TurboTronic airchefPro User manual

INSTRUCTION MANUAL
DIGITAL AIR FRYER OVEN
TT-AF8
www.zline-world.com
®
EN

Thank you for buying airchef Pro - Digital air fryer oven by TurboTronic®.
You will now be able to cook a wide assortment of food in a healthier manner – with little or no oil!
The air fryer uses hot air, in combination with high-speed air circulation, and a top grill to prepare your dishes
quickly and easily. The ingredients are heated from all sides, at once, and there is no need to add oil in most
cases.
IMPORTANT SAFEGUARDS
HOUSEHOLD USE ONLY. READ ALL INSTRUCTIONS.
When using electrical appliance, basic safety precautions should always be followed,
including the following:
Read this user manual carefully, before you use the appliance, and keep it safely for future reference.
WARNINGS
1. NEVER immerse the main body of the appliance in water or any other liquid. NEVER rinse it under
the tap.
2. Do not let ingredients be in contact with the heating elements.
3. Do not fill the tray with oil as this may cause a fire hazard.
4. The surface of the appliance may become hot during operation. Do not touch the surface of the
appliance except the door handle and the buttons. And never touch the inside of the appliance while
it is operating.
5. Check whether the voltage indicated on the appliance corresponds to the local mains voltage in your
country before connecting the appliance to mains socket.
6. Do not use the appliance if the plug, the power cord or the appliance itself is damaged.
7. This appliance is not suitable for children or for people who are either physically or mentally
handicapped or who lack experience and knowledge. Should you want anyone else to use the
appliance, that person should be properly guided on its use.
8. Place the appliance on a horizontal, level and stable surface. Keep the power cord away from hot
surfaces.
9. Do not place the appliance on or near combustible materials such as a tablecloth or curtains.
10. Do not place the appliance against a wall or against other appliances. Leave at least 10cm free space
at the back and sides and 10cm free space above the appliance. Do not cover the appliance, air inlets
and air exhaust openings.
11. Do not let the appliance operate unattended, and always unplug the appliance after use.
12. During cooking, steam and hot air are released through the air outlet. Keep your hands and face at a

safe distance from the steam and hot air and from the air outlet. And be careful of steam and hot air
when opening the door of the appliance.
13. Immediately unplug the appliance if you see dark smoke coming out of the appliance. Wait for the
smoke emission to stop before opening the door of the appliance.
14. Let the appliance cool down completely (over 30 minutes) before cleaning. Always remove food
residues after each use to prevent smells.
Indicates to read and review instructions to understand operation and use of product.
Indicates the presence of a hazard that can cause personal injury, death or substantial
property damage if the warning included with this symbol is ignored.
Take care to avoid contact with hot surface. Always use hand protection to avoid burns.
For indoor and household use only.
SAVE THESE INSTRUCTIONS

GETTING TO KNOW YOUR AIR FRYER OVEN
MAIN COMPONENTS
1. Control panel
2. Touch handle
3. Glass window
4. Pull-down door
5. Anti-slip feet
Oven Rack: Used for meat, bread, pizza etc.
Air Fryer Basket: Use the Air Fryer Basket in conjunction with the Air Fry function to optimize your cooking results.
Used for fries, wings, onion etc. It also could be used as the dehydrate basket.
Baking Pan: Used for cookies, cake, turkey etc. It can also hold the drippings from the food or oil when Air frying.
Basket Remover: Used for basket removal.
Rolling Cage: Used for french-fries, popcorn, etc. Rolling Cage can not be used independently.
FEATURES
By using all-new 360° HOT AIR CIRCULATION technology, the Air Fryer Oven can offer you more delicious and
healthier cuisine.
DOOR SENSOR
If the door is opened during cooking, the cooking will be paused, and the oven light will be lit up. When the door
is closed, resumed cooking process will be continued. Please keep the oven door closed during cooking.
Note: Don’t let the process pause for long time, it will let the oven cold down and affect the taste of food!

TECHNICAL SPECIFICATIONS
Voltage
Power
Frequency
Capacity
220~240V
1650W-1900W
50-60Hz
21L
AIRFRYER TOASTER OVEN FUNCTION REVIEW
The above default data are for reference only, the user can adjust the desired temperature and time as required.
Program
Adjustable time
range (Min)
Default time
(Min)
Adjustable
temperature
range (°C)
Default
temperature (°C)
Rotisserie
function
CHICKEN
0：01-60:00
0：30
30-230
200
YES
WINGS
0：01-60:00
0：15
30-230
200
×
DEFROST
0：01-60:00
0：10
30-230
80
×
STEAK
0：01-60:00
0:12
30-230
200
YES
HOT DOG
0：01-60:00
0:15
30-230
150
×
CAKE
0：01-60:00
0:30
30-230
180
×
VEGETABLES
0：01-60:00
0:12
30-230
180
×
PIZZA
0：01-60:00
0:16
30-230
200
×
TOAST
0：01-60:00
0:03
30-230
160
×
FRENCH FRIES
0：01-60:00
0:20
30-230
200
×
FISH
0：01-60:00
0:15
30-230
180
×
EGG TARTS
0：01-60:00
0:20
30-230
200
×
POPCORN
0：01-60:00
0:10
30-230
200
×
SKEWER
0：01-60:00
0:15
30-230
200
×
DEHYDRATE
60:00-480:00
480:00
30-230
30
×
PROOF
0：01-240:00
90:00
30-230
40
×
COOKIE
0：01-60:00
0:12
30-230
180
×
KEEP WARM
0：01-60:00
0:30
30-230
80
×

CONTROL PANEL
ON/OFF
A. After plug in, touch to turn the Air Fryer Oven On.
B. Touch to turn the Air Fryer Oven Off.
C. Touch to awake the Oven from Standby mode.
DISPLAY
There are 2 rows in the Display Panel. The upper shows TEMPERATURE
and the lower shows Time!
FUNCTION SELECTION
a) Press to select forward
b) Press to make Backward

TEMPERATURE ADJUSTMENT
a) Press , the temperature display will keep flash;
b) Press to increase temperature;
c) Press to decrease temperature;
TIME ADJUSTMENT
a) Press , the temperature display will keep flash;
b) Press to increase time;
c) Press to decrease time;
START/PAUSE
a) Press to start the selected function
b) Press to pause process while oven is working
LIGHT
Press to light up the Oven light.

BEFORE USING YOUR AIR FRYER TOASTER OVEN
1. Place the appliance on a stable, level, heat-resistant surface, away from anything that can be
damaged by heat. Keep at least 110 mm(4.33inch) distance between the electrical outlet and
the wall, furniture, etc.
2. Upon first use, it is necessary to run the oven for 18 minutes at the highest temperature (230℃)
in order to sterilize and remove any manufacturing odor. The Air fryer Toaster Oven may emit
an odor or smoke due to the heater’s protective film.
OPERATION GUIDE
POWER ON
A. Plug in, the panel will light up for 3 Seconds, then go out and the ON/OFF icon will keep
flashing.
B. Touch the ON/OFF icon to turn on the Air Fryer Toaster Oven, after a beep sound, the digital
screen will display 230 ℃ and 30min, the light of Chicken function will flash.
POWER ON
FUNCTION
START

ACCESSORIES POSITIONS
Oven Rack, Air frying Basket and Bake Pan
Accessories
Position3:
TOAST
DEHYDRATE
BAKE
VEGETABLES
PIZZA
position4:
ROAST
Position2:
TOAST
DEHYDRATE
position2:
FRENCHFRIES
CHICKENWINGS
Position1:
DEHYDRATE
OvenRack Air Fryer Basket Baking Pan
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
Rolling Cage
Great for fries, roasted nuts, popcorn and other snacks.
Use one of the included screws to secure the baking cage to the rotisserie stick at the indentation
point on the rotisserie stick.
Twist the screw to secure the baking cage to the rotisserie stick
(1) (2)
(3) (4)
Note:
• Please always keep the drip tray in the lowest layer inside the air fryer for gathering oil from fried
food.
• The ingredients inside may increase in size during the cooking process, ensure that the heated
volume of food will not touch the inside walls of the air fryer.
• Only when the door is closed, the air fryer will operate.

Function
A. Select function with icons and ;
B. Adjust temperature with icons , and
Temperature adjustment range is 30-230℃. the temperature will increase or decrease by 5℃
per move rapidly and continuously if you long time press on the temperature +, temperature will
increase by 5℃ each time, if you tap on the temperature “-“, temperature will decrease by 5℃
each time.
Note: At 230℃, press "+", the temperature will cycle back to 30℃, at 30℃, press the "-"
temperature will return to 230℃, in the process of temperature adjustment, the temperature will
be displayed on the screen flicker (no flicker in the process of adjustment), flashing 3 times then
indicating that the temperature has been set.
C. Adjust time with icons , and
The time adjustment range is 001-480 minutes, and the time will increase or decrease by 5
minutes per move rapidly and continuously if you long time press on the time adjust + / -, and
the time will increase or decrease by 5mins each time if you tap on + / -. In the process of time
adjustment, time digital display will flicker on the screen (no flicker during the process of
adjustment), flashing 3 times and then indicating that the time has been set.
Operating
1. Press the key to start cooking. The fan will start and the display will show the timer down
counting and the colon between H:MM will keep flashing.
2. After process ended, the oven will beep 10 times, the display will go out, the fan will stop, and
icon will keep flashing for 5 Minutes, then go to Standby mode.
CARE, CLEANING & STORAGE
Before cleaning, remove the power plug from the power outlet. Allow the oven and all accessories to cool
completely before disassembling and cleaning.
Cleaning the outer body and door

Wipe the outer body with a soft, damp sponge. A non-abrasive liquid cleanser or mild spray solution may be
used to avoid build-up of stains. Apply the cleanser to the sponge, not the oven’s surface, before cleaning.
To clean the inner glass door, use a glass cleaner or mild detergent and a soft, damp sponge or soft plastic
scouring pad. Do not use an abrasive cleanser or metal scouring pad as these will scratch the oven’s surface.
Wipe the outer door with a soft, damp cloth. Apply cleanser to the cloth, do not apply cleanser directly on to
the LED. Cleaning the LED screen surface with a dry cloth and/or abrasive cleaners may produce scratches.
WARNING: To prevent electrocution, do not immerse the appliance or power cord into
water or any other liquid.
CLEANING THE INTERIOR
To clean any spattering that may occur while cooking, wipe the walls with a soft, damp sponge. A non-
abrasive liquid cleanser or mild spray solution may be used to avoid build-up of stains. Apply the cleanser
to the sponge, not the interior, before cleaning.
WARNING: Use extreme caution when cleaning the heating elements. Allow the oven to cool
completely, and then gently rub a soft, damp sponge or cloth along the length of the heating element.
Do not use any type of cleanser or cleaning agent. Let all surfaces dry thoroughly prior to inserting
the power plug into a power outlet and turning the oven on.
CLEANING THE ACCESSORIES
Wash all accessories in warm soapy water with a soft sponge or soft plastic scouring pad. Rinse and dry
thoroughly. Do not use abrasive cleansers, metal scouring pads or metal utensils to clean any of the
accessories as they may damage the surfaces.
To extend the life of your accessories, cleaning them in the dishwasher is not recommended.
STORAGE
Ensure the oven and all accessories are clean and dry.
Ensure the door is closed.
Store the appliance in an upright position, standing level and on its supporting legs. Do not store appliance
when wet or hot. Do not store in a wet or hot environment.

REPLACING THE LIGHT
ATTENTION:
Be sure to unplug the Air Fryer Toaster Oven and allow it to cool completely before replacing the oven light.
SPECIFICATION:25W halogen bulb
1. Rotate the light cover counterclockwise to remove it.
1
2. Remove the used bulb by pulling it directly.
2
3. Insert the new bulb.
3
4. Rotate the light cover clockwise to tighten it.
4

TROUBLESHOOTING
Possible Problem
Possible Cause
Solution
The oven does NOT work
The appliance is not plugged in
Make sure the oven is plugged in
You have not turned on the oven
Press “ON/OFF" button to power on
The door is not closed properly
Make sure the door is closed well
Steam is coming out from the top of the
oven door
You are cooking high moisture content foods
This is normal. The door is vented to release steam
created from high-moisture content foods such as frozen
breads
White smoke is coming out of the oven
This is the first time to use oven
This is normal. The oven may produce some white smoke
when you use if for the first time. We suggest to set the
highest temperature in function working 18~20 minutes
without food to eliminate smoke.
You're cooking the greasy food
This is normal. Frying greasy foods will cause oil to leak
into the heaters or crumb tray or baking pan, the oil will
produce white smoke, and should not affect cooking.
Baking pan or crumb tray or heaters still
contains grease residues or oil from
previous use
Make sure you clean these parts properly after each use
Dark smoke is coming out of the oven
Food is burning
Immediately turn off the oven, be careful when you take
out the food.
The ingredients cooked with the oven
are not done
Too much amount of food
Reduce the amount of food for single cooking
Setting temperature too low or time too short
Set the temperature higher or time longer
Choose the incorrect function
Make sure you cook with the proper function
Foods are cooked unevenly
Ingredients are stacked or close to each
other during cooking
Make sure ingredients spread out evenly
Baking pan, Air Fry basket or oven rack
position is not adjusted
Before or during cooking, adjust these accessories on the
proper position
Foods are not crispy after Air Frying
Ingredients with high moisture
Spraying or brushing a small amount of oil on food evenly
can increase crispiness
Disposal of old electrical appliances
The European directive 2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE), requires that old household electrical appliances must not be disposed of in
the normal unsorted municipal waste stream. Old appliances must be collected separately in order
to optimize the recovery and recycling of the materials they contain, and reduce the impact on

human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you
dispose of the appliance, it must be separately collected.
Consumers should contact their local authority or retailer for information concerning the correct
disposal of their old appliance.
LIMITED WARRANTY
Limited Warranty applies to purchases made from authorized retailers of TurboTronic®.
TurboTronic® Warranty coverage applies to the original owner and to the original product only and
is not transferable.
TurboTronic® warrants that the unit shall be free from defects in material and workmanship. Limited
Warranty apply only when it is used under normal household conditions and maintained according
to the requirements outlined in the Owner’s Guide, subject to the following
conditions and exclusions:
What is covered by this warranty?
1. The original unit and/or non-wearable parts deemed defective, in TurboTronic® sole discretion,
will be repaired or replaced
2. TurboTronic® reserves the right to replace the unit with one of equal or greater value.
What is not covered by this warranty?
1. Normal wear and tear of wearable parts (such as blending vessels, lids, cups, blades, blender
bases, removable pots, racks, pans, etc.), which require regular maintenance and/or replacement
to ensure the proper functioning of your unit, are not covered by this warranty.
2. Any unit that has been tampered with or used for commercial purposes.
3. Damage caused by misuse, abuse, negligent handling, failure to perform required maintenance
(e.g., failure to keep the well of the motor base clear of food spills and other debris), or damage due
to mishandling in transit.
4. Consequential and incidental damages.
5. Defects caused by repair persons not authorized by TurboTronic®. These defects include
damages caused in the process of shipping, altering, or repairing the TurboTronic® product (or any
of its parts) when the repair is performed by a repair person not authorized by TurboTronic®.
6. Products purchased, used, or operated outside Europe.
Illustrations may differ from actual product.
We are constantly striving to improve our products, therefore the specifications contained herein are
subject to change without notice.
TurboTronic®and Z-Line® are registered trademarks of Z-GLOBAL B.V.B.A®.
PRINTED IN PRC
