooking
NOTE: To turn on the internal light during the cooking process, you can press the middle knob to turn on
Once TIME is expired, the unit will automatically stop cooking and beep
Using the Rotisserie Spit
With the Forks removed, force the Rotisserie Spit through the center of the food length wise
Slide the Forks onto each side of the Spit and secure them in place by tightening the two Set Screws.
NOTE: To support the food on the Rotisserie Spit, insert the Rotisserie Forks into the food at different angles
Using the Spit holder, hold the assembled Rotisserie Spit at a slight angle with the left side higher than the right side and
insert the right
side of the Spit into the Rotisserie connection inside the unit
Plug unit in to power on unit
Press the left knob to select Rotisserie function
Using the middle knob, rotate left or right to adjust the TEMP if needed
Using the right knob, rotate left or right to adjust cooking TIME
Once TIME and TEMP are adjusted, press START/STOP button to begin Cooking
NOTE: To turn on the internal light during the cooking process, you can press the middle knob to turn on
Once cooking is complete, press START/STOP to stop cooking process.
To remove cooked food, insert the Spit fork under the spit and twist right. At the same time, raise to remove the Spit from
the right slot and
then remove the food from the unit with slight lifting motion. Transfer the food to a carving board or serving plate.

Shelf Positions
NOTE: Certain foods may require different shelf positions depending on the recipe, size, amount of food to be cooked and
personal taste. Use the following information as a guide only.
There are 3 height positions that the air fryer/dehydrator basket, wire rack or the bake/broil pan may be inserted.
Use the upper shelf position for the BROIL function.
The centre shelf position is commonly used for TOAST, BAGEL, PIZZA, COOKIES, AIR FRY, and DEHYDRATE functions.
4.Use the lower shelf position for BAKE, SLOW COOK, ROAST, REHEAT and WARM functions.
WARNING: Never set the bake/broil pan directly onto the lower heating elements. Adjusting Fan Speed
Press the Right knob button to adjust the fan. A twirling fan appears on the digital display indicating the fan is turned on.
Multi press the knob to adjust the speed of the fan.
The fan maximizes convection airflow, shortens cook time and increases cooking efficiency and is available when using any
function except, TOAST, BAGEL, DEHYDRATE, and PROOF.
Before Using for The First Time
CAUTION: To protect against electric shock, do not immerse the Toaster Oven or allow cord to come into contact with water
or other liquids.
1. Read all operating instructions carefully.
2. Carefully unpack the Toaster Oven and accessories, removing all packaging materials. Remove any labels from the
outer surfaces.
3. Place your Toaster Oven on a level surface such as a countertop or table. Be sure the sides, back, and top of the
Toaster Oven are at least 4 inches away from any walls, cabinets, or objects on the counter or table.
4. To avoid scratching, marring, or discoloration, do not store anything on top of the Toaster Oven during operation.
5. Wash the air fryer/dehydrator basket, bake/broil pan, wire rack, and crumb tray in warm, soapy water. Rinse and dry
thoroughly before placing in the Toaster Oven.
6. Do not use abrasive cleaners.
7. To ensure that the Toaster Oven is free from oils used in manufacturing, it is necessary to operate the unit once,
empty.
8. Make sure the crumb tray is in place in the bottom of the Toaster Oven.
9. Plug into a 230V AC electrical wall outlet. A long audible beep will sound.
10. Press the START button; the button will illuminate indicating the Toaster Oven is ON.

9
CAUTION:
Appliance surfaces are hot during and after use. Always wear protective, insulated oven mitts on hands when touching a
hot Toaster Oven.
NOTE: The Toaster Oven will not operate until the START/CANCEL button is pressed.
NOTE: Press the red START/CANCEL button at any time to turn the Toaster Oven OFF
If no buttons are pressed within 1 minute, the backlighted digital display will turn OFF as the Toaster Oven rests in
standby mode.
Care & Cleaning Instructions
1. Unplug the Toaster Oven and allow the Toaster Oven and all accessories to cool completely before cleaning.
2. Clean the outside of the Toaster Oven with a damp cloth and dry thoroughly.
A non-abrasive liquid cleaner may be used for stubborn stains. Rinse and dry thoroughly. Do not use metal
scouring pads or abrasive cleaners that will scratch the surface.
3. Clean the interior with a mild or non-abrasive cleaner and plastic scouring pad after each use to avoid build-up.
Do not rub too hard as surface can be scratched.
4. To remove baked-on food, pour a small amount of cooking oil onto the food and allow to stand for 5 to 10
minutes. Remove the softened food with a soft cloth. Do not use steel wool, scouring pads or abrasive cleaners.
5. Rinse and dry thoroughly before closing the glass door. Clean the glass door with a cloth or sponge dampened
with warm, sudsy water. Dry thoroughly.
6. Wash the air fryer/dehydrator basket, bake/broil pan, wire rack, and crumb tray in soapy water and dry
thoroughly. Toaster Oven accessories
may be washed in the dishwasher.
7. If crumbs and spills have accumulated on the crumb tray, wipe with a damp cloth. Always dry the crumb tray
thoroughly before replacing.
8. DO NOT use abrasive cleaners or metal scouring pads to clean bake/broil pan, wire rack, wire rack, or crumb
tray. For stubborn stains, clean
with a nylon or polyester mesh pad and a mild, non-abrasive cleaner. Rinse and dry thoroughly.
CAUTION：DO NOT use spray-on or other oven cleaners. Using these types of cleaners may cause cosmetic and/or
electrical damage to the Toaster Oven.
Storing Instructions
Unplug unit, allow to cool, and clean before storing.
Slide the bake/broil assembly (wire rack and bake/broil pan) into the lower shelf position.
Store Toaster Oven in its box in a clean, dry place.
Never store appliance while it is hot or still plugged in.
Never wrap cord tightly around the appliance. Do not put any stress on the cord where it enters the unit, as it could
cause the cord to fray and break.

10
DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE),
requires that old household electrical appliances must not be disposed of in the normal unsorted
municipal waste stream. Old appliances must be collected separately in order to optimize the
recovery and recycling of the materials they contain, and reduce the impact on human health
and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance, it must be separately collected.
Consumers should contact their local authority or retailer for information concerning the correct disposal of their
old appliance.
LIMITED WARRANTY
Limited Warranty applies to purchases made from authorized retailers of TurboTronic®.
TurboTronic®Warranty coverage applies to the original owner and to the original product only and is not
transferable.
TurboTronic®warrants that the unit shall be free from defects in material and workmanship. Limited Warranty
apply only when it is used under normal household conditions and maintained according to the requirements
outlined in the Owner’s Guide, subject to the following
conditions and exclusions:
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in TurboTronic®sole discretion, will be
repaired or replaced
2. TurboTronic®reserves the right to replace the unit with one of equal or greater value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as blending vessels, lids, cups, blades, blender bases,
removable pots, racks, pans, etc.), which require regular maintenance and/or replacement to ensure the proper
functioning of your unit, are not covered by this warranty.
2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse, abuse, negligent handling, failure to perform required maintenance (e.g., failure
to keep the well of the motor base clear of food spills and other debris), or damage due to mishandling in
transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by TurboTronic®. These defects include damages caused
in the process of shipping, altering, or repairing the TurboTronic®product (or any of its parts) when the repair
is performed by a repair person not authorized by TurboTronic®.
6. Products purchased, used, or operated outside Europe.
Illustrations may differ from actual product.
We are constantly striving to improve our products, therefore the specifications contained herein are subject to
change without notice.
TurboTronic®and Z-Line®are registered trademarks of Z-GLOBAL B.V.B.A ®
PRINTED IN PRC
